During this research, an automatic monitoring system was developed to monitor the working parameters in a solar power plant consisting of two flexible silicon modules. The first stage of the monitoring system relies on a microcontroller, which collects data from wattmeter modules made using a microcontroller. This tier also includes DC/DC converter and RS232-TCP converter modules for data transfer. The second stage, the industrial PLC, receives data from the first stage and transmits them to the PC, where the information is stored and the processes are visualized on the HMI screen. During this study, the charging process was analyzed using PWM- and MPPT-type charging controllers, as well as the power supply of Fito LED strips for lighting plants. Using the created monitoring system, the parameters of the solar power plant with flexible PV modules were monitored. This study compared PWM and MPPT battery charging methods, finding that MPPT is more efficient, especially under unstable solar conditions. MPPT technology optimizes energy usage more efficiently, resulting in faster battery charging compared to PWM technology. Full article

The link between the world of communications and the world of racing is provided by the telemetry systems in electric racing cars. These systems send real-time data about the vehicle’s behavior and systems to enable informed decisions during the race. The objective of this research was to integrate telemetry into the battery bank of an electric racing car in order to find the optimal values of current and voltage that optimize the charging process and thus improve the performance of the vehicle in competition using Response Surface Analysis. Specifically, the telemetry system consisted of an Arduino Mega, a digital wattmeter, and temperature sensors, all installed in the vehicle. Once the telemetry data were obtained, a response surface design was fitted with current, voltage, and temperature as factors varying from low to high values, with the objective function being to minimize the battery charging time. Using the response surface methodology and the steepest descent algorithm, it was found that all factors significantly affect the charging time, with the minimum charging time being 6961 s, obtained with a current of 2.4 amps and voltages of 50.5 volts and 43.6 volts. Full article

Smart energy meters supporting bidirectional data communication enable novel remote error monitoring applications. This research targets characterization of the systematic worst-case error of the previously published remote watthour meter’s gain estimation method based on the comparison of synchronous measurements by the reference and meter under test. To achieve the research aim a methodology based on global maximization of the systematic error objective function assuming the typical low voltage electrical distribution network operation parameters ranges as defined by the standard recommendations for network design. To cross verify the reliability of the assessed solutions the suggested error analysis methodology was implemented utilizing two stochastic global extremum search techniques (genetic algorithms, pattern search) and the third one utilizing nonlinear programming solver. It was determined that the wattmeter adjustment gain worst-case error does not exceed 0.5% if the remote wattmeter monitored load power factor is larger than 0.1 and a network is designed according to the recommendation of the acceptable voltage drop less than 5%. For a load exhibiting power factor larger than $\cos \phi =$ 0.9 the worst-case error was found to be less than 0.1%. It is concluded therefore that considering the systematic worst-case error the previously suggested remote wattmeter adjustment gain estimation method is suitable for remote error monitoring of Class 2 and Class 1 wattmeters. Full article

In the present work, the design and microfabrication of a tunneling magnetoresistance (TMR) electrical current sensor is presented. After its physical and electrical characterization, a wattmeter is developed to determine the active power delivered to a load from the AC 50/60 Hz mains line. Experimental results are shown up to 1000 W of power load. A relative uncertainty of less than 1.5% with resistive load and less than 1% with capacitive load was obtained. The described application is an example of how TMR sensing technology can play a relevant role in the management and control of electrical energy. Full article

This paper presents a home area network (HAN)-based domestic load energy consumption monitoring prototype device as part of an advanced metering system (AMS). This device can be placed on individual loads or configured to measure several loads as a whole. The wireless communication infrastructure is supported on IEEE 805.12.04 radios that run a ZigBee stack. Data acquisition concerning load energy transit is processed in real time and the main electrical parameters are then transmitted through a RF link to a wireless terminal unit, which works as a data logger and as a human-machine interface. Voltage and current sensing are implemented using Hall effect principle-based transducers, while C code is developed on two 16/32-bit microcontroller units (MCUs). The main features and design options are then thoroughly discussed. The main contribution of this paper is that the proposed metering system measures the reactive energy component through the Hilbert transform for low cost measuring device systems. Full article
