Search Results (70)

Biocompatible vaterite microspheres, renowned for their porous structure, are promising carriers for magnetic nanoparticles (MNPs) in biomedical applications such as targeted drug delivery and diagnostic imaging. Precise control over the magnetic moment of individual microspheres is crucial for these applications. This study employs widefield quantum diamond microscopy to map the stray magnetic fields of individual vaterite microspheres (3–10 μm) loaded with Fe₃O₄ MNPs of varying sizes (5 nm, 10 nm, and 20 nm). By analyzing over 35 microspheres under a 222 mT external magnetizing field, we measured peak-to-peak stray field amplitudes of 41 ± 1 μT for 5 nm and 10 nm superparamagnetic MNPs, reflecting their comparable magnetic response, and 12 ± 1 μT for 20 nm ferrimagnetic MNPs, due to distinct magnetization behavior. Finite-element simulations confirm variations in MNP distribution and magnetization uniformity within the vaterite matrix, with each microsphere encapsulating thousands of MNPs to generate its magnetization. This high-resolution magnetic imaging approach yields critical insights into MNP-loaded vaterite, enabling optimized synthesis and magnetically controlled systems for precision therapies and diagnostics. Full article

With the rapid development of current sensor technology, tunnel magnetoresistance (TMR) current sensors have been widely adopted in industrial detection due to their high sensitivity, excellent linearity, and broad measurement range. This study focuses on closed-loop TMR current sensors, utilizing COMSOL Multiphysics 6.2 software and the finite element method to conduct an in-depth analysis of structural parameters affecting sensor sensitivity. A novel magnetic shielding package architecture is proposed and designed. Simulation results demonstrate that the shielding efficiency of this structure improves by 44.3% compared to a single magnetic ring under a stray magnetic field of 0.1 mT along the sensing axis. At the same time, the measurement accuracy is 2.1 times higher than that of traditional structures. Current detection experiments conducted in a strong magnetic field environment further validate that the shielding package effectively suppresses external electromagnetic interference, significantly enhancing sensor stability and measurement accuracy. This research provides important theoretical and practical insights for applying high-precision TMR current sensors in complex electromagnetic environments. Full article

An efficient numerical calculation method of stray-field loss is investigated for typical magnetic load components (grain-oriented silicon steel sheets (GO), magnetic steel plate, and combined components of both materials) under non-sinusoidal excitations (NSE) containing symmetrical harmonic and DC to avoid the local overheating caused by high stray-field loss density. The paper investigates the stray-field loss with different types of load components and working conditions based on the leakage flux complementary-based measurement method, derives an analytical formulation calculating the energetic hysteresis model parameters under different magnetic flux densities to reduce the dependence on measurement data, establishes a loss calculation method considering the influence of non-sinusoidal magnetization on magnetic loss, and discusses the advantages and limitations of existing numerical approaches of additional loss to establish an effective computational strategy of stray-field loss. Finally, the effectiveness of the proposed method is verified by simulations and experiments. Full article

Defects in the free layer are considered to be the main cause of the balloon effect, but there is little insight into the synthetic antiferromagnetic (SAF) layer. To address this shortcoming, in this work, an optimized SAF layer was introduced in the perpendicular magnetic tunneling junction (pMTJ) stack to eliminate the low-probability bifurcated-switching phenomenon. The results indicated that the Hf field in the film stack improved significantly from ~5700 Oe to ~7500 Oe. A magnetoresistive random access memory (MRAM) test chip was also fabricated with a 300 mm process, resulting in a significantly improved ballooning effect. The results also indicated that the switching voltage decreased by 18.6% and the writing energy decreased by 33.7%. In addition, the low-probability stray field along the x-axis was thought to be the main cause of the ballooning effect, and was experimentally optimized for the first time by enhancing the SAF layer. This work provides a new perspective on spin-flipping dynamics, facilitating a deeper comprehension of the internal mechanism and helping to secure improvements in MRAM performance. Full article

