This paper presents the design, fabrication, calibration, and comprehensive characterization of a homemade tri-axial fluxgate magnetometer. The magnetometer, utilizing a ring core configuration, was developed to measure ultra-low magnetic fields with high sensitivity and stability. Critical stages from material selection to sensor geometry optimization are discussed in detail. A series of critical characterization processes were conducted, including zero-field voltage determination, scale factor calculation, resolution measurement, noise analysis, bias assessment, cross-field effect evaluation, temperature dependency, and bandwidth determination. The sensor demonstrated a minimum detectable magnetic field resolution of 2.2 nT with a noise level of 1.1 nT/√Hz at 1 Hz. Temperature dependency tests revealed minimal impact on sensor output with a maximum shift of 120 nT in the range of 60 °C, which was effectively compensated through calibration to less than 5 nT. Additionally, the paper introduces a model function in matrix form to relate the magnetometer’s output voltage to the measured magnetic field, incorporating temperature dependency and cross-field effects. This work highlights the importance of meticulous calibration and optimization in developing fluxgate magnetometers suitable for various applications, from space exploration to biomedical diagnostics. Full article

Robust robot manipulation hinges on effective state estimation. The VRT 6 robot leverages an inertia measurement unit with triaxial gyroscopes, magnetometers, and accelerometers, as well as a position sensor, but these sensors are plagued by noise that demands rigorous filtering. To tackle this, an adaptively scaled unscented Kalman filter was employed. The filter’s scaling parameter was meticulously optimized using density- and moment-based techniques, as both system properties and estimated state impact this crucial parameter. A Maximum Likelihood Estimation (ML) substantiates the enhanced quality of the estimated velocity and acceleration, on par with the position estimate. Minimizing measurement prediction error (MMPE) also shows better results with less RMSE when compared to fixed-kappa values, and the quality of position estimates is higher with the increase in the domain of the scaling parameter. By carefully selecting the adaptive scaling parameters’ range to minimize sigma point weights and ensure the positive definiteness of the covariance matrix, this enhanced UKF method achieved markedly superior state estimates compared to standard UKF implementations. Full article

To address the measurement accuracy degradation of triaxial magnetometers caused by manufacturing errors and environmental interference, and the limited robustness of traditional calibration methods, this study proposes a Dynamic Hierarchical Elite-guided Particle Swarm Optimization (DHEPSO)-based ellipsoid fitting algorithm. First, an error model for the triaxial magnetometers is established. Next, the DHEPSO algorithm is utilized to fit the ellipsoid parameters by integrating a dynamic hierarchical mechanism, elite guidance strategy, and adaptive inertia weight adjustment, thereby balancing global exploration and local exploitation to efficiently optimize the parameters. Finally, error compensation and precise calibration are achieved using the optimized parameters. The simulation results show that, compared to the Least Squares Method (LSM), it reduces the absolute distance between the simulated data and the ellipsoid by 63.10% and the post-calibration total magnetic field intensity standard deviation by 60% under outlier interference. Against the traditional PSO, TSLPSO, MPSO, and AWPSO, DHEPSO achieves total distance reductions of 48.52%, 47.74%, 56.71%, and 33.09%, respectively, with faster convergence. The statistical analysis of 60 trials confirms DHEPSO’s stability, exhibiting lower median error and interquartile range. The results validate DHEPSO’s high precision and robustness in high-noise environments, offering theoretical support for engineering applications. Full article

