Field Study on Humidification Performance of a Desiccant Air-Conditioning System Combined with a Heat Pump
AbstractA desiccant air-conditioning system was developed as a latent-load-processing air conditioner in a dedicated outdoor air system during the summer. This study investigated the application of this air-conditioning system to humidification during the winter without using make-up water, thereby eliminating the cause of microbial contamination in air-conditioning systems. The experiments were conducted with a system used for summer applications to determine the feasibility of adsorbing vapor from outdoor air and supplying it to an indoor space. The humidification performance, energy efficiency, and operating conditions were examined. Although the conditions were subpar because the experiments were performed with an actual dedicated outdoor air system, the results showed that it is possible to supply air with a minimum humidity ratio of 5.8 g/kg dry air (DA) when the humidity ratio of outdoor air ranges from 1.8 to 2.3 g/kg DA. The minimum humidification performance required for a dedicated outdoor air system was achieved by increasing the airflow rate of the moisture-adsorption side to 2–3 times that of the humidification side. In addition, air leaking from the moisture-adsorption side to the humidification side, improving the mechanical structure, such as by the insulation of the moisture-adsorption side, and an efficient operating method were examined for humidification during the winter. View Full-Text
Share & Cite This Article
Kawamoto, K.; Cho, W.; Kohno, H.; Koganei, M.; Ooka, R.; Kato, S. Field Study on Humidification Performance of a Desiccant Air-Conditioning System Combined with a Heat Pump. Energies 2016, 9, 89.
Kawamoto K, Cho W, Kohno H, Koganei M, Ooka R, Kato S. Field Study on Humidification Performance of a Desiccant Air-Conditioning System Combined with a Heat Pump. Energies. 2016; 9(2):89.Chicago/Turabian Style
Kawamoto, Koichi; Cho, Wanghee; Kohno, Hitoshi; Koganei, Makoto; Ooka, Ryozo; Kato, Shinsuke. 2016. "Field Study on Humidification Performance of a Desiccant Air-Conditioning System Combined with a Heat Pump." Energies 9, no. 2: 89.
