Annular flow is a common flow configuration encountered in fields such as food engineering, energy and power engineering, and petroleum engineering. The annular space formed by the inner and outer pipes exhibits unique characteristics, with the distinct curvatures of the inner and outer pipes rendering the annulus fundamentally different from a circular pipe. The complexity of the annular structure complicates the rapid calculation of turbulent statistics in engineering practice, as modeling these statistics necessitates a comprehensive understanding of their peak characteristics. However, current research lacks a thorough understanding of the peak characteristics of turbulent flows in annuli with varying diameter ratios (the ratio of the inner tube’s diameter to the outer tube’s diameter) between the inner and outer pipes. To gain a deeper insight into the turbulent peak characteristics within annular flows, this study employs numerical simulation methods to investigate the first- and second-order turbulent statistics under different diameter ratios resulting from varying curvatures of the inner and outer pipes. These statistics encompass velocity distribution, the position and magnitude of maximum velocity, turbulence intensity, turbulent kinetic energy, and Reynolds stress. The research findings indicate that the contour plots of velocity, turbulence intensity, and turbulent kinetic energy distributions under different diameter ratio conditions exhibit central symmetry. The peaks of the first-order statistical quantities are located in the mainstream region of the annulus, and their positions gradually shift closer to the center of the annulus as the diameter ratio increases. For the second-order statistical quantities, peaks are observed near both the inner and outer walls, and their positions move closer to the walls as the diameter ratio rises. The peak values of turbulent characteristics show significant variations across different diameter ratios. Both the inner and outer wall surfaces exhibit peaks in their second-order statistical quantities. For instance, the maximum value of Reynolds stress near the inner tube is 101.4% of that near the outer tube, and the distance from the wall where the maximum Reynolds stress occurs near the inner tube is 97.2% of the corresponding distance near the outer tube. This study is of great significance for optimizing the diameter combination of the inner and outer pipes in annular configurations and for evaluating turbulent statistics. Full article

Recycled concrete is widely recognized as favorable for environmental protection and sustainable development. However, recycled concrete, especially containing abandoned brick aggregate, is rarely used in main structural members due to its inherent defects. Concrete-filled double steel tube columns (CFDSTCs), consisting of an outer and an inner steel tube with concrete filling the entire section, are effective in load bearing and deformation resistance. The structural application of abandoned brick aggregate, resulting from urbanization renewal, might be widened through CFDSTCs. This paper presents an experimental and analytical study aiming to investigate the axial compressive behavior of recycled-brick-aggregate-concrete-filled double steel tube columns (RBCDSTs). A total of six specimens were tested under concentric compression, including five RBCDSTs and one concrete-filled single steel tube column. The varied parameters included the replacement ratios (0% and 25%) of brick aggregate and the thickness ratio of the inner and outer steel tubes (0.75, 1, and 1.25). Theoretical analysis was also carried out. A new constitutive model of RBCDST was proposed and used in finite element analysis. The investigation indicated that, under the current conditions, the presence of the inner steel tube only increased the strength by 0.14%. When the inner and outer diameter ratio is 0.73, using a 25% replacement rate of bricks in the entire cross-section or only in the ring area of the cross-section will result in 21.1% and 10.1% strength decreases, respectively. For every 0.6% increase in the diameter-to-thickness ratio of the outer tube, the strength of RBCDST increases 16.3% on average. Full article

This study innovatively proposes a pipeline-type pneumatic lift sediment removal device for cleaning pollutants at the bottom of fish breeding tanks and conducts hydrodynamic characteristic analysis on its core component, the pneumatic lift pipeline structure, which consists of a horizontal circular tube with multiple micro-orifices at the bottom and an upward-inclined circular tube. The pipeline has an inner diameter of 20 mm and a vertical length of 1.2 m, with the orifice at one end of the horizontal tube connected to the gas supply line. During operation, compressed gas enters the horizontal tube, generating negative liquid pressure that draws solid–liquid mixtures from the tank bottom into the pipeline, while buoyant forces propel the gas–liquid–solid mixture upward for discharge through the outlet. Under a constant gas flow rate, numerical simulations investigated efficiency variations through three operational scenarios: ① different pipeline orifice diameters, ② varying orifice quantities and spacings, and ③ adjustable pipeline bottom clearance heights. The results indicate that in scenario ①, an orifice diameter of 4 mm demonstrated optimal efficiency; in scenario ②, the eight-orifice configuration achieved peak efficiency; and scenario ③ showed that the proper adjustment of the bottom clearance height enhances pneumatic efficiency, with maximum efficiency observed at a clearance of 10 mm between sediment suction pipe and tank bottom. Full article

