Open AccessArticle
Energies 2017, 10(1), 142; doi:10.3390/en10010142

Study on the Adsorption, Diffusion and Permeation Selectivity of Shale Gas in Organics

1
State Key Laboratory of Oil and Gas Reservoir Geology and Exploitation, Southwest Petroleum University, Chengdu 610500, China
2
Petroleum Systems Engineering, Faculty of Engineering and Applied Science, University of Regina, Regina, SK S4S 0A2, Canada
3
School of Chemical Engineering, Sichuan University, Chengdu 610065, China
*
Author to whom correspondence should be addressed.
Academic Editor: Alireza Bahadori
Received: 26 October 2016 / Revised: 12 January 2017 / Accepted: 16 January 2017 / Published: 23 January 2017
(This article belongs to the Special Issue Oil and Gas Engineering)
View Full-Text   |   Download PDF [2678 KB, uploaded 23 January 2017]   |

Abstract

As kerogen is the main organic component in shale, the adsorption capacity, diffusion and permeability of the gas in kerogen plays an important role in shale gas production. Based on the molecular model of type II kerogen, an organic nanoporous structure was established. The Grand Canonical Monte Carlo (GCMC) and Molecular Dynamics (MD) methods were used to study the adsorption and diffusion capacity of mixed gas systems with different mole ratios of CO2 and CH4 in the foregoing nanoporous structure, and gas adsorption, isosteric heats of adsorption and self-diffusion coefficient were obtained. The selective permeation of gas components in the organic pores was further studied. The results show that CO2 and CH4 present physical adsorption in the organic nanopores. The adsorption capacity of CO2 is larger than that of CH4 in organic pores, but the self-diffusion coefficient of CH4 in mixed gas is larger than that of CO2. Moreover, the self-diffusion coefficient in the horizontal direction is larger than that in the vertical direction. The mixed gas pressure and mole ratio have limited effects on the isosteric heat and the self-diffusion of CH4 and CO2 adsorption. Regarding the analysis of mixed gas selective permeation, it is concluded that the adsorption selectivity of CO2 is larger than that of CH4 in the organic nanopores. The larger the CO2/CH4 mole ratio, the greater the adsorption and permeation selectivity of mixed gas in shale. The permeation process is mainly controlled by adsorption rather than diffusion. These results are expected to reveal the adsorption and diffusion mechanism of gas in shale organics, which has a great significance for further research. View Full-Text
Keywords: adsorption diffusion; kerogen; molecular simulation; permeation selectivity; shale gas adsorption diffusion; kerogen; molecular simulation; permeation selectivity; shale gas
Figures

Figure 1

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited. (CC BY 4.0).
