Open AccessArticle
Energies 2018, 11(7), 1776; https://doi.org/10.3390/en11071776

Impact of Road-Block on Peak-Load of Coupled Traffic and Energy Transportation Networks

1
College of Electrical and Information Engineering, Hunan University, Changsha 410082, China
2
School of Mechanical and Electrical Engineering, Hunan City University, Yiyang 413002, China
3
College of Electrical and Information Engineering, Changsha University of Science &Technology, Changsha 410114, China
4
Department of Electrical and Computer Engineering, Baylor University, Waco, TX 76798-7356, USA
5
State Grid Yiyang Power Supply Company, State Grid, Yiyang 413000, China
*
Author to whom correspondence should be addressed.
Received: 19 May 2018 / Revised: 22 June 2018 / Accepted: 25 June 2018 / Published: 6 July 2018
View Full-Text   |   Download PDF [3277 KB, uploaded 6 July 2018]   |

Abstract

With electric vehicles (EVs) pouring into infrastructure systems, coupled traffic and energy transportation networks (CTETNs) can be applied to capture the interactions between the power grids and transportation networks. However, most research has focused solely on the impacts of EV penetration on power grids or transportation networks. Therefore, a simulation model was required for the interactions between the two critical infrastructures, as one had yet to be developed. In this paper, we build a framework with four domains and propose a new method to simulate the interactions and the feedback effects among CTETNs. Considered more accurately reflecting a realistic situation, an origin-destination (OD) pair strategy, a charging strategy, and an attack strategy are modeled based on the vehicle flow and power flow. The model is able to analyze the spatial and temporal distribution characteristics of EVs, and measure the impacts on power grids and transportation networks with road-block. The IEEE 33-bus system with geographic information was used as a test system to verify the effectiveness of the model. View Full-Text
Keywords: coupled traffic and energy transportation networks (CTETNs); electric vehicles (EVs); interactions; peak-load spot; road-block coupled traffic and energy transportation networks (CTETNs); electric vehicles (EVs); interactions; peak-load spot; road-block
Figures

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
