This study presents a comprehensive numerical framework for Background-Oriented Schlieren (BOS) to systematically evaluate its performance and reconstructive capabilities under complex flow conditions. This framework integrates two stages: forward modeling, using ray tracing to simulate image degradation, and inverse processing, using optical flow and a conjugate gradient algorithm to extract displacements and reconstruct phase information. This method is first validated using turbulent flow fields in the Johns Hopkins Turbulence Database, where the reconstructed phase screens closely match the original data, with relative errors below 4% and structural similarity indices above 0.75 in all cases, providing a possible restoration method for degraded flow field images. It is then applied to shock wave fields with varying Mach numbers; this method achieves meaningful reconstruction at short ranges but fails under long-range imaging due to severe wavefront distortions. However, even in degraded conditions, the extracted optical flow fields preserve structural features correlated with the underlying shock patterns, indicating potential for BOS-based target recognition. These findings highlight both the capabilities and limitations of BOS and suggest new pathways for extending its use beyond traditional flow visualization. Full article

Wavefront shaping is a well-known method of restoring a focus deep within scattering media by manipulating the incident light. However, the achievable focus enhancement depends on and is limited by the optical and geometrical properties of the medium. These properties contribute to the number of linearly independent transmission channels for light propagating through the turbid medium. Correlations occur when the number of incident waves coupled into the scattering medium exceeds this finite number of transmission channels. This paper investigates the wavefront shaping of such correlated electric fields. The influence of the observed correlations persists even though the average electric field distribution at positions in the focal plane follows a circular complex Gaussian. We show that correlations of the transmitted electric fields reduce the achievable intensity enhancement, even deep in the turbid medium. The investigations are carried out using a Monte Carlo algorithm. It is based on the speckle statistics of independent waves and introduces correlations of neighbouring electric fields via a Cholesky decomposition of the covariance matrix. Additional investigations include scenarios where the electric fields are not completely randomized, such as for ballistic or insufficiently scattered light. Significant contributions from such little-scattered light are observed to reduce the intensity enhancement further. Data from simulations solving Maxwell’s equations are compared with the results obtained from the Monte Carlo simulations for validation throughout this paper. Full article

Polymeric Intraocular lenses (IOLs) are vital for restoring vision following cataract surgery and for correcting refractive errors. Despite technological and medical advancements, challenges persist in achieving optimal vision and preventing complications. Surface modifications aim to mitigate the risk of posterior capsule opacification (PCO), while pre-operative measurements aid in selecting suitable IOLs. However, individualized solutions are lacking and there is a clear demand for the development of fully customized IOL surfaces. We employ laser micromachining technology for precise modifications via ablation on PMMA and acrylic IOLs, using femtosecond (fs), nanosecond (ns), and diode continuous wave (CW) lasers, at wavelengths ranging from near-ultraviolet to infrared. Characterization reveals controlled ablation patterning, achieving feature sizes from as small as 400 nm to several micrometers. Regular and confocal micro-Raman spectroscopy revealed alterations of the IOL materials’ structural integrity for some patterning cases, thus affecting the optical properties, while these can be minimized by the proper selection of micromachining conditions. The results suggest the feasibility of accurate IOL patterning, which could offer personalized vision correction solutions, based on relevant corneal wavefront data, thus surpassing standard lenses, marking a significant advancement in cataract surgery outcomes. Full article

Digital holographic microscopy is an important measurement method for micro-nano structures. However, when the structured features are of high-slopes, the interference fringes can become too dense to be recognized. Due to the Nyquist’s sampling limit, reliable wavefront restoration and phase unwrapping are not feasible. To address this problem, the interference fringes are proposed to be sparsified by tilting the reference wavefronts. A data fusion strategy including region extraction and tilt correction is developed for reconstructing the full-area surface topographies. Experimental results of high-slope elements demonstrate the validity and reliability of the proposed method. Full article

