Remote Sens. 2017, 9(4), 315; doi:10.3390/rs9040315

Characterization of Snow Facies on the Greenland Ice Sheet Observed by TanDEM-X Interferometric SAR Data

1
German Aerospace Center (DLR), Microwaves and Radar Institute, Oberpfaffenhofen, 82234 Weßling, Germany
2
ENVEO IT GmbH, Technikerstrasse 21a, A-6020 Innsbruck, Austria
3
Institute of Atmospheric and Cryospheric Sciences, University of Innsbruck, A-6020 Innsbruck, Austria
*
Author to whom correspondence should be addressed.
Academic Editors: Xiaofeng Li and Prasad S. Thenkabail
Received: 18 January 2017 / Revised: 21 March 2017 / Accepted: 24 March 2017 / Published: 28 March 2017
View Full-Text   |   Download PDF [15254 KB, uploaded 28 March 2017]   |

Abstract

This paper presents for the first time a detailed study on information content of X-band single-pass interferometric spaceborne SAR data with respect to snow facies characterization. An approach for classifying different snow facies of the Greenland Ice Sheet by exploiting X-band TanDEM-X interferometric synthetic aperture radar acquisitions is firstly detailed. Large-scale mosaics of radar backscatter and volume correlation factor, derived from quicklook images of the interferometric coherence, represent the starting point for applying an unsupervised classification method based on the c-means fuzzy clustering algorithm. The data was acquired during winter 2010/2011. A partition of four different snow facies was chosen and interpreted using reference melt data, snow density, and in situ measurements. The variations in the stratification and micro-structure of firn, such as the variations of density with depth and the presence of percolation features, are identified as relevant parameters for explaining the significant differences in the observed interferometric signatures among different snow facies. Moreover, a statistical analysis of backscatter and volume correlation factor provided useful parameters for characterizing the snow facies behavior and analyzing their dependency on the acquisition geometry. Finally, knowing the location and characterization of the different snow facies, the two-way X-band penetration depth over the whole Ice Sheet was estimated. The obtained mean values vary from 2.3 m for the outer snow facies up to 4.18 m for the inner one. The presented approach represents a starting point for a long-term monitoring of ice sheet dynamics, by acquiring time-series, and is of high relevance for the design of future SAR missions as well. View Full-Text
Keywords: TanDEM-X; SAR; interferometric coherence; volume decorrelation; Greenland; Ice Sheet; snow facies TanDEM-X; SAR; interferometric coherence; volume decorrelation; Greenland; Ice Sheet; snow facies
Figures

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Rizzoli, P.; Martone, M.; Rott, H.; Moreira, A. Characterization of Snow Facies on the Greenland Ice Sheet Observed by TanDEM-X Interferometric SAR Data. Remote Sens. 2017, 9, 315.
