Control of the Bidirectional Buck-Boost Converter Operating in Boundary Conduction Mode to Provide Hold-Up Time Extension
Abstract
:1. Introduction
2. General Description of the Control System
3. Modeling and Control of the BBBC Converter
3.1. Capacitor Charging Mode
3.2. Stand-By Mode
3.3. Recharging Mode of the Capacitor
3.4. Discharging Mode of the Capacitor
3.5. Complete Control Diagram
3.6. Converter Design Parameters
4. Simulation and Experimental Results
4.1. Simulation Results
4.2. Experimental Results
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