The traditional finite element method deals with the temperature field around the cooling tube due to the computational efficiency problems caused by grid division and the uncertainty of the convective heat transfer coefficient, resulting in inaccurate calculation results around the cooling tube. We conducted experiments to study the thermal stress and temperature gradient caused by various factors such as different materials of cooling pipes, pipe diameters, cooling water temperatures, and flow rates. The results showed that aluminum alloy pipes had the highest cooling efficiency but also produced a large temperature gradient. Pipe diameter had the most significant impact on cooling efficiency. Additionally, it is recommended that the cooling water flow velocity is not less than 0.6 m/s to achieve the best efficiency for the cooling pipe of any pipe diameter. The influence range of the cooling pipe on concrete could vary with pipe material, flow rate, and ambient factors. Our experimental results were compared with other heat transfer formulas (the Dittus–Boelter formula and the Yang Joo-Kyoung formula). According to the measured results, the formula is modified). The modified formula can estimate the heat transfer coefficient more accurately according to the flow rate and pipeline characteristics. Finally, the applicability of the formula is further verified by comparing the concrete on the bottom plate of a dam. The proposed heat transfer prediction model can estimate the heat transfer coefficient according to the flow rate and pipeline characteristics, The accuracy of the convection coefficient under different working conditions is improved by 10–25%. It is convenient to predict concrete temperature in practical engineering. Full article

The continuous cooling transformation (CCT) curves of undercooled austenite serve as crucial references for obtaining desired microstructures and properties in metallic materials (particularly deformed metals) through heat treatment. In this study, static and dynamic CCT curves were constructed for experimental steels micro-doped with rare earth element Ce by combining temperature-dilatometric curves recorded after austenitization at 900 °C with microstructural characterization and microhardness measurements. Comparative analyses were conducted on the microstructures and microhardness of three experimental steels with varying Ce contents subjected to sizing (reducing) diameter deformation at 850 °C and 950 °C. The CCT experimental results revealed that the microhardness of the tested steels increased with cooling rates. Notably, dynamic CCT specimens cooled at 50 °C/s to room temperature following superheated deformation exhibited 56.7 HV5 higher microhardness than static CCT specimens, accompanied by increased martensite content. The reduction of deformation temperature from 950 °C to 850 °C resulted in the expansion of the bainitic phase region. The incorporation of trace Ce elements demonstrated a significant enhancement in the microhardness of 30MnNbRE steel. This research proposes an effective processing route for improving strength-toughness combination in microalloyed oil well tubes: introducing trace Ce additions followed by sizing (reducing) diameter deformation at 950 °C and subsequent ultra-fast cooling at 50 °C/s to room temperature. This methodology facilitates the production of high-strength/toughness steels containing abundant martensitic microstructures. Full article

In the development, evaluation, and application of medical flat-panel detectors, the modulation transfer function (MTF) is crucial, as it reflects the device’s ability to restore detailed information. Medical flat-panel detectors encompass both image data acquisition and digitization processes, and detectors with varying pixel sizes exhibit differing capabilities for observing details. Accurately quantifying MTF is a critical challenge. The complexity of MTF calculation, combined with unclear principles and details, may result in erroneous outcomes, thereby misleading research and decision-making processes. This paper presents an improved MTF oversampling method based on the slit model. MTF testing is conducted under various sample conditions and using different focal spot diameters of the X-ray tube to analyze the impact of focal spot size. High-precision tungsten plates and fixtures are designed and fabricated, and MTF results with varying line spread function (LSF) sampling intervals are compared. The results demonstrate that the improved slit model offers distinct advantages, with MTF measurements achieving 92.4% of the ideal value. Compared to traditional tungsten edge and point (aperture) model testing methods, the accuracy of the proposed method is improved by 5–13%. The optimal sampling interval is approximately 1/29 of the pixel pitch, offering a more accurate method for evaluating detector performance. Full article

Unidirectional pulsating heat pipes (PHPs) have been extensively investigated. However, a comprehensive understanding of the mechanism is still lacking. In this study, we analyze the unidirectional flow (distinct from thermosyphon) in closed PHP loops and reveal that the combined effect of the diameter variation and pressure distribution leads to a stable circulatory flow. Analogous to the Carnot thermodynamic cycle, a flow dynamical cycle along the loop is proposed to determine the highest momentum increment rate at the limit of the pressures and tube cross-sections. Furthermore, an effective pressure cycle considering friction resistance is introduced to elucidate the balance between fluid momentum increase and decrease. Experiments with glass PHP tubes are conducted to visualize fluid movements and characterize unidirectional flow PHPs accurately. The results confirm that varying-diameter PHP significantly promotes the circulatory flow, highlighting its potential for PHP development. Full article

