Due to the long operation period of Beijing Metro Line 2 and the complex surrounding building environment, this paper comprehensively studied the mechanical properties of new tunnels using close-fitting undercrossing based on pre-support technology. To control structural deformation caused by the expansion project, methods such as laboratory tests, numerical simulation, and field tests were adopted to systematically analyze the tunnel mechanics during the undercrossing of existing metro lines. First, field tests were carried out on the existing Line 2 and Line 3 tunnels during the construction period. It was found that the close-fitting construction based on pre-support technology caused small deformation displacement in the subway tunnels, with little impact on the smoothness of the existing subway rail surface. The fluctuation range was −1 to 1 mm, ensuring the safety of existing subway operations. Then, a refined finite difference model for the close-fitting undercrossing construction process based on pre-support technology was established, and a series of field and laboratory tests were conducted to obtain calculation parameters. The reliability of the numerical model was verified by comparing the monitored deformation of existing structures with the simulated structural forces and deformations. The influence of construction methods on the settlement changes of existing line tracks, structures, and deformation joints was discussed. The research results show that this construction method effectively controls the settlement deformation of existing lines. The settlement deformation of existing lines is controlled within 1~3 cm. The deformation stress of the existing lines is within the concrete strength range of the existing structure, and the tensile stress is less than 3 MPa. The maximum settlement and maximum tensile stress of the station in the pre-support jacking scheme are −5.27 mm and 2.29 MPa. The construction scheme with pre-support can more significantly control structural deformation, reduce stress variations in existing line structures, and minimize damage to concrete structures. Based on the monitoring data and simulation results, some optimization measures were proposed. Full article

Surface settlement prediction is crucial to assess the safety of subway station construction. To overcome challenges such as missing on-site settlement data and a limited number of monitoring points, this study proposes a composite prediction model that integrates finite element analysis, a time-series interval GA-BP neural network, and variational mode decomposition (VMD) techniques. Using the Dongba-zhongjie Station in Beijing Subway Line 3 as a case study, surface settlement predictions were made for both typical monitoring points and randomly selected feature points throughout the construction period, followed by validation. The experimental results show that the root mean square error (RMSE) of the finite element model is 15.77%, confirming the model’s effectiveness. As excavation progressed through the second underground floor and bottom plate, the settlement at the maximum settlement point began to rebound, and the structure tended to stabilize. At this stage, construction of the comprehensive utility tunnel above the station can proceed concurrently. Full article

The analysis of the impact of the construction of the subway protection zone on the adjacent subway tunnel has become the premise on which to ensure the safe operation of the tunnel. The need for expert members to carry out safety assessments based on specific calculations to determine the impact of construction on the safety of protected tunnels is extremely inconvenient for safety management and significantly reduces management efficiency. This paper analyzes and qualitatively judges the influence range and disturbance size of pile foundation construction, shallow foundation engineering, and foundation pit excavation. Based on relevant research results from scholars and numerical simulation methods, quantitative analysis and comparison are performed on the parameter sensitivity of pile foundation engineering, shallow foundation engineering, and foundation pit engineering along the subway line, and the influence of multi-factor combination is studied and discussed to obtain the influence sensitivity of each factor. The results show that the increase in pile spacing can effectively reduce the pile group effect. The sensitivity of subway tunnel settlement displacement is mainly controlled by the settlement displacement value. The larger the settlement displacement is, the stronger the sensitivity is. The loaded pile foundation arranged along the direction of the subway tunnel has more obvious disturbance to the subway tunnel than that arranged perpendicular to the direction of the subway tunnel. Full article

Subway tunnels excavated in soil–rock composite strata face great challenges due to the prevalence of inner defects. The instability of tunnels in these strata poses significant risks to construction safety. In this paper, indoor experiments are adopted to study the instability process of a subway tunnel in soil–rock composite strata influenced by inner cavities. A total of six groups of tests are designed based on the location of the cavity and the distance of the cavity from the tunnel. High-resolution monitoring techniques are employed to capture the real-time deformation and failure process of strata. The results show that a cavity in the strata significantly affects the stability of the strata after the tunnel excavation. The existence of a cavity increases ground deformation, and a cavity at different locations affects ground deformation. The strata around the cavity are the first to experience failure by the upper loads applied after the tunnel is excavated. The location of the cavity changes the stress distribution state of the strata and thus alters the emergence of cracks, which finally disturbs the collapse process and pattern of the composite strata. The probability and collapse range increase when the tunnel excavation impact zone is connected with the cavity weakening zone. The findings can provide technical support for the collapse prevention and safety control of subway tunnels in composite strata with internal defects. Full article

