Energies 2018, 11(2), 287; https://doi.org/10.3390/en11020287

Application of H Robust Control on a Scaled Offshore Oil and Gas De-Oiling Facility

Department of Energy Technology, Aalborg University, Esbjerg Campus, Niels Bohrs Vej 8, 6700 Esbjerg, Denmark
*
Author to whom correspondence should be addressed.
Received: 21 December 2017 / Revised: 13 January 2018 / Accepted: 22 January 2018 / Published: 24 January 2018
(This article belongs to the Section Energy Sources)
View Full-Text   |   Download PDF [2955 KB, uploaded 25 January 2018]   |

Abstract

The offshore de-oiling process is a vital part of current oil recovery, as it separates the profitable oil from water and ensures that the discharged water contains as little of the polluting oil as possible. With the passage of time, there is an increase in the water fraction in reservoirs that adds to the strain put on these facilities, and thus larger quantities of oil are being discharged into the oceans, which has in many studies been linked to negative effects on marine life. In many cases, such installations are controlled using non-cooperative single objective controllers which are inefficient in handling fluctuating inflows or complicated operating conditions. This work introduces a model-based robust H control solution that handles the entire de-oiling system and improves the system’s robustness towards fluctuating flow thereby improving the oil recovery and reducing the environmental impacts of the discharge. The robust H control solution was compared to a benchmark Proportional-Integral-Derivative (PID) control solution and evaluated through simulation and experiments performed on a pilot plant. This study found that the robust H control solution greatly improved the performance of the de-oiling process. View Full-Text
Keywords: oil & gas; offshore; phase separation; multiple input and multiple output (MIMO) control; robust control oil & gas; offshore; phase separation; multiple input and multiple output (MIMO) control; robust control
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
