With the expansion of offshore oil and gas resources to deepwater areas, the problem of the vortex-induced vibration of marine risers, as a key structure connecting offshore platforms and subsea wellheads, has become increasingly prominent. At present, there are few reviews on the vortex-induced vibration of flexible risers. This review provides a detailed discussion of vortex-induced vibration in marine risers. This review begins with the engineering background. It then systematically analyzes the key factors that influence VIV response. These factors include the riser’s structural parameters, such as aspect ratio and mass ratio. They also include the external fluid environment. Next, this review evaluates current VIV suppression strategies by analyzing specific experimental results. It compares the effectiveness and trade-offs of passive techniques. It also examines the potential and limitations of active methods, which often use smart materials, like piezoelectrics. This study highlights the major challenges in VIV research today. These challenges relate to prediction accuracy and suppression efficiency. Key problems include model uncertainty at high Reynolds numbers and the practical implementation of suppression devices in engineering systems. Finally, this paper presents an outlook on the future directions. It concludes that an intelligent, full-lifecycle integrity management system is the best path forward. Full article

Subsea wellheads and Christmas trees are commonly utilized in deepwater oil and gas development. However, the special structure of subsea wellheads makes it difficult to monitor casing–casing annular pressure buildup, which in turn poses a greater risk to the integrity of the wellbore. In order to analyze the effect of changes in the casing-free section and the sealed section on the variation in annulus volume, a new annular pressure buildup model of casing-cement sheath-formation deformation was established and verified according to the elastic deformation theory. Furthermore, the influence of casing deformation on annulus pressure buildup was analyzed. Results indicate that the error of annulus pressure buildup predicted by the multi-string mechanical model proposed in this paper that considers the deformation of the casing sealing section is approximately 13% lower than the one that does not consider this factor. This paper provides guidance for the design of casing strings in deepwater oil and gas wells, ensuring safe production. Full article

Subsea wellhead systems are the crucial equipment for the development of oil and gas resources offshore, while the sealing device plays a vital role as the main component of the wellhead system. Once the seal fails, it is necessary to retrieve the original wellhead system and either repair the sealing device or reinstall a new one. This will result in a delay in normal production and an increase in development costs. Therefore, a novel subsea wellhead sealing device is designed. A finite element analysis model is developed to study the underwater wellhead sealing mechanism regarding the equivalent stress and contact stress. The research results show that as the driving block gradually increases from 4 mm to 12 mm, the stress of the 12 convex parts on the sealing body also increases. The maximum equivalent stress reaches 3.5 times the yield limit, indicating that it has entered the yield stage and can achieve a more effective seal. The analysis of the contact stress of the sealing body reveals that the contact stress of the driving block increases, leading to plastic deformation of the sealing body while driving it to achieve a complete seal. In general, the finite element simulation results are consistent with the engineering practice. By analyzing the sealing characteristics, it can serve as the foundation for designing and providing theoretical support for the optimization of the metal-sealing structure. Full article

The vast reserves of natural gas hydrates in offshore areas present significant challenges to development. Surface well construction technology is crucial for the extraction of deepwater natural gas hydrates. To ensure the safety of the subsea wellhead during the drilling process for deepwater natural gas hydrates, a novel conductor suction pile device has been designed, comprising a combination of suction piles and surface conductors. And research has been conducted to investigate the lateral stability characteristics of the conductor suction pile. Drawing upon the pile foundation load-bearing theory and the equilibrium of the differential element, a theoretical analysis model and corresponding governing equations of the conductor suction pile system are established. A solution for a multi-point boundary value problem by simplifying the conductor suction pile system into a two-end free beam is proposed. The governing equations are then converted into a first-order differential equation system, and the four-stage Lobatto IIIa collocation method program for the multi-point boundary value problem is developed and resolved using MATLAB 2023a. Furthermore, a case study of a well in the South China Sea elucidates the effects of wellhead load and seabed soil properties on the lateral load-bearing capacity of the conductor suction pile system, verifying the collocation method’s validity against the results from the finite difference method. After conducting a comparative analysis of the lateral load-bearing performance between conductor suction piles and traditional surface conductors, it is observed that conductor suction piles exhibit lower horizontal displacement and bending moments compared to surface conductors. Therefore, conductor suction piles demonstrate a substantial safety margin. The research findings provide a theoretical basis for the lateral stability of conductor suction piles during deepwater natural gas hydrate drilling. This offers a safe and efficient method for surface well construction in the extraction of natural gas hydrates. Full article