Measuring the intensity and distribution of atmospheric optical turbulence at large-aperture astronomical telescope sites is crucial to optimizing turbulence correction for different layers. A real-time measurement of turbulence distribution in large-aperture telescopes would be valuable for the parameter optimization of adaptive optics (AO) systems, especially for large field-of-view AO systems such as multi-conjugate adaptive optics (MCAO) and ground-layer adaptive optics (GLAO). Based on the GLAO system of NVST at FSO, a real-time measurement system was deployed to assess the site’s atmospheric turbulence intensity and distribution. This system is, to our knowledge, the first real-time turbulence parameter measurement system in the world with an AO system. We adopt pseudo-open loop methods to restore the turbulence information from the close-loop data of GLAO and measure the turbulence strength and distribution. Multiple subaperture pairs are used instead of a pair of subapertures for fitting calculation to increase the measurement accuracy. Two conventional measurement algorithms, SLODAR and S-DIMM+, are compared with the data from the open-source simulator SOAPY, to cross-verify the correctness of our calculation based on the data process of pseudo-open loop data and multiple subaperture pairs. The simulation results show that for two layers’ turbulence input, approximately 93% of the turbulence is correctly detected with the SLODAR method and the given parameters of wavefront sensors and correctors, while the S-DIMM+ is 87%. Real-time measurements of atmospheric turbulence at the NVST site were carried out on 28 May 2023. The observation results indicated that approximately 80% of the turbulence was located below an altitude of 2000 m; only a few appear in the upper height. Full article

Wavefront encoding (WFC) is a depth-of-field (DOF) extension technology that combines optical encoding and digital decoding. The system extends DOF at the expense of intermediate image quality and then decodes it through an image restoration algorithm to obtain a clear image. Affected by point spread differences, traditional decoding methods are often accompanied by artifacts and noise amplification problems. In this paper, based on lens-combined modulated wavefront coding (LM-WFC), we simulate the imaging process under different object distances, generate a simulation data set of WFC, and train a multi-scale convolutional neural network. The simulation experiment proves that this method can effectively reduce artifacts and improve image clarity. In addition, we used the LM-WFC camera to obtain real scene images with different target distances for experiments. The decoding results showed that the network model can enhance the quality of image restoration and generate clear images that are more in line with human vision, which is conducive to the improvement and practical application of wavefront coding systems. Full article

Phase mask optimization is one of the critical steps in designing a wavefront coding system to extend the depth of field (DoF). As a classical phase mask, a cubic phase mask was taken as an example. An improved particle swarm optimization (PSO) algorithm was applied to calculate the parameters of the cubic phase mask by introducing the modulation transfer function as the optimization criterion and a threshold as a constraint. The quality of the subsequent image restoration is guaranteed on the premise of the extended DoF. Finally, the improved PSO was proved to be faster, more efficient, and more accurate compared to the simulated annealing algorithm and the traditional PSO. The experimental results verify that the cubic phase mask optimized by the improved PSO can achieve DoF extension in the wavefront coding system. The improved PSO can also be applied to other phase masks of wavefront coding systems. Full article

Age-related macular degeneration (AMD) causes severe vision impairments, including blindness. An option to improve vision in AMD patients is through intraocular lenses and optics. Among others, implantable miniaturized telescopes, which direct light to healthy lateral regions of the retina, can be highly effective in improving vision in AMD patients. Yet, the quality of the restored vision might be sensitive to the optical transmission and aberrations of the telescope. To shed light on these points, we studied the in vitro optical performance of an implantable miniaturized telescope, namely, the SING IMT™ (Samsara Vision Ltd., Far Hills, NJ, USA) designed to improve vision in patients affected by late-stage AMD. Specifically, we measured the optical transmission in the spectral range 350–750 nm of the implantable telescope with a fiber-optic spectrometer. Wavefront aberrations were studied by measuring the wavefront of a laser beam after passing through the telescope and expanding the measured wavefront into a Zernike polynomial basis. Wavefront concavity indicated that the SING IMT™ behaves as a diverging lens with a focal length of −111 mm. The device exhibited even optical transmission in the whole visible spectrum and effective curvature suitable for retinal images magnification with negligible geometrical aberrations. Optical spectrometry and in vitro wavefront analysis provide evidence supporting the feasibility of miniaturized telescopes as high-quality optical elements and a favorable option for AMD visual impairment treatments. Full article