Condensation dehumidification is currently the mainstream means of dehumidification, and the idea is to precipitate moisture by cooling the air below the dew point temperature; however, this process requires the use of a chiller to provide a low-temperature cooling source, which triggers reheat losses. By positive-pressure condensation, the dew point temperature can be increased, thereby increasing the cooling source temperature. In this paper, the dehumidification process in the bent-tube heat exchanger is investigated theoretically and experimentally. The bent-tube heat exchanger efficiently removes moisture from the air and increases the dehumidification efficiency through positive-pressure condensation. Experiments on positive-pressure condensation and dehumidification were conducted at varying pressures, with the results demonstrating that the model’s accuracy is within ±17%. As the fluid flow rate and pipe diameter rise, so do the dehumidification capacity and heat transfer coefficient. Furthermore, the findings show that the air humidity after dehumidification drops from 16.2 g/kg to 12.9 g/kg, meaning it is just over half of the value at atmospheric pressure, within the pressure that ranges from 100 kPa to 800 kPa. Increasing pressure enhances the heat transfer coefficient, while increasing humidity exacerbates this effect. With a 20% increase in wet air humidity, the heat transfer coefficient varies between 18% and 37%. Full article

This paper presents a modified finite element analysis (FEA) model for predicting the axial compression strength of large-diameter concrete-filled steel tubular (CFST) stub columns, addressing the gap in research that has often focused on smaller diameters. The size effect, which significantly impacts the structural performance of large-diameter CFST columns, is a key focus of this study. The goal is to validate the accuracy and reliability of the modified FEA model by comparing its predictions with experimental data from the literature, specifically examining ultimate axial load capacity, failure modes, and deformed shapes. In addition to validating the model, this study includes a comprehensive parametric analysis that explores how critical geometric parameters such as the diameter-to-thickness (D/t) ratio and length-to-diameter (L/D) ratio affect the axial compressive behavior of CFST stub columns. By systematically varying these parameters, the research provides valuable insights into the load-bearing capacity, deformation characteristics, and failure mechanisms of CFST columns. Furthermore, the material properties of the steel tube—particularly its yield strength—and the compressive strength of the concrete core are investigated to optimize the design and safety performance of these columns. The results indicate that the FEA model shows excellent agreement with experimental results, accurately predicting the axial load-strain response. It was observed that as the diameter of the steel tube increases, the peak stress, peak strain, strength index, and ductility index tend to decrease, underscoring the size effect. Conversely, an increase in the yield strength and thickness of the steel tube enhances the ultimate strength of the CFST columns. These findings demonstrate the reliability of the modified FEA model in predicting the behavior of large-diameter CFST columns, offering a useful tool for optimizing designs and improving safety margins in structural applications. Full article

Background/Objectives: Arteriovenous (AV) graft is a procedure for hemodialysis performed in the arm. Optimizing AV graft design is vital to enhance haemodialytic efficiency in patients with kidney disease. Despite being a standard procedure, making it work optimally is still difficult due to various graft diameters and anastomosis configurations, which have limited studies. This research aims to find the ideal AV graft tube diameter on blood flow and pressure gradients and the ideal body site for AV graft implantation and to study their angles for dialysate flow. Methods: Nine models were designed in Autodesk Fusion 360 with 40°, 50°, and 60° angles each having 2 mm, 5.1 mm, and 14.5 mm diameters, all following specific equations on continuity, momentum (Navier-Stokes Equation)), and the Reynolds Stress Model (RSM). The CFD simulation of these models was performed in ANSYS Fluent with an established parameter of 0.3 m/s inlet velocity and stiff/no-slip graft and artery wall boundary condition. Results: As a result, the design with a diameter of 14.5 mm and a 40° angle was overall the most ideal in terms of minimal wall shear stress and turbulence. Conclusions: Thus the brachiocephalic area or the forearm is calculated to be the most optimal implantation site. Additionally, varying angles do affect dialysate flow, as smaller values cause less stress. Full article

This paper examines the atomization characteristics of liquid hydrogen fuel in a premixing tube under different operating conditions. Hydrogen fuel’s unique injection morphology and atomization behavior were analyzed using the Volume of Fluid-to-Discrete Particle Model (VOF to DPM) approach, coupled with the SST $k-\omega$ turbulence model and adaptive mesh refinement. The study revealed that the breakup and transformation of liquid surfaces into particles are significantly impacted by varying air velocities and injection pressure. Specifically, higher air velocities caused the liquid sheet to lengthen and narrow due to intensified vortices. However, the breakup was delayed at higher velocities, occurring at distances of 0.037 m and 0.043 m for air velocities of 10 m/s and 20 m/s, respectively. The research also highlights the significant role that injection pressure plays in fluid sheet breakup. Higher pressures promote better atomization and fuel–lair mixing, resulting in more particles with increased diameters. Notably, the fluid sheet exhibited a small angle of about 43.79° when using the velocity component corresponding to p1 = 0.5 MPa. Similarly, for p2 = 1 MPa and p3 = 2 MPa, the angles were measured to be approximately 47.5° and 49.5°, respectively. Additionally, the study observed that the injection expands in length and diameter as time progresses, indicating fuel dispersion. These insights have significant implications for the design principles of injectors in power generation technologies that utilize liquid hydrogen fuel. Full article