In the current landscape of natural gas hydrate extraction, the lifting pump assumes a pivotal role as the essential equipment for conveying subsea fluidized hydrate slurry to the wellhead. The inherent shear-thinning characteristics of natural gas hydrate slurry, compounded by the complex multiphase flow conditions of the “gas-liquid-solid” system, present significant challenges to the operational efficiency and stability of the lifting pump. Consequently, this study adopts a hybrid approach, combining experimental and numerical simulations, to comparatively investigate the impact of non-Newtonian and viscous Newtonian fluids on the hydraulic performance, vortex structure evolution, and induced pressure fluctuations in a multiphase pump. Concurrently, a comparative analysis is conducted on the influence of these two fluid types on the distribution patterns of the “gas-solid” two-phase system. The research findings indicate that the apparent viscosity variations are more pronounced in the diffuser region compared to the impeller region. Under non-Newtonian fluid conditions, two separation vortices emerge at the trailing edge of the diffuser, as opposed to a single separation vortex in the viscous Newtonian fluid, with the latter exhibiting a smaller vortex structure scale. Moreover, the shear-thinning characteristics intensify the interaction between the separated vortex and the mainstream, resulting in an exacerbation of pressure fluctuations. In contrast to the viscous Newtonian fluid, the rotor–stator interaction and shear-thinning characteristics play a predominant role in pressure fluctuations, with shear-thinning attributes giving rise to low-frequency pressure fluctuations. Additionally, shear-thinning characteristics significantly influence the distribution behavior of the gas-solid two-phase flow. Full article

This research explores the geomechanical challenges associated with gas hydrate extraction in submarine slope zones, a setting posing a high risk of significant geological calamities. We investigate slope and wellbore deformations driven by hydrate decomposition within a subsea environment. Utilizing Abaqus, a fluid-solid-thermal multi-field coupling model for gas hydrate reservoirs was created. Hydrate decomposition during drilling is minimal, resulting in minor formation deformation near the wellbore. However, a year of hydrate production caused a maximum displacement of up to 7 m in the wellbore and formation, highlighting the risk of submarine landslides. This indicates the need for meticulous surveillance of formation subsidence and wellhead equipment displacement. In the aftermath of a hydrate-induced submarine landslide, both the hydrate layer and the overlying strata descend together, inflicting considerable damage on the formation and wellbore. Our study presents a holistic examination of the interplay between environmental geomechanics risks and engineering structure risks for submarine slope instability and wellbore stability during hydrate development, providing crucial insights for enhancing safety measures in hydrate drilling and production, and ensuring wellbore stability. Full article

During deepwater drilling, the subsea wellhead will be subjected to dynamic loads transmitted from the marine environment, floating drilling platform, riser, and blowout preventer (BOP). Therefore, complex dynamic responses will be induced, which will seriously affect the safety of the subsea wellhead. In this paper, considering the effect of auxiliary pipelines on the riser, a novel entire mechanical model of the floating platform–riser–BOP–subsea wellhead is established. By using the finite-difference method, the governing equations are solved. Finally, the dynamic bending moment and stress distribution of the subsea wellhead are obtained. Moreover, the model is verified by numerical simulation in Orcaflex. On this basis, the influence of the wave height, wave period, sludge height of the subsea wellhead, rotational stiffness of the lower flexible joint, and wall thickness of the conductor on the dynamic characteristics of the subsea wellhead is discussed. Analysis results show that the theoretical analysis results are in good agreement with the numerical simulation. The auxiliary pipelines have important influence on the dynamic characteristics of the subsea wellhead. Wave period is the most important factor affecting the mechanical behavior of the subsea wellhead. Wave height, wall thickness of the conductor, and sludge height are secondary factors affecting the mechanical behavior of the subsea wellhead. The rotational stiffness of the lower flexible joint has little influence on the mechanical behavior of the subsea wellhead. By solving the optimized mechanical model proposed in this paper, the dynamic characteristic of the subsea wellhead conforms more to the actual deepwater drilling conditions. This study has reference significance for the design and mechanical control of the subsea wellhead in deepwater drilling. Full article

