Search Results (32)

Search Parameters:
Keywords = traveling wave electrodes

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
16 pages, 5292 KiB
Article
A Large-Bandwidth Electro-Optic Modulator with U-T Double-Layer Traveling-Wave Electrode Structure Based on Thin-Film Lithium Niobate
by Yuxiang Hao, Haiou Li, Yue Li, Haisheng Li, Yingbo Liu, Jiayu Yang and Liangpeng Qin
Photonics 2025, 12(7), 648; https://doi.org/10.3390/photonics12070648 - 26 Jun 2025
Viewed by 451
Abstract
Thin-film lithium niobate (TFLN) electro-optic modulators serve as critical components in microwave photonic systems. To improve device performance, we developed a U-T double-layer traveling-wave electrode configuration. Using finite element analysis, we systematically simulated and optimized both modulation efficiency and radiofrequency characteristics, ultimately realizing [...] Read more.
Thin-film lithium niobate (TFLN) electro-optic modulators serve as critical components in microwave photonic systems. To improve device performance, we developed a U-T double-layer traveling-wave electrode configuration. Using finite element analysis, we systematically simulated and optimized both modulation efficiency and radiofrequency characteristics, ultimately realizing a low half-wave voltage-length product of 1.77 V·cm, a minimal optical loss of 0.022 dB/cm, and an ultra-wide modulation bandwidth surpassing 100 GHz. Full article
Show Figures

Figure 1

22 pages, 7971 KiB
Article
A Numerical Investigation of Enhanced Microfluidic Immunoassay by Multiple-Frequency Alternating-Current Electrothermal Convection
by Qisheng Wu, Shaohua Huang, Shenghai Wang, Xiying Zhou, Yuxuan Shi, Xiwei Zhou, Xianwu Gong, Ye Tao and Weiyu Liu
Appl. Sci. 2025, 15(9), 4748; https://doi.org/10.3390/app15094748 - 24 Apr 2025
Viewed by 451
Abstract
Compared with traditional immunoassay methods, microfluidic immunoassay restricts the immune response in confined microchannels, significantly reducing sample consumption and improving reaction efficiency, making it worthy of widespread application. This paper proposes an exciting multi-frequency electrothermal flow (MET) technique by applying combined standing-wave and [...] Read more.
Compared with traditional immunoassay methods, microfluidic immunoassay restricts the immune response in confined microchannels, significantly reducing sample consumption and improving reaction efficiency, making it worthy of widespread application. This paper proposes an exciting multi-frequency electrothermal flow (MET) technique by applying combined standing-wave and traveling-wave voltage signals with different oscillation frequencies to a three-period quadra-phase discrete electrode array, achieving rapid immunoreaction on functionalized electrode surfaces within straight microchannels, by virtue of horizontal pumping streamlines and transverse stirring vortices induced by nonlinear electrothermal convection. Under the approximation of a small temperature rise, a linear model describing the phenomenon of MET is derived. Although the time-averaged electrothermal volume force is a simple superposition of the electrostatic body force components at the two frequencies, the electro-thermal-flow field undergoes strong mutual coupling through the dual-component time-averaged Joule heat source term, further enhancing the intensity of Maxwell–Wagner smeared structural polarization and leading to mutual influence between the standing-wave electrothermal (SWET) and traveling-wave electrothermal (TWET) effects. Through thorough numerical simulation, the optimal working frequencies for SWET and TWET are determined, and the resulting synthetic MET flow field is directly utilized for microfluidic immunoassay. MET significantly promotes the binding kinetics on functionalized electrode surface by simultaneous global electrokinetic transport along channel length direction and local chaotic stirring of antigen samples near the reaction site, compared to the situation without flow activation. The MET investigated herein satisfies the requirements for early, rapid, and precise immunoassay of test samples on-site, showing great application prospects in remote areas with limited resources. Full article
Show Figures

