Search Results (146)

A condition assessment of a group of field-aged insulators operated for only 6 years on the island of Rhodes after incidents of intense electrical activity is presented in this paper. The investigated insulators were in service in 150 kV overhead transmission lines operating in proximity to the seacoast, exposed to the action of marine pollution. Although the same type of insulator has been widely used in similar conditions, both on the island of Rhodes and on the island of Crete, incidents of intense electrical activity have only been experienced in a specific area on the southwest side of Rhodes. To understand the deterioration mechanism, in addition to a group of failed insulators, a number of insulators from the same area without indication of deterioration were removed to be tested. In total, 40 insulators were examined: 23 with extensive failure, three without any deterioration and 14 with different levels of tracking and erosion traces along the polymeric housing. A series of tests were performed, including visual inspection, hydrophobicity classification, insulation performance through tanδ measurements, an adhesion test between the polymeric housing and the rod and material identification of the housing material through FTIR-ATR. The results indicate that the main failure mechanism is insulator flashunder due to the poor adhesion between the polymeric housing and the rod, as well as the poor sealing of insulators, favoring the ingress of water on the insulator rod and the initiation of electrical discharges. Full article

This study investigated the relationship between Mn segregation, damping capacity, and mechanical properties of a Mn–Cu damping alloy after aging at different temperatures. The results showed that after aging, the alloy underwent spinodal decomposition, forming Mn-segregated regions, while α-Mn precipitates appeared at the grain boundaries. The microstructure resulting from spinodal decomposition promoted martensitic transformation, created twin boundaries, and enhanced damping capacity. As the aging temperature increased, the Mn content in the Mn-rich regions gradually rose, thereby raising the martensitic transformation temperature. The twin density first increased and then decreased, which may be attributed to the precipitation and broadening of the α-Mn phase along the grain boundaries of the Mn-rich regions when the aging temperature was too high. At an aging temperature of 425 °C, the tanδ reaches a maximum of 0.05, and the martensitic transformation temperature reaches 100 °C, at which point the tanδ remains 0.04. After aging at 425 °C, a preferred orientation along <001> develops. The [001] orientation has the largest Schmid factor, which is most favorable for the reversible motion of twin boundaries under external stress, thus achieving the highest energy dissipation. To summarize, by promoting the creation of fine {011} twins by means of spinodal decomposition and by increasing the [001] oriented grain fraction through texture development, aging enhances the damping properties of the Mn–Cu alloy. In particular, the aging at 425 °C can provide the best combination of the microstructure and texture conditions, providing the highest damping performance in a wide temperature range. Full article

In this study, the sintering behavior and electrical properties of 0.7Pb(Zr_0.46Ti_0.54)O₃ (PZT)–0.1Pb(Zn₁/₃Nb₂/₃)O₃ (PZN)–0.2Pb(Ni₁/₃Nb₂/₃)O₃ (PNN) piezoelectric ceramics with different Pb(Fe₂/₃W₁/₃)O₃ (PFW) doping contents were investigated to obtain a formulation that can be co-fired with silver (Ag) electrodes below 900 °C for multilayer ceramics. PFW was introduced as a sintering aid, which effectively reduced the sintering temperature of the ceramics from 1200 °C to 850 °C. The sample with x = 0.12 exhibited the largest average grain size of 1.72 μm, achieving excellent comprehensive properties with piezoelectric constant (d₃₃) = 477 pC/N, planar electromechanical coupling factor (k_p) = 0.68, dielectric loss tangent (tanδ) = 0.0154, and relative density of 98.2%. Furthermore, the feasibility of fabricating piezoelectric actuators based on this optimized composition was verified. Multilayer piezoelectric devices were prepared via screen printing combined with a carbon-based sacrificial layer method. No obvious interdiffusion was observed at the interface between the Ag internal electrodes and the ceramic matrix. The 9-layer device attained a high d₃₃ = 1470 pC/N and produced a large displacement of 5.5 μm (corresponding to a strain = 1.83%) with a voltage of 500 V. The thickness of the multilayer piezoelectric film was approximately 0.3 mm. Through this, the feasibility of manufacturing a multilayered actuator with an Ag electrode was confirmed through the composition of 0.58PZT–0.1PZN–0.2PNN–0.12PFW. Full article

