Open AccessArticle
ISPRS Int. J. Geo-Inf. 2018, 7(7), 235; https://doi.org/10.3390/ijgi7070235

Method of Constructing Point Generalization Constraints Based on the Cloud Platform

1
Key Laboratory of Virtual Geographic Environment (Nanjing Normal University), Ministry of Education, Nanjing 210023, China
2
School of Geography Science, Nanjing Normal University, Nanjing 210023, China
3
Department of Geoinformatics—Z_GIS, University of Salzburg, 5020 Salzburg, Austria
4
Jiangsu Center for Collaborative Innovation in Geographical Information Resource Development and Application, Nanjing 210023, China
5
Laboratory on Geoinformatics and Cartography, Department of Geography, Faculty of Science, Masaryk University, Kotlarska 2, 61137 Brno, Czech Republic
*
Author to whom correspondence should be addressed.
Received: 25 May 2018 / Revised: 10 June 2018 / Accepted: 18 June 2018 / Published: 21 June 2018
View Full-Text   |   Download PDF [2766 KB, uploaded 21 June 2018]   |

Abstract

As an important part of spatial data, the point feature has always been an essential element in web maps and navigation maps. With the development of location-based services and the rapid increase in volunteered geographic information and social media data, the amount of point data is increasing day by day, resulting in inevitable problems of overlay and congestion during visualization. Map generalization provides multiple algorithms that can be used to select, aggregate and make typification of points or point clusters. For the generalization of point data, however, the traditional stand-alone computing environment has difficulty with real-time realization. Currently, the rapid development of cloud computing technology provides a powerful support for improving the efficiency of map generalization. However, compared with the stand-alone environment, the data decomposition and the real-time display of point generalization in the cloud platform imposes higher requirements on the point generalization constraints, which play an important role in point-generalized process control. Based on the computational characteristics of the cloud platform, this paper analyzes the changes in point generalization constraints. In addition, our work proposes the constraints of point generalization based on the cloud platform and its construction method, builds a prototype system based on the Hadoop cloud platform. Our prototype system is tested using typical experimental data. Its efficiency and the quality of its results is examined. The results show that the efficiency and quality of point selection can be significantly improved by controlling the point generalization process with the generalization constraints in the cloud computing environment proposed in this paper. This paper provides a possible way for the realization of map generalization in the cloud computing environment. Its usability with real data and with many users accessing it will be the focus of further research. View Full-Text
Keywords: cloud platform; point generalization; generalization constraints cloud platform; point generalization; generalization constraints
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
SciFeed

Share & Cite This Article

MDPI and ACS Style

Zhou, J.; Shen, J.; Yang, S.; Yu, Z.; Stanek, K.; Stampach, R. Method of Constructing Point Generalization Constraints Based on the Cloud Platform. ISPRS Int. J. Geo-Inf. 2018, 7, 235.