Figure 1

12 pages, 4571 KiB
Article
High-Efficiency Lithium Niobate Electro-Optic Modulator with Barium Titanate Cladding on Quartz
by Hongkang Liu, Jianping Li, Weiqin Zheng, Zixin Chen, Jianbo Zhang and Yuwen Qin
Photonics 2025, 12(2), 157; https://doi.org/10.3390/photonics12020157 - 14 Feb 2025
Viewed by 1666
Abstract
The thin-film lithium niobate (TFLN)-based electro-optic (EO) modulator is one of the most important devices for optical communications in terms of the advantages of low voltages and large bandwidth. However, the large size of devices limits their applicability in large-scale integrated optical systems, [...] Read more.
The thin-film lithium niobate (TFLN)-based electro-optic (EO) modulator is one of the most important devices for optical communications in terms of the advantages of low voltages and large bandwidth. However, the large size of devices limits their applicability in large-scale integrated optical systems, posing a key challenge in maintaining performance advantages under restricted design space. In this paper, we propose a novel TFLN modulator on a quartz substrate incorporating barium titanate (BaTiO3, BTO) as the cladding material. The device is designed with silicon–lithium niobate (Si-LN) hybrid waveguides for operation at a wavelength of 1.55 µm. After theoretical analysis and parameter optimization, the proposed 10 mm long modulator demonstrates high-efficiency modulation, featuring a low half-wave voltage-length product of 1.39 V·cm, a broad 3 dB EO bandwidth of 152 GHz, and low optical loss. This theoretical model provides a novel design solution for TFLN modulators on quartz substrates. Moreover, it is a promising solution for enhancing the integration of photonic devices on the TFLN platform. Full article
Show Figures

Figure 1

14 pages, 13287 KiB
Article
Large-Bandwidth Lithium Niobate Electro-Optic Modulator for Frequency-Division Multiplexing RFID Systems
by Xueting Luo, Zhenqian Gu, Chong Wang, Chao Fan and Weijia Zhang
Electronics 2024, 13(24), 5054; https://doi.org/10.3390/electronics13245054 - 23 Dec 2024
Cited by 3 | Viewed by 1086
Abstract
In the face of increasingly complex application scenarios, there is an urgent need for (Radio Frequency Identification) RFID systems that are capable of accurately identifying microwave signals of different frequency bands. Based on the acumen detection characteristics of microwave signals by lithium niobate [...] Read more.
In the face of increasingly complex application scenarios, there is an urgent need for (Radio Frequency Identification) RFID systems that are capable of accurately identifying microwave signals of different frequency bands. Based on the acumen detection characteristics of microwave signals by lithium niobate electro-optic modulators, applying large-bandwidth thin-film lithium niobate electro-optic modulation to RFID systems can achieve efficient operation across multiple frequency bands. This study discusses, in detail, the design, simulation, fabrication, and testing process of the electro-optic modulator to obtain a high-performance, large-bandwidth lithium niobate electro-optic modulator. By using multilayer lithography techniques to prepare thick traveling-wave electrodes, the problem of irregular cross-sections during the fabrication of thick electrodes has been successfully reduced, improving the stability and controllability of the device. Test results show that the insertion loss of the electro-optic modulator is about 6 dB, the extinction ratio is 36.5 dB, the optical waveguide mode field is 1 μm, the full-band characteristic impedance is 50 Ω, the test bandwidth is 50 GHz, and the half-wave voltage is 1.8 V. Compared with existing optimization schemes, this design not only achieves a large bandwidth and a small half-wave voltage, but also proposes a new fabrication process scheme, optimizing the process and resulting in samples with stable performance. Full article
(This article belongs to the Special Issue RFID Applied to IoT Devices)
Show Figures

