Tunnel excavation typically induces disturbance to the surrounding soil. Advance grouting using small-diameter pipes can effectively mitigate surface settlement. Taking the mine-method tunnel at the southern end of Xiancun Station on Guangzhou Rail Transit Line 18 as the research object, this paper uses the Midas GTS NX three-dimensional finite element (FE) software and adopts the upper-lower excavation method that prioritizes the formation of an upper support closed loop to simulate and analyze the impact of the CRD method on tunnel excavation under different grouting layer thicknesses. The research indicates that the surface settlement curve exhibits a “U”-shape. The settlement value decreases as the thickness of the grouting layer increases; when the thickness increases from 1.2 m to 2.0 m, the maximum surface settlement decreases from 12.87 mm to 9.09 mm, with successive reductions of 1.30 mm, 1.11 mm, 0.81 mm, and 0.56 mm, corresponding to rates of 10.10%, 9.59%, 7.67%, and 5.6%. Increasing the thickness of the grouting layer can effectively control surface settlement; however, when the thickness reaches 2.0 m, the stress distribution undergoes a change. Specifically, the compressive stress at the arch waist increases to 1683.01 kPa, and plastic failure occurs in the surrounding rock. By comparing the numerical results with field monitoring data, it is determined that when the grouting layer thickness is 1.4 m and the elastic modulus is increased by 30% based on that of the upper-soft soil, the model prediction shows the highest consistency with the actual effect. Furthermore, it is suggested that the grouting layer thickness be increased to 1.6 m. This study delivers a scientific foundation for the design of grouting parameters and the optimization of construction schemes for tunnels in composite strata and is of importance to improving tunnel construction technology in underground rail transit. Full article

Taking a completely stacked section of Beijing Metro Line 22 as the research background, a three-dimensional finite element model was established to study and analyze the displacement and stress variation laws of the existing lower tunnel under different working conditions. The results show that the combined reinforcement measures of radial grouting and trolley support can effectively reduce the adverse effects of the upper tunnel on the lower tunnel during the construction of the overlapping tunnel. It cut the vault vertical displacement from 5.31 mm to 2.67 mm and reduced the stress range from 2.30 MPa to 0.71 MPa, reducing vertical displacement by 50% and maximum principal stress changes by 40% compared to the unreinforced condition. Furthermore, a parametric study indicated an optimal grouting scheme with a 2 m thickness, 120° angle, and 200 MPa modulus, which achieved similar reinforcement effectiveness with a 50% reduction in grout volume. Full article

As Earth Pressure Balance (EPB) shield machine crossed with steep slopes beneath an existing highway in sandstone–mudstone alternating strata, case studies of changes in vertical displacement, settlement trough evolution, and tunnel stress induced by shield tunnel construction were investigated. The quality of synchronous grouting was evaluated using ground penetrating radar (GPR) technology. The results showed that highway settlement could be categorized into four stages: initial settlement, uplift, secondary settlement, and stabilization. The secondary settlement caused by shield tail detachment was significantly greater than the initial settlement induced by distant shield construction. The settlement trough evolved throughout construction; the maximum settlement point shifted from the tunnel centerline but it consistently remained within 3 m. During the early phase of shield tail detachment, the circumferential stress of shield tunnel changed rapidly. The circumferential stress was primarily compressive, tensile stress was observed at some monitoring points. The tensile stress at the monitoring points gradually transitioned to compressive stress. After the tunnel undercrossed, the circumferential stress gradually stabilized. The GPR detection revealed that in groundwater-rich strata, poor grouting quality areas were prone to appear at the tunnel crown, while grouting quality in other areas performed better. This engineering case can serve as a positive reference for similar EPB shield tunnels passing in close proximity beneath existing highways. Full article

The long-term stability of grout-reinforced fractured rock masses in acidic groundwater environments after tunnel fires is critical for the safe operation of underground engineering. In this study, grouting reinforcement tests were performed on fractured diorite specimens using a high-strength fast-anchoring agent (HSFAA), and their mechanical degradation and microstructural evolution mechanisms were investigated under coupled high-temperature (25–1000 °C) and acidic corrosion (pH = 2) conditions. Multi-scale characterization techniques, including uniaxial compression strength (UCS) tests, X-ray computed tomography (CT), scanning electron microscopy (SEM), three-dimensional (3D) topographic scanning, and X-ray diffraction (XRD), were employed systematically. The results indicated that the synergistic thermo-acid interaction accelerated mineral dissolution and induced structural reorganization, resulting in surface whitening of specimens and decomposition of HSFAA hydration products. Increasing the prefabricated fracture angles (0–60°) amplified stress concentration at the grout–rock interface, resulting in a reduction of up to 69.46% in the peak strength of the specimens subjected to acid corrosion at 1000 °C. Acidic corrosion suppressed brittle disintegration observed in the uncorroded specimens at lower temperature (25–600 °C) by promoting energy dissipation through non-uniform notch formation, thereby shifting the failure modes from shear-dominated to tensile-shear hybrid modes. Quantitative CT analysis revealed a 34.64% reduction in crack volume (V_ca) for 1000 °C acid-corroded specimens compared to the control specimens at 25 °C. This reduction was attributed to high-temperature-induced ductility, which transformed macroscale crack propagation into microscale coalescence. These findings provide critical insights for assessing the durability of grouting reinforcement in post-fire tunnel rehabilitation and predicting the long-term stability of underground structures in chemically aggressive environments. Full article

