Search Results (76)

This paper presents a neural network model, PINN-AeroFlow-U, for reconstructing full-field aerodynamic quantities around three-dimensional compressor blades, including regions near the wall. This model is based on structured CFD training data and physics-informed loss functions and is proposed for direct 3D compressor flow prediction. It maps flow data from the physical domain to a uniform computational domain and employs a U-Net-based neural network capable of capturing the sharp local transitions induced by fluid acceleration near the blade leading edge, as well as learning flow features associated with internal boundaries (e.g., the wall boundary). The inputs to PINN-AeroFlow-U are the flow-field coordinate data from high-fidelity multi-geometry blade solutions, the 3D blade geometry, and the first-order metric coefficients obtained via mesh transformation. Its outputs include the pressure field, temperature field, and velocity vector field within the blade passage. To enhance physical interpretability, the network’s loss function incorporates both the Euler equations and gradient constraints. PINN-AeroFlow-U achieves prediction errors of 1.063% for the pressure field and 2.02% for the velocity field, demonstrating high accuracy. Full article

Three-dimensional reconstruction entails the development of mathematical models of three-dimensional objects that are suitable for computational representation and processing. This technique constructs realistic 3D models of images and has significant practical applications across various fields. This study proposes a rapid and precise multi-view 3D reconstruction method to address the challenges of low reconstruction efficiency and inadequate, poor-quality point cloud generation in incremental structure-from-motion (SFM) algorithms in multi-view geometry. The methodology involves capturing a series of overlapping images of campus. We employed the Scale-invariant feature transform (SIFT) algorithm to extract feature points from each image, applied the KD-Tree algorithm for inter-image matching, and Enhanced autonomous threshold adjustment by utilizing the Random sample consensus (RANSAC) algorithm to eliminate mismatches, thereby enhancing feature matching accuracy and the number of matched point pairs. Additionally, we developed a feature-matching strategy based on similarity, which optimizes the pairwise matching process within the incremental structure from a motion algorithm. This approach decreased the number of matches and enhanced both algorithmic efficiency and model reconstruction accuracy. For dense reconstruction, we utilized the patch-based multi-view stereo (PMVS) algorithm, which is based on facets. The results indicate that our proposed method achieves a higher number of reconstructed feature points and significantly enhances algorithmic efficiency by approximately ten times compared to the original incremental reconstruction algorithm. Consequently, the generated point cloud data are more detailed, and the textures are clearer, demonstrating that our method is an effective solution for three-dimensional reconstruction. Full article

Vegetation characteristics significantly influence the impact of wildfires on individual building structures, and these effects can be systematically analyzed using heat transfer modelling software. Close-range light detection and ranging (LiDAR) data obtained from uncrewed aerial systems (UASs) capture detailed vegetation morphology; however, the integration of dense vegetation and merged canopies into three-dimensional (3D) models for fire modelling software poses significant challenges. This study proposes a method for integrating the UAS–LiDAR-derived geometric features of vegetation components—such as bark, wooden core, and foliage—into heat transfer models. The data were collected from the natural woodland surrounding an elevated building in Samford, Queensland, Australia. Aboveground biomass (AGB) was estimated for 21 trees utilizing three 3D tree reconstruction tools, with validation against biomass allometric equations (BAEs) derived from field measurements. The most accurate reconstruction tool produced a tree mesh utilized for modelling vegetation geometry. A proof of concept was established with Eucalyptus siderophloia, incorporating vegetation data into heat transfer models. This non-destructive framework leverages available technologies to create reliable 3D tree reconstructions of complex vegetation in wildland–urban interfaces (WUIs). It facilitates realistic wildfire risk assessments by providing accurate heat flux estimations, which are critical for evaluating building safety during fire events, while addressing the limitations associated with direct measurements. Full article

This paper presents three 3D reconstructions of different analogue models used to reproduce, interpret, and describe the geological setting of a seismogenic area in Southern Italy—the Messina Strait. Three-dimensional analysis is a technique that allows for less sparse and more congruent and coherent information about a study zone whose complete understanding reduces uncertainties and risks. A thorough structural and geodynamic description of the effects of low-angle normal faulting in the same region through analogue models has been widely investigated in the scientific literature. Sandbox models for fault behaviour during deformation and the effects of a Low Angle Normal Fault (LANF) on the seismotectonic setting are also studied. The deformational patterns associated with seismogenic faults, rotational behaviour of faults, and other related problems have not yet been thoroughly analysed. Most problems, like the evolution of normal faults, fault geometry, and others, have been cited and briefly outlined in earlier published works, but a three-dimensional approach is still significant. Here, we carried out a three-dimensional digital model for a complete and continuous structural model of a debated, studied area. The aim of this study is to highlight the importance of fully representing faults in complex and/or non-cylindrical structures, mainly when the shape and dimensions of the fault(s) are key parameters, like in seismogenic contexts. Full article