Figure 1

17 pages, 8620 KiB
Article
Unique Characteristics of Pulse-Echo Sensing Systems for Ultrasonic Immersion Testing in Harsh Environments
by Gaofeng Sha, Andrew R. Bozek, Bernhard R. Tittmann and Cliff J. Lissenden
Sensors 2024, 24(23), 7748; https://doi.org/10.3390/s24237748 - 4 Dec 2024
Viewed by 1135
Abstract
Ultrasound is an excellent way to acquire data that reveal useful information about systems operating in harsh environments, which may include elevated temperature, ionizing radiation, and aggressive chemicals. The effects of harsh environments on piezoelectric materials have been studied in much more depth [...] Read more.
Ultrasound is an excellent way to acquire data that reveal useful information about systems operating in harsh environments, which may include elevated temperature, ionizing radiation, and aggressive chemicals. The effects of harsh environments on piezoelectric materials have been studied in much more depth than the other aspects of ultrasonic transducers used in pulse-echo mode. Therefore, finite element simulations and laboratory experiments are used to demonstrate the unique characteristics of pulse-echo immersion testing. Using an aluminum nitride piezoelectric element mounted on a vessel wall, characteristics associated with electrode thickness, couplant, backing material, and an acoustic matching layer are investigated. Considering a wave path through a vessel wall and into a fluid containing a target, when the travel distance in the fluid is relatively short, it can be difficult to discern the target echo from the reverberations in the vessel wall. When an acoustic matching layer between the vessel wall and the fluid does not suffice, a simple subtractive signal-processing method can minimize the reverberations, leaving just the target echoes of interest. Simulations and experiments demonstrate that sufficient target echoes are detected to determine the time of flight. Furthermore, a simple disc-like surface anomaly on the target is detectable. Full article
Show Figures

Figure 1

11 pages, 1771 KiB
Article
Lithium Niobate Electro-Optic Modulation Device without an Overlay Layer Based on Bound States in the Continuum
by Guangyuan Chen, Ning Xue, Zhimei Qi, Weichao Ma, Wangzhe Li, Zhenhu Jin and Jiamin Chen
Micromachines 2024, 15(4), 516; https://doi.org/10.3390/mi15040516 - 12 Apr 2024
Viewed by 2124
Abstract
Electro-optic modulation devices are essential components in the field of integrated optical chips. High-speed, low-loss electro-optic modulation devices represent a key focus for future developments in integrated optical chip technology, and they have seen significant advancements in both commercial and laboratory settings in [...] Read more.
Electro-optic modulation devices are essential components in the field of integrated optical chips. High-speed, low-loss electro-optic modulation devices represent a key focus for future developments in integrated optical chip technology, and they have seen significant advancements in both commercial and laboratory settings in recent years. Current electro-optic modulation devices typically employ architectures based on thin-film lithium niobate (TFLN), traveling-wave electrodes, and impedance-matching layers, which still suffer from transmission losses and overall design limitations. In this paper, we demonstrate a lithium niobate electro-optic modulation device based on bound states in the continuum, featuring a non-overlay structure. This device exhibits a transmission loss of approximately 1.3 dB/cm, a modulation bandwidth of up to 9.2 GHz, and a minimum half-wave voltage of only 3.3 V. Full article
Show Figures

Figure 1

11 pages, 2946 KiB
Communication
Broadband Thin-Film Lithium Niobate Electro-Optic Modulator
by Jinming Tao, Yinuo Yang, Xintong Li, Peng Wang, Jinye Li and Jianguo Liu
Photonics 2024, 11(4), 325; https://doi.org/10.3390/photonics11040325 - 30 Mar 2024
Cited by 4 | Viewed by 6686
Abstract
Recently, thin-film lithium niobate electro-optical modulators have developed rapidly and have become the core solution for the next generation of electro-optical problems. Compared with bulk lithium niobate modulators, these modulators not only retain the advantages of lithium niobate materials, such as low loss, [...] Read more.
Recently, thin-film lithium niobate electro-optical modulators have developed rapidly and have become the core solution for the next generation of electro-optical problems. Compared with bulk lithium niobate modulators, these modulators not only retain the advantages of lithium niobate materials, such as low loss, high extinction ratio, high linear response and high optical power handling capabilities, but can also effectively improve some performance parameters, such as the voltage bandwidth performance of the modulator. Unfortunately, the extremely small electrode gap of thin-film lithium niobate EO (electro-optic) modulators causes metal absorption, resulting in higher microwave losses. The electro-optical performance of the modulator, thus, deteriorates at high frequencies. We designed traveling-wave electrodes with microstructures to overcome this limitation and achieve a 3 dB electro-optical bandwidth of 51.2 GHz. At the same time, we maintain low on-chip losses of <2 dB and a high extinction ratio of 15 dB. It is important to note that the devices we manufactured were metal-encapsulated and passed a series of reliability tests. The success of this modulator module marks a key step in the commercialization and application of thin-film lithium niobate modulation devices. Full article
(This article belongs to the Section Optoelectronics and Optical Materials)
Show Figures