Natural gas hydrate reservoir has been identified as a new alternative energy resource which has characteristics of weak cementation, low reservoir strength and shallow overburden depth. Thus, the stability of subsea equipment and formation can be affected during the drilling process. To quantitatively assess the vertical displacement of the formation induced by hydrate decomposition and clearly identify the influence laws of various factors on wellhead stability, this study established a fully coupled thermo-hydro-mechanical-chemical (THMC) model by using ABAQUS software. The important factor that affects the wellhead stability is the decomposition range of hydrates. Based on this, the orthogonal experimental design method was utilized to analyze the influence laws of some factors on wellhead stability, including the thickness of hydrate formation, initial hydrate saturation, overburden depth of hydrate sediment, and mudline temperature. The results revealed that the decomposition of hydrate weakens the mechanical properties of the hydrate formation, thus leading to the compression of the hydrate formation, further causing the wellhead subsidence. When the duration of drilling operations was 24 h and no decomposition of natural gas hydrate occurs, the wellhead subsidence is recorded at 0.053 m, this value increases with an increase in drilling fluid temperature. The factors were listed in descending order as following, according to their significance of influences on wellhead stability: the thickness of hydrate formation, initial hydrate saturation, overburden depth of hydrate sediment, and mudline temperature. Among the above factors, statistical significance of the mudline temperature was less than 15% confidence level, suggesting that the effect of mudline temperature on wellhead stability is negligible. These findings not only confirm the influence of hydrate decomposition on wellhead stability, but also suggest important implications for the drilling of hydrate-bearing formation. Full article

Subsea jumpers connecting the underwater wellhead and nearby manifold commonly undergo flow-induced vibration (FIV) due to the spatially frequent alteration in the flow direction, velocity, pressure and phase volume fraction of the oil–gas two-phase flow, potentially leading to fatigue damage. This paper reports the numerical results of the FIV of a reversed U-shaped jumper excited by gas–liquid two-phase flow, which evolves from the initial slug flow with a fixed gas–liquid ratio of 1:2 when transporting through the jumper. The FIV response and flow pattern evolution are examined with a gas flow rate of Q_g = 4–12 kg/s and a liquid flow rate of Q_L = 96–288 kg/s. When the gas–liquid flow passes through the jumper, the flow regime subsequently presents the slug flow, bubble flow, churn flow and imperfect annular flow. The out-of-plane response frequency coincides with the pressure fluctuation frequency for the four connecting bends, suggesting the fluid–structure interaction (FSI). Nevertheless, the vibration displacement is limited with the maximum value less than 0.0014D (where D is the jumper diameter) in the present considered flow rate range. Full article

The subsea wellhead (SW) system is a crucial connection between blowout preventors (BOPs) and subsea oil and gas wells. Excited by cyclical fatigue dynamic loadings, the SW is prone to fatigue failure, which would lead to the loss of well integrity and catastrophic accidents. Based on the Bayesian Regularization Artificial Neuron Network (BRANN), this paper proposes an efficient probability approach to predict the fatigue failure probability of SW during its entire life. In the proposed method, the BRANN fatigue damage (BRANN-FD) model reflecting the non-linear relationship between the input and output data was developed by the limited fatigue damage analysis data, which was utilized to generate thousands of non-numerical fatigue damage data of SW rapidly. Combining parametric and non-parametric estimation methods, the probability density function (PDF) of SW fatigue damage was determined to calculate the accumulation fatigue damage during service life. Using the logistic regression, the fatigue failure probability of SW was predicted. The application of the proposed approach was demonstrated by a case study. The results illustrated that the fatigue damage of SW would be viewed as obeying the Lognormal distribution, which could be used to obtain the accumulation fatigue damage in operation conveniently. Furthermore, the fatigue failure probability of SW nonlinearly increased with the increment in the accumulation fatigue damage of SW, which could be helpful to ensure the operation safety of SW in deepwater oil and gas development, especially for aged wellhead. Full article

It is important to accurately assess the interaction between the conductor and the soil to ensure the stability of the subsea wellheads during deepwater drilling. In this paper, numerical simulations were carried out to study the lateral dynamic bearing capacity of the conductor considering different contact models between the conductor and the soil. In particular, the contact surface model and contact element model were selected to study the dynamic behavior of pile–soil under a transverse periodic load. On this basis, the influence of the bending moment, the wellhead stick-up, the outer diameter (O.D.) of the conductor and the wall thickness (W.T.) of the conductor, as well as the physical parameters of the soil on the dynamic bearing capacity are discussed in detail. Analysis results show that the lateral deformation, deflection angle and von Mises stress calculated by the contact element model are greater than those calculated by the contact surface model. The maximum value of the lateral deformation and bending moment of the conductor decrease with the O.D. and W.T. of the conductor, and the cohesion and internal friction angle of the soil. However, the maximum value of the lateral deformation and bending moment of the conductor increase with the wellhead stick-up. Both the vertical force and the soil density have a negligible effect on the lateral behavior of the conductor. This study has reference value for the design and stability assessment of subsea wellheads. Full article

