In scientific research, the optimization of organic light-emitting diodes (OLEDs) is generally achieved through a lengthy and expensive experimental process as new ideas and configurations are tested on real devices. Electro-optical simulation allows for the rapid evaluation of key performance parameters of device structures, thus reducing manufacturing time and costs. This paper presents an original contribution to the electro-optical modeling and optimization of multilayer OLED devices using the Non-dominated Sorting Genetic Algorithm II (NSGA-II). This optimization explicitly incorporates defect states within the ITO/NPB/Alq₃:C545T/Alq₃/LiF-Al structure. The simulated model is calibrated using experimental data by fitting the trap state distribution. The Pareto front resulting from the multi-objective optimization identifies a set of non-dominated configurations, including an optimal intermediate structure defined by an electron transport layer (ETL) thickness of approximately 42 nm and a hole transport layer (HTL) thickness of approximately 53 nm. This configuration leads to a limited reduction of 1.75–2% in current efficiency (${\eta }_c$) while offering a remarkable improvement of 23–30% in power efficiency (${\eta }_p$) compared to the extreme configurations of the optimal Pareto set. Thus, this solution represents an optimal Pareto trade-off between high current efficiency and improved power efficiency. This paper shows that combining defect modeling and thickness optimization provides a reliable framework for the electro-optical optimization of OLED devices. Future work will extend this approach to spectral and colorimetric analysis. Full article

To overcome the inherent limitations of 2D MXenes in photocatalysis, namely severe nanosheet restacking and rapid charge recombination, this study reports a synergistic dual-modification strategy. By integrating microwave-assisted in situ growth of carbon nanotubes (CNTs) with the hydrothermal incorporation of multivalent cobalt (Co) species, a 3D hierarchical Co-Ti₃C₂/CNT composite was successfully fabricated. Structural characterization reveals that the in situ grown CNTs act as robust spatial spacers and conductive highways, effectively preventing Ti₃C₂ agglomeration while providing a continuous electron-transfer network. The introduction of Co significantly enriches the surface with redox-active sites and facilitates the formation of an interfacial Schottky junction. Under visible-light irradiation, the optimized Co_10%-Ti₃C₂/CNT composite achieved a superior methylene blue degradation efficiency of 90.3% within 120 min. Mechanistic insights, supported by EPR and electrochemical analyses, confirm that the Schottky barrier at the semiconductor-metal interface acts as a potent electron trap, significantly suppressing e⁻/h⁺ recombination and accelerating surface-mediated radical generation (•OH, •O₂⁻). This work provides a sophisticated template for designing high-performance, dimensionally stable MXene-based heterostructures for advanced environmental remediation. Full article

Dark current represents a fundamental limiting factor in photodiode performance, establishing the noise floor and constraining detectivity in low-light applications. This comprehensive literature review examines publications covering the physical mechanisms underlying dark current generation and diverse techniques employed for its reduction. Covered mechanisms include diffusion current, Shockley–Read–Hall (SRH) generation–recombination, trap-assisted tunneling, band-to-band tunneling, and surface leakage, each examined with respect to its physical origin and characteristic signatures. Reduction strategies are categorized into thermal management approaches, surface passivation techniques including atomic-layer-deposited aluminum oxide (ALD Al₂O₃), guard ring architectures (attached, floating, and combined configurations), gettering and defect engineering methods, doping profile optimization, bias voltage management, and advanced device architectures such as pinned photodiodes and black silicon structures. A classification table organizes all the reviewed literature by material system, reduction technique, and key findings. Special emphasis is placed on silicon, germanium, III–V compounds, and emerging material photodiodes relevant to near-infrared detection, CMOS imaging, single-photon avalanche diodes (SPADs), and Time-of-Flight (ToF) applications. Full article

