Fault Detection and Location by Static Switches in Microgrids Using Wavelet Transform and Adaptive Network-Based Fuzzy Inference System

1,* , 1
, 2
, 2
 and 2
Received: 7 February 2014; in revised form: 4 April 2014 / Accepted: 9 April 2014 / Published: 23 April 2014
(This article belongs to the Special Issue Smart Grids: The Electrical Power Network and Communication System)
View Full-Text   |   Download PDF [660 KB, uploaded 23 April 2014]   |   Browse Figures
Abstract: Microgrids are a highly efficient means of embedding distributed generation sources in a power system. However, if a fault occurs inside or outside the microgrid, the microgrid should be immediately disconnected from the main grid using a static switch installed at the secondary side of the main transformer near the point of common coupling (PCC). The static switch should have a reliable module implemented in a chip to detect/locate the fault and activate the breaker to open the circuit immediately. This paper proposes a novel approach to design this module in a static switch using the discrete wavelet transform (DWT) and adaptive network-based fuzzy inference system (ANFIS). The wavelet coefficient of the fault voltage and the inference results of ANFIS with the wavelet energy of the fault current at the secondary side of the main transformer determine the control action (open or close) of a static switch. The ANFIS identifies the faulty zones inside or outside the microgrid. The proposed method is applied to the first outdoor microgrid test bed in Taiwan, with a generation capacity of 360.5 kW. This microgrid test bed is studied using the real-time simulator eMegaSim developed by Opal-RT Technology Inc. (Montreal, QC, Canada). The proposed method based on DWT and ANFIS is implemented in a field programmable gate array (FPGA) by using the Xilinx System Generator. Simulation results reveal that the proposed method is efficient and applicable in the real-time control environment of a power system.
Keywords: microgrid; static switch; wavelet transform; adaptive network-based fuzzy inference system (ANFIS) microgrid; static switch; wavelet transform; adaptive network-based fuzzy inference system (ANFIS)