This study investigated the influence of Mn content (70 wt.%, 75 wt.%, and 80 wt.%) on the microstructure, mechanical properties and damping capacity of Mn-Cu alloys using X-ray diffraction (XRD), scanning electron microscopy (SEM), transmission electron microscopy (TEM), mechanical testing and dynamic mechanical analysis (DMA). The results indicate that during cooling after aging, the Mn-Cu alloy undergoes martensitic transformation, resulting in a dual-phase structure of fcc and fct. The 70 wt.% Mn alloy exhibits a mixed-grain structure with mostly long, straight twin bands, while the 75 wt.% and 80 wt.% Mn alloys consist of fine equiaxed grains with mostly intersecting twin bands. The microstructure determines the properties of the alloy. As the Mn content increases, the mechanical properties initially increase and then decrease, and the 75 wt.% Mn alloy has the best mechanical performance (UTS = 534 MPa, YS = 263 MPa). In contrast, the damping capacity shows a decreasing trend, and the 70 wt.% Mn alloy exhibits the best damping capacity (tanδ = 0.064). The main damping peak of tanδ in Mn-Cu alloys is derived from the relaxation of the twin boundaries, and the less obvious secondary peak is the internal friction peak of martensitic transformation. Full article

With the capacity of generators continuing to increase, higher demands are placed on the heat dissipation of epoxy resin (EP), the main insulation material used in stator bars and windings. To overcome its low thermal conductivity, a multiscale hybrid filler strategy was adopted to investigate the effects of spherical Al₂O₃ (10 and 1 μm), platelet BN (1 μm), and SiO₂ (50 nm) on the thermal and insulating properties of EP composites. Unlike conventional studies focusing on individual fillers, this work highlights the synergistic design of fillers with different sizes and morphologies. The filler ratios were optimized by finite element simulation, and the composites were prepared by melt blending. The results show that, at a total filler loading of 38.5 wt%, the EP composite filled with spherical Al₂O₃ particles of 10 and 1 μm, platelet BN of 1 μm, and nano-SiO₂ of 50 nm achieves a thermal conductivity of 0.5497 W/(m·K), corresponding to an increase of 158.2% compared with pure EP (0.2129 W/(m·K)). This enhancement is attributed to the synergistic effect of multiscale and multishape fillers, where large Al₂O₃ particles form the main thermally conductive framework, small Al₂O₃ particles fill the gaps, platelet BN acts as a bridging filler, and nano-SiO₂ improves the interfacial region. In addition, the composite exhibits low relative permittivity and dissipation factor tanδ in the frequency range of 10⁻²–10⁶ Hz, and its breakdown strength reaches 65.99 kV/mm. These results demonstrate that simulation-guided multiscale hybrid filler design is an effective strategy for improving the thermal conductivity of EP while maintaining acceptable insulating performance. Full article

This study investigated the linear and nonlinear viscoelastic properties of cherry Jell-O^® samples through oscillatory shear methods including small-amplitude (SAOS), medium-amplitude (MAOS), and large-amplitude (LAOS) experiments. Cherry Jell-O^® showed solid-like gel behavior (tanδ < 1) up to γ₀:160%. The sample transitioned into nonlinear behavior above γ_cri: 16% and was classified as type III (weak strain overshoot). Chebyshev coefficients revealed that the samples exhibited strain-stiffening (e₃/e₁ > 0) and shear-thickening (v₃/v₁ > 0) intracycle behavior in the nonlinear region. Both elastic and viscous Lissajous–Bowditch curves showed distortions from elliptical trajectories in the nonlinear region. FTIR spectra showed LAOS deformation-induced structural changes, particularly in the Amide I and Amide II regions. Tanδ decreased below 1 upon the removal of the LAOS deformation. These findings showed that although LAOS deformation induced molecular changes in the cherry Jell-O^® samples, their elasticity was largely preserved by a strong, resilient network. Full article

