Search Results (27)

In short-range microwave imaging, the collection of data in real environments for the purpose of developing techniques for target detection is very cumbersome. Simultaneously, to develop effective and efficient AI/ML-based techniques for target detection, a sufficiently large dataset is required. Therefore, to complement labor-intensive and tedious experimental data collected in a real cluttered environment, synthetic data generation via cost-efficient electromagnetic wave propagation simulations is explored in this article. To obtain realistic synthetic data, a 3-D model of an antenna, instead of a point source, is used to include the coupling effects between the antenna and the environment. A novel printed scalable ultra-wide band (UWB) log-periodic antenna with a tapered feed line is designed and incorporated in simulation models. The proposed antenna has a highly directional radiation pattern with considerable high gain (more than 6 dBi) on the entire bandwidth. Synthetic data are generated for two different applications, namely through-the-wall imaging (TWI) and through-the-foliage imaging (TFI). After the generation of synthetic data, clutter removal techniques are also explored, and results are analyzed in different scenarios. Post-analysis shows evidence that the proposed UWB log-periodic antenna-based synthetic imagery is suitable for use as an alternative dataset for TWI and TFI application development, especially in training machine learning models. Full article

Over the past few years, the Internet of Things paradigm has brought renewed significant interest to indoor positioning, tracking, and localization topics, principally since real-time locating technology allows a reference node to infer the position of tagged target nodes, creating the opportunity for millions of object-to-object awareness applications. This study first presents an overview of positioning localization techniques and discusses the use of ultra-wide bandwidth technology for complex environment monitoring, followed by consideration of the error sources that are present in line-of-sight (LOS) and non-line-of-sight (NLOS) scenarios between a reader and a tag. A technical review of the available industrial and commercial UWB real-time locating transceivers (RTLSs) is presented, with a focus on the frontend antennas that are integrated in these systems to establish the needed wireless communication for positioning. Then, the different characteristics of these antennas are summarized and discussed, along with their impact on the localization performance in terms of the reading range, position information accuracy, object-orientation-independent localization, and multipath mitigation. Solutions are suggested to achieve antenna-based improvements to the performance of RTLSs. Full article

For vehicle positioning applications in Intelligent Transportation Systems (ITS), lane-level or even more precise localization is desired in some typical urban scenarios. With the rapid development of wireless positioning technologies, ultrawide bandwidth (UWB) has stood out and become a prominent approach for high-precision positioning. However, in traffic scenarios, the UWB-based positioning method may deteriorate because of not-line-of-sight (NLOS) propagation, multipath effect and other external interference. To overcome these problems, in this paper, a fusion strategy utilizing UWB and onboard sensors is developed to achieve reliable and precise vehicle positioning. It is a two-step approach, which includes the preprocessing of UWB raw measurements and the global estimation of vehicle position. Firstly, an ARIMA–GARCH model to address the NLOS problem of UWB at vehicular traffic scenarios is developed, and then the NLOS of UWB can be detected and corrected efficiently. Further, an adaptive IMM algorithm is developed to realize global fusion. Compared with traditional IMM, the proposed AIMM is capable of adjusting the model probabilities to make them better matching for current driving conditions, then positioning accuracy can be improved. Finally, the method is validated through experiments. Field test results verify the effectiveness and feasibility of the proposed strategy. Full article

The development of electronic systems and wireless communication has led to a proportional increase in data traffic over time. One potential solution for alleviating data congestion is to augment the bandwidth capacity. This study presents a novel asymmetric circular slotted semi-circle-shaped monopole antenna design using a defective ground structure. The extended ultrawide bandwidth is achieved by implementing a design where the semi-circle radiator is etched in a specific asymmetric circular slot. This involves etching a circle with a radius of 1.25 mm at the center of the radiator, as well as a succession of circles with a radius of 0.75 mm along the edges of the radiator. In addition, the ground plane is situated at a lower elevation and features a U-shaped truncation that has been etched onto its surface. The expansion of the impedance bandwidth can be accomplished by making adjustments to the radiator and ground plane. The UWB antenna under consideration possesses a geometric configuration of 21.6 × 20.8 × 1.6 mm³ and the antenna is fabricated using an FR-4 glass epoxy substrate. The UWB antenna operates throughout the frequency range of 2.2–16.5 GHz, exhibiting a gain of at least 3.45 dBi across the entire impedance bandwidth and the maximum peak gain of 9.57 dBi achieved at the mid-resonance frequency of 10.5 GHz. The investigation of the antenna’s physical properties is conducted utilizing characteristic mode analysis. The investigation also includes an analysis of the time-domain characteristics, revealing that the group delay was found to be less than 1 ns across the operational frequency range. The predicted and measured findings demonstrate consistency and confirm that the suggested antenna is suitable for electronic systems and wireless applications. Full article