In this work, a high-performance mid-wave infrared (MWIR) photodetector (PD) utilizing an InAs/GaSb Type-II superlattice absorber and a quaternary AlGaAsSb barrier is designed and analyzed based on numerical simulations aimed at determining an optimized detector structure. Through these simulations, the composition of the AlGaAsSb barrier is carefully designed to achieve lattice matching, high conduction band offset and zero valence band offset. By optimizing the barrier thickness and doping concentration, the depletion region is effectively shifted from the narrow-bandgap absorber to the wide-bandgap barrier; additionally, at 150 K and a reversed bias of 0.05 V, the dark current density in the PD with the barrier (pBn) is reduced to 1.83 × 10⁻⁵ A/cm², about two orders of magnitude lower than that of the PD without the barrier. Furthermore, the effect of the barrier on the generation–recombination (G-R) and the trap-assisted tunneling (TAT) currents are analyzed and compared in detail, and it is found that the barrier structure is much more effective in suppressing the TAT current at low reversed bias when the electric field is low in the absorber layer. These results demonstrate the efficacy of the proposed AlGaAsSb barrier design for realizing high-operating-temperature MWIR PDs. It also provides an insight into the physical mechanism that leads to the performance enhancement of InAs/GaSb PDs. Full article

We investigate the defect-dependent electronic structure and gas-sensing potential of cubic α-CsPbI₃ using first-principles density functional theory and nonadiabatic molecular dynamics. Among the intrinsic defects, interstitials, vacancies, antisites, and switches studied, the I_Pb and Pb_I antisite defects exhibit transition energy levels near the middle of the band gap, thus functioning as deep traps. Short-term adsorption of ammonia selectively modifies the electronic structure, coordinating with Pb at Pb_I sites and Cs at I_Pb sites, significantly altering recombination pathways. Detailed analysis reveals that NH₃ reduces anharmonicity at I_Pb defects, enabling enhanced recombination at elevated temperatures, while trap-assisted recombination dominates at room temperature. Other analytes, including CH₃NH₂ and NO₂, show negligible impact on the band gap or recombination dynamics, highlighting the potential selectivity of NH₃ interactions. Ab initio nonadiabatic molecular dynamics simulations at 300 K and 600 K further demonstrate temperature-dependent modulation of carrier lifetimes, with NH₃ accelerating recombination at ambient conditions and suppressing certain pathways at higher temperatures. These findings suggest that α-CsPbI₃ can serve as a selective and sensitive ammonia sensor over a broad temperature range and offer insights for ammonia detection under industrially relevant conditions. Full article

In situ preparation routes have become central to advancing lead sulfide (PbS) quantum dots (QDs) for solar-energy conversion, owing to their ability to create strongly coupled QD/oxide interfaces that are difficult to achieve with ex situ colloidal methods, along with their simplicity and potential for low-cost, scalable processing. This review systematically examines the fundamental mechanisms, processing levers, and device implications of the dominant in situ approaches successive ionic layer adsorption and reaction (SILAR), voltage-assisted SILAR (V-SILAR), and chemical bath deposition (CBD). These methods enable conformal QD nucleation within mesoporous scaffolds, improved electronic coupling, and scalable low-temperature fabrication, forming the materials foundation for high-performance PbS-based architectures. We further discuss how these in situ strategies translate into enhanced solar-energy applications, including quantum-dot-sensitized solar cells (QDSSCs) and photoelectrochemical (PEC) hydrogen production, highlighting recent advances in interfacial passivation, scaffold optimization, and bias-assisted growth that collectively suppress recombination and boost photocurrent utilization. Representative device metrics reported in recent studies indicate that in-situ-grown PbS quantum dots can deliver photocurrent densities on the order of ~5 mA cm⁻² at applied potentials around 1.23 V versus RHE in photoelectrochemical systems, while PbS-based quantum-dot-sensitized solar cells typically achieve power conversion efficiencies in the range of ~4–10%, depending on interface engineering and device architecture. These performances are commonly associated with conformal PbS loading within mesoporous scaffolds and quantum-dot sizes in the few-nanometer regime, underscoring the critical role of morphology and interfacial control in charge transport and recombination. Recent studies indicate that performance improvements in PbS-based solar-energy devices are primarily governed by interfacial charge-transfer kinetics and recombination suppression rather than QD loading alone, with hybrid heterostructures and inorganic passivation layers playing a key role in modifying band offsets and surface trap densities at the PbS/oxide interface. Remaining challenges are associated with defect-mediated recombination, transport limitations in densely loaded porous scaffolds, and long-term chemical stability, which must be addressed to enable scalable and durable PbS-based photovoltaic and photoelectrochemical technologies. Full article

