Remote Sens. 2017, 9(6), 573; doi:10.3390/rs9060573

Moving to the RADARSAT Constellation Mission: Comparing Synthesized Compact Polarimetry and Dual Polarimetry Data with Fully Polarimetric RADARSAT-2 Data for Image Classification of Peatlands

1
Environment and Climate Change Canada, National Wildlife Research Centre, 1125 Colonel by Drive, Ottawa, ON K1S 5B6, Canada
2
Department of Geography and Environmental Studies, Carleton University, 1125 colonel By Drive, Ottawa, ON K1S 5B6, Canada
3
Defence Research and Development Canada (DRDC), Ottawa Research Center, 3701 Carling Ave., Ottawa, ON K2K 2Y7, Canada
*
Author to whom correspondence should be addressed.
Academic Editors: Deepak R. Mishra and Prasad S. Thenkabail
Received: 7 April 2017 / Revised: 19 May 2017 / Accepted: 4 June 2017 / Published: 7 June 2017
View Full-Text   |   Download PDF [4566 KB, uploaded 21 June 2017]   |

Abstract

For this research, the Random Forest (RF) classifier was used to evaluate the potential of simulated RADARSAT Constellation Mission (RCM) data for mapping landcover within peatlands. Alfred Bog, a large peatland complex in Southern Ontario, was used as a test case. The goal of this research was to prepare for the launch of the upcoming RCM by evaluating three simulated RCM polarizations for mapping landcover within peatlands. We examined (1) if a lower RCM noise equivalent sigma zero (NESZ) affects classification accuracy, (2) which variables are most important for classification, and (3) whether classification accuracy is affected by the use of simulated RCM data in place of the fully polarimetric RADARSAT-2. Results showed that the two RCM NESZs (−25 dB and −19 dB) and three polarizations (compact polarimetry, HH+HV, and VV+VH) that were evaluated were all able to achieve acceptable classification accuracies when combined with optical data and a digital elevation model (DEM). Optical variables were consistently ranked to be the most important for mapping landcover within peatlands, but the inclusion of SAR variables did increase overall accuracy, indicating that a multi-sensor approach is preferred. There was no significant difference between the RF classifications which included RADARSAT-2 and simulated RCM data. Both medium- and high-resolution compact polarimetry and dual polarimetric RCM data appear to be suitable for mapping landcover within peatlands when combined with optical data and a DEM. View Full-Text
Keywords: RADARSAT-2; RADARSAT Constellation Mission; Landsat; Random Forest; peatlands; wetlands RADARSAT-2; RADARSAT Constellation Mission; Landsat; Random Forest; peatlands; wetlands
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

White, L.; Millard, K.; Banks, S.; Richardson, M.; Pasher, J.; Duffe, J. Moving to the RADARSAT Constellation Mission: Comparing Synthesized Compact Polarimetry and Dual Polarimetry Data with Fully Polarimetric RADARSAT-2 Data for Image Classification of Peatlands. Remote Sens. 2017, 9, 573.
