Identification of Woodland Vernal Pools with Seasonal Change PALSAR Data for Habitat Conservation
Previous Article in Journal
Drivers of Productivity Trends in Cork Oak Woodlands over the Last 15 Years
Article Menu

Export Article

Open AccessArticle
Remote Sens. 2016, 8(6), 491; doi:10.3390/rs8060491

Vegetation Indices for Mapping Canopy Foliar Nitrogen in a Mixed Temperate Forest

1
Faculty of Geo-Information Science and Earth Observation (ITC), University of Twente, P.O. Box 217, 7500 AE Enschede, The Netherlands
2
School of Mathematical and Geospatial Sciences, RMIT University, GPO Box 2476, Melbourne, VIC 3001, Australia
3
Cooperative Research Centre for Spatial Information, Carlton, VIC 3053, Australia
4
Oceans and Atmosphere, Commonwealth Scientific and Industrial Research Organisation, Yarralumla, ACT 2600, Australia
5
Department of Land Surface, German Remote Sensing Data Center (DFD), German Aerospace Center (DLR), Oberpfaffenhofen, 82234 Wessling, Germany
6
Bavarian Forest National Park, Freyunger Straße 2, 94481 Grafenau, Germany
*
Author to whom correspondence should be addressed.
Academic Editors: Lenio Soares Galvao and Prasad S. Thenkabail
Received: 30 March 2016 / Revised: 3 June 2016 / Accepted: 7 June 2016 / Published: 10 June 2016
View Full-Text   |   Download PDF [2524 KB, uploaded 10 June 2016]   |

Abstract

Hyperspectral remote sensing serves as an effective tool for estimating foliar nitrogen using a variety of techniques. Vegetation indices (VIs) are a simple means of retrieving foliar nitrogen. Despite their popularity, few studies have been conducted to examine the utility of VIs for mapping canopy foliar nitrogen in a mixed forest context. In this study, we assessed the performance of 32 vegetation indices derived from HySpex airborne hyperspectral images for estimating canopy mass-based foliar nitrogen concentration (%N) in the Bavarian Forest National Park. The partial least squares regression (PLSR) was performed for comparison. These vegetation indices were classified into three categories that are mostly correlated to nitrogen, chlorophyll, and structural properties such as leaf area index (LAI). %N was destructively measured in 26 broadleaf, needle leaf, and mixed stand plots to represent the different species and canopy structure. The canopy foliar %N is defined as the plot-level mean foliar %N of all species weighted by species canopy foliar mass fraction. Our results showed that the variance of canopy foliar %N is mainly explained by functional type and species composition. The normalized difference nitrogen index (NDNI) produced the most accurate estimation of %N (R2CV = 0.79, RMSECV = 0.26). A comparable estimation of %N was obtained by the chlorophyll index Boochs2 (R2CV = 0.76, RMSECV = 0.27). In addition, the mean NIR reflectance (800–850 nm), representing canopy structural properties, also achieved a good accuracy in %N estimation (R2CV = 0.73, RMSECV = 0.30). The PLSR model provided a less accurate estimation of %N (R2CV = 0.69, RMSECV = 0.32). We argue that the good performance of all three categories of vegetation indices in %N estimation can be attributed to the synergy among plant traits (i.e., canopy structure, leaf chemical and optical properties) while these traits may converge across plant species for evolutionary reasons. Our findings demonstrated the feasibility of using hyperspectral vegetation indices to estimate %N in a mixed temperate forest which may relate to the effect of the physical basis of nitrogen absorption features on canopy reflectance, or the biological links between nitrogen, chlorophyll, and canopy structure. View Full-Text
Keywords: canopy foliar nitrogen; vegetation indices; hyperspectral data; mixed forest; plant traits canopy foliar nitrogen; vegetation indices; hyperspectral data; mixed forest; plant traits