The impact of the interface phenomena on the properties of nanostructured materials is the focus of modern physics. We studied the magnetic properties of the nanostructured In–Ag alloy confined within a porous glass. The alloy composition was close to the eutectic point in the indium-rich range of the phase diagram. Temperature dependences of DC magnetization evidenced two superconducting transitions at 4.05 and 3.38 K. The magnetization isotherms demonstrated the superposition of two hysteresis loops with low and high critical fields below the second transition, a single hysteresis between the transitions and ferromagnetism with weak remanence in the normal state of the alloy. The shape of the loop seen below the second transition, which closes at a low magnetic field, corresponded to the intermediate state of the type-I superconductor. It was ascribed to strongly linked indium segregates. The loop observed below the first transition is referred to as type-II superconductivity. The secondary and tertiary magnetization branches measured at decreasing and increasing fields were shifted relative to each other, revealing the proximity of superconducting and ferromagnetic phases at the nanometer scale. This phenomenon was observed for the first time in the alloy, whose components were not magnetic in bulk. The sign of the shift shows the dominant role of the stray fields of ferromagnetic regions. Ferromagnetism was suggested to emerge at the interface between the In and AgIn₂ segregates. Full article

Magnetic encoders are composed of a magnetic sensor, a hard magnetic recording medium and a signal processing circuit. Electrodeposited micro-magnet arrays produced by micro-fabrication are promising recording media for enhancing encoder performance. However, two major engineering issues have yet to be resolved. One issue is an unknown relationship between the feature sizes of micro-magnet arrays and their stray field shapes, and another issue is the formation of micro-cracks due to the built-up residual stresses of thick films. In this study, we investigated the effect of feature sizes on the emanating stray field shape at various observation heights. Feature sizes include two height (i.e., film thickness) values of 78 μm and 176 μm, and both width and spacing with three values of 360 μm, 520 μm and 680 μm. Ultrasound-assisted agitation was adopted for investigating the effects of electrodepositing current densities on the film crystalline microstructures and magnetic properties. Narrowing the width of micro-magnets helps the stray field to become a sinusoidal profile. Thinner film, i.e., thickness 78 μm in this study, supports the stray field taking on a sinusoidal profile. Moreover, the spacing between the micro-magnets plays a key factor in determining the shape of the stray field. Under 37 kHz/156 W ultrasound agitation, the optimal hard magnetic properties of electrodeposited CoMnP films are residual magnetization 2329 G and coercivity 968 Oe by a current density of 10.0 mA/cm². Ultrasound-assisted electrodeposition, along with duly designed feature size, facilitates the micro-magnet arrays having a sinusoidal stray field shape using high quality films. Furthermore, for the first time, a systematic understanding of feature-size-dependent stray field evolution and improved polarities quality has been realized for the recording media of sinusoidal magnetic encoders. Full article

The detection of magnetic nanoparticles in a liquid medium and the quantification of their concentration have the potential to improve the efficiency of several relevant applications in different fields, including medicine, environmental remediation, and mechanical engineering. To this end, sensors based on the magneto-impedance effect have attracted much attention due to their high sensitivity to the stray magnetic field generated by magnetic nanoparticles, their simple fabrication process, and their relatively low cost. To improve the sensitivity of these sensors, a multidisciplinary approach is required to study a wide range of soft magnetic materials as sensing elements and to customize the magnetic properties of nanoparticles. The combination of magneto-impedance sensors with ad hoc microfluidic systems favors the design of integrated portable devices with high specificity towards magnetic ferrofluids, allowing the use of very small sample volumes and making measurements faster and more reliable. In this work, a magneto-impedance sensor based on an amorphous Fe_73.5Nb₃Cu₁Si_13.5B₉ wire as the sensing element is integrated into a customized millifluidic chip. The sensor detects the presence of magnetic nanoparticles in the ferrofluid and distinguishes the different stray fields generated by single-domain superparamagnetic iron oxide nanoparticles or magnetically blocked Co-ferrite nanoparticles. Full article