Figure 1

13 pages, 6228 KiB
Communication
Circularly Polarized Ultra-Wideband Antenna for Uni-Traveling-Carrier Photodiode Terahertz Source
by Qi Li, Chuang Nie, Zihao Liu, Xin Zhou, Xiaohe Cheng, Song Liang and Yuan Yao
Sensors 2023, 23(23), 9398; https://doi.org/10.3390/s23239398 - 25 Nov 2023
Cited by 4 | Viewed by 1485
Abstract
This paper proposes a circularly polarized ultra-wideband (UWB) antenna for a Uni-Traveling-Carrier Photodiode (UTC-PD) to meet the growing demand for bandwidth and polarization diversity in terahertz (THz) communication. In the design of the UTC-PD integrated antenna, the planar electrodes of the chip are [...] Read more.
This paper proposes a circularly polarized ultra-wideband (UWB) antenna for a Uni-Traveling-Carrier Photodiode (UTC-PD) to meet the growing demand for bandwidth and polarization diversity in terahertz (THz) communication. In the design of the UTC-PD integrated antenna, the planar electrodes of the chip are directly integrated with the antenna to simplify the integration process. However, this integration introduces new problems, such as asymmetry inside the spiral antenna, which leads to a deterioration in the corresponding high-frequency performance. To address this issue, the antenna’s structure is optimized, and a lens is integrated to enhance directivity and eliminate surface waves. As a result, the proposed antenna achieves a 100–1500 GHz (175%) impedance bandwidth and a 150–720 GHz (131%) axial ratio bandwidth for the UTC-PD. The maximum gain of the antenna is 21.05 dBi at 1 THz. Full article
Show Figures

Figure 1

11 pages, 644 KiB
Article
Optimizing Energy Conversion in a Piezo Disk Using a Controlled Supply of Electrical Load
by Oleksandr Boryseiko, Oleksandr Laptiev, Oleh Perehuda and Anton Ryzhov
Axioms 2023, 12(12), 1074; https://doi.org/10.3390/axioms12121074 - 23 Nov 2023
Cited by 1 | Viewed by 1254
Abstract
Piezoceramic products are actively used in modern technical devices and appliances. Disk piezoelectric devices are widely used in elements of information systems: in wireless communication, elements of satellite communication, global positioning systems. Among such devices, microwave piezo motors on traveling waves of various [...] Read more.
Piezoceramic products are actively used in modern technical devices and appliances. Disk piezoelectric devices are widely used in elements of information systems: in wireless communication, elements of satellite communication, global positioning systems. Among such devices, microwave piezo motors on traveling waves of various types are distinguished, including a motor built on an electromechanical disk converter, which performs non-axisymmetric oscillations under the action of a harmonic electric load. In this study, we perform separation of the electrode coating of the plate with thin diametrical dielectric sections and introduce a time-varying electric potential difference of different amplitude or phase to individual parts of the plate. We study the problem of non-axisymmetric planar oscillations of a piezoceramic disk with thickness polarization and the problem of optimization of the electromechanical coupling coefficient (EMCO) value as a function of an infinite number of parameters in space l2 of square summable sequences. Full article
(This article belongs to the Special Issue Stability, Approximation, Control and Application)
Show Figures