The realization of desirable vertical phase separation, enabled by sequential processing that allows for the separate deposition and targeted regulation of donor and acceptor components to construct a well-defined donor–acceptor (D-A) interface, serves as a pivotal factor governing the performance of layer-by-layer organic photovoltaics (LOPVs). This study explores the utility of 4-trifluoromethyl benzoic anhydride (4-TBA), a multifunctional benzene-based solid additive, in the PM6/L8-BO LOPV system, focusing on its role in regulating the vertical phase separation of donor-PM6 and acceptor-L8-BO components to form a well-structured D-A interface. To this end, 4-TBA is doped into the donor-PM6 layer, acceptor-L8-BO layer, or both layers, and its effects on device performance are systematically characterized. The results show that simultaneous doping of 0.05 wt% 4-TBA in both PM6 and L8-BO layers yields the optimal performance, with the power conversion efficiency reaching 18.49% compared to the pristine device with a PCE of 17.05%, and this is accompanied by a significant increase in short-circuit current density from 24.71 mA/cm² to 26.65 mA/cm². Additionally, the optimal devices exhibit better stability, as unencapsulated devices retain 76% of their initial PCE after 175 h under ambient conditions compared to 73% for the devices without 4-TBA doping. Essentially, solid additive 4-TBA modulates molecular packing via its interaction between the donor and acceptor molecules and enhances molecular aggregation and hydrophobicity, thereby suppressing bimolecular and trap-assisted recombination, reducing trap density of states, and forming favorable interpenetrating networks. This work validates 4-TBA, which contains benzene rings and other functional groups, as a versatile additive suitable for the LOPV system and offers a generalizable strategy for optimizing LOPV performance by leveraging multifunctional solid additives. Full article

Perovskite solar cells (PSCs) have achieved remarkable efficiencies, yet further progress is limited by defect-induced nonradiative recombination and instability associated with uncontrolled crystallization. Here, we develop a protic ionic-liquid precursor engineering strategy based on methylammonium acetate (MAAc) for high-performance inverted (p–i–n) triple-cation perovskite solar cells. Systematic variation of the MAAc content reveals that a moderate concentration yields perovskite films with enlarged grains, suppressed pinholes, and strongly reduced residual PbI₂. Steady-state and time-resolved photoluminescence measurements, together with electrochemical impedance spectroscopy and light-intensity-dependent analysis, demonstrate that MAAc effectively suppresses trap-assisted nonradiative recombination, prolongs carrier lifetime, and increases recombination resistance without introducing additional transport losses. As a result, optimized inverted devices deliver a champion power conversion efficiency of 23.68% with a high open-circuit voltage of 1.21 V, a fill factor of ~0.83, negligible J–V hysteresis, and excellent device-to-device reproducibility. Moreover, the MAAc-2M devices exhibit markedly improved operational and shelf stability, retaining 73.2% of their initial efficiency after 30 days, compared to 53.2% for the control. This work establishes MAAc as an effective ionic-liquid additive that simultaneously governs crystallization and defect chemistry, offering a general route to efficient and stable inverted perovskite solar cells via protic ionic-liquid-assisted precursor engineering. Full article

Wide-bandgap diamond photodetectors face a fundamental trade-off between dark current suppression and photocurrent collection due to high Schottky barriers. Here, a photo-modulation strategy is demonstrated by integrating monolayer graphene as transparent electrodes on oxygen-terminated single-crystal diamond. The atomically thin graphene (87.3% UV transmittance at 220 nm) allows photons to penetrate and dynamically reduce Schottky barriers through photoinduced electric fields, while maintaining high barriers (~2.3 eV) under dark conditions for ultralow leakage current. Compared with conventional 100 nm Au electrodes, graphene-based devices exhibit a 4.9-fold responsivity improvement (0.158 A/W at 220 nm) and a 5.2-fold detectivity increase (8.35 × 10¹³ cm·Hz^1/2/W), while preserving ultralow dark current (~10⁻¹² A at ±100 V). XPS measurements confirm a minimal Fermi level shift (0.06 eV) upon graphene integration, demonstrating robust surface state pinning by oxygen termination. Transient photoresponse reveals a 27% faster rise time (30 ns vs. 41 ns) with bi-exponential decay governed by band-to-band recombination (τ1 ≈ 75 ns) and trap-assisted recombination (τ2 ≈ 411 ns). The devices maintain stable performance after one month of ambient exposure and successfully demonstrate UV optical communication capability. This transparent electrode approach offers a versatile strategy for enhancing wide-bandgap semiconductor photodetectors for secure communications, environmental monitoring, and industrial sensing applications. Full article