The accuracy of a magnetic gradient tensor (MGT) measured by tri-axial magnetometer cross arrays (TAMCAs) is compromised by inherent errors in individual tri-axial magnetometers (TAMs) and inter-sensor misalignment angles (MAs), both of which degrade the resultant MGT data quality. This paper proposes a novel lossless scalar calibration algorithm that eliminates mathematical approximations while tracking the fluctuation of the reference magnetic intensity (MI). The calibration algorithm is developed to improve TAMCAs’ measurement precision; however it is difficult to provide a completely accurate MGT by experiments. Therefore, we have designed a kind of validation experiment based on a constrained Euler localization to demonstrate the effectiveness of the calibration algorithm. The fundamental principles of the proposed lossless scalar calibration methodology are systematically presented, accompanied by a numerical analysis of relative errors calibrating TAMCA parameters. Key influencing factors are carefully investigated, including the TAM noise level quantified by standard deviation (STD), calibration dataset size, and STD of reference MI fluctuations. In the experiments, to validate the effectiveness of calibrating TAMCAs composed of four fluxgate TAMs (FTAMs), we measured the true geo-MI using a proton magnetometer and regarded an energized circular coil as the alternating current (AC) magnetic source of the constrained Euler localization, respectively. The results indicated that the lossless scalar calibration algorithm significantly improves the measurement accuracy of the geo-MI of the calibration site and MGT of the energized coil. Full article

Introduction: Gait analysis is a vital tool in the assessment of human movement and has been widely used in clinical settings to identify potential abnormalities in individuals. However, there is a lack of consensus on the normative values for gait metrics in large populations. The primary objective of this study is to establish a normative database of spatiotemporal gait metrics across various age groups, contributing to a broader understanding of human gait dynamics. By doing so, we aim to enhance the clinical utility of gait analysis in diagnosing and managing health conditions. Methods: We conducted an observational case–control study involving 313 healthy participants. The MetaMotionC IMU by Mbientlab Inc., equipped with a triaxial accelerometer, gyroscope, and magnetometer, was used to capture gait data. The IMU was placed at the sternal angle of each participant to ensure optimal data capture during a 50 m walk along a flat, unobstructed pathway. Data were collected through a Bluetooth connection to a smartphone running a custom-developed application and subsequently analysed using IMUGaitPY, a specialised version of the GaitPY Python package. Results: The data showed that gait speeds decrease with ageing for males and females. The fastest gait speed is observed in the 41–50 age group at $1.35\pm 0.23\mathrm{m}/\mathrm{s}$. Males consistently exhibit faster gait speeds than females across all age groups. Step length and cadence do not have clear trends with ageing. Gait speed and step length increase consistently with height, with the tallest group (191–200 cm) walking at an average speed of $1.49\pm 0.12\mathrm{m}/\mathrm{s}$, with an average step length of $0.91\pm 0.05\mathrm{m}$. Cadence, however, decreases with increasing height, with the tallest group taking $103.52\pm 5.04\mathrm{s}\mathrm{t}\mathrm{e}\mathrm{p}\mathrm{s}/\mathrm{m}\mathrm{i}\mathrm{n}$ on average. Conclusions: This study has established a comprehensive normative database for the spatiotemporal gait metrics of gait speed, step length, and cadence, highlighting the complexities of gait dynamics across age and sex groups and the influence of height. Our findings offer valuable reference points for clinicians to distinguish between healthy and pathological gait patterns, facilitating early detection and intervention for gait-related disorders. Moreover, this database enhances the clinical utility of gait analysis, supporting more objective diagnoses and assessments of therapeutic interventions. The normative database provides a valuable reference future research and clinical practice. It enables a more nuanced understanding of how gait evolves with age, gender, and physical stature, thus informing the development of targeted interventions to maintain mobility and prevent falls in older adults. Despite potential selection bias and the cross-sectional nature of the study, the insights gained provide a solid foundation for further longitudinal studies and diverse sampling to validate and expand upon these findings. Full article

In the past few decades, there has been a notable technological advancement in geophysical sensors. In the case of magnetometry, several sensors were used, having the common feature of being miniaturized and lightweight, thus idoneous to be carried by UAVs in drone-borne magnetometric surveys. A common feature is that their sensitivity ranges from 0.1 to about 200 nT, thus not comparable to that of optically pumped, standard fluxgate or even proton magnetometers. However, their low cost, volume and weight remain very interesting features of these sensors. In fact, such sensors have the common feature of being very inexpensive, so new ways of making surveys using many of these sensors could be devised, in addition to the possibility, even with limited resources, of creating gradiometers by combining two or more of them. In this paper, we explore the range of applicability of small tri-axial magnetometers commonly used for attitude determination in several devices. We compare the results of surveys performed with standard professional geophysical instruments with those obtained using these sensors and find that in the presence of strongly magnetized sources, they succeeded in identifying the main anomalies. Full article