This study evaluates adhesive bolts (chemical anchors) bonded with epoxy and vinyl ester resins for surface and tunnel excavations in tropical mining environments under static and dynamic loading. Over 300 pull-out tests in concrete and hard rock examined the effects of bolt length, curing time, and substrate condition on load capacity, failure mode, and bond–slip response. Epoxy anchors exhibited higher bond strength, including under early-age and thermally active conditions, while vinyl ester showed improved ductility and post-peak behaviour in fractured rock. Numerical modelling with Rocscience RS2 (Phase 2) and Unwedge simulated excavation responses for bolt lengths of 190–250 mm and spacings of 0.5–2.0 m. Tensile failure dominated at wider spacings, whereas closely spaced anchors enhanced confinement and redistributed stresses. The combined experimental–numerical evidence quantifies chemical-anchor performance in complex subsurface settings and supports their use for early-age support and long-term stability. Findings motivate integration of resin-grouted bolts into modern support designs, particularly in seismically sensitive or hydrothermally variable mines. Full article

Grouting-reinforced crushed rock is widely used for stability control in tunneling and deep mining, yet the coupled influence of particle size, curing time, grouting pressure, and clay content on post-grouting mechanical behavior remains insufficiently quantified. This study investigates the uniaxial compressive response and energy-evolution characteristics of grouting-reinforced crushed quartz sandstone under a multi-factor experimental program. Using a custom test setup and standardized loading protocol, stress–strain responses were recorded and decomposed into elastic-strain energy and dissipated energy to interpret the failure evolution. Results reveal systematic trends and interactions among the four factors in terms of strength, stiffness, and energy evolution, demonstrating that energy-based indices provide a robust lens for interpreting failure processes in grouting-reinforced crushed rock. These findings offer practical insights for optimizing grouting parameters for construction and post-grouting stability assessment in underground engineering. Full article

Tunneling in fractured zones significantly affects surface and building deformation. This paper investigates the deformation of overlying buildings and the surrounding ground induced by multi-line TBM tunneling in fractured zones of the Qingdao Metro, combining a 3D physical model test, numerical simulations, and field monitoring to analyze the evolution of settlement and structural responses. The results show that settlement induced by TBM excavation peaks at the center and diminishes laterally, with amplified differential settlement and building torsion near fractured zones. Comparative analyses of reinforcement strategies indicate that crown grouting is the most effective in reducing deformation. Sensitivity analysis further indicates that tunnel depth, grouting pressure, and building–tunnel relative position are the dominant factors influencing building settlement. The findings provide practical guidance for similar projects in complex geological conditions and contribute to deformation control in underground works. Full article

For tunnels constructed in a single direction, the pipe roof at the tunnel exit portal can be installed either as Outside-to-Inside advanced support arrangements (Out–In ASA) or Inside-to-Outside advanced support arrangements (In–Out ASA). To investigate the pipe roof’s mechanical behavior and deformation characteristics under two excavation methods, this study establishes Pasternak two-parameter elastic foundation beam models for the pipe roof. Corresponding boundary conditions are proposed for each support configuration, and the governing differential equation for pipe roof deflection is derived and solved. The Hanjiashan Tunnel is used as an engineering case study to validate the theoretical results by comparing them with field monitoring data. A comparative analysis and parametric sensitivity study are then conducted for the two construction methods. The results show that theoretical predictions align well with the field measurements, confirming the validity of the proposed model. This study proposed calculation parameters for the Hanjiashan Tunnel. Under this circumstance, the method of Out–In ASA has been proven to offer improved structural performance and safety when the tunnel face is close to the portal. Moreover, the timely installation of the initial support and the strong bearing capacity of the surrounding rock can further reduce pipe roof deformation near the tunnel exit. Therefore, the Out–In ASA method is recommended for single-direction tunnel excavation. If the method of Out–In ASA is not feasible due to site constraints, the method of In–Out ASA can be adopted, while early support and effective grouting should be guaranteed to ensure control of excessive deformation. The findings of this study can provide a theoretical reference for the construction of tunnel portals in single-direction excavation. Full article