Ternary organic photovoltaics (OPVs) are considered as the next step beyond binary systems, aiming to achieve synergistic improvements in absorption, energetic alignment, and charge transport. However, despite their conceptual appeal, most ternary blends do not outperform binary counterparts, particularly under indoor illumination where photon flux and carrier dynamics impose strict limitations. To comprehensively understand this discrepancy, multiple ternary systems were systematically examined to ensure that the observed behaviors are representative rather than case specific. In this study, we systematically investigate this discrepancy by comparing representative donor–donor–acceptor (D–D–A) and donor–acceptor–acceptor (D–A–A) systems under both AM 1.5G and TL84 lighting. In all cases, the broadened absorption fails to yield effective photocurrent; instead, redundant excitations, reduced driving forces for charge separation, and disrupted percolation networks collectively diminish device performance. Recombination and transient analyses reveal that the third component often introduces energetic disorder and trap-assisted recombination instead of facilitating beneficial cascade pathways. Although the film morphology remains smooth, interfacial instability under low-light conditions further intensifies performance losses. The inclusion of several systems allows the identification of consistent mechanistic trends across different ternary architectures, reinforcing the generality of the conclusions. This work establishes a mechanistic framework linking molecular miscibility, energetic alignment, and percolation continuity to device-level behavior, clarifying why ternary strategies rarely deliver consistent efficiency improvements. Ultimately, indoor OPV performance is determined not by spectral breadth but by maintaining balanced charge transport and stable energetic landscapes, which represents an essential paradigm for advancing ternary OPVs from concept to practical application. Full article

Quasi-two-dimensional (Q2D) perovskite films have garnered significant attention as novel gain media for lasers due to their tunable bandgap, narrow linewidth, and solution processability. Q2D perovskites endowed with intrinsic quantum well structures demonstrate remarkable potential as gain media for cost-effective miniaturized lasers, owing to their superior ambient stability and enhanced photon confinement capabilities. However, the mixed-phase distribution within Q2D films constitutes a critical determinant of their optical properties, exhibiting pronounced sensitivity to specific fabrication protocols and processing parameters, including annealing temperature, duration, antisolvent volume, injection timing, and dosing rate. These factors frequently lead to broad phase distribution in Q2D perovskite films, thereby inducing incomplete exciton energy transfer and multiple emission peaks, while simultaneously making the fabrication processes intricate and reducing reproducibility. Here, we report a novel annealing-free and antisolvent-free method for the preparation of Q2D perovskite films fabricated in ambient atmosphere. By constructing a tailored mixed-solvent vapor atmosphere and systematically investigating its regulatory effects on the nucleation and growth processes of film via in situ photoluminescence spectra, we successfully achieved the fabrication of Q2D perovskite films with large n narrow phase distribution characteristics. Due to the reduced content of small n domains, the incomplete energy transfer from small n to large n phases and the carriers’ accumulation in small n can be greatly suppressed, thereby suppressing the trap-assistant nonradiative recombination and Auger recombination. Ultimately, the Q2D perovskite film showed a single emission peak at 519 nm with the narrow full width at half maximum (FWHM) of 21.5 nm and high photoluminescence quantum yield (PLQY) of 83%. And based on the optimized Q2D film, we achieved an amplified spontaneous emission (ASE) with a low threshold of 29 μJ·cm⁻², which was approximately 60% lower than the 69 μJ·cm⁻² of the control film. Full article

