Open AccessArticle
Energies 2017, 10(7), 858; doi:10.3390/en10070858

Bandwidth and Accuracy-Aware State Estimation for Smart Grids Using Software Defined Networks

DIEE - Department of Electrical and Electronic Engineering, University of Cagliari, Piazza D’Armi, 09123 Cagliari, Italy
*
Author to whom correspondence should be addressed.
Received: 6 April 2017 / Revised: 31 May 2017 / Accepted: 21 June 2017 / Published: 27 June 2017
(This article belongs to the Special Issue ICT for Energy)
View Full-Text   |   Download PDF [1989 KB, uploaded 3 July 2017]   |

Abstract

Smart grid (SG) will be one of the major application domains that will present severe pressures on future communication networks due to the expected huge number of devices that will be connected to it and that will impose stringent quality transmission requirements. To address this challenge, there is a need for a joint management of both monitoring and communication systems, so as to achieve a flexible and adaptive management of the SG services. This is the issue addressed in this paper, which provides the following major contributions. We define a new strategy to optimize the accuracy of the state estimation (SE) of the electric grid based on available network bandwidth resources and the sensing intelligent electronic devices (IEDs) installed in the field. In particular, we focus on phasor measurement units (PMUs) as measurement devices. We propose the use of the software defined networks (SDN) technologies to manage the available network bandwidth, which is then assigned by the controller to the forwarding devices to allow for the flowing of the data streams generated by the PMUs, by considering an optimization routine to maximize the accuracy of the resulting SE. Additionally, the use of SDN allows for adding and removing PMUs from the monitoring architecture without any manual intervention. We also provide the details of our implementation of the SDN solution, which is used to make simulations with an IEEE 14-bus test network in order to show performance in terms of bandwidth management and estimation accuracy. View Full-Text
Keywords: smart grid (SG); software defined networks (SDN); state estimation (SE); wide area monitoring system; phasor measurement unit (PMU); intelligent electronic device (IED); accuracy smart grid (SG); software defined networks (SDN); state estimation (SE); wide area monitoring system; phasor measurement unit (PMU); intelligent electronic device (IED); accuracy
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