In three-dimensional (3D) measurement, the motion of objects inevitably introduces errors, posing significant challenges to high-precision 3D reconstruction. Most existing algorithms for compensating motion-induced phase errors are tailored for object motion along the camera’s principal axis (Z direction), limiting their applicability in real-world scenarios where objects often experience complex combined motions in the X/Y and Z directions. To address these challenges, we propose a universal motion error compensation algorithm that effectively corrects both pixel mismatch and phase-shift errors, ensuring accurate 3D measurements under dynamic conditions. The method involves two key steps: first, pixel mismatch errors in the camera subsystem are corrected using adjacent coarse 3D point cloud data, aligning the captured data with the actual spatial geometry. Subsequently, motion-induced phase errors, observed as sinusoidal waveforms with a frequency twice that of the projection fringe pattern, are eliminated by applying the Hilbert transform to shift the fringes by π/2. Unlike conventional approaches that address these errors separately, our method provides a systematic solution by simultaneously compensating for camera-pixel mismatch and phase-shift errors within the 3D coordinate space. This integrated approach enhances the reliability and precision of 3D reconstruction, particularly in scenarios with dynamic and multidirectional object motions. The algorithm has been experimentally validated, demonstrating its robustness and broad applicability in fields such as industrial inspection, biomedical imaging, and real-time robotics. By addressing longstanding challenges in dynamic 3D measurement, our method represents a significant advancement in achieving high-accuracy reconstructions under complex motion environments. Full article

The ability to localize and image radiation sources has found use in various applications for nuclear nonproliferation practices, specifically in treaty verification, nuclear safeguards, and homeland security. Technologies that are capable of angular radiation imaging have been prevalent for years and, recently, 3D imaging technologies making use of emerging media like mixed reality have been rapidly developing and gaining popularity. Modern imaging techniques typically use a Compton camera to record coincident events and reconstruct the incident directional information of a gamma ray-emitting radiation source. However, Compton cameras are limited as they cannot obtain accurate source depth information when used for simple back projection imaging. Neutron scatter cameras are a complementary imaging technique that use double elastic scatters but also have their own limitations. This work presents a framework for multiple scatter-based particle imagers to construct 3D images and to localize a radiation source using gamma rays or fast neutrons. Specifically, localization is achieved by accounting for the position of the imagers. The imaging algorithm was validated using experimental data, measuring a ²⁵²Cf source. A three-dimensional representation of the imaging data provides a more intuitive and informative depiction of source positions and can aid in scenarios with complex environmental geometries such as when sources are in containers. Full article

Moulds for aeronautical applications must fulfil highly demanding requirements, including the geometrical tolerances before and after curing cycles at high temperatures and pressures. The growing availability of thermoplastic materials printed by material extrusion systems requires research to verify the geometrical accuracy after three-dimensional printing processes to assess whether the part can meet the required geometry through milling processes. In this sense, the application of automated techniques to assess quick and reliable measurements is an open point under this promising technology. This work investigates the integration of a 3D vision system using a structured-light 3D scanner, placed onto an industrial robot in an eye-in-hand configuration and synchronized by a computer. The complete system validates an in-house algorithm, which inspects the whole reconstructed part, acquiring several views from different poses, and makes the alignment with the theoretical model of the geometry of big parts manufactured by 3D printing. Moreover, the automation of the validation process for the manufactured parts using contactless detection of the offset-printed material can be used to define milling strategies to achieve the geometric qualifications. The algorithm was tested using several parts printed by the material extrusion of a thermoplastic material based on black polyamide 6 reinforced with short carbon fibres. The complete inspection process was performed in 38 s in the three studied cases. The results assure that more than 95.50% of the evaluated points of each reconstructed point cloud differed by more than one millimetre from the theoretical model. Full article