Various diffractive, refractive and holographic optical elements, such as diffraction gratings; microlens raster; phase plates; multi-order diffractive optical elements; adaptive mirrors; diffractive and refractive axicons; holographic multiplexes and many others are used to analyze wavefront aberrations. We shortly discuss the features (advantages and disadvantages) of various wavefront aberration sensors in the Introduction. The main part of the paper is devoted to the analysis of the weight coefficients of Zernike polynomials obtained during medical examinations of the cornea in the human eye. Using data obtained by aberrometers, the average values of the Zernike polynomial coefficients for the anterior and posterior surfaces of the healthy eye cornea and a myopic one were calculated. The original wavefront for the anterior and posterior surfaces of the cornea was restored separately, as well as the total wave aberration. For an objective assessment of the quality of vision, the corresponding point spread functions (PSFs) were calculated. We propose to compensate for the aberrations of the myopic eye, taking into account the physical features of the corneal surface. The results of numerical simulation showed that in order to improve the quality of the patient’s vision, it is necessary to take into account high-order aberrations of the anterior surface of the cornea in the form of a coma of the third order and aberrations of the fourth order. Full article

Adaptive optics (AO) is an effective method to compensate the wavefront distortion caused by atmospheric turbulence and system distortion. The accuracy and speed of aberration restoration are important factors affecting the performance of adaptive optics correction. In recent years, an AO correction method based on a convolutional neural network (CNN) has been proposed for the non-iterative extraction of light intensity image features and recovery of phase information. This method can directly predict the Zernike coefficient of the wavefront from the measured light intensity image and effectively improve the real-time correction ability of the AO system. In this paper, a turbulence aberration restoration based on two frames of a light intensity image using GoogLeNet is established. Three depth scales of GoogLeNet and different amounts of data training are tested to verify the accuracy of Zernike phase difference restoration at different turbulence intensities. The results show that the training of small data sets easily overfits the data, while the training performance of large data sets is more stable and requires a deeper network, which is conducive to improving the accuracy of turbulence aberration restoration. The restoration effect of third-order to seventh-order aberrations is significant under different turbulence intensities. With the increase in the Zernike coefficient, the error increases gradually. However, there are valley points lower than the previous growth for the 10th-, 15th-, 16th-, 21st-, 28th- and 29th-order aberrations. For higher-order aberrations, the greater the turbulence intensity, the greater the restoration error. The research content of this paper can provide a network design reference for turbulence aberration restoration based on deep learning. Full article

In order to solve the problem of atmospheric influence on the far-field measurement of the quality of a laser beam, we proposed a direct wavefront measurement system based on the Hartmann detection principle, which can measure large apertures and high-power laser beams. The measuring system was composed of a lens array and a detector. The wavefront detection of a large aperture laser beam could be realized by controlling the distance between the lenses and the size of the lens. The influence of different duty cycle factors on the accuracy of the wavefront reconstruction under the same arrangement and different arrangement conditions was simulated and analyzed. The simulation results showed that when the sub-lenses of the system were not in close contact, the reconstruction accuracy of the duty factor of 0.8 was close to that of the case of the duty factor of 1. Within a certain detection range, the hexagonal arrangement of 19 lenses and the arrangement of 8 × 8 lens arrays had a high wavefront restoration accuracy; both were lower than 0.10 λ. The system proposed in this paper was suitable for measuring a large aperture laser beam, providing a new idea for measuring and analyzing the quality of large aperture laser beams. It also has an important significance for improving the measurement accuracy of the beam quality. Full article