To investigate the safety risks associated with gas tunnel coal uncovering, a physical and mechanical model of the critical safety rock pillar is proposed through a combination of theoretical analysis, numerical simulation, and field testing. Based on the principles of energy conservation and catastrophe theory, an expression for calculating the critical safety for rock pillar thickness is derived. The effects of tunnel radius, burial depth, axial stress, coal seam dip angle, and gas pressure on the critical thickness are systematically analyzed. The results indicate that the critical safety of rock pillar thickness increases with the tunnel radius, burial depth, gas pressure, and axial stress. Moreover, as the tunnel radius increases, the growth rate of the critical thickness also increases. Conversely, as the burial depth increases, the growth rate of the critical thickness decreases. For gas pressure and axial stress, the growth rate remains relatively constant. Using a tunnel project in Hunan as a case study, theoretical analysis yields a critical safety rock pillar thickness of 3.95 m. A corresponding numerical model is developed to simulate this scenario, and the simulation results align well with the theoretical predictions. Based on these findings, a combined treatment scheme of “advanced small-pipe grouting + gas drainage and pressure relief” is proposed for excavation upon reaching the critical rock pillar thickness. This scheme successfully ensures safe tunnel passage through the coal seam. Full article

Polyurethane grouting materials are polymer materials formed through the reaction of polyisocyanates and polyols. They play important roles in underground engineering, tunnel construction, and mining due to their fast reaction rate, high bonding strength, and excellent impermeability. However, traditional polyurethane grouting materials have shortcomings such as high reaction heat release, high brittleness, and poor flame retardancy, which limit their applications in high-demand engineering projects. This paper systematically reviews the research progress on modified polyurethane grouting materials. Four major modification technologies are summarized: temperature reduction modification, flame retardant modification, mechanical enhancement, and environmental adaptability improvement. A multi-dimensional performance characterization system is established, covering slurry properties, solidified body performance, microstructure characteristics, thermal properties and flame retardancy, diffusion grouting performance, and environmental adaptability. The application effects of modified polyurethane grouting materials in grouting reinforcement, grouting water plugging, and grouting lifting are analyzed. Future development directions are projected. This review is particularly valuable for researchers and engineers working in tunneling, mining, geotechnical engineering, and infrastructure rehabilitation. Full article

With the increasing demand for urban rail transit capacity, shield tunneling has become the predominant method for constructing underground metro systems in densely populated cities. However, the spatial interaction between shield tunnels and adjacent retaining structures poses significant engineering challenges, potentially leading to excessive ground settlement, structural deformation, and even stability failure. This study systematically investigates the deformation behavior and associated risks of retaining systems during adjacent shield tunnel construction. An orthogonal multi-factor analysis was conducted to evaluate the effects of grouting pressure, grout stiffness, and overlying soil properties on maximum surface settlement. Results show that soil cohesion and grouting pressure are the most influential parameters, jointly accounting for over 72% of the variance in settlement response. Based on the numerical findings, a Bayesian network model was developed to assess construction risk, integrating expert judgment and field monitoring data to quantify the conditional probability of deformation-induced failure. The model identifies key risk sources such as geological variability, groundwater instability, shield steering correction, segmental lining quality, and site construction management. Furthermore, the effectiveness and cost-efficiency of various grouting reinforcement strategies were evaluated. The results show that top grouting increases the reinforcement efficiency to 34.7%, offering the best performance in terms of both settlement control and economic benefit. Sidewall grouting yields an efficiency of approximately 30.2%, while invert grouting shows limited effectiveness, with an efficiency of only 11.6%, making it the least favorable option in terms of both technical and economic considerations. This research provides both practical guidance and theoretical insight for risk-informed shield tunneling design and management in complex urban environments. Full article

Synchronous grouting slurry is widely used in shield tunnel construction to fill the gaps between stratum and shield tail segments. However, as grout is nearly liquid in the initial stages, the tunnel lining segments recently separated from the shield tail are easily affected by the upward buoyancy generated by grout, causing issues such as longitudinal misalignment and opening of ring joints. Therefore, studying the upward buoyancy characteristics of synchronous grout is crucial. In this study, floating characterisation parameters of grout were investigated using buoyancy model tests, orthogonal tests, and comprehensive tests. The floating characterisation parameters are affected by distribution ratio and types of each grout component. The relationship between the floating characterisation parameters of grout and buoyancy was established. The results show that density, flow index, and shear strength can be used as the floating characterisation parameters. Binder–sand and water–binder ratios have the largest impact on the density. The bentonite–water ratio exerts a primary influence on the flow index, while the water–binder ratio contributes a secondary effect. In addition, bentonite–water and binder–sand ratios have the greatest effect on the shear strength. Furthermore, the particle size of sand and type of bentonite considerably influence the flow index and shear strength. A high-shear grout using well-graded fine sand and a high mesh of sodium bentonite was considered in this study. When the content of bentonite exceeds 7% (P2.2), Archimedes’ law is not applicable for calculating the upward buoyancy of grout. Buoyancy supply rate exhibits gradual enhancement with flow index elevation, yet with diminishing growth rates. Full article