In this article, a compact 4-port UWB (Ultra-Wide Band) MIMO (Multiple Input Multiple Output) antenna is proposed. A low profile FR-4 substrate is used as a dielectric material with the dimensions of 58 × 58 mm² (0.52λ × 0.52λ) at 2.8 GHz and a standard thickness of 1.6 mm. The proposed design characterizes an impedance bandwidth starting from 2.8 to 12.1 GHz (124.1%). Each of the four elements of the proposed MIMO antenna configuration consists of a monopole antenna with PG (partial ground) that has a slot at its center. The corner of each patch (radiator) and ground slot are rounded for impedance matching. Each unit cell is in an orthogonal orientation, forming a quad-port MIMO antenna system. For reference, the partial ground of each unit cell is connected meticulously with the others. The simulated results of the proposed quad-port MIMO antenna design were configured and validated by fabrication and testing. The proposed Quad-port MIMO design has a 6.57 dBi peak gain and 97% radiation efficiency. The proposed design has good isolation below 15 dB in the lower frequency range and below 20 dB in the higher frequency range. The design has a measured ECC (Envelop Correlation Co-efficient) of 0.03 and DG (Diversity Gain) of 10 dB. The value of TARC (Total Active Reflection Coefficient) over the entire operating band is less than 10 dB. Moreover, the design maintained CCL (Channel Capacity Loss) < 0.4 bits/sec/Hz and MEG (Mean Effective Gain) < 3 dB. Based on the obtained results, the proposed design is suitable for the intended high data rate UWB wireless communication portable devices. Full article

Long-Range Wide-Area Networks (LoRaWAN) allow the transmission of data via radio link from sensors, which are potentially isolated or difficult to access, to gateways and servers that are connected to cellular networks for data processing, exchange, or relay, with low transmission power. This concept employs Long-Range (LoRa) modulation and has led to the emergence of many applications for the monitoring and tracking of objects. However, due to its characteristic of a low data rate for low-power communication, the transmission of information with LoRa technology is not suitable for the fast real-time monitoring of data. Additionally, due to its narrow bandwidth, an attempt to perform localization through the LoRa modulation technique will result in very limited accuracy because of its inability to resolve multipath problems. Thus, in this paper, we propose a multi-standard Ultra-Wide Bandwidth (UWB) and LoRa end-device that is capable of measuring location with high accuracy using UWB technology and then transmitting the location information through LoRa method to gateways and the Internet of Things Network. The results of measurements in indoor and outdoor scenarios show a UWB localization accuracy that is of sub-meter level, being between 10 and 33 cm, and a UWB range of 124 m in Line-of-Sight (LOS) and 55 m in Non-Line-of-Sight (NLOS) applications, respectively. Full article

Indoor localization is a key research area and has been stated as a major goal for Sixth Generation (6G) communications. Indoor localization faces many challenges, such as harsh wireless propagation channels, cluttered and dynamic environments, non-line-of-sight conditions, etc. There are various technologies that can be applied to address these issues. In this paper, four major technologies for implementing an indoor localization system are reviewed: Wireless Fidelity (Wi-Fi), Ultra-Wide Bandwidth Radio (UWB), Bluetooth Low Energy (BLE), and Inertial Measurement Units (IMU). Sections on Data Fusion (DF) and Machine Learning (ML) have been included as well due to their key role in Indoor Positioning Systems (IPS). These technologies have been categorized based on the techniques that they employ and the associated errors in localization. A brief comparison between these technologies is made based on specific performance metrics. Finally, the limitations of these techniques are identified to aid future research. Full article

The integration of the physical and digital world has become increasingly important, and location-based services have become the most sought-after application in the field of the Internet of Things (IoT). This paper delves into the current research on ultra-wideband (UWB) indoor positioning systems (IPS). It begins by examining the most common wireless communication-based technologies for IPSs followed by a detailed explanation of UWB. Then, it presents an overview of the unique characteristics of UWB technology and the challenges still faced by the IPS implementation. Finally, the paper evaluates the advantages and limitations of using machine learning algorithms for UWB IPS. Full article