In practical applications, integrating three-dimensional models of bionic devices with simulation systems can predict their behavior and performance under various operating conditions, providing a basis for subsequent engineering optimization and improvements. This study proposes a framework for characterizing three-dimensional models of objects, focusing on extracting 3D structures and generating high-quality 3D models. The core concept involves obtaining the density output of the model from multiple images to enable adaptive boundary surface detection. The framework employs a hierarchical octree structure to partition the 3D space based on surface and geometric complexity. This approach includes recursive encoding and decoding of the octree structure and surface geometry, ultimately leading to the reconstruction of the 3D model. The framework has been validated through a series of experiments, yielding positive results. Full article

Infrared binocular cameras, leveraging their distinct thermal imaging capabilities, are well-suited for visual measurement and 3D reconstruction in challenging environments. The precision of camera calibration is essential for leveraging the full potential of these infrared cameras. To overcome the limitations of traditional calibration techniques, a novel method for calibrating infrared binocular cameras is introduced. By creating a virtual target plane that closely mimics the geometry of the real target plane, the method refines the feature point coordinates, leading to enhanced precision in infrared camera calibration. The virtual target plane is obtained by inverse projecting the centers of the imaging ellipses, which are estimated at sub-pixel edge, into three-dimensional space, and then optimized using the RANSAC least squares method. Subsequently, the imaging ellipses are inversely projected onto the virtual target plane, where its centers are identified. The corresponding world coordinates of the feature points are then refined through a linear optimization process. These coordinates are reprojected onto the imaging plane, yielding optimized pixel feature points. The calibration procedure is iteratively performed to determine the ultimate set of calibration parameters. The method has been validated through experiments, demonstrating an average reprojection error of less than 0.02 pixels and a significant 24.5% improvement in calibration accuracy over traditional methods. Furthermore, a comprehensive analysis has been conducted to identify the primary sources of calibration error. Ultimately, this achieves an error rate of less than 5% in infrared stereo ranging within a 55-m range. Full article

Atrial fibrillation (AF) is the most common sustained cardiac arrhythmia associated with significant morbidity and mortality. Managing risk of stroke and AF burden are pillars of AF management. Atrial geometry has long been recognized as a useful measure in achieving these goals. However, traditional diagnostic approaches often overlook the complex spatial dynamics of the atria. This review explores the emerging role of three-dimensional (3D) atrial geometry in the evaluation and management of AF. Advancements in imaging technologies and computational modeling have enabled detailed reconstructions of atrial anatomy, providing insights into the pathophysiology of AF that were previously unattainable. We examine current methodologies for interpreting 3D atrial data, including qualitative, basic quantitative, global quantitative, and statistical shape modeling approaches. We discuss their integration into clinical practice, highlighting potential benefits such as personalized treatment strategies, improved outcome prediction, and informed treatment approaches. Additionally, we discuss the challenges and limitations associated with current approaches, including technical constraints and variable interpretations, and propose future directions for research and clinical applications. This comprehensive review underscores the transformative potential of leveraging 3D atrial geometry in the evaluation and management of AF, advocating for its broader adoption in clinical practice. Full article

Three-dimensional echocardiography (3D ECHO) and magnetic resonance (MR) imaging are frequently used in patients and animals to evaluate heart functions. Inverse finite element (FE) modeling is increasingly applied to MR images to quantify left ventricular (LV) function and estimate myocardial contractility and other cardiac biomarkers. It remains unclear, however, as to whether myocardial contractility derived from the inverse FE model based on 3D ECHO images is comparable to that derived from MR images. To address this issue, we developed a subject-specific inverse FE model based on 3D ECHO and MR images acquired from seven healthy swine models to investigate if there are differences in myocardial contractility and LV geometrical features derived using these two imaging modalities. We showed that end-systolic and end-diastolic volumes derived from 3D ECHO images are comparable to those derived from MR images ($R^2=0.805$ and $0.969$, respectively). As a result, ejection fraction from 3D ECHO and MR images are linearly correlated ($R^2=0.977$) with the limit of agreement (LOA) ranging from −17.95% to 45.89%. Using an inverse FE modeling to fit pressure and volume waveforms in subject-specific LV geometry reconstructed from 3D ECHO and MR images, we found that myocardial contractility derived from these two imaging modalities are linearly correlated with an $R^2$ value of 0.989, a gradient of 0.895, and LOA ranging from −6.11% to 36.66%. This finding supports using 3D ECHO images in image-based inverse FE modeling to estimate myocardial contractility. Full article