Tunneling in structurally complex, tectonically active regions such as southwest China poses significant environmental risks to groundwater, especially in heterogeneous karst fault systems where conventional prediction methods often fail. This study innovatively coupled MODFLOW’s STREAM package (for simulating karst conduit networks) and DRAIN package (for tunnel inflow prediction) within a 3D groundwater model to assess hydrogeological impacts in complex mountainous terrain. The simulations show that an uncased tunnel lining causes significant groundwater changes under natural conditions, with predicted inflows reaching 34,736 m³/d. Conventional cement grouting (permeability: 1 × 10⁻⁵ cm/s; thickness: 10 m) mitigates the effects considerably and reduces the inflows in the tunnel sections by 27–97%. Microfine cement grouting (5 × 10⁻⁶ cm/s; 10 m thickness) further improves performance by achieving a 49–98% reduction in inflows and limiting the reduction in spring discharge to ≤13.28%. These results establish a valid theoretical framework for predicting groundwater impacts in heterogeneous terrain and demonstrate that targeted seepage control—particularly grouting with microfine cement—effectively protects groundwater-dependent ecosystems during infrastructure development. Full article

The deformation characteristics of the surrounding rock in tunnel groups are considered critical for the design of support structures and the assurance of the long-term safety of deep-buried diversion tunnels. The deformation behavior of surrounding rock in tunnel groups was investigated to guide structural support design. Field tests and numerical simulations were performed to analyze the distribution of ground stress and the ground reaction curve under varying conditions, including rock type, tunnel spacing, and burial depth. A solid unit–structural unit coupled simulation approach was adopted to derive the two-liner support characteristic curve and to examine the propagation behavior of concrete cracks. The influences of surrounding rock strength, reinforcement ratio, and secondary lining thickness on the bearing capacity of the secondary lining were systematically evaluated. The following findings were obtained: (1) The tunnel group effect was found to be negligible when the spacing (D) was ≥65 m and the burial depth was 1600 m. (2) Both P_0.3 and P_max of the secondary lining increased linearly with reinforcement ratio and thickness. (3) For surrounding rock of grade III (IV), 95% u_lim and 90% u_lim were found to be optimal support timings, with secondary lining forces remaining well below the cracking stress during construction. (4) For surrounding rock of grade V in tunnels with a burial depth of 200 m, 90% u_lim is recommended as the initial support timing. Support timings for tunnels with burial depths between 400 m and 800 m are 40 cm, 50 cm, and 60 cm, respectively. Design parameters should be adjusted based on grouting effects and monitoring data. Additional reinforcement is recommended for tunnels with burial depths between 1000 m and 2000 m to improve bearing capacity, with measures to enhance impermeability and reduce external water pressure. These findings contribute to the safe and reliable design of support structures for deep-buried diversion tunnels, providing technical support for design optimization and long-term operation. Full article

Pea-gravel grouting, which fills the gap between the lining of tunnels and the surrounding rock, is crucial for the structural stability and waterproofing of water delivery TBM tunnels. However, it is prone to defects due to complex construction conditions and geological factors. To provide practical insights for engineers to evaluate grouting quality and take appropriate remedial action during TBM tunnel construction, this paper assesses four types of pea-gravel grouting defects, including local cavities, less density, rich rock powder and rich cement slurry. Detailed numerical simulation models comprising segment lining, pea-gravel grouting and surrounding rock were built using the 3D finite element method to analyze the displacement and stress of the segments at the transition zone between different classes of surrounding rocks, labeled V–IV, V–III and IV–III. The results indicate that a local cavity defect has the greatest impact on the loading response of segment lining, followed by less density, rich rock powder and rich cement slurry defects. Their impact will weaken with better self-support of the surrounding rocks in the order of V–IV, V–III and IV–III. The tensile stress of segment lining is within the limit of concrete cracking for combinations of all four defects when the surrounding rock is of the class IV–III, and it is within this limit for two-defect combinations when the surrounding rock is of classes V–III and V–IV. When three defects or all four defects are present in the pea-gravel grouting, the possibility of segment concrete cracking increases from the transition zone of class V–III surrounding rock to the transition zone of class V–IV surrounding rock. Full article
