Open AccessArticle
Sensors 2018, 18(2), 628; https://doi.org/10.3390/s18020628

A Model-Driven Co-Design Framework for Fusing Control and Scheduling Viewpoints

1
Laboratory of Advanced Software Systems (LASSY), CSC Research Unit, University of Luxembourg, Maison du Nombre, L-4364 Esch-sur-Alzette, Luxembourg
2
CSA Group, University of Amsterdam, 1098XH Amsterdam, The Netherlands
3
RealTime-at-Work (RTaW), 4 Rue Piroux, 54000 Nancy, France
*
Author to whom correspondence should be addressed.
Received: 12 December 2017 / Revised: 7 February 2018 / Accepted: 14 February 2018 / Published: 20 February 2018
(This article belongs to the Special Issue Design and Implementation of Future CPS)
View Full-Text   |   Download PDF [2365 KB, uploaded 23 February 2018]   |

Abstract

Model-Driven Engineering (MDE) is widely applied in the industry to develop new software functions and integrate them into the existing run-time environment of a Cyber-Physical System (CPS). The design of a software component involves designers from various viewpoints such as control theory, software engineering, safety, etc. In practice, while a designer from one discipline focuses on the core aspects of his field (for instance, a control engineer concentrates on designing a stable controller), he neglects or considers less importantly the other engineering aspects (for instance, real-time software engineering or energy efficiency). This may cause some of the functional and non-functional requirements not to be met satisfactorily. In this work, we present a co-design framework based on timing tolerance contract to address such design gaps between control and real-time software engineering. The framework consists of three steps: controller design, verified by jitter margin analysis along with co-simulation, software design verified by a novel schedulability analysis, and the run-time verification by monitoring the execution of the models on target. This framework builds on CPAL (Cyber-Physical Action Language), an MDE design environment based on model-interpretation, which enforces a timing-realistic behavior in simulation through timing and scheduling annotations. The application of our framework is exemplified in the design of an automotive cruise control system.
View Full-Text
Keywords: model-driven engineering; control software; timing tolerance contract; controller model; schedulability; stability; input jitters; varying execution-times; output jitters; input-to-output delay; co-simulation; real-time scheduling; control system performance model-driven engineering; control software; timing tolerance contract; controller model; schedulability; stability; input jitters; varying execution-times; output jitters; input-to-output delay; co-simulation; real-time scheduling; control system performance
Figures

Figure 1