This study investigates the combined effects of thermal and moisture aging on PVC-insulated low voltage (LV) photovoltaic (PV) cables using an accelerated-aging design to represent realistic PV operating conditions commonly encountered in hot and humid climates. Thermal aging was carried out at 90 °C for five aging cycles, with each thermal cycle followed by controlled moisture injection to simulate moisture stress. The degradation behavior was evaluated using broadband dielectric spectroscopy, FTIR analysis, and Shore D hardness measurements. Changes in dielectric dissipation factor (tanδ) and real permittivity (${\epsilon }^{\prime }$) were analyzed over a wide frequency range, with 100 kHz selected for its high sensitivity to aging-induced oxidation-related dipolar and interfacial polarization mechanisms. Degradation indices (DI) and degradation rates (DR) were derived from tanδ and correlated with mechanical and chemical changes. The results showed a 5% and 7% increase in tanδ at 100 kHz and in hardness, respectively, with decreases of 68% and 75% in the carbonyl and hydroxyl indices, respectively. Three distinct aging stages were identified: early thermo-oxidation with limited functional impact; mid-stage dehydrochlorination and moisture interaction; and late-stage chain scission, plasticizer loss, and insulation stiffening. The findings demonstrate the importance of climate-specific aging assessment and confirm the effectiveness of integrated electrical, mechanical, and chemical diagnostics for PV cable condition monitoring. Full article

This paper proposes a small size meander-line patch antenna which is designed to have biomedical telemetry applications using the Industrial, Scientific and Medical (ISM) band from 2.40 to 2.48 GHz supported by the equivalent circuit model (ECM). Antenna miniaturization is realized by the effective use of several slot structures placed in the rectangular microstrip patch structure, in order to realize electrical length extension and reduce the physical size. The antenna has overall dimensions of 12 × 22 × 0.787 mm³ and is made on a low-loss Arlon AD 450 (ε_r = 4.50 and tanδ = 0.0035) dielectric substrate, which has the desired stable electrical behavior and, importantly, can be used in implantable environments. Experimental validation is done by implanting the fabricated prototype into a laboratory-manufactured tissue-mimicking phantom, and it showed good agreement with simulated results. The designed antenna has a peak gain of 1.29 dBi in free space and −24.99 dBi at a frequency of 2.45 GHz and a fractional impedance bandwidth of about 250 MHz, which will guarantee reliable operation in the face of diversity and fluctuation in the surrounding environment (biological tissues). Furthermore, specific absorption rate (SAR) analysis is carried out in order to comply with international safety standards with peak SAR values kept within the permissible level of 2 W/kg for 10 g averaging tissue. The results show that the proposed antenna provides a good trade-off between the reduction in size, radiation performance and safety to the patient, making it a good candidate for short-range in-body wireless communication, implantable medical devices, and biomedical monitoring systems. Full article

To address the lack of systematic comparison regarding rheological properties and the unclear structure–property relationships among three core fracturing fluid materials including synthetic polymers, vegetable gums, and microbial polysaccharides, this study selected acrylamide-based polymers, hydroxypropyl guar gum and xanthan gum as the representative systems. The steady-state viscosity, rheological curves, thixotropy, viscoelasticity, and temperature-shear resistance of the three samples were systematically characterized at concentrations ranging from 0.1 to 0.7 wt% using an MCR301 rotational rheometer. The outcomes indicate that the structural strength values of all three materials increase with rising concentration, but their rheological behaviors and stability differ significantly due to distinct molecular structures. The acrylamide-based copolymer forms a temporary network via weak hydrogen bonds (amide-carboxyl or amide-amide) and physical entanglements, exhibiting thixotropy and a stress pre-elastic response. The most significant effects occur at 0.7 wt%, with a thixotropic loop area of 2.874 Pa·s⁻¹ and a stress overshoot of 4.97 Pa.; hydroxypropyl guar gum has insufficient thermal stability and poor heat resistance. Its viscosity retention rate is as low as 31%, and it always exhibits a solution-type rheological property of G′ < G″; the xanthan gum exhibits elastic gel properties with tanδ < 1 due to its double-helix molecular structure. It has excellent temperature shear tolerance and the viscosity retention value can reach up to 98.6 mPa·s. Two mathematical models were established and demonstrated strong applicability: a modified Carreau model for flow curve fitting yielded a coefficient of determination (R²) greater than 0.95, enabling accurate description of fluid-type transitions; a four-parameter equation for temperature–shear resistance curves also achieved an R² above 0.95, effectively characterizing viscosity evolution with temperature. Full article

