Temperature-Dependent Phase Behaviors in Cylinder-Forming Block Copolymers
Department of Mechanical Engineering, University of Colorado, Boulder, CO 80309-0427, USA
Department of Polymer Engineering, The University of Akron, Akron, OH 44325-0301, USA
* Author to whom correspondence should be addressed.
Received: 4 April 2009; in revised form: 30 April 2009 / Accepted: 13 May 2009 / Published: 15 May 2009
Abstract: We demonstrate that the temperature-dependent phase behaviors of parallel and perpendicular cylinder-forming block copolymers are governed by domain-domain segregation forces inherently present in block copolymer material itself. With increasing temperature, a parallel cylinder-forming block copolymer experienced a parallel cylinder straightening process before the order-disorder transition (ODT) and did not show long-range composition fluctuations near the ODT temperature due to the weak segregation forces between the block domains. A perpendicular cylinder-forming block copolymer with a strong segregation force between the block domains displayed cylinder orientation transition from perpendicular to parallel below the ODT temperature. On the other hand, a perpendicular cylinder-forming block copolymer material with an exceptionally strong segregation force between the block domains maintained its initial perpendicular cylinder orientation up to near the ODT temperature. In both cases of perpendicular cylinder-forming block copolymers, submicrometer-scale long-range composition fluctuations were observed well above the ODT temperature due to their intrinsically strong segregation forces between the block domains.
Keywords: block copolymers; block copolymer self-assembly; dynamic mechanical properties; orientation transition of block copolymer nano-cylinders; order-disorder transition of block copolymers
Citations to this Article
Cite This Article
MDPI and ACS Style
Ahn, D.U.; Sancaktar, E. Temperature-Dependent Phase Behaviors in Cylinder-Forming Block Copolymers. Int. J. Mol. Sci. 2009, 10, 2169-2189.
Ahn DU, Sancaktar E. Temperature-Dependent Phase Behaviors in Cylinder-Forming Block Copolymers. International Journal of Molecular Sciences. 2009; 10(5):2169-2189.
Ahn, Dae Up; Sancaktar, Erol. 2009. "Temperature-Dependent Phase Behaviors in Cylinder-Forming Block Copolymers." Int. J. Mol. Sci. 10, no. 5: 2169-2189.
