Energies 2017, 10(7), 973; https://doi.org/10.3390/en10070973

Power Take-Off Simulation for Scale Model Testing of Wave Energy Converters

1
Cascadia Coast Research Ltd., 26 Bastion Square, Third Floor Burnes House, Victoria, BC V8W-1H9, Canada
2
Wave Energy Research Group, Aalborg University, P.O. Box 159, Aalborg DK - 9100, Denmark
3
Department of Mechanical Engineering, University of Victoria, P.O. Box 3055, Stn. CSC, Victoria, BC V8W-3P6, Canada
*
Author to whom correspondence should be addressed.
Academic Editor: Stephen Nash
Received: 20 May 2017 / Revised: 3 July 2017 / Accepted: 6 July 2017 / Published: 11 July 2017
View Full-Text   |   Download PDF [5365 KB, uploaded 17 July 2017]   |

Abstract

Small scale testing in controlled environments is a key stage in the development of potential wave energy conversion technology. Furthermore, it is well known that the physical design and operational quality of the power-take off (PTO) used on the small scale model can have vast effects on the tank testing results. Passive mechanical elements such as friction brakes and air dampers or oil filled dashpots are fraught with nonlinear behaviors such as static friction, temperature dependency, and backlash, the effects of which propagate into the wave energy converter (WEC) power production data, causing very high uncertainty in the extrapolation of the tank test results to the meaningful full ocean scale. The lack of quality in PTO simulators is an identified barrier to the development of WECs worldwide. A solution to this problem is to use actively controlled actuators for PTO simulation on small scale model wave energy converters. This can be done using force (or torque)-controlled feedback systems with suitable instrumentation, enabling the PTO to exert any desired time and/or state dependent reaction force. In this paper, two working experimental PTO simulators on two different wave energy converters are described. The first implementation is on a 1:25 scale self-reacting point absorber wave energy converter with optimum reactive control. The real-time control system, described in detail, is implemented in LabVIEW. The second implementation is on a 1:20 scale single body point absorber under model-predictive control, implemented with a real-time controller in MATLAB/Simulink. Details on the physical hardware, software, and feedback control methods, as well as results, are described for each PTO. Lastly, both sets of real-time control code are to be web-hosted, free for download, modified and used by other researchers and WEC developers. View Full-Text
Keywords: wave energy conversion; model testing; power take-off; control wave energy conversion; model testing; power take-off; control
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Beatty, S.; Ferri, F.; Bocking, B.; Kofoed, J.P.; Buckham, B. Power Take-Off Simulation for Scale Model Testing of Wave Energy Converters. Energies 2017, 10, 973.
