In the field of nondestructive evaluation (NDE) using ultrasonic guided waves, accurately assessing the aging failure of insulation coatings remains a challenging and prominent research topic. While the application of ultrasonic guided waves in material testing has been extensively explored in the existing literature, there is still a significant gap in quantitatively evaluating the aging failure of insulation coatings. This study innovatively proposes an NDE method for assessing insulation coating aging failure by integrating signal processing and machine learning technologies, thereby effectively addressing both theoretical and practical gaps in this domain. The proposed method not only enhances the accuracy of detecting insulation coating aging failure but also introduces new approaches to non-destructive testing technology in related fields. To achieve this, an accelerated aging experiment was conducted to construct a cable database encompassing various degrees of damage. The effects of aging time, temperature, mechanical stress, and preset defects on coating degradation were systematically investigated. Experimental results indicate that aging time exhibits a three-stage nonlinear evolution pattern, with 50 days marking the critical inflection point for damage accumulation. Temperature significantly influences coating damage, with 130 °C identified as the critical threshold for performance mutation. Aging at 160 °C for 100 days conforms to the time-temperature superposition principle. Additionally, mechanical stress concentration accelerates coating failure when the bending angle is ≥90°. Among preset defects, cut defects were most destructive, increasing crack density by 5.8 times compared to defect-free samples and reducing cable life to 40% of its original value. This study employs Hilbert–Huang Transform (HHT) for noise reduction in ultrasonic guided wave signals. Compared to Fast Fourier Transform (FFT), HHT demonstrates superior performance in feature extraction from ultrasonic guided wave signals. By combining HHT with machine learning techniques, we developed a hybrid prediction model—HHT-LightGBM-PSO-SVM. The model achieved prediction accuracies of 94.05% on the training set and 88.36% on the test set, significantly outperforming models constructed with unclassified data. The LightGBM classification model exhibited the highest classification accuracy and AUC value (0.94), highlighting its effectiveness in predicting coating aging damage. This research not only improves the accuracy of detecting insulation coating aging failure but also provides a novel technical means for aviation cable health monitoring. Furthermore, it offers theoretical support and practical references for nondestructive testing and life prediction of complex systems. Future studies will focus on optimizing model parameters, incorporating additional environmental factors such as humidity and vibration to enhance prediction accuracy, and exploring lightweight algorithms for real-time monitoring. Full article

This work presents two types of ultrasonic vibrators in order to comparatively analyze their dust removal properties for microscopic particles. The vibrators were constructed by pasting four piezoceramic (PZT) plates onto the upper surface of a rectangular metal substrate. The longitudinal or bending mode is excited to form a standing wave in the vibrators. The superposition of the longitudinal and bending modes generates a traveling wave. Because the bending and longitudinal vibrations are two different modes, the process of tuning their resonant frequencies to be close is necessary for the traveling wave vibrator. The structural parameters of the vibrators were optimized by the finite element method. During experiments, the dust removal performances of these vibrators were evaluated by dumping cigarette ash or alumina powders randomly on the surface of the prototype vibrators. The measured experimental results indicate that the dust removal performance of the traveling wave oscillator is better than that of the standing wave oscillator. The two operating modes of the traveling wave vibrator produce orthogonal vibration displacements on the vibrator driving points. Vibration in one direction generates friction force, which drives adherent dust particles. Vibration in the other direction provides intermittent contact pressure between the vibrators and deposited dust particles. The synthesized elliptical motion of vibrator particles helps to improve the dust removal characteristics of the vibrators. The simple structure of the developed vibrators makes them the most promising candidates for dust removal from engines, camera lenses, car windows, and navigation systems. Full article

In this paper, the potential of directional ultrasonic wave superposition by moving sound generators for laser beam welding of high-strength steel alloys 1.5528 (22MnB5) is studied. Steel sheets of identical thickness and in form of tailored blanks were joined in butt joint configuration. The influences of the various excitation parameters of the moving sound generators on the ultrasonic coupling and their influence on the distribution of the AlSi coating components within the melting zone and the weld seam characteristics are investigated. Etched cross-sections, scanning electron microscopy, energy dispersive X-ray spectroscopy, and electron backscattering measurements were used as the investigation methods to determine the AlSi distribution in the weld as well as its microstructure. The results presented a series of experiments which show that a suitable superposition of ultrasonic waves by the moving sound generators lead to a more homogeneous distribution of AlSi particles in the melt as well as to a finer microstructure within the weld, which improves the mechanical–technological properties. Full article

Ultrasonic testing of polycrystalline media relies heavily on simulation of the expected signals in order to detect and correctly interpret deviations due to defects. Many effects disturb ultrasonic waves propagating in polycrystalline media. One of them is scattering due to the granular microstructure of the polycrystal. The thus arising so-called microstructural noise changes with grain size distribution and testing frequency. Here, a method for simulating this noise is introduced. We geometrically model the granular microstructure to determine its influence on the backscattered ultrasonic signal. To this end, we utilize Laguerre tessellations generated by random sphere packings dividing space into convex polytopes—the cells. The cells represent grains in a real polycrystal. Cells are characterized by their volume and act as single scatterers. We compute scattering coefficients cellwise by the Born approximation. We then combine the Generalized Point Source Superposition technique with the backscattered contributions resulting from the cell structure to compute the backscattered ultrasonic signal. Applying this new methodology, we compute the backscattered signals in a pulse-echo experiment for a coarse grain cubic crystallized Inconel-617 and a fine grain hexagonal crystallized titanium. Fitting random Laguerre tessellations to the observed grain structure allows for simulating within multiple realizations of the proposed model and thus to study the variation of the backscattered signal due to microstructural variation. Full article

