Wireless electric vehicle charging (WEVC) is rapidly advancing as an enabling technology for convenient electrified transportation. The trend toward high-power WEVC systems is accelerating, which not only enhances charging speed and user convenience but also introduces new and complex safety challenges. These challenges are particularly acute at the coupler level, where electrical, thermal, and magnetic risks often interact. This review offers a comprehensive analysis of safety management technologies that are specific to WEVC, with an exclusive focus on coupler-related risks. System-level and coupler-level hazards associated with high-power operation are first examined, followed by an in-depth discussion of recent progress in passive safety materials, such as insulation, thermal dissipation, and electromagnetic shielding. Active safety management strategies are also reviewed in detail, including foreign object detection, live body detection, misalignment detection, and multifunctional detection schemes that integrate these capabilities. Emphasis is placed on the ongoing rapid iteration of safety technologies as power levels increase and on the necessity for solutions that are comprehensive, precise, orderly, and reliable. This review concludes by highlighting future research directions, such as data-driven safety management, intelligent sensor integration, regulatory evolution, and user-centered system design, aiming to support the safe and scalable deployment of WEVC in next-generation mobility. Full article

In a simultaneous wireless power and data transfer (SWPDT) system using common coils, achieving high-speed communication in high-power wireless charging systems is challenging due to power transfer interference on communication. Based on high-frequency data carrier-based SWPDT (HFDC-SWPDT) technology, this paper proposes an orthogonal-frequency simultaneous wireless power and data transfer (OF-SWPDT) method to minimize interference where the data carrier frequency is orthogonal to the power carrier frequency and its harmonics. In addition, a guard band is inserted between the spectra of power harmonics and data in order to further separate the power and data spectra. Thus, a high-power, high-speed SWPDT system is achieved. Finally, an 11 kW prototype with 64.125 kbps full-duplex communication is developed to validate the proposed method. Full article

Wireless charging schemes aim to counter some drawbacks of electric vehicles’ wired charging, such as the fact that it does not encourage mobility, leads to safety issues regarding high voltage cables, power adapters high cost, and has more battery waste by companies. In this paper, a comparative study of wireless power transfer multiple coil geometries is performed to analyze the efficiency, coupling coefficient, mutual inductance, and magnetic flux density production for each geometry. Results show that coil geometry, current excitation, and shielding techniques within the Wireless Electric Vehicle Charging (WEVC) system substantially influence magnetic flux leakage. In addition, the paper proposes an analytical framework for a WEVC scheme via electromagnetic resonance coupling. Safety considerations of the WEVC system, including the effects on humans, are investigated in several scenarios based on the relative location of the human while EV charging is conducted as the leading paper’s goal. The exposure measurements are performed across various radial distances from the coils using 3-D FEA ANSYS Maxwell Software (American technology company, Pennsylvania, United States). The analysis shows that WEVC systems can achieve high power transfer, resulting in increased magnetic flux leakage around the coils. The safe distance for humans and animals during the charging sequence is attained from research results. For instance, in the 120 mm spiral coil, 120 mm square coil, and 600 mm spiral coil operating at 1 A, excitation, the SAR levels are under the threshold of 700 mm away from the coils. For the 600 mm spiral coil excited at 8 A, the SAR levels fall under the threshold at 900 mm away from the coils. When shielding is utilized, the safe distance is improved by up to 350 mm. Considering the regulations of the Non-Ionizing Radiation Protection (ICNIRP) standards, 600 mm is a safe distance away from the coils, and, vertically, anywhere past 300 mm is safe for humans. Full article

In the commercialization process of wireless electric vehicle charging (WEVC), it is essential to ensure the interoperability between diverse WEVC systems due to the wide application of various coil configurations and compensation topologies. This paper proposes a novel electrical interoperability evaluation method based on impedance indices and corresponding feasible space in the complex plane. Firstly, the electromagnetic description of the coil system is introduced to reveal the energy flow process of WEVC system. Further, two key impedance indices and their feasible space are derived and verified. Interoperability evaluation results show that the reference devices in Chinese WEVC standard GB/T 38775.6 and GB/T 38775.7 are able to achieve the requirements of power capability. Moreover, it is necessary to reduce the duty cycle of rectifier when the battery voltage rises so as to narrow down the variation of load resistance and avoid dangerous working conditions. The proposed method can effectively evaluate the electrical interoperability of WEVC systems from different manufacturers under different power or distance levels before conducting experiments. Full article

In order to design a high efficiency Wireless Electric Vehicle Charging (WEVC) system, the design of the different system components needs to be optimized, particularly the design of a high-coupling, misalignment-tolerant inductive link (IL), comprising primary and secondary charging coils. Different coil geometries can be utilized for the primary and the secondary sides, each with a set of advantages and drawbacks in terms of weight, cost, coupling at perfect alignment and coupling at lateral misalignments. In this work, a Finite Element Method (FEM)-based systematic approach for the design of double-D (DD) charging coils is presented in detail. In particular, this paper studies the effect of different coil parameters, namely the number of turns and the turn-to-turn spacing, on the coupling performance of the IL at perfect alignment and at $\pm 200$ mm lateral misalignment, given a set of space constraints. The proposed design is verified by an experimental prototype to validate the accuracy of the FEM model and the simulation results. Accordingly, FEM simulations are utilized to compare the performance of rectangular, DD and DDQ coils. The FEM results prove the importance of utilizing an additional quadrature coil on the secondary side, despite the added weight and cost, to further improve the misalignment tolerance of the proposed inductive link design. Full article

This paper presents a study of the magnetic leakage field of a 7 kW wireless electric vehicle charging (WEVC) system. The leakage field was measured in different test configurations and environments. Typical system parameters, such as coil offset and air gap were evaluated in order to determine their influence on the leakage field distribution. All measured results were then validated by magnetic field simulations. Based on the results of this study, a magnetic leakage field assessment method based on simulation is proposed. Full article