Bismuth layer-structured ferroelectrics (BLSFs) are core candidates for high-temperature piezoelectric applications owing to their excellent thermal stability and fatigue resistance, yet traditional Bi₄Ti₃O₁₂ (BiT)-based ceramics suffer from limited piezoelectric performance. To address this, MBi₄Ti₄O₁₅-Bi₄Ti₃O₁₂ (M=Ba, Sr, Ca) symbiotic structure bismuth-layered piezoelectric ceramics were fabricated via the conventional solid-state reaction method. Their crystal structure, microstructure, and electrical properties were systematically characterized using a X-ray diffractometer, scanning electron microscope, high-temperature dielectric spectrometer, and quasi-static d₃₃ meter to explore the effects of different A-site divalent elements. Results show that all samples form a pure-phase symbiotic structure with the P2₁am space group, without secondary phases. The lattice constant decreases with increasing A-site ionic radius, while symbiosis-induced lattice mismatch and long-range disorder refine grains, reduce aspect ratio, lower conductivity, enhance spontaneous polarization, and improve piezoelectric properties. The ceramics exhibit d₃₃ of 10 to 15 pC/N and T_C of 502 to 685 °C, with SrBi₄Ti₄O₁₅-Bi₄Ti₃O₁₂ showing optimal comprehensive performance (d₃₃ ≈ 15 pC/N, T_C = 593 °C, tanδ = 0.6% at 1 kHz/475–575 °C, and a low AC conductivity of 5.3 × 10⁻⁵~4.8 × 10⁻⁴ S/m). This study improves bismuth-layered ceramics’ performance via A-site regulation and symbiotic structure design, offering theoretical and technical support for high-performance lead-free high-temperature piezoelectric ceramics. Full article

The rapid advancement of fifth-generation (5G) communication technologies has increased the demand for high-frequency circuits that offer high signal transmission rates and low latency. Traditional epoxy resin materials, characterized by their high dielectric constant (εr) and dielectric loss (tanδ), lead to significant signal attenuation and reflection in high-frequency applications, thus limiting their suitability for modern communication devices. Accordingly, reducing the dielectric constant and dielectric loss of epoxy resins has become a prominent research focus in materials science. This paper reviews various methods for developing low-dielectric epoxy resin composites, emphasizing strategies to reduce polarization and material density. It subsequently provides a concise analysis of the advantages and current challenges associated with each technique and offers insights into potential future research directions. Full article

The article studies the influence of chlorosulfonated polyethylene CSM 40 as a compatibilizer on the curing characteristics of the rubber compound, dynamic mechanical analysis, morphology, physico-mechanical and performance properties of vulcanized rubber based on a compound of ethylene propylene diene monomer EPDM S 501A and nitrile butadiene NBR 2645 rubbers. DMA studies indicate that the temperature dependence of tanδ for vulcanizates with and without a compatibilizer based on EPDM S 501A/NBR 2645 at a ratio of 75/25 parts per hundred parts of rubber (phr) has a bimodal character, which indicates the incompatibility of the rubber phases. The temperature dependence for EPDM S 501A/NBR 2645 vulcanizates (25/75 phr) with and without a compatibilizer has a monomodal form, which characterizes the improved compatibility of the rubber phases. SEM showed that a clearly defined microporous structure is observed on a cleavage of vulcanizate sample EPDM/NBR (25/75 phr) without a compatibilizer; with the addition of CSM 40, this feature is retained, but becomes less pronounced. It is shown that vulcanizates containing the compatibilizer CSM 40 are characterized by increased strength properties and hardness compared to vulcanized rubber without a compatibilizer. It was established that the vulcanized rubber based on EPDM S 501A/NBR 2645/CSM 40 (25/75/5 phr) is characterized by the smallest changes in the elastic-strength properties and hardness of vulcanizates after a day of thermo-oxidative aging in air and their weight after exposure to industrial oil I-20A and standard petroleum fluid SZhR-1 at room temperature among vulcanizates based on EPDM S 501A and NBR 2645. The vulcanizate of the rubber compound, including a compound of EPDM/NBR (25/75 phr) with a compatibilizer CSM 40 in an amount of 5 phr (2.88 wt.%), is characterized by stable physico-mechanical properties and improved performance properties. This rubber compound can be used for the manufacture of rubber products operating under the influence of oils and hydrocarbon environments. Full article