Riserless Mud Recovery (RMR) technology, as an emerging and efficient drilling method, is advantageous to reduce the shallow flow hazards and the number of casings. The wave current effect is one of the reasons limiting the application of RMR technology in deep and ultra-deep water, and fewer quantitative and qualitative analyses of the effect of the current are made on the stability of conductors. This paper investigates the influence of the overturning moment generated by the continuous subsea internal wave flow and the soil resistance to the conductor. The numerical simulation software ABAQUS is used to study the effects of sea state recurrence period, seabed soil properties, conductor material, driving depth in the mud, and conductor wellhead height on the stability of the conductor, and the influence weights of the factors affecting the stability of the conductor are analyzed using the weight analysis algorithm of extreme learning machine-mean impact value (ELM-MIV). Finally, the qualitative and quantitative analyses affecting the stability of the conductor are carried out, which provide reference values for the application of the RMR technology. Full article

The deepwater drilling riser is a very important and vulnerable connection between an offshore platform and subsea wellhead. Under some certain complex marine environment and operating conditions, the offshore platform may drift beyond the safe limitations or be driven away rapidly. In order to protect the safety of the platform, personnel and equipment, it is necessary to implement the emergency disconnection of the drilling riser. Since the riser is stretched under a normal connection, the riser will perform a recoil response under the combined effect of elastic potential energy and drilling fluid (mud) discharge frictional resistance after the emergency disconnection. There are complex mechanical mechanisms, influencing factors and difficult safety control problems in the recoil control process. Therefore, effectively controlling the recoil response of the deepwater drilling riser after emergency release has become one of the technical difficulties faced by deepwater drilling. The drilling mud discharge frictional resistance and tensioning force are important factors affecting the recoil response. It is necessary to develop a more general dynamic recoil model for the riser that considers the actual conditions of drilling mud discharge, floating platform motion and nonlinear tensioner factors. This paper introduces the research progress on the recoil analysis and control technology of the deepwater drilling riser, including the discharge, mechanical analysis model, the top tensioner system and control method of the recoil response, which provides a reference for future research on recoil response analyses and design of deepwater drilling risers. Full article

The enormous cost of handling the challenges of flow assurance in subsea wells, flowlines, and risers, especially in deepwater applications, has necessitated a proactive approach to prevent their risk of occurrence. To ensure that transportation of the hydrocarbon is economical and efficient from the subsea wellhead to the processing units, a flow assurance heat management system is relevant in the design and planning of a fluid transport system. Consequently, the advancement of new technologies to serve the increasing need by exploring the technologically challenging and hostile subsea fields is of great importance. A comparative study on heat management systems in flowlines was conducted from the top five publishers (Elsevier, Springer, Taylor & Francis, Wiley, and Sage) based on the number of publications to determine the level of work done by researchers in the last decade, the figures from the study showed the need for scientific research in the field of active heating. Additionally, a review was implemented to ascertain the likely advantages and drawbacks of each technique, its limitations concerning field applications and then recommend suitable cost-effective technique(s). The active heating system gives the most cost-effective solution for subsea deepwater fields. Full article

In production environments, failure data of a complex system are difficult to obtain due to the high cost of experiments; furthermore, using a single model to analyze risk, reliability, availability and uncertainty is a big challenge. Based on the fault tree, fuzzy comprehensive evaluation and Markov method, this paper proposed a fuzzy Markov method that takes the full advantages of the three methods and makes the analysis of risk, reliability, availability and uncertainty all in one. This method uses the fault tree and fuzzy theory to preprocess the input failure data to improve the reliability of the input failure data, and then input the preprocessed failure data into the Markov model; after that iterate and adjust the model when uncertainty events occur, until the data of all events have been processed by the model and the updated model obtained, which best reflects the system state. The wellhead connector of a subsea production system was used as a case study to demonstrate the above method. The obtained reliability index (mean time to failure) of the connector is basically consistent with the failure statistical data from the offshore and onshore reliability database, which verified the accuracy of the proposed method. Full article