In subway tunnel construction, current hand–eye integrated drilling robots use a camera mounted on the drilling arm for image acquisition. However, dust interference and long-distance operation cause a decline in image quality, affecting the stability and accuracy of the visual recognition system. Additionally, the computational complexity of high-precision detection models limits deployment on resource-constrained edge devices, such as industrial controllers. To address these challenges, this paper proposes a dual-arm tunnel drilling robot system with hand–eye separation, utilizing the first-frame localization and follower tracking method. The vision arm (“eye”) provides real-time position data to the drilling arm (“hand”), ensuring accurate and efficient operation. The study employs an RFBNet model for initial frame localization, replacing the original VGG16 backbone with ShuffleNet V2. This reduces model parameters by 30% (135.5 MB vs. 146.3 MB) through channel splitting and depthwise separable convolutions to reduce computational complexity. Additionally, the GIoU loss function is introduced to replace the traditional IoU, further optimizing bounding box regression through the calculation of the minimum enclosing box. This resolves the gradient vanishing problem in traditional IoU and improves average precision (AP) by 3.3% (from 0.91 to 0.94). For continuous tracking, a SiamRPN-based algorithm combined with Kalman filtering and PID control ensures robustness against occlusions and nonlinear disturbances, increasing the success rate by 1.6% (0.639 vs. 0.629). Experimental results show that this approach significantly improves tracking accuracy and operational stability, achieving 31 FPS inference speed on edge devices and providing a deployable solution for tunnel construction’s safety and efficiency needs. Full article

Air pollution remains a critical global health concern, with 91% of the world’s population exposed to air quality exceeding World Health Organization (WHO) standards and indoor pollution causing approximately 3.8 million deaths annually due to incomplete fuel combustion. Subways, as major public transportation modes in densely populated cities, can exhibit fine particulate matter (PM) levels that surpass safety limits, even in developed countries. Contributing factors include station location, ambient air quality, train frequency, ventilation efficiency, braking systems, tunnel structure, and electrical components. While elevated PM levels in underground platforms are recognized, the vertical and horizontal variations within stations are not well understood. This study examines the vertical and horizontal distribution of PM2.5 and PM10 levels at Shibuya Station, a structurally complex hub in the Tokyo Subway System. Portable sensors were employed to measure PM concentrations across different platform levels—both above and underground—and at various locations along the platforms. The results indicate that above-ground platforms have significantly lower PM2.5 and PM10 levels compared to underground platforms (17.09 μg/m³ vs. 22.73 μg/m³ for PM2.5; 39.54 μg/m³ vs. 56.98 μg/m³ for PM10). Notably, the highest pollution levels were found not at the deepest platform but at the one with the least effective ventilation. On the same platform, PM levels varied by up to 63.72% for PM2.5 and 120.23% for PM10, with elevated concentrations near the platform extremities compared to central areas. These findings suggest that ventilation efficiency plays a more significant role than elevation in vertical PM variation, while horizontal differences are likely influenced by piston effects from moving trains. This study underscores the risk of exposure to unsafe PM2.5 levels in underground platforms, particularly at platform extremities, highlighting the need for improved ventilation strategies to enhance air quality in subway environments. Full article

Recently, there has been a growing interest in underground construction safety, during activities such as subway construction, underground mining, and tunnel excavation. While Internet of Things (IoT) sensors help to monitor these conditions, large-scale deployment is limited by high power needs and complex tunnel layouts, making real-time response a critical challenge. A delay-sensitive multi-sensor multi-base-station routing scheduling method is proposed for the IoT in underground mining. First, a mixed network topology of wireless and wired networks is formed based on the irregular distribution characteristics of multiple tunnels in the mine construction environment. Based on this topology, a multi-sensor and multi-base-station real-time routing scheduling problem is proposed, proving that the problem is NP-hard. Secondly, the corresponding solving algorithms are designed based on the greedy strategy and the heuristic strategy. Finally, an experimental platform is built, and the performance of the proposed algorithm is compared and analyzed. Full article