Nano/microsized organic fillers play an important role in developing new types of polyurethane (PU) composites. In this study, microsized hollow poly(styrene-alt-maleic anhydride) (PSMA) microsphere was grafted with polytetramethylene glycol (PTMG) or 4-butanediol (BDO) and subsequently incorporated into a PU matrix to fabricate composites. For comparison, composites containing pristine hollow PSMA microsphere and neat PU were also prepared. The mechanical properties, damping properties, thermal stability, crystalline structure and water uptake of the composites and neat PU were investigated. The results show that the incorporation of surface-grafted hollow PSMA microspheres could effectively improve the mechanical and damping properties of PU, increasing tensile strength to 18.7 MPa, raising the tanδ peak to 1.05 and broadening the effective damping range (tanδ > 0.3) to 39.1–40.4 °C. Both PU composites and neat PU exhibited three-step decomposition regions. In the first decomposition region, the thermal stability of PU composites was improved slightly except that it was filled with BDO-graft-PSMA microspheres. But in the second and third decomposition regions, all PU composites showed lower thermal stability than neat PU. The introduction of hollow PSMA microspheres also reduced the crystallinity of the PU matrix, which is attributed to the large diameter of the microspheres disrupting crystalline order. Full article

We determined the reference characteristics of the loss tangent and the real component of the complex permittivity of the cellulose-insulating oil–water nanodroplet nanocomposite with a moisture content of 5.17% by weight in pressboard. Such a high moisture content was selected because a value close to 5% by weight is critical, and reaching it may lead to catastrophic transformer failure as well as contamination of the natural environment with poorly biodegradable mineral oil and products of its incomplete combustion. Based on the measurement results, the values of the loss tangent and the real and imaginary components of the complex permittivity of the power transformer insulation system, consisting of moistened pressboard and insulating oil, were determined according to CIGRE. These values were obtained for both factory-new and moistened mineral oil. It was found that oil moisture content has a significant impact on the tanδ characteristics of strongly moistened liquid–solid insulation in the lowest frequency range. In the intermediate frequency range, this effect gradually decreases and then practically disappears. In the frequency range above 50 Hz, the tanδ values depend on the moisture content in cellulose and on the geometrical parameters of the insulation components in the CIGRE system, and do not depend on the oil moisture content. The influence of oil moisture on the estimation of cellulose moisture content becomes noticeable starting from a water content of 2% in pressboard. This should be taken into account in insulation condition analysis and in moisture level estimation in order to detect a critical state threatening catastrophic failure of a power transformer. It was also determined that the real component of the complex permittivity depends only weakly on oil moisture, and only in the low-temperature and low-frequency ranges. In contrast, the imaginary component of the complex permittivity depends on oil moisture practically in the same way as the loss tangent of the power transformer insulation system. Full article

Giant dielectric oxides are attractive for next-generation capacitors and related applications, but their practical use is limited by high loss tangent (tanδ), strong temperature dependence of dielectric permittivity (ε′), and the need for energy-intensive high-temperature sintering. To address these challenges, this study focuses on the development of (In_0.5Ta_0.5)_xTi_1−xO₂ (ITTO, x = 0.02–0.06) ceramics via a green egg-white solution route, targeting high dielectric performance at reduced processing temperatures. The as-calcined powders exhibited the anatase TiO₂ phase with particle sizes of ~20–50 nm. These powders promoted densification at a sintering temperature of 1300 °C, significantly lower than those of conventional co-doped TiO₂ systems. The resulting ceramics exhibited refined grains, high relative density, and homogeneous dopant incorporation, as confirmed by XRD, SEM/TEM, EDS mapping, and XPS. Complementary density functional theory calculations were performed to examine the stability of In³⁺/Ta⁵⁺ defect clusters and their role in electron-pinned defect dipoles (EPDDs). The optimized ceramic (x = 0.06, 1300 °C) achieved a high ε′ of 6.78 × 10³, a low tanδ of 0.038, and excellent thermal stability with Δε′ < 3.9% from 30 to 200 °C. These results demonstrate that the giant dielectric response originates primarily from EPDDs associated with Ti³⁺ species and oxygen vacancies, in agreement with both experimental and theoretical evidence. These findings emphasize the potential of eco-friendly synthesis routes combined with rational defect engineering to deliver high-performance dielectric ceramics with reliable thermal stability at reduced sintering temperatures. Full article
