Open AccessArticle
Energies 2017, 10(3), 322; doi:10.3390/en10030322

Study of the Effect of Clay Particles on Low Salinity Water Injection in Sandstone Reservoirs

Chemical Engineering and Chemistry Department, School of Science and Engineering, Teesside University, Middlesbrough TS1 3BA, UK
*
Author to whom correspondence should be addressed.
Academic Editor: Alireza Bahadori
Received: 22 December 2016 / Revised: 1 March 2017 / Accepted: 2 March 2017 / Published: 7 March 2017
(This article belongs to the Special Issue Oil and Gas Engineering)
View Full-Text   |   Download PDF [2282 KB, uploaded 7 March 2017]   |

Abstract

The need for optimal recovery of crude oil from sandstone and carbonate reservoirs around the world has never been greater for the petroleum industry. Water-flooding has been applied to the supplement primary depletion process or as a separate secondary recovery method. Low salinity water injection is a relatively new method that involves injecting low salinity brines at high pressure similar to conventional water-flooding techniques, in order to recover crude oil. The effectiveness of low salinity water injection in sandstone reservoirs depends on a number of parameters such as reservoir temperature, pressure, type of clay particle and salinity of injected brine. Clay particles present on reservoir rock surfaces adsorb polar components of oil and modify wettability of sandstone rocks to the oil-wet state, which is accountable for the reduced recovery rates by conventional water-flooding. The extent of wettability alteration caused by three low salinity brines on oil-wet sandstone samples containing varying clay content (15% or 30%) and type of clay (kaolinite/montmorillonite) were analyzed in the laboratory experiment. Contact angles of mica powder and clay mixture (kaolinite/montmorillonite) modified with crude oil were measured before and after injection with three low salinity sodium chloride brines. The effect of temperature was also analyzed for each sample. The results of the experiment indicate that samples with kaolinite clay tend to produce higher contact angles than samples with montmorillonite clay when modified with crude oil. The highest degree or extent of wettability alteration from oil-wet to intermediate-wet state upon injection with low salinity brines was observed for samples injected with brine having salinity concentration of 2000 ppm. The increase in temperature tends to produce contact angles values lying in the higher end of the intermediate-wet range (75°–115°) for samples treated at 50 °C, while their corresponding samples treated at 25 °C produced contact angle values lying in the lower end of intermediate-wet range. View Full-Text
Keywords: clay particles; wettability; temperature’s effect; contact angle; sandstone reservoirs clay particles; wettability; temperature’s effect; contact angle; sandstone reservoirs
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).

Scifeed alert for new publications

Never miss any articles matching your research from any publisher
  • Get alerts for new papers matching your research
  • Find out the new papers from selected authors
  • Updated daily for 49'000+ journals and 6000+ publishers
  • Define your Scifeed now

SciFeed Share & Cite This Article

MDPI and ACS Style

Rezaei Gomari, S.; Joseph, N. Study of the Effect of Clay Particles on Low Salinity Water Injection in Sandstone Reservoirs. Energies 2017, 10, 322.
