Journal of Manufacturing and Materials Processing

Journal of Manufacturing and Materials Processing is an international, peer-reviewed, open access journal on the scientific fundamentals and engineering methodologies of manufacturing and materials processing published monthly online by MDPI.

Quartile Ranking JCR - Q2 (Engineering, Mechanical | Engineering, Manufacturing | Materials Science, Multidisciplinary)

All Articles (1,633)

Development of an Automated CAD Framework for Fully Parametric Design of Injection Molds

  • Alexandros-Stavros Toumanidis,
  • Savvas Koltsakidis and
  • Dimitrios Tzetzis

Injection mold design is a repetitive and time-consuming process with common individual tasks related to each other. This study presents the development of an automatic computer-aided design (CAD) tool for basic injection molds with complete modeling and no other interaction by the user after inserting the part, built on the SolidWorks Application Programming Interface 2022 (API) and Visual Basic for Applications 7.1 2012(VBA). The tool combines user input forms and supplier catalog data as inputs in an algorithm to automatically generate mold structures, cavity blocks, runner system, ejection system and straight drilled cooling channels without further manual modeling. Three case studies with one-, two-, and four-cavity molds demonstrate the approach. The results show that complete mold assemblies can be produced in less than 10 min rather than hours while maintaining standard component dimensions. Although the present version applies to rule-based geometric placement rather than thermal or injection process optimization, it provides a framework for future integration of more complex mold structures and functions such as slides, hot runner system, unscrewing geometries, conformal cooling, heat-transfer-based design, family molds and machine selection. This work demonstrates how API-driven automation can reduce design time, standardize layouts, and lay the groundwork for next-generation injection mold development.

9 February 2026

Four different parts developed to study representative case examples: (A) a pot component with a single cavity, (B) an egg strainer with two cavities, (C) spinner components with multiple cavities, and (D) a cable holder used to evaluate small cavities.

In mechanical engineering, interest in reliable and practicable technologies for nano- and microstructuring of tool surfaces is increasing. Femtosecond laser structuring offers a promising approach that combines high processing speeds with high precision. However, a knowledge gap remains regarding the optimal process parameters for achieving specific surface patterns on hot-work tool steel substrates. The current study aims to investigate the effects of laser scanning parameters on the formation of self-organized surface structures and the resulting topography and morphology. Therefore, samples were irradiated using a 300 fs laser with linearly polarized light (λ = 1030 nm). Scanning electron microscopy revealed four structure types: laser-induced periodic surface structures (LIPSSs), micrometric ripples, micro-crater structures, and pillared microstructures. The results for surface area and line roughness indicate that high laser pulse overlaps lower the strong ablation threshold more effectively than high scanning line overlaps, promoting the formation of pillared microstructures. For efficient ablation and increased surface roughness, higher pulse overlaps are therefore advantageous. In contrast, at low fluences, higher scanning line overlaps support a more homogeneous formation of nanostructures and reduce waviness.

7 February 2026

Schematic illustration of the laser setup and scanning system with the corresponding scanning parameters: theoretical circular focus diameter



        d


        f



, line distance of the scanning lines


      ∆
      d


, scanning velocity



        v


        s



, laser pulse overlap

    PO

, as well as scanning line overlap

    LO

.

Ultra-precision grinding is widely used in fields such as precision instrumentation, military industry, and aerospace. Focusing on a grinding system based on hydrostatic support, this paper investigates the formation mechanism and variation patterns of roundness error during grinding. The dynamic equations are derived based on the structural characteristics of a vertical grinding system. The uncut chip thickness is formulated, enabling the prediction of grinding forces through mathematical expressions. The dynamic equations are solved using a fully discrete algorithm to obtain the surface profile of the workpiece after machining, and roundness error is extracted using the least squares method. As the speed ratio of the grinding wheel to the workpiece increases, the grinding accuracy improves, and the roundness error can be controlled within 0.2 μm. The farther the grinding force application point is from the center of the slider, the greater the roundness error. Under the condition of meeting the processing range, a shorter grinding wheel contact rod should be selected.

6 February 2026

Schematic Diagram of the Grinding Process System Structure.

Computed tomography and magnetic resonance imaging are two powerful modalities which can be used in the clinical setting to produce data for the creation of patient-specific finite element analysis (FEA) models and physical analogues—for instance, by using additive manufacturing (AM)—that mimic the properties of soft and hard tissues, both morphologically and mechanically. However, there remains a gap between creating a perfect biofidelic physical analogue and its computational counterpart. This gap exists because, firstly, in silico models are often too complex to realise, and secondly, real-life conditions are challenging to emulate both computationally and mechanically, as they involve multiscale situations that are inherently heterogeneous and patient specific. In this study, we applied a multi-scale approach to design and model porcine vertebral specimens. Our results identified critical design factors that affect the quality and accuracy of the models, specifically highlighting that scanning resolution/fidelity and the thresholding technique have a directly proportional impact on model accuracy. A small shift up and down the greyscale level by 20 units can affect the behaviour of the AM sample by as much as [−15% +47%]. Working up the levels for manufacturing, testing and modelling (i) cylindrical cores to (ii) whole vertebrae and then (iii) a whole spine motion segment, we observed that the fidelity of predictions reduces, and errors increase as the structure becomes more complicated and intricate (3.6%, 7.5% and 15%, respectively). We are confident that further material-level developments will provide solutions for the more intricate parts of spinal motion segments, such as the intervertebral discs and facets, which in their natural form are highly sophisticated structures. To the best of our knowledge, this is the first time a holistic multiscale approach has been implemented to produce AM biofidelic analogues of skeletal parts. Our data showed good agreement between the physical and in silico models, confirming that it is possible to model real-time objects and situations both physically and in silico. This ultimately will enable the development of accurate, patient-specific physical models for use in biomechanical testing and medicolegal applications.

6 February 2026

An example of a holistic approach involving the creation of both a physical model and an in silico (computational) model of a human skull, as studied in [15,16]. (A) A number of replicas of the skull were impacted at the same point in a drop tower, suitable illumination and high speed cameras were used, full details in [15,16]; (B) crack patterns at the site of impact were emanating in 3 diverging crack routes, which were identical in all replicas of the skull used [15]; (C) other cracks at the base of the skull (red square) appeared reliably and repeatedly in certain areas and where FEA modelling predicted them to appear (enlarged views of the area in (D,E)), showing a synergy and agreement between these two powerful biomechanical testing methodologies (AM produced physical model and in silico computational model).