Figure 1

18 pages, 6452 KiB
Article
Numerical Solution of the Electric Field and Dielectrophoresis Force of Electrostatic Traveling Wave System
by Yue Yu, Yao Luo, Jan Cilliers, Kathryn Hadler, Stanley Starr and Yanghua Wang
Micromachines 2023, 14(7), 1347; https://doi.org/10.3390/mi14071347 - 30 Jun 2023
Cited by 2 | Viewed by 1821
Abstract
Electrostatic traveling wave (ETW) methods have shown promising performance in dust mitigation of solar panels, particle transport and separation in in situ space resource utilization, cell manipulation, and separation in biology. The ETW field distribution is required to analyze the forces applied to [...] Read more.
Electrostatic traveling wave (ETW) methods have shown promising performance in dust mitigation of solar panels, particle transport and separation in in situ space resource utilization, cell manipulation, and separation in biology. The ETW field distribution is required to analyze the forces applied to particles and to evaluate ETW design parameters. This study presents the numerical results of the ETW field distribution generated by a parallel electrode array using both the charge simulation method (CSM) and the boundary element method (BEM). A low accumulated error of the CSM is achieved by properly arranging the positions and numbers of contour points and fictitious charges. The BEM can avoid the inconvenience of the charge position required in the CSM. The numerical results show extremely close agreement between the CSM and BEM. For simplification, the method of images is introduced in the implementation of the CSM and BEM. Moreover, analytical formulas are obtained for the integral of Green’s function along boundary elements. For further validation, the results are cross-checked using the finite element method (FEM). It is found that discrepancies occur at the ends of the electrode array. Finally, analyses are provided of the electric field and dielectrophoretic (DEP) components. Emphasis is given to the regions close to the electrode surfaces. These results provide guidance for the fabrication of ETW systems for various applications. Full article
(This article belongs to the Special Issue Microfluidic Device Fabrication and Cell Manipulation)
Show Figures

Figure 1

26 pages, 8708 KiB
Article
Design and Development of a Traveling Wave Ferro-Microfluidic Device and System Rig for Potential Magnetophoretic Cell Separation and Sorting in a Water-Based Ferrofluid
by Rodward L. Hewlin, Maegan Edwards and Christopher Schultz
Micromachines 2023, 14(4), 889; https://doi.org/10.3390/mi14040889 - 21 Apr 2023
Cited by 21 | Viewed by 3044
Abstract
The timely detection and diagnosis of diseases and accurate monitoring of specific genetic conditions require rapid and accurate separation, sorting, and direction of target cell types toward a sensor device surface. In that regard, cellular manipulation, separation, and sorting are progressively finding application [...] Read more.
The timely detection and diagnosis of diseases and accurate monitoring of specific genetic conditions require rapid and accurate separation, sorting, and direction of target cell types toward a sensor device surface. In that regard, cellular manipulation, separation, and sorting are progressively finding application potential within various bioassay applications such as medical disease diagnosis, pathogen detection, and medical testing. The aim of this paper is to present the design and development of a simple traveling wave ferro-microfluidic device and system rig purposed for the potential manipulation and magnetophoretic separation of cells in water-based ferrofluids. This paper details in full: (1) a method for tailoring cobalt ferrite nanoparticles for specific diameter size ranges (10–20 nm), (2) the development of a ferro-microfluidic device for potentially separating cells and magnetic nanoparticles, (3) the development of a water-based ferrofluid with magnetic nanoparticles and non-magnetic microparticles, and (4) the design and development of a system rig for producing the electric field within the ferro-microfluidic channel device for magnetizing and manipulating nonmagnetic particles in the ferro-microfluidic channel. The results reported in this work demonstrate a proof of concept for magnetophoretic manipulation and separation of magnetic and non-magnetic particles in a simple ferro-microfluidic device. This work is a design and proof-of-concept study. The design reported in this model is an improvement over existing magnetic excitation microfluidic system designs in that heat is efficiently removed from the circuit board to allow a range of input currents and frequencies to manipulate non-magnetic particles. Although this work did not analyze the separation of cells from magnetic particles, the results demonstrate that non-magnetic (surrogates for cellular materials) and magnetic entities can be separated and, in some cases, continuously pushed through the channel based on amperage, size, frequency, and electrode spacing. The results reported in this work establish that the developed ferro-microfluidic device may potentially be used as an effective platform for microparticle and cellular manipulation and sorting. Full article
(This article belongs to the Special Issue Microfluidic Device Fabrication and Cell Manipulation)
Show Figures