Currently, subway and underground engineering projects are vital for alleviating urban congestion and enhancing citizens’ quality of life. Among these, excavation engineering for foundation pits involves the most accidents in geotechnical engineering. Although there are various construction methods, most face issues such as a large footprint, high investments, resource waste, and low mechanization. Addressing these, this paper focuses on a subway foundation pit project in Guangzhou using mechanical shaft sinking technology. Using intelligent cloud monitoring, we analyzed the stress–strain patterns of the cutting edge and segments. The results showed significant improvements in construction efficiency, cost reduction, safety, and resource conservation. Based on this work, this paper makes the following conclusions: (1) The mechanical shaft sinking method offers advantages such as small footprint, high mechanization, minimal environmental impact, and cost-effectiveness. The achievements include a 22.22% reduction in construction time, a 20.27% decrease in investment, and lower worker risk. (2) Monitoring confirmed that all cutting edge and segment values remained safe, demonstrating the method’s feasibility and rationality. (3) Analyzing shaft monitoring data and field uncertainties, this study proposes recommendations for future work, including precise segment lowering control and introducing high-precision total stations and GPS technology to mitigate tunneling and assembly inaccuracies. The research validates the mechanical shaft sinking scheme’s scientific and logical nature, ensuring safety and contributing to technological advancements. It offers practical insights, implementable suggestions, and significant economic benefits, reducing project investment by RMB 41,235,600. This sets a benchmark for subway excavation projects in South China and beyond, providing reliable reference values. Furthermore, the findings provide valuable insights and guidance for industry peers, enhancing overall efficiency and sustainable development in subway construction. Full article

In evaluating the construction safety of the building in the subway tunnel using the cover-and-cut method, the main objective is to analyze the diaphragm wall, the central pillar, and the roof. This article conducted a blasting vibration test based on the background of the Guiyang Metro Line 3 project and used the FLAC3D software to establish a three-dimensional numerical model. The results showed that the peak particle velocity (PPV) decreased with increasing distance from the blasting center. The PPV measured at the underground diaphragm wall was 1.424 cm/s, while at the bottom of the central pillar it was 1.482 cm/s. The predicted PPV on the roof was up to 1.537 cm/s, which met the safety standards. According to the cloud map of particle vibration velocity and the comprehensive analysis of particle vibration velocity, the degree of impact of artificial structures in the subway tunnel was the central pillar, the underground diaphragm wall, and the roof in order from high to low. After eight blasting operations per day, the vibration velocity trend at the vulnerable point of the central column increases, but it will not exceed the safety standard. Full article

With the widespread construction of the subway in the Chinese mainland, the environmental vibration caused by subway operation has attracted increasing attention. Train-induced environmental vibrations can cause structural deformation, uneven settlement of line foundations, and tunnel leakage, affecting the structural safety of lines and foundations. This research focuses on a segment of the Nanchang Metro Line 3, which has been chosen as the subject of investigation. A numerical model was developed to analyze the subway train-induced environmental vibration, employing the finite element method (FEM). Utilizing a numerical model, an investigation was conducted to examine the impact of train speed on the subway train-induced environmental vibration, the train-induced environmental vibration transmission characteristics were analyzed, and the control effects of vibration reduction tracks on train-induced environmental vibration were discussed. Train-induced vibration tests were also conducted on Nanchang Metro Line 3 to verify the control effects of various vibration reduction tracks. The results indicate that the subway train-induced environmental vibration rises as the train speed goes up, and the vibration peaks always appear around 63 Hz. When the train speed doubles, the Z-vibration level increases from about 5.1 dB to 5.9 dB. Subway train-induced environmental vibration shows a fluctuating decreasing trend with increasing distance from the centerline of the tunnel. The Z-vibration level reaches its maximum 4 m away from the centerline of the tunnel. Compared with the embedded sleeper, the vibration-damping fastener exhibits a vibration reduction effect of about 9 dB to 18 dB, the rubber vibration-damping pad exhibits a better vibration reduction effect of about 16 dB to 24 dB, and the steel spring floating plate exhibits the best vibration-damping effect of about 18 dB to 28 dB. The calculated Z-vibration levels are basically consistent with the measured values, indicating the accuracy of the calculated results of the control effects of the vibration reduction tracks. Full article

This study focuses on the safe evacuation strategy and evacuation process in the subway train under the fires. The subway station evacuation mode should be adopted if the power system of a subway train is normal on fire. While, the tunnel evacuation mode should be adopted if the power system of the train fails because of the effects of fire. Under the tunnel evacuation mode, the direction of tunnel smoke should be opposite to that of most passengers, and passengers should be evacuated toward the fresh wind. By using the numerical simulation software Pathfinder and PyroSim, the passenger evacuation time under different conditions is calculated, and the safety of the evacuation process is evaluated. The results show that the evacuation time of the station evacuation mode is obviously shorter than that of the tunnel evacuation mode. With the same conditions, the evacuation time of the tunnel evacuation mode is 2193 s, which is about four times as much as the evacuation time of the station evacuation mode (526 s). The total evacuation time increases with the total number of passengers and the proportion of older people and children. Under an oil pool fire, which is an extreme fire condition, the fire environment inside the train may reach a level threatening the passengers’ safety before the evacuation is complete, even before the door opens; therefore, special attention should be paid to the safety issues in stage from the fire begins to the evacuation complete. Full article