This paper presents a single-substrate microstrip rectenna for dedicated radio frequency energy harvesting applications. The proposed configuration of the rectenna circuit is composed of a clipart moon-shaped cut in order to improve the antenna impedance bandwidth. The curvature of the ground plane is modified with a simple U-shaped slot etched into it to improve the antenna bandwidth by changing the current distribution; therefore, this affects the inductance and capacitance embedded into the ground plane. The linear polarized ultra-wide bandwidth (UWB) antenna is achieved by using 50 Ω microstrip line and build on Roger 3003 substrate with an area of 32 × 31 mm². The operating bandwidth of the proposed UWB antenna extended from 3 GHz to 25 GHz at −6 dB reflection coefficient (VSWR ≤ 3) and extended from both 3.5 to 12 GHz, from 16 up to 22 GHz at −10 dB impedance bandwidth (VSWR ≤ 2). This was used to harvest RF energy from most of the wireless communication bands. In addition, the proposed antenna integrates with the rectifier circuit to create the rectenna system. Moreover, to implement the shunt half-wave rectifier (SHWR) circuit, a planar Ag/ZnO Schottky diode uses a diode area of 1 × 1 mm². The proposed diode is investigated and designed, and its S-parameter is measured for use in the circuit rectifier design. The proposed rectifier has a total area of 40 × 9 mm² and operates at different resonant frequencies, namely 3.5 GHz, 6 GHz, 8 GHz, 10 GHz and 18 GHz, with a good agreement between simulation and measurement. The maximum measured output DC voltage of the rectenna circuit is 600 mV with a maximum measured efficiency of 25% at 3.5 GHz, with an input power level of 0 dBm at a rectifier load of 300 Ω. Full article

The demand for high-speed wireless communication systems has led to the development of ultrawide-band (UWB) antennas with a compact size and high performance. In this paper, we propose a novel four-port multiple-input multiple-output (MIMO) antenna with an asymptote-shaped structure that overcomes the limitations of existing designs for UWB applications. The antenna elements are placed orthogonally to each other for polarization diversity, and each element features a stepped rectangular patch with a tapered microstrip feedline. The unique structure of the antenna significantly reduces its dimensions to 42 × 42 mm² ($0.43\lambda \times 0.43\lambda @ 3.09\mathrm{GHz}$), making it highly desirable for use in small wireless devices. To further enhance the antenna’s performance, we use two parasitic tapes on the ground plane at the back as decoupling structures between adjacent elements. The tapes are designed in a windmill shape and a rotating extended cross shape, respectively, to further improve the isolation. We fabricated and measured the proposed antenna design on a single-layer substrate (FR4) with a dielectric constant of 4.4 and a thickness of 1 mm. The measured results show that the impedance bandwidth of the antenna is 3.09–12 GHz, with an isolation of −16.4 dB, an envelope correlation coefficient (ECC) of 0.02, a diversity gain (DG) of 9.991 dB, an average total effective reflection coefficient (TARC) of −20 dB, an overall group delay value less than 1.4 ns, and a peak gain of 5.1 dBi. Although there may be some antennas that have better performance in one or two specific aspects, our proposed antenna has an excellent trade-off among all the antenna characteristics including bandwidth, size, and isolation. The proposed antenna also exhibits good quasi-omnidirectional radiation properties, making it well-suited for a range of emerging UWB-MIMO communication systems, particularly in small wireless devices. In summary, the compact size and ultrawide-band capabilities of the proposed MIMO antenna design, coupled with its improved performance compared to other recent UWB-MIMO designs, make it a promising candidate for 5G and next-generation wireless communication systems. Full article

This paper presents the development of a new complete wearable system for detecting breast tumors based on fully textile antenna-based sensors. The proposed sensor is compact and fully made of textiles so that it fits conformably and comfortably on the breasts with dimensions of 24 × 45 × 0.17 mm³ on a cotton substrate. The proposed antenna sensor is fed with a coplanar waveguide feed for easy integration with other systems. It realizes impedance bandwidth from 1.6 GHz up to 10 GHz at |S₁₁| ≤ −6 dB (VSWR ≤ 3) and from 1.8 to 2.4 GHz and from 4 up to 10 GHz at |S₁₁| ≤ −10 dB (VSWR ≤ 2). The proposed sensor acquires a low specific absorption rate (SAR) of 0.55 W/kg and 0.25 W/kg at 1g and 10 g, respectively, at 25 dBm power level over the operating band. Furthermore, the proposed system utilizes machine-learning algorithms (MLA) to differentiate between malignant tumor and benign breast tissues. Simulation examples have been recorded to verify and validate machine-learning algorithms in detecting tumors at different sizes of 10 mm and 20 mm, respectively. The classification accuracy reached 100% on the tested dataset when considering $\left|{\mathrm{S}}_{21}\right|$ parameter features. The proposed system is vision as a “Smart Bra” that is capable of providing an easy interface for women who require continuous breast monitoring in the comfort of their homes. Full article