Magnetic anomaly detection (MAD) technology based on the magnetic gradient tensor (MGT) has broad application prospects in fields such as unexploded ordnance detection and mineral exploration. The difference approximation method currently employed in the MGT measurement system introduces measurement errors. Designing reasonable geometric structures and configuring optimal structural parameters can effectively reduce measurement errors. Based on research into differential MGT measurement, this paper proposes three simplified planar MGT measurement structures and provides the differential measurement matrix. The factors that affect the design of the baseline distance of the MGT measurement system are also theoretically analyzed. Then, using the magnetic dipole model, the error analysis of the MGT measurement structures is carried out. The results demonstrate that the planar cross-shaped structure is optimal, with the smallest measurement error, only 3.15 × 10⁻¹⁰ T/m. Furthermore, employing the control variable method, the impact of sensor resolution constraints, noise level, target magnetic moment, and detection distance on the design of the optimal baseline distance of the MGT measurement system is simulated and verified. The results indicate that the smaller the target magnetic moment, the farther the detection distance, the lower the magnetometer resolution, the greater the noise, and the greater the baseline distance required. These conclusions provide reference and guidance for the construction of the MGT measurement system based on triaxial magnetometers. Full article

Aeromagnetic surveys are widely used in geological exploration, mineral resource assessment, environmental monitoring, military reconnaissance, and other areas. It is necessary to perform magnetic compensation for interference in these fields. In recent years, large unmanned aerial vehicles (UAVs) have been more suitable for magnetic detection missions because of the greater loads they can carry. This article proposes some methods for the magnetic compensation of large multiload UAVs. Because of the interference of the large platform and instrument noise, the standard deviations (stds) of the compensation data used in this paper are larger. At the beginning of this article, using the traditional T-L model, we avoid the shortcomings of the anti-magnetic interference ability of triaxial magnetic gate magnetometers. The direction cosine information is obtained by using an inertial navigation system, the global positioning system, and a triaxial magnetic gate magnetometer. Then, we increase the amplitude of the maneuvers in the compensation process; this reduces the multicollinearity problems in the compensation matrix to a certain extent, but it also results in greater magnetic field interference. Lastly, we employ the method of Lasso regularization Newton iteration (LRNM). Compared to the traditional methods of least squares (LS) and singular value decomposition (SVD), LRNM provides improvements of 34% and 27%, respectively. In summary, this series of schemes can be used to perform effective compensation for large multi-load UAVs and improve the actual use of large UAVs, making them more accurate in the measurement of aeromagnetic survey data. Full article

A typical magnetometer-based measurement-while-drilling (MWD) system determines the azimuth of the bottom hole assembly during the drilling process by employing triaxial accelerometers and magnetometers. The geomagnetic azimuth solution is susceptible to magnetic interference, especially strong magnetic interference and so a rotary norm constraint filtering (RNCF) method for azimuth estimation, designed to support a gyroscope-aided magnetometer-based MWD system, is proposed. First, a new magnetic dynamical system, one whose output is observed by the magnetometers triad, is designed based on the Coriolis equation of the desired geomagnetic vector. Second, given that the norm of the non-interfered geomagnetic vector can be approximated as a constant during a short-term drilling process, a norm constraint procedure is introduced to the Kalman filter. This is achieved by the normalization of the geomagnetic part of the state vector of the dynamical system and is undertaken in order to obtain a precise geomagnetic component. Simulation and actual drilling experiments show that the proposed RNCF method can effectively improve the azimuth measurement precision with 98.5% over the typical geomagnetic solution and 37.1% over the KF in a RMSE sense when being strong magnetic interference environment. Full article