The performance of optoelectronic devices is affected by various noise sources. A notable factor is the 4.2% lattice mismatch at the Ge/Si interface, which significantly influences the efficiency of Ge-on-Si photodetectors. These noise sources can be analyzed by examining the impact of the Ge/Si interface and deep traps on dark and photocurrents. This study evaluates the impact of these charge traps on key photodetector performance metrics, including responsivity, photo-to-dark current ratio, noise equivalent power (NEP), and specific detectivity (D^*). The trapping effects on charge transport under both forward and reverse bias conditions are monitored through hysteresis analysis. When illuminated with an unmodulated 1550 nm laser, all the key performance metrics exhibit maximum variations at a specific reverse bias. This critical bias marks the transition from saturated to exponential charge transport regimes, where intensified electric fields enhance trap-assisted recombination and thus maximize metric fluctuations. Full article

Flexible perovskite solar cells (F-PSCs) have the advantages of high power-per-weight, solution processability, and bending durability and have emerged as a competitive photovoltaic technology for various applications. As the core electron transport layer (ETL) in n-i-p-type device configurations, the solution-processed SnO₂ generally suffers from serious defect stacking on films, compromising the charge transport properties and the performance of resulting devices. Herein, we proposed a media-filling strategy to optimize the contact quality at the buried interface by introducing Al₂O₃ nanoparticles on the SnO₂ surface. Rather than forming a compact insulating layer, the Al₂O₃ can fill the grain boundaries of SnO₂ and smooth the substrate surface. Optimized interfacial contact under careful concentration control can rationally minimize the contact area of the perovskite with the surface imperfections of SnO₂ to mitigate trap-assisted charge recombination. Furthermore, the reduced surface roughness of SnO₂ facilitates the uniform deposition and oriented growth of upper perovskite film. As a result, the target F-PSCs achieved an impressive efficiency of 23.83% and retained 80% of the initial performance after 5000 bending cycles at a radius of four mm. Full article

This study proposes an alternative process for obtaining ZnO/ZnS:rGO heterostructures for use in DSSCs and as promising materials for potential applications in other photonic process, such as photocatalysis and photodetection. The compound was obtained through a microwave-assisted hydrothermal method, where the electromagnetic waves and temperature were crucial points for forming ZnO, ZnO/ZnS and reducing graphene oxide (GO). The XRD, Raman, FT-IR, and FESEM results presented the structural, morphological, and chemical structures, which suggest the conversion of ZnO to ZnS for samples with higher concentrations of reduced graphene oxide (rGO). Additionally, the optical properties were analyzed through photoluminescence and UV-Vis measurements. The electrical behavior of the photoelectrodes was investigated through J-V measurements in light and dark conditions. In addition, electrochemical impedance spectroscopy (EIS) was performed and Bode phase plots were created, analyzing the recombination processes and electron lifetime. The J-V results showed that for smaller amounts of rGO, the dye-sensitized solar cells (DSSC) efficiency improved compared to the ZnO/ZnS single structure. However, it was observed that with more significant amounts of rGO, the photocurrent value decreased due to the presence of charge-trapping centers. On the other hand, the best results were obtained for the ZnO/ZnS:1% rGO sample, which showed an increase of 14.2% in the DSSC efficiency compared to the pure ZnO/ZnS photoelectrode. Full article

Regulating the nucleation temperature and growth rates during inverse temperature crystallization (ITC) is vital for obtaining high-quality perovskite single crystals via this technique. Precise control over these parameters enables growing crystals optimized for various optoelectronic devices. In this study, it is demonstrated that incorporating a 1-butyl-3-methylimidazolium bromide (BMIB) ionic liquid into the precursor solution of cesium lead bromide (CsPbBr₃) brings about a dual enhancement effect. This includes a reduction in nucleation temperature from 85 °C to 65 °C and a significant improvement in both optoelectronic characteristics and crystal properties. The CsPbBr₃ single crystals grown using ITC with BMIB added (method (2)) demonstrate improved chemical and physical properties (crystallinity, lattice strain, nonradioactive recombination, and trap density) compared to CsPbBr₃ single crystals produced through conventional 85 °C ITC alone (method (1)). The exceptional quality of CsPbBr₃ single crystals produced with the inclusion of BMIB allowed for the development of a highly responsive optoelectronic device, demonstrating heightened sensitivity to green light. The findings of this investigation reveal that the growth of perovskite single crystals assisted by ionic liquid exerts a substantial impact on the characteristics of the crystals. This influence proves advantageous for the development of optoelectronic devices based on single crystals. Full article