Figure 1

14 pages, 933 KiB
Article
Modeling and Analysis of Device Orientation, Analog and Digital Performance of Electrode Design for High Speed Electro-Optic Modulator
by Tushar Gaur, Pragya Mishra, Gopalkrishna Hegde and Talabattula Srinivas
Photonics 2023, 10(3), 301; https://doi.org/10.3390/photonics10030301 - 12 Mar 2023
Cited by 5 | Viewed by 2549
Abstract
Electro-optic modulators (EOMs) are crucial devices for modern communication enabling high bandwidth optical communication links. Traveling wave electrodes are used to obtain high-speed modulation in these EOMs. We present the electrode design and analysis along with the study of effects of changing orientation [...] Read more.
Electro-optic modulators (EOMs) are crucial devices for modern communication enabling high bandwidth optical communication links. Traveling wave electrodes are used to obtain high-speed modulation in these EOMs. We present the electrode design and analysis along with the study of effects of changing orientation on device performance for a thin-film lithium niobate tunable Mach–Zehnder interferometer (MZI) that offers sub-THz bandwidth operations. High velocity and impedance matching with low RF attenuation, high third-order SFDR (∼121 dB/Hz2/3) and a low half-wave voltage length product (1.74 V.cm) have been achieved for a bandwidth of 136 GHz. High-speed digital modulation using multi-level signal formats (PAM-2, QAM-4 and QAM-16) with low BER for 400 Gbps data has been demonstrated to assess the digital performance of the device. Full article
(This article belongs to the Section Optical Communication and Network)
Show Figures

Figure 1

15 pages, 11606 KiB
Article
A Design Method of Traveling Wave Rotary Ultrasonic Motors Driving Circuit under High Voltage Using Single-Sided Hertzian Contact Forced Oscillator Model
by Xiaoniu Li, Tianlu Huang, Ning Zhao, Youtao Shen, Jiada Huang, Xuan Li, Jiayi Li and Lin Yang
Micromachines 2023, 14(1), 64; https://doi.org/10.3390/mi14010064 - 26 Dec 2022
Cited by 3 | Viewed by 2545
Abstract
Traveling wave rotary ultrasonic motors (TRUMs) are widely used in various industrial processes due to their attractive features, such as compact structure, high accuracy, and fast response. However, the major limiting factors of the operational performance of TRUMs under high-voltage excitation are the [...] Read more.
Traveling wave rotary ultrasonic motors (TRUMs) are widely used in various industrial processes due to their attractive features, such as compact structure, high accuracy, and fast response. However, the major limiting factors of the operational performance of TRUMs under high-voltage excitation are the nonlinear behavior caused by the nonlinearities of the piezoelectric materials and the friction between the stator and rotor of the motor. In this study, a nonlinear dynamics model and an identification method are presented to directly design the driver circuit for suppressing the nonlinear behavior under high voltage excitation. Firstly, by studying the time–frequency characteristics of the isolated electrode voltage, a single-sided Hertzian contact forced oscillator model of TRUMs is established, involving the nonlinearities of the piezoelectric material and friction. Secondly, a harmonic balance nonlinear identification is proposed in the time domain for TRUMs. The influence of the voltage and preload on the nonlinear phenomena is discussed. Lastly, a novel driver circuit is proposed to suppress the nonlinearities using feedback from the isolated electrode. Experiments showed that the total harmonic distortion decreased by 89.4% under 500 Vpp. The proposed drive circuit design method is used to find a high excitation voltage and preload to achieve greater motor output power. Full article
(This article belongs to the Special Issue Recent Advance in Piezoelectric Actuators and Motors)
Show Figures