High-power ore furnaces mainly use single-phase transformers supplied by phase-to-phase voltage with the secondary winding made in the form of four to eight isolated splits and a high-voltage busbar assembly made of the same number of pairs of tube buses. Due to these design features, turn-to-turn faults are the main faults in the primary winding of the transformer, and flexible coupling breaks and arc faults in splitting circuits prevail in the high-voltage system. This is why current and gas protections are currently used to protect transformers against short circuits. However, current protections are insensitive to turn faults, and the gas protection response time can be long since it strongly depends on the oil temperature. High-current systems are protected from arc faults only by insulating tube buses. However, this insulation is gradually destroyed under the impact of abrasive dust in the air, and the presence of coal dust in the air creates conditions for arc faults. There is no protection against breaks in the circuits of pairs of tube buses. The extent of damage in a transformer and its high-current system due to the faults can be significantly reduced by using new protection devices based on the measurements of the longitudinal and transverse asymmetry of the stray magnetic fields of the protected transformer. To implement these protections, this article suggests a method for protecting a transformer and a high-current system using magnetic current transformers (MCTs). The number and points for MCT winding coils are determined through the analysis of their EMF values versus their positions relative to the windings of the transformer operating under different modes. The results serve as the basis for the protection circuit design; the protection response threshold is calculated, the protection operation is described, and the results of the experiment are given. Full article

Patterned micro-scale thin-film magnetic structures, in conjunction with weak (~few tens of Oe) applied magnetic fields, can create energy landscapes capable of trapping and transporting fluid-borne magnetic microparticles. These energy landscapes arise from magnetic field magnitude variations that arise in the vicinity of the magnetic structures. In this study, we examine means of calculating magnetic fields in the local vicinity of permalloy (Ni_0.8Fe_0.2) microdisks in weak (~tens of Oe) external magnetic fields. To do this, we employ micromagnetic simulations and the resulting calculations of fields. Because field calculation from micromagnetic simulations is computationally time-intensive, we discuss a method for fitting simulated results to improve calculation speed. Resulting stray fields vary dramatically based on variations in micromagnetic simulations—vortex vs. non-vortex micromagnetic results—which can each appear despite identical simulation final conditions, resulting in field strengths that differ by about a factor of two. Full article

Designing and manufacturing transformers often involves variations in heights and thicknesses of windings. However, such geometric asymmetry introduces a significant impact on the magnitude of stray transformer losses. This study examines the effects of asymmetric coils on the generation of stray losses within core clamps and transformer tank walls. A model has been introduced to ascertain the dispersion magnetic field’s value at a specific distance from the coil. The analysis extends to characterising the dispersion magnetic field reaching the tank walls by using electromagnetic simulation by a finite element method. It explores strategies to diminish stray losses, including the placement of magnetic shunts as protective shields for the tank walls. It delves into the efficacy of employing a transformer shell-type configuration to mitigate the magnetic dispersion field. The findings revealed that achieving greater symmetry in transformer coils can minimise stray losses. Specifically, the incorporation of magnetic shunts has the potential to reduce additional losses by 40%, while the adoption of a shell-type configuration alone can lead to a 14% reduction. This work provides valuable insights into optimising transformer designs, contributes a user-friendly tool for estimating additional tank losses, thereby enhancing the knowledge base for transformer manufacturers. Full article

To mitigate the impact of low-frequency noise from the tunnel magnetoresistance (TMR) current sensor and ambient stray magnetic fields on weak current detection accuracy, we propose a high-resolution modulation-demodulation test method. This method modulates and demodulates the measurement signal, shifting low-frequency noise to the high-frequency band for effective filtering, thereby isolating the target signal from the noise. In this study, we developed a Simulink model for the TMR current sensor modulation-demodulation test method. Practical time-domain and frequency-domain tests of the developed high-resolution modulation-demodulation method revealed that the TMR current sensor exhibits a nonlinearity as low as 0.045%, an enhanced signal-to-noise ratio (SNR) of 77 dB, and a heightened resolution of 100 nA. The findings indicate that this modulation-demodulation test method effectively reduces the impact of low-frequency noise on TMR current sensors and can be extended to other types of resistive devices. Full article