This paper investigates the application of Schlieren flow visualization for detecting leaks in pipelines carrying high-temperature fluids. Two experimental setups were constructed: one with a 25 mm PTFE tube featuring a 2 mm diameter perforation, and another with a 100 mm diameter pipe insulated with an aluminum jacket and featuring a 12 mm leak gap. A single-mirror-off-axis Schlieren system, employing a 150 mm diameter parabolic mirror, was used to visualize the leaks. The temperature of the leaking air varied between 20 and 100 °C, while the ambient temperature was maintained at 14 °C. To quantify the leaks, the coefficient of variation for pixel intensity within the leak region was calculated. Results showed that for the PTFE tube, leaks became detectable when the temperature difference exceeded 34 °C, with the coefficient of variation surpassing 0.1. However, in the insulated pipe, detecting clear leak patterns was challenging. This research demonstrates the potential of Schlieren visualization as a valuable tool in enhancing pipeline leak detection. Full article

Effective sound absorption is crucial in environments like schools and hospitals. This study evaluates open-pore polyurethane foam and perforated onyx panels, which attenuate noise via distinct mechanisms: porous materials convert sound energy to heat through viscous and thermal losses, while perforated panels use resonant behaviour for energy dissipation. The impact of hole geometries and panel orientations on the sound absorption coefficient and noise reduction coefficient was investigated using COMSOL Multiphysics 6.0 for finite element analysis and ISO 10534-2 compliant impedance tube experiments. Six perforated panel configurations were 3D-printed with varying hole diameters and backed by a 24 mm polyurethane foam layer. Both ‘forward’ and ‘reverse’ configurations were assessed. A tapered hole from 4 mm to 2 mm showed the highest sound absorption across the 100–4000 Hz range, with a noise reduction coefficient of 0.444, excelling in both orientations. Reverse designs generally performed less, underscoring the importance of hole geometry and orientation. Experimental results aligned with FEA simulations, validating the computational model. This study elucidates sound absorption mechanisms of porous and perforated materials, providing a validated framework for material selection in noise-sensitive settings and highlighting 3D-printing’s potential in noise control. Full article

In this study, three randomly packed beds with varying tube-to-particle diameter ratios (D/d) are constructed using the discrete element method (DEM) and simulated via CFD under low pore Reynolds numbers (Re_p < 100). An innovation of this research lies in the application of hydrogen in randomly packed beds, coupled with the consideration of its temperature-dependent thermal properties. The axial analysis of the heat transfer characteristics shows that PB−5 and PB−6 achieve thermal equilibrium 44% and 58% faster than PB−4, respectively, demonstrating enhanced heat transfer efficiency. However, at higher flow rates (0.8 m/s), the large-sized fluid channels in PB−6 severely impact the heat transfer efficiency, slightly reducing it compared to PB−5. Additionally, this study introduces a localized segmentation method for calculating the axial local Nusselt number, showing that the axial local Nusselt number (Nu) not only exhibits an inverse relationship with the axial porosity distribution, but also matches its amplitude fluctuations. The wall effect significantly impacts the flow and temperature distribution in the packed bed, causing notable velocity and temperature oscillations in the near-wall region. In the near-wall region, the average temperature is lower than in the core region, and the axial temperature profile exhibits more intense oscillations. These findings may provide insights into the use of hydrogen in randomly packed beds, which are vital for enhancing industrial applications such as hydrogen storage and utilization. Full article

In certain precision work scenarios, underwater robots require the ability to adhere to surfaces in order to perform tasks effectively. An efficient and stable suction device plays a pivotal role in the functionality of such underwater robots. The vortex suction cup, distinguished by its uncomplicated design, high suction efficiency, and capability for non-contact adhesion, holds significant promise for integration into underwater robotic systems. This paper presents a novel design for a vortex suction cup and investigates its suction force and torque when encountering surfaces with varying curvature radii using Computational Fluid Dynamics (CFD) simulations and experimental testing. These findings offer valuable insights for the development of robots capable of adapting to underwater structures of different dimensions. Results from both experiments and simulations indicate that reducing the curvature radius of the adhered surface results in a decrease in suction force and an increase in torque exerted on the suction cup. As the adhered surface transitions from flat to a curvature radius of 150 mm, the adhesion force of our proposed vortex suction cup decreases by approximately 10%, while the torque increases by approximately 20% to 30%. Consequently, the adhesion efficiency of the suction cup decreases by about 25% to 30%. Full article