Figure 1

20 pages, 1045 KiB
Article
Travelling-Wave Electrophoresis, Electro-Hydrodynamics, Electro-Rotation, and Symmetry-Breaking of a Polarizable Dimer in Non-Uniform Fields
by Touvia Miloh and Eldad J. Avital
Micromachines 2022, 13(8), 1173; https://doi.org/10.3390/mi13081173 - 25 Jul 2022
Cited by 3 | Viewed by 1932
Abstract
A theoretical framework is presented for calculating the polarization, electro-rotation, travelling-wave dielectrophoresis, electro-hydrodynamics and induced-charge electroosmotic flow fields around a freely suspended conducting dimer (two touching spheres) exposed to non-uniform direct current (DC) or alternating current (AC) electric fields. The analysis is based [...] Read more.
A theoretical framework is presented for calculating the polarization, electro-rotation, travelling-wave dielectrophoresis, electro-hydrodynamics and induced-charge electroosmotic flow fields around a freely suspended conducting dimer (two touching spheres) exposed to non-uniform direct current (DC) or alternating current (AC) electric fields. The analysis is based on employing the classical (linearized) Poisson–Nernst–Planck (PNP) formulation under the standard linearized ‘weak-field’ assumption and using the tangent-sphere coordinate system. Explicit expressions are first derived for the axisymmetric AC electric potential governed by the Robin (mixed) boundary condition applied on the dimer surface depending on the resistance–capacitance circuit (RC) forcing frequency. Dimer electro-rotation due to two orthogonal (out-of-phase) uniform AC fields and the corresponding mobility problem of a polarizable dimer exposed to a travelling-wave electric excitation are also analyzed. We present an explicit solution for the non-linear induced-charge electroosmotic (ICEO) flow problem of a free polarized dimer in terms of the corresponding Stokes stream function determined by the Helmholtz–Smoluchowski velocity slip. Next, we demonstrate how the same framework can be used to obtain an exact solution for the electro-hydrodynamic (EHD) problem of a polarizable sphere lying next to a conducting planar electrode. Finally, we present a new solution for the induced-charge mobility of a Janus dimer composed of two fused spherical colloids, one perfectly conducting and one dielectrically coated. So far, most of the available electrokinetic theoretical studies involving polarizable nano/micro shapes dealt with convex configurations (e.g., spheres, spheroids, ellipsoids) and as such the newly obtained electrostatic AC solution for a dimer provides a useful extension for similar concave colloids and engineered particles. Full article
(This article belongs to the Special Issue AC Electrokinetics in Microfluidic Devices, Volume II)
Show Figures

Figure 1

10 pages, 2508 KiB
Article
Particle-Induced Electrostatic Repulsion within an Electric Curtain Operating below the Paschen Limit
by Stuart J. Williams, Joseph D. Schneider, Benjamin C. King and Nicolas G. Green
Micromachines 2022, 13(2), 288; https://doi.org/10.3390/mi13020288 - 11 Feb 2022
Cited by 5 | Viewed by 3334
Abstract
The electric curtain is a platform developed to lift and transport charged particles in air. Its premise is the manipulation of charged particles; however, fewer investigations isolate dielectric forces that are observed at lower voltages (i.e., less than the Paschen limit). This work [...] Read more.
The electric curtain is a platform developed to lift and transport charged particles in air. Its premise is the manipulation of charged particles; however, fewer investigations isolate dielectric forces that are observed at lower voltages (i.e., less than the Paschen limit). This work focuses on observations of simultaneous dielectrophoretic and electrostatic forces. The electric curtain was a printed circuit board with interdigitated electrodes (0.020 inch width and spacing) coated with a layer of polypropylene, where a standing wave or travelling wave AC signal was applied (50 Hz) to produce an electric field below the Paschen limit. Soda lime glass beads (180–212 µm) demonstrated oscillatory rolling via dielectrophoretic forces. In addition, several particles simultaneously experienced rapid projectile repulsion, a behavior consistent with electrostatic phenomena. This second result is discussed as a particle-induced local increase in the electric field, with simulations demonstrating that a particle in close proximity to the curtain’s surface produces a local field enhancement of over 2.5 times. The significance of this is that individual particles themselves can trigger electrostatic repulsion in an otherwise dielectric system. These results could be used for advanced applications where particles themselves provided triggered responses, perhaps for selective sorting of micrometer particles in air. Full article
(This article belongs to the Special Issue Micromachines for Dielectrophoresis, Volume II)
Show Figures

Figure 1