Residual current is an important monitoring quantity of a power system, and a current sensor plays an important role in detecting current. The substation environment is complex. In addition to the power frequency signal, residual current also has AC and DC components. But it is also affected by the stray magnetic field of the substation. Therefore, the accuracy of the current sensor demands higher requirements. The tunnel magnetoresistive sensor has the advantages of a stable operation, high efficiency, and energy saving, but it is easily affected by the external stray magnetic field during measurements, resulting in a large error. Therefore, this paper proposes a residual-current sensing monitoring system considering the magnetic shielding effect. The root mean square error of the magnetic shielding structure is only 0.572 mA, which can effectively reduce the influence of the external magnetic field and improve the detection accuracy. At the same time, the DC measurement error is less than 1%, the AC measurement error is less than 5%, and the hybrid AC/DC error is less than 8%. It has good response ability and can accurately detect residual current. Full article

Currently, two-dimensional (2D) materials with intrinsic antiferromagnetism have stimulated research interest due to their insensitivity to external magnetic fields and absence of stray fields. Here, we predict a family of stable transition metal (TM) borides, TMB₁₂ (TM = V, Cr, Mn, Fe) monolayers, by combining TM atoms and B₁₂ icosahedra based on first-principles calculations. Our results show that the four TMB₁₂ monolayers have stable antiferromagnetic (AFM) ground states with large magnetic anisotropic energy. Among them, three TMB₁₂ (TM=V, Cr, Mn) monolayers display an in-plane easy magnetization axis, while the FeB₁₂ monolayer has an out-of-plane easy magnetization axis. Among them, the CrB₁₂ and the FeB₁₂ monolayers are AFM semiconductors with band gaps of 0.13 eV and 0.35 eV, respectively. In particular, the AFM FeB₁₂ monolayer is a spin-polarized AFM material with a Néel temperature of 125 K. Moreover, the electronic and magnetic properties of the CrB₁₂ and the FeB₁₂ monolayers can be modulated by imposing external biaxial strains. Our findings show that the TMB₁₂ monolayers are candidates for designing 2D AFM materials, with potential applications in electronic devices. Full article

The paper considers the model predictive current control (MPCC) of an induction motor (IM) drive and evaluates five IM models of different complexities—from conventional to magnetic saturation, iron losses, and stray-load losses—for the MPCC design. The validity of each considered IM model and the corresponding MPCC algorithm is evaluated by comparison of the following performance metrics: the total harmonic distortion of the stator current, the average switching frequency, the rotor flux magnitude error, the rotor flux angle error, and the product of the first two metrics. The metrics’ values are determined in wide ranges of the rotor speed (0.1–1 p.u.) and load torque (0–1 p.u.) through simulations performed in the MATLAB Simulink environment. The obtained results allow us to identify the IM model that offers the best tradeoff between the practicability and accuracy. Furthermore, a control effort penalization (CEP) is suggested to reduce the average switching frequency and, hence, the power converter losses. This involves constraining the simultaneous switching to a maximum of two branches of the three-phase power converter, as well as inclusion of the weighted switching penalization term in the cost function. Finally, the performance—both steady-state and dynamic—of the proposed MPCC system with CEP is compared with that of the analogous field-oriented controlled (FOC) IM drive. The inverter switching frequency is reduced more than twice by including the frequency-dependent iron-loss resistance in the MPCC. It is additionally reduced by implementing the proposed CEP strategy without sacrificing many other performance metrics, thus achieving a performance comparable to the FOC IM drive. Full article

The superconducting magnet energy storage (SMES) has become an increasingly popular device with the development of renewable energy sources. The power fluctuations they produce in energy systems must be compensated with the help of storage devices. A toroidal SMES magnet with large capacity is a tendency for storage energy because it has great energy density and low stray field. A key component in the creation of these superconducting magnets is the material from which they are made. The present work describes a comparative numerical analysis with finite element method, of energy storage in a toroidal modular superconducting coil using two types of superconducting material with different properties bismuth strontium calcium copper oxide (BSCCO) and yttrium barium copper oxide (YBCO). Regarding the design of the modular torus, it was obtained that for a 1.25 times increase of the critical current for the BSCCO superconducting material compared with YBCO, the dimensions of the BSCCO torus were reduced by 7% considering the same stored energy. Also, following a numerical parametric analysis, it resulted that, in order to maximize the amount of energy stored, the thickness of the torus modules must be as small as possible, without exceeding the critical current. Another numerical analysis showed that the energy stored is maximum when the major radius of the torus is minimum, i.e., for a torus as compact as possible. Full article
