Simplified Analytical Model and Shaking Table Test Validation for Seismic Analysis of Mid-Rise Cold-Formed Steel Composite Shear Wall Building
Previous Article in Journal
Measuring Taxi Accessibility Using Grid-Based Method with Trajectory Data
Article Menu
Issue 9 (September) cover image

Export Article

Open AccessArticle
Sustainability 2018, 10(9), 3189; https://doi.org/10.3390/su10093189

Adaptive Analysis of Green Space Network Planning for the Cooling Effect of Residential Blocks in Summer: A Case Study in Shanghai

1
Center for Modern Chinese City Studies, School of Urban and Regional Science, East China Normal University, Shanghai 200062, China
2
Institute for Innovation and Strategic Studies, East China Normal University, Shanghai 200062, China
3
Institute of Ecological Urbanization and Green Building, Shenyang Jianzhu University, Shenyang 110168, China
4
Research Center for Eco Civilization, Shanghai Institute of Eco-Chongming, Shanghai 200062, China
*
Authors to whom correspondence should be addressed.
Received: 3 August 2018 / Revised: 30 August 2018 / Accepted: 4 September 2018 / Published: 6 September 2018
Full-Text   |   PDF [7612 KB, uploaded 6 September 2018]   |

Abstract

The effect of Urban Heat Islands (UHIs) is becoming increasingly serious in cities. Research on the adaptive planning policies for microthermal environments at the residential block level of cities is thus becoming of greater significance. Based on the cooling effect of planning control elements in residential block areas, the element effects characteristics of water bodies and vegetation distribution on the thermal environment of residential blocks were analyzed by using ENVI-met software. The simulation data analysis showed that the combination of water bodies and vegetation had a synergistic cooling effect. Based on these results, simulations of five effective adaptive measures were carried out step by step in planning scenarios, that is, improving the water bodies with vegetation corridors, the application of high-albedo material on streets, and increasing the number of green patches, east-west green corridors, and north-south green corridors. The results were as follows. First, although each of the five optimization strategies have a certain degree of cooling effect on the entire block, the superposition of each factor had a synergistic effect. Second, different spatial optimization strategies had different cooling ranges for each subzone. The optimization of the north-south green corridor, green patches, and water features corridors were particularly significant for microclimate cooling. The east-west green corridor has a certain influence on a certain range of downwind zones and had an auxiliary cooling effect. The high-albedo material also had a weak overall decrease function for the thermal environment. Finally, the downwind area of the urban creek network had a great impact on cooling intensity, with distance attenuation characteristics; it was also proposed that the comprehensive cooling effect of the green space network with optimized layout was greater than that of any single green space element. The optimization scenario planning research provided a method for improving the scientific distribution of adaptation measures in urban residential blocks. View Full-Text
Keywords: adaptive planning; cooling effect; ENVI-met; numerical simulation; residential block; Shanghai adaptive planning; cooling effect; ENVI-met; numerical simulation; residential block; Shanghai
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
