Open AccessArticle
Minerals 2017, 7(3), 39; https://doi.org/10.3390/min7030039

The Use of Integrated Fluid Inclusion Studies for Constraining Petroleum Charge History at Parsons Pond, Western Newfoundland, Canada

1
Geological Survey of Newfoundland Labrador, Department of Natural Resources, P.O. Box 8700, St. John’s, NL A1B 4J6, Canada
2
Department of Earth Sciences, Memorial University of Newfoundland, St. John’s, NL A1B 3X5, Canada
*
Author to whom correspondence should be addressed.
Academic Editor: Martin Feely
Received: 10 January 2017 / Revised: 22 February 2017 / Accepted: 27 February 2017 / Published: 12 March 2017
(This article belongs to the Special Issue Fluid Inclusions: Study Methods, Applications and Case Histories)
View Full-Text   |   Download PDF [5211 KB, uploaded 12 March 2017]   |

Abstract

This study, based on fluid inclusion petrography, microthermometry and ultraviolet microspectroscopy of inclusion oil, investigates the petroleum charge history at Parsons Pond, western Newfoundland. To address this matter, drill core and cuttings samples of allochthonous and autochthonous strata in the Parson’s Pond area were collected from three exploration wells. Fluid inclusions were examined from fragments of calcite and quartz veins, diagenetic cements in sandstone, and in large hydrothermal dolomite and calcite crystals. Primary aqueous inclusions in authigenic sandstone cements indicate that cementation occurred at relatively shallow depths and low temperatures (<50 °C). Hydrocarbon-bearing fluid inclusions (petroleum, wet gas and gas) are generally restricted to calcite and quartz veins, indicating that petroleum and gas migration at Parson’s Pond is fracture-controlled. No hydrocarbons were observed in the diagenetic cements of the essentially tight sandstones. Fluid inclusion microthermometry and ultraviolet microspectroscopy indicate the presence of multiple generations of hydrocarbon fluid, ranging in composition from ~33 API gravity petroleum to pure CH4. Petrographic evidence suggests that hydrocarbons were generated multiple times during progressive burial and heating. In addition, the distribution of hydrocarbon bearing inclusions with depth suggests that deeper levels are gas-prone, with petroleum confined to relatively shallow depths. Although only gas flow was encountered during the drilling of exploration wells at Parson’s Pond, the presence of petroleum-bearing fluid inclusions in calcite and quartz veins indicates that the historical production from shallow wells in the Parsons Pond area likely tapped small reservoirs of fractured petroliferous strata. View Full-Text
Keywords: fluid inclusions; petroleum; fluorescence spectroscopy; fractured reservoir; Newfoundland fluid inclusions; petroleum; fluorescence spectroscopy; fractured reservoir; Newfoundland
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