Proper documentation is fundamental to providing structural health monitoring, damage identification and failure assessment for Cultural Heritage (CH). Three-dimensional models from photogrammetric and laser scanning surveys usually provide 3D point clouds that can be converted into meshes. The point clouds usually contain noise data due to different causes: non-cooperative material or surfaces, bad lighting, complex geometry and low accuracy of the instruments utilized. Point cloud denoising has become one of the hot topics of 3D geometric data processing, removing these noise data to recover the ground-truth point cloud and adding smoothing to the ideal surface. These cleaned point clouds can be converted in volumes with different algorithms, suitable for different uses, mainly for structural analysis. This paper aimed to analyse the geometric accuracy of algorithms available for the conversion of 3D point clouds into volumetric models that can be used for structural analyses through the FEA process. The process is evaluated, highlighting problems and difficulties that lie in poor reconstruction results of volumes from denoised point clouds due to the geometric complexity of the objects. Full article

Due to potentially harmful exposure to X-rays, condylar growth in response to orthodontic treatment is poorly studied. To overcome this limitation, here, the authors have proposed high-resolution MRI as a viable alternative to CBCT for clinical 3D assessment of TMJ. A male subject underwent both MRI and CBCT scans. The obtained three-dimensional reconstructions of the TMJ were segmented and superimposed by a semiautomatic algorithm developed in MATLAB R2022a. The condylar geometries were reconstructed using dedicated software for image segmentation. Two geometrical parameters, i.e., the total volume and surface of the single condyle model, were selected to quantify the intraclass and interclass variability from the mean of each DICOM series (CBCT and MRI). The final comparison between the reference standard model of CBCT and 3T MRI showed that the former was more robust in terms of reproducibility, while the latter reached a higher standard deviation compared to CBCT, but these values were similar between the operators and clinically not significant. Within the inherent limitation of image reconstruction on MRI scans due to the current lower resolution of this technique, the method proposed here could be considered as a nucleus for developing future completely automatic AI algorithms, owing to its great potential and satisfactory consistency among different times and operators. Full article

A three-dimensional (3D) understanding of muscle attachment footprints became increasingly relevant for musculoskeletal modeling. The established method to project attachments as points ignores patient-specific individuality. Research focuses on investigating certain muscle groups rather than comprehensively studying all muscles spanning a joint. Therefore, we present a reliable method to study several muscle attachments in order to reconstruct the attachment sites in 3D based on CT imaging for future applications in musculoskeletal modeling. For the present feasibility study, 23 knee-related muscle attachments were CT-scanned postmortem from four nonadipose male specimens. For this, the specific muscle attachments were dissected and marked with a barium sulfate containing paint (60 g BaSO₄ in 30 mL water and 10 mL acrylic paint). Subsequently, bone geometries and muscle attachments were reconstructed and evaluated from CT datasets. Bone morphology and footprint variations were studied. Exemplarily, variations were high for pes anserinus insertions (mean 56%) and the origins of M. biceps femoris (mean 54%). In contrast, the origins of the vastus muscles as well as the insertion of the Achilles tendon showed low variation (mean 9% and 13%, respectively). Most attachment sites showed variation exceeding the individuality of bone morphology. In summary, the present data were consistent with the few published studies of specific muscle footprints. Our data shed light on the high variability of muscle attachments, which need to be addressed when studying muscle forces and movements through musculoskeletal modeling. This is the first step to achieving a more profound understanding of muscle morphology to be utilized in numerical simulations. Full article

As the variety of space targets expands, two-dimensional (2D) ISAR images prove insufficient for target recognition, necessitating the extraction of three-dimensional (3D) information. The 3D geometry reconstruction method utilizing energy accumulation of ISAR image sequence (ISEA) facilitates superior reconstruction while circumventing the laborious steps associated with factorization methods. Nevertheless, ISEA’s neglect of valid information necessitates a high quantity of images and elongated operation times. This paper introduces a partitioned parallel 3D reconstruction method utilizing sorted-energy semi-accumulation with ISAR image sequences (PP-ISEA) to address these limitations. The PP-ISEA innovatively incorporates a two-step search pattern—coarse and fine—that enhances search efficiency and conserves computational resources. It introduces a novel objective function ‘sorted-energy semi-accumulation’ to discern genuine scatterers from spurious ones and establishes a redundant point exclusion module. Experiments on the scatterer model and simulated electromagnetic model demonstrate that the PP-ISEA reduces the minimum image requirement from ten to four for high-quality scatterer model reconstruction, thereby offering superior reconstruction quality in less time. Full article