The existence of aberrations has always been an important limiting factor in the imaging field. Especially in optical microscopy imaging, the accumulated aberration of the optical system and the biological samples distorts the wavefront on the focal plane, thereby reducing the imaging resolution. Here, we propose an adaptive optical aberration correction method based on convolutional neural network. By establishing the relationship between the Zernike polynomial and the distorted wavefront, with the help of the fast calculation advantage of an artificial intelligence neural network, the distorted wavefront information can be output in a short time for the reconstruction of the wavefront to achieve the purpose of improving imaging resolution. Experimental results show that this method can effectively compensate the aberrations introduced by the system, agarose and HeLa cells. After correcting, the point spread function restored the doughnut-shape, and the resolution of the HeLa cell image increased about 20%. Full article

Near-eye display (NED) systems for virtual reality (VR) and augmented reality (AR) have been rapidly developing; however, the widespread use of VR/AR devices is hindered by the bulky refractive and diffractive elements in the complicated optical system as well as the visual discomfort caused by excessive binocular parallax and accommodation-convergence conflict. To address these problems, an NED system combining a 5 mm diameter metalens eyepiece and a three-dimensional (3D), computer-generated holography (CGH) based on Fresnel diffraction is proposed in this paper. Metalenses have been extensively studied for their extraordinary capabilities at wavefront shaping at a subwavelength scale, their ultrathin compactness, and their significant advantages over conventional lenses. Thus, the introduction of the metalens eyepiece is likely to reduce the issue of bulkiness in NED systems. Furthermore, CGH has typically been regarded as the optimum solution for 3D displays to overcome limitations of binocular systems, since it can restore the whole light field of the target 3D scene. Experiments are carried out for this design, where a 5 mm diameter metalens eyepiece composed of silicon nitride anisotropic nanofins is fabricated with diffraction efficiency and field of view for a 532 nm incidence of 15.7% and 31°, respectively. Furthermore, a novel partitioned Fresnel diffraction and resample method is applied to simulate the wave propagations needed to produce the hologram, with the metalens capable of transforming the reconstructed 3D image into a virtual image for the NED. Our work combining metalens and CGH may pave the way for portable optical display devices in the future. Full article

Non-uniform intensity distribution of laser near-field beam results in the irregular shape of the spot in the wavefront sensor. The intensity of some sub-aperture spots may be too weak to be detected, and the accuracy of wavefront restoration is seriously affected. Therefore, an extreme learning machine method is proposed to realize high precision wavefront restoration under dynamic non-uniform intensity distribution. The simulation results show that this method has better accuracy of wavefront restoration than the classical modal algorithm under dynamic non-uniform intensity distribution. The root mean square error of the residual wavefront for the proposed method is only 2.9% of the initial value. Full article

Satellites have many high-, medium-, and low-frequency micro vibration sources that lead to the optical axis jitter of the optical load and subsequently degrade the remote sensing image quality. To address this problem, this paper developed an image motion detection and restoration method based on an inertial reference laser, and describe edits principle and key components. To verify the feasibility and performance of this method, this paper also built an image motion measurement and restoration system based on an inertial reference laser, which comprised a camera (including the inertial reference laser unit and a Hartmann wavefront sensor), an integrating sphere, a simulated image target, a parallel light pope, a vibration isolation platform, a vibration generator, and a 6 degrees of freedom platform. The image restoration principle was also described. The background noise in the experiment environment was measured, and an image motion measurement accuracy experiment was performed. Verification experiments of image restoration were also conducted under various working conditions. The experiment results showed that the error of image motion detection based on the inertial reference laser was less than 0.12 pixels (root mean square). By using image motion data to improve image quality, the modulation transfer function (MTF) of the restored image was increased to 1.61–1.88 times that of the original image MTF. The image motion data could be used as feedback to the fast steering mirror to compensate for the satellite jitter in real time and to directly obtain high-quality images. Full article