While the availability of low-cost micro electro-mechanical systems (MEMS) accelerometers, gyroscopes, and magnetometers initially seemed to promise the possibility of using them to easily track the position and orientation of virtually any object that they could be attached to, this promise has not yet been fulfilled. Navigation-grade accelerometers and gyroscopes have long been the basis for tracking ships and aircraft, but the signals from low-cost MEMS accelerometers and gyroscopes are still orders of magnitude poorer in quality (e.g., bias stability). Therefore, the applications of MEMS inertial measurement units (IMUs), containing tri-axial accelerometers and gyroscopes, are currently not as extensive as they were expected to be. Even the addition of MEMS tri-axial magnetometers, to conform magnetic, angular rate, and gravity (MARG) sensor modules, has not fully overcome the challenges involved in using these modules for long-term orientation estimation, which would be of great benefit for the tracking of human–computer hand-held controllers or tracking of Internet-Of-Things (IoT) devices. Here, we present an algorithm, GMVDμK (or simply GMVDK), that aims at taking full advantage of all the signals available from a MARG module to robustly estimate its orientation, while preventing damaging overcorrections, within the context of a human–computer interaction application. Through experimental comparison, we show that GMVDK is more robust to magnetic disturbances than three other MARG orientation estimation algorithms in representative trials. Full article

The Korean Pathfinder Lunar Orbiter (KPLO)-MAGnetometer (KMAG) consists of three triaxial fluxgate sensors (MAG1, MAG2, and MAG3) that measure the magnetic field around the Moon. The three sensors are mounted in the order MAG3, MAG2, and MAG1 inside a 1.2 m long boom, away from the satellite body. Before it arrived on the Moon, we compared the magnetic field measurements taken by DSCOVR and KPLO in solar wind to verify the measurement performance of the KMAG instrument. We found that there were artificial disturbances in the KMAG measurement data, such as step-like and spike-like disturbances, which were produced by the spacecraft body. To remove spacecraft-generated disturbances, we applied a multi-sensor method, employing the gradiometer technique and principal component analysis, using KMAG magnetic field data, and confirmed the successful elimination of spacecraft-generated disturbances. In the future, the proposed multi-sensor method is expected to clean the magnetic field data measured onboard the KPLO from the lunar orbit. Full article

Understanding the seismo–ionospheric coupling mechanism requires a quiet geomagnetic condition, as this represents an ideal situation to detect abnormal variations in the geomagnetic field. In reality, continuous interactions between solar wind and Earth’s magnetosphere create many fluctuations in the geomagnetic field that are more related to sun–magnetosphere interactions than to seismotectonic causes. A triaxial magnetometer was installed at the Muntele Rosu Observatory near the Vrancea seismic zone in 1996 to measure the local magnetic field. Since 2002, the data have become more consistent, allowing for the representation of long time series. Since then, variations have been observed on the eastern component (B_y) of the magnetic field, which sometimes overlaps with significant earthquakes. Previous studies have shown that high decreases in amplitude recorded on the B_y component of the magnetic field measured at Muntele Rosu have been accompanied by higher seismicity, while small decreases have been accompanied by lower seismic energy release. This research analyzes the geomagnetic data collected between September 2002 and May 2008 from two geomagnetic observatories, one located in the proximity of the Vrancea seismic zone and another one situated 120 km away. For each geomagnetic anomaly identified, the daily seismic energy released was plotted logarithmically, along with seismicity and Kp indices. Additionally, the daily seismic energy released was also plotted logarithmically for all earthquakes with Mw ≥3. To identify variations in the B_y component, datasets recorded at Muntele Rosu (MLR) were compared with those recorded at Surlari National Geomagnetic Observatory (SUA), to discriminate between global magnetic variations associated with solar activity and possible seismo–electromagnetic variations. The standard deviation (SD_By) was calculated for each anomaly recorded on the B_y component of the magnetic field and compared with the cumulative seismic energy release. To determine if this type of variation was present in other components of the magnetic field, the following ratios were calculated for all data recorded at Muntele Rosu: B_z/B_x, B_z/B_y, and B_z/B_H. The size of the anomalies resulting from the standard deviation measured on the B_y component (SD_By) partially validates the relationship between the size of the anomalies and the seismic energy release during the anomaly. The relationship between the released seismic energy and the anomaly magnitude is vaguely respected, but these variations seem to follow two patterns. One pattern is described by smooth decreases, and the other pattern involves decreases where the B_y component varies significantly over short periods, generating decreases/increases in steps. It was noticed that seismic activity is greater for the second pattern. Additionally, using standard deviation measured on the magnetic field represents a great tool to discriminate external magnetic field variations from local, possibly seismo–magnetic variations. Full article

