Computational Fluid Dynamics Simulation Study of a Novel Membrane Contactor for Simultaneous Carbon Dioxide Absorption and Stripping
Abstract
:1. Introduction
2. Hybrid Absorption/Stripping Membrane Contactor (HASMC)
3. Modeling
3.1. Computational Domain and Grids
3.2. Governing Equations
3.2.1. Fluid Channels
3.2.2. Membrane Layer
3.2.3. Boundary Conditions and Solution Algorithms
4. Results and Discussion
4.1. Model Verification
4.2. Parallel-Flow HASMC
4.3. Cross-Flow HASMC
4.4. Transfer Coefficients
5. Conclusions
Acknowledgments
Author Contributions
Conflicts of Interest
Nomenclature
BC | base case |
C | concentration (kmol/m3) |
CE | cross-flow configuration with empty channels |
CS | cross-flow configuration with spacer-filled channels |
dh | hydraulic diameter (m) |
Df | diameter of filament (m) |
D | molecular diffusivity (m2/s) |
E | specific total energy (J/kg) |
h | heat transfer coefficient (W/m2 K) or specific enthalpy (J/kg) |
H | height of spacer (m) |
HVL | specific enthalpy of vaporization (J/kg) |
HASMC | hybrid absorption and stripping membrane contactor |
I | unit matrix |
ji | diffusion flux of species i (kg/m2 s) |
kc | thermal conductivity (kg/m2 s) |
kL | mass transfer coefficient in the liquid (m/s) |
km | mass transfer coefficient in the membrane (m/s) |
Lm | filament mesh size (m) |
N | mass flux (kg/m2 s) |
P | Pressure (Pa) |
PE | parallel-flow configuration with empty channel |
PS | parallel-flow configuration with spacer-filled channel |
Q | heat flux (W/m2) |
R | gas constant (J/mole K) |
Re | Reynolds number, |
Sc | Schmidt number, |
Sh | Sherwood number, |
Sh | energy source term (kJ/m3 s) |
Si | mass source term of species i (kg/m3 s) |
Sm | mass source term of mixture (kg/m3 s) |
T | temperature (K) |
Tm | membrane mean temperature (K) |
v | velocity (m/s) |
yi | mass fraction of species i |
Greek Letters
δm | membrane thickness (m) |
membrane porosity or spacer porosity | |
θ | hydrodynamic angles (degree) |
μ | viscosity (Pa s) |
ρ | density (kg/m3) |
tortuosity or stress tensor (Pa/m) |
Subscript
abs | absorption |
avg | average |
bulk | bulk fluid |
fg | flue gas |
i | species i |
L | liquid |
m | membrane |
sat | saturation |
sg | stripping gas |
strip | stripping |
References