In this paper, an effective technique for mutual coupling (MC) reduction between antenna elements of two multiple input multiple output (MIMO) microstrip patch antennas operating in the ultra-wide band (UWB) between 3.1 and 13.5 GHz is presented. The antenna array separation was kept at 44 mm for investigation, and the isolation was achieved through a modified electromagnetic band gap (MEBG) decoupling structure. The MEBG is embedded behind the radiating elements connected to the ground plane. HFSSv15 software was used to design and simulate the antenna. The effectiveness of the antenna and the MC reduction method was examined with and without the MEBG structure. The results revealed that the MC between the MIMO antenna elements was minimized when the MEBG structure was introduced. An MC of about −23 dB was obtained over the entire UWB frequency spectrum. This is more than a 10 dB improvement over the reference antenna (without the MEBG structure). Without limiting the effectiveness of the antenna when the MEBG structure was introduced, the results of the envelope correlation coefficient (ECC) gave the antenna a satisfactory diversity performance. The MEBG UWB MIMO antenna has an ECC less than 0.09 with a wide bandwidth. In addition, the total gain and the Voltage Standing Ware Ratio (VSWR) results were analyzed, which show that the performance of the antenna was not degraded while reducing the MC effect between the MIMO antenna elements. Full article

A compact four-port multiple-input multiple-output (MIMO) antenna for ultrawideband (UWB) applications is presented in this paper. The proposed antenna has four unit cell antennas. Each unit cell is placed orthogonal to its adjacent elements. The radiation element of each unit cell is composed of a cut semicircular patch and a stepped microstrip feed line. The whole ground on the back side consists of four parts of defective ground and their extended branches, which are connected through a “卍” structure. The main decoupling technology used in the MIMO antenna is polarization diversity. In addition, protruded ground and parasitic elements are added to achieve a higher isolation. This compact antenna has a small area of 45 mm × 45 mm and is printed on a single layer substrate (FR4) with an ε_r = 4.4 and a thickness of 1.6 mm. This antenna has an impedance bandwidth (S11 < −10 dB) of 3.1–13.1 GHz (123%) and an isolation of less than −17 dB. The envelope correction coefficient (ECC) is less than 0.02 and the average gain is 4 dBi. The ultrawide bandwidth and compact size of the proposed antenna make it a promising candidate for UWB applications. Full article

An ultrawide bandwidth (UWB) antenna for ground-penetrating radar (GPR) applications is designed to check soil moisture and provide good-quality images of metallic targets hidden in the soil. GPR is a promising technology for detecting and identifying buried objects, such as landmines, and investigating soil in terms of moisture content and contamination. A paddle-shaped microstrip antenna is created by cutting a rectangular patch at one of its diametrical edges fed by the coplanar waveguide technique. The antenna is loaded by stubs, shorting pins, and a split-ring resonator (SRR) metamaterial structure to increase the antenna’s gain and enhance the bandwidth (BW) towards both the lower and higher end of the working BW. The antenna’s performance in soil inspection is studied in terms of the operating frequency range, different types of soil, different distances (e.g., 50 cm) between the antenna arrays and soil, S-parameters, and gain. Following this, the antenna’s ability to find a metallic target in the soil is tested, considering different array numbers, multi-targets, and locations. The antenna is designed on a thin layer of economic polytetrafluoroethylene (PTFE) substrate with dimensions 50 × 39 × 0.508 mm³ and works in the frequency range 1.9–9.2 GHz. In addition, two more resonances at 0.9 and 1.8 GHz are also achieved; hence, the antenna works for more than two application bands, such as the ISM- and L-bands. The measurement results validated excellent agreement with the simulated results. Furthermore, the recommended antenna offering a high gain of about 10.8 dBi and maximum efficiency above 97% proved able to discriminate between hidden objects and even recognize their shapes. Moreover, the reconstructed images show that the antenna can detect an object in the soil at any location. Full article