Fetal magnetocardiography (fMCG) has proven to be an important tool for the prenatal monitoring of electrical cardiac activity; however, the high cost of superconducting quantum instrumentation (SQUID) poses a limitation for the dissemination of fMCG as a routine clinical technique. Recently, optically pumped magnetometers (OPMs) operating within person-sized, cylindrical shields have made fMCG more practical, but environmental magnetic interference entering through the shield opening substantially degrades the quality of fMCG signals. The goal of this study was to further attenuate these interferences by placing the OPM array within a small ferrite shield. FMCG recordings were made with and without the ferrite shield in ten subjects inside a person-sized, three-layer mu-metal cylindrical shield. Although the fetal signal was slightly attenuated, the environmental interference was reduced substantially, and maternal interference was also diminished. This increased the signal-to-noise ratio significantly and improved the resolution of the smaller waveform components. The performance improvement was highest in the axial direction and compensated for a major weakness of open-ended, person-sized shields. The ferrite shield is especially beneficial for the deployment of triaxial OPM sensors, which require effective shielding in all directions. Full article

In this paper, we present the FIU MARG Dataset (FIUMARGDB) of signals from the tri-axial accelerometer, gyroscope, and magnetometer contained in a low-cost miniature magnetic–angular rate–gravity (MARG) sensor module (also known as magnetic inertial measurement unit, MIMU) for the evaluation of MARG orientation estimation algorithms. The dataset contains 30 files resulting from different volunteer subjects executing manipulations of the MARG in areas with and without magnetic distortion. Each file also contains reference (“ground truth”) MARG orientations (as quaternions) determined by an optical motion capture system during the recording of the MARG signals. The creation of FIUMARGDB responds to the increasing need for the objective comparison of the performance of MARG orientation estimation algorithms, using the same inputs (accelerometer, gyroscope, and magnetometer signals) recorded under varied circumstances, as MARG modules hold great promise for human motion tracking applications. This dataset specifically addresses the need to study and manage the degradation of orientation estimates that occur when MARGs operate in regions with known magnetic field distortions. To our knowledge, no other dataset with these characteristics is currently available. FIUMARGDB can be accessed through the URL indicated in the conclusions section. It is our hope that the availability of this dataset will lead to the development of orientation estimation algorithms that are more resilient to magnetic distortions, for the benefit of fields as diverse as human–computer interaction, kinesiology, motor rehabilitation, etc. Full article

Inside a spin-exchange relaxation-free (SERF) co-magnetometer with a high-pressure buffer gas atomic cell, the magnetic field gradient causes the decoherence of atomic spins to produce magnetic-field gradient relaxation. This paper presents a new method for the accurate measurement of magnetic field gradient relaxation of alkali metal atoms and inert atoms of strongly coupled spin systems under triaxial magnetic field gradients in the K-Rb-²¹Ne co-magnetometer. The magnetic field gradient relaxation of alkali metal atoms is measured using a step magnetic field modulation method, and the magnetic field gradient relaxation of inert atoms is measured using a combined free induction decay and spin growth method. The method does not require the use of large background magnetic fields and RF fields to maintain the atoms in the SERF state, does not require additional optics, and is not affected by the pumping or detecting of optical power. A kinetic model that considers a large electron-equivalent magnetic field was designed and a gradient relaxation model was developed. The quadratic coefficients of the experimentally measured gradient relaxation curves fit the theoretical model well over the range of the applied magnetic field gradients, confirming the validity of the proposed method. Full article