This paper presents a disc-type ultrasonic piezoelectric motor, which is designed for micro flying vehicles. It provides a high output rotation speed under low operating voltage, compared with common piezoelectric devices, by employing a “contact teeth” wave transmission structure. The ultrasonic motor (USM) consists of a trimorph disc stator, with triple internal contact teeth, a shaft and two hemispheric hard-wearing rotors. The operating principle of the USM is based on the superposition of the in-plane B₀₃ vibration mode of the trimorph disc, and the first longitudinal vibration of the contact teeth. An optimization method of the stator structure parameters was proposed and validated by numerical modeling. The diameter and thickness of the stator are 20 mm and 1 mm, respectively. A prototype with the weight of 2 g was made for this experimental test. The optimal frequency of the excitation signal and the preload force are 98.5 kHz and 0.5 N, respectively. The minimum operating voltage was tested under 7.5 V and reached the speed of 225 rpm, and the maximum unloaded rotational speed of the USM reached 5172 rpm when 30 V driving voltage was applied. The maximum lifting force generated by this USM was measured as 46.1 mN, which is 2.35 times bigger than its weight. Full article

The scattering of surface waves by a three-dimensional shallow cavity of arbitrary shape at the surface of a homogenous, isotropic, linearly elastic half-space is theoretically investigated. A novel analytical approach based on a reciprocity consideration is introduced in this article to determine the particle displacements of the scattered wave field generated by the interaction between the surface waves and the cavity. In the usual manner, the scattered field was shown to be equivalent to the radiation from the distribution of tractions, calculated from the incident wave, on the surface of the cavity. The radiation of surface waves subjected to the computed tractions applied at a single location was found using reciprocity theorems. The field scattered by the cavity was subsequently obtained from the superposition of displacements due to all the forces applied on the cavity surface. Solutions for the scattering of surface waves by a spherical, a circular cylindrical (coin-shaped) and a square cylindrical cavity are presented in detail. We here derive the closed-form expressions of the displacement amplitudes, which represent the far-field scattered waves produced by each of the cavities. An experimental setup using the ultrasonic pulse-echo technique was then carried out to record the scattered echoes of surface waves from these cavities in order to provide practical validation of the analytical findings. The vertical displacements measured at a significant distance of about twenty-five wavelengths from the cavities of the same width and different depth were compared with the corresponding theoretical predictions. The comparisons show excellent agreement for the case of a spherical cavity and good agreement in the cases of a circular and a cylindrical cavity in terms of trends and magnitudes. It is followed by a discussion on the results of the comparison and the limitations of the proposed approach regarding the degree of smoothness and the size of cavity. Full article

As ultrasonic wave field radiated by an ultrasonic transducer influences the results of ultrasonic nondestructive testing, simulation and emulation are widely used in nondestructive testing. In this paper, a simulation study is proposed to detect defects in a circular tube material. Firstly, the ultrasonic propagation behavior was analyzed, and a formulation of the Multi-Gaussian beam model (MGB) based on a superposition of Gaussian beams is described. The expression of the acoustic field from a linear phased-array ultrasonic transducer in the condition of a convex interface on the circular tube material is proposed. Secondly, in order to make the tapered probe wedge better fit the curved circular tube material and carry out the ultrasonic inspection of the curved surface, it was necessary to pare the angle probe wedge. Finally, acoustic field simulations in a circular tube were carried out and analyzed. The simulation results indicated that the method of ultrasonic phased-array inspection is feasible in circular tube testing. Tube materials with different curvatures need different array element lengths and widths to get the desired focused beam. Full article

Ultrasonic Lamb wave testing has been successfully applied in nondestructive testing. However, because of Lamb wave multimodal and dispersion characteristics, the received signals are often multimodal and overlapping, which makes them very complicated. This paper proposes a mode separation method by combining dispersion compensation with the independent component analysis of fourth-order cumulant. Taking two-mode overlapped signals as an example, the single-mode dispersion compensation is performed according to the measured distance difference between the two sets of signals. The two sets of signals are returned to the same distance. The fourth-order cumulant independent component analysis method is further used to process the Lamb wave signals of different superposition situations at the same distance. The corresponding mode signal contained in the two sets of signals is separated through the joint diagonalization of the whitened fourth-order cumulant matrix. The different modes are compensated and separated successively, achieving the multimodal signal separation. Experimental results in steel plates show that the presented method can accurately achieve mode separation for the multimodal overlapping Lamb waves. This is helpful for the signal processing of multimodal Lamb waves. Full article

This research put forward an exogenous liquid level measurement method based on continuous sound wave amplitude. The distribution of round piston transducers in the sound field of a metal solid was analyzed by building 15 Multi-Gaussian Beam superposition models; the calculation method for echo sound pressure was worked out according to the reflection and refraction properties of ultrasonic wave. The continuous wave with three amplitudes was used as the driving source of ultrasonic sensor, and two single-crystal sensors with the same diameter were used as the transmitting terminal and receiving terminal of ultrasonic waves to carry out experiments for four groups of containers of different wall thickness and to compare the characteristics of echo energy of driving sources with three amplitudes above and below the liquid levels with different wall thickness. Two groups of sensors of different diameters were used to measure the liquid levels of experimental models, and the measuring errors of the two groups of sensors were analyzed and compared. The experimental result shows that the measuring error of the model is less than 5 mm, so it is applicable to the level measurement of liquids or liquid mixtures in many sectors. Full article