Analyzing the mechanisms of soil instability in tunnels due to sudden water ingress is essential for construction safety. This kind of problem belongs to the category of seepage deformation, mostly due to the near tunnel range of water pipeline blowing cracks and heavy rainfall flooding rainwater into the tunnel. Distinguished from general infiltration behavior, the relevant problems have the characteristics of rapid occurrence and short action time. This study develops a 3D fluid–solid coupling model for soil deformation in tunnels with water ingress, grounded in Biot’s theory and Darcy’s law while considering water level variations within the tunnel. The governing equations are discretized in space and time, and the model’s accuracy is validated through comparison with actual measurements from a Zhengzhou subway project. The study analyzes pore pressure, stress-deformation responses, and surface settlement patterns in surrounding soil and rock mass under soil–water coupling. The findings show that (1) the tunnel cavern, as a seepage source, has minimal impact on the lateral settlement trough width, while seepage mainly affects the vertical deformation of surrounding rock; (2) pressure dissipation exhibits hysteresis in clay strata; (3) water ingress increases soil saturation and decreases effective stress, resulting in persistent surface settlement until drainage. There is a minimal discrepancy between model-calculated and measured settlements. Full article

Soft marine soil exhibits unique mechanical properties that can lead to significant deformation and instability in the surrounding rock of urban subway tunnels. This presents a critical challenge for tunnel engineering researchers and designers. This thesis investigates the stability characteristics of surrounding rock in marine soft soil tunnels under cyclic loading conditions. Focusing on the shield tunnel segment between Left Fortress Station and Taiziwan Station of Shenzhen Urban Rail Transit Line 12, a discrete–continuous coupled numerical analysis method is employed to examine the deformation characteristics of the surrounding rock. This analysis takes into account the effects of dynamic loads resulting from train operations on the arch bottom’s surrounding rock. The findings indicate that damage to the surrounding rock occurs gradually, with the marine soft soil layer, particularly at higher water content, being prone to substantial plastic deformation. Additionally, under the influence of train vibration loads, the degree of vertical fluctuation in the internal marine soft soil diminishes with increasing depth from the bottom of the tunnel arch. This coupled numerical analysis approach offers valuable insights and methodologies for assessing the structural safety of tunnel projects throughout their operational periods. Full article

Modern subway systems have increased in size and complexity, and this growth presents significant challenges for planners of emergency evacuations. In this study, the effectiveness of the simplified and advanced evacuation analysis methods recommended by the International Maritime Organization (IMO) are evaluated for Guryong Station in Seoul, South Korea. The simplified evacuation analysis method facilitates rapid assessments by using general parameters, while the advanced evacuation analysis entails performing detailed simulations of human behavior and physical interactions. Our findings indicate that the results of the simplified evacuation analysis method are reasonably close to those of the more time-consuming advanced evacuation analysis method, thereby demonstrating the practical applicability of the former method for conducting initial evacuation safety assessments. Specifically, both the simplified and advanced methods showed a 20% reduction in Total Evacuation Time when tunnel evacuation routes were utilized. This finding demonstrates that the simplified method can produce results comparable to the advanced method, making it a reliable tool for initial assessments and for evaluating alternative strategies to reduce evacuation time. By demonstrating that the simplified evacuation analysis method can yield reliable results, we provide valuable insights for developing smart, resilient cities with efficient emergency-response capabilities. Full article

High-precision and rapid detection of apparent defects in subway tunnel linings is crucial for ensuring the structural integrity of tunnels and the safety of train operations. However, current methods often do not adequately account for the spatial characteristics of these defects and perform poorly in detecting and extracting small-scale defects, which limits the accuracy of detection and geometric parameter extraction. To address these challenges, this paper proposes an efficient algorithm for detecting and extracting apparent defects in subway tunnels. Firstly, YOLOv8 was selected as the foundational architecture due to its comprehensive performance. The coordinate attention module and Bottleneck Transformer 3 were then integrated into the model’s backbone to enhance the focus on defect-prone areas and improve the learning of feature relationships between defects and other infrastructure. Subsequently, a high-resolution detection layer was added to the model’s head to further improve sensitivity to subtle defects. Additionally, a low-quality crack dataset was created using an open access dataset, and transfer learning combined with Real-ESRGAN was employed to enhance the detail and resolution of fine cracks. The results of the field experiments demonstrate that the proposed model significantly improves detection accuracy in high-incidence areas and for small-scale defects, achieving a mean average precision (mAP) of 87% in detecting cracks, leakage, exfoliation, and related infrastructure defects. Furthermore, the crack enhancement techniques substantially improve the representation of fine-crack details, increasing feature extraction accuracy by a factor of four. The findings of this paper could provide crucial technical support for the automated operation and maintenance of metro tunnels. Full article
