Search Results (43)

We propose a hub ridesharing method that considers path similarity to swiftly evacuate high volumes of passengers arriving at a high-speed railway hub. The technique aims to minimize total mileage and the number of service vehicles, considering the characteristics of hub passengers, such as the constraints of large luggage, departure times, and arrival times. Meanwhile, to meet passengers’ expectations, a path morphology similarity indicator combining directional and locational features is developed and used as a crucial criterion for passenger matching. A two-stage algorithm is designed as a solution. Passenger requests are clustered based on path vector similarity in the first stage using a heuristic approach. In the second stage, we employ an adaptive large-scale neighborhood search to form passenger matches and shared routes. The experiments demonstrate that this method can reduce operational costs, enhance computational efficiency, and shorten passenger wait times. Taking path similarity into account significantly decreases passenger detour distances. It improves the Jaccard coefficient (JAC) of post-ridesharing paths, fulfilling the passenger’s psychological expectation that the shared route will closely resemble the original one. Full article

Linear spatial data are primarily used in Geographic Information Systems (GISs) to represent spatial data in the form of roads, rivers, railways, and utility lines. Linear spatial data are mostly composed of one-dimensional linear elements, incorporating geometric attributes such as location, direction, and length, as well as the interconnections of these elements. In the case of roads, this information is used to map and analyze traffic data, such as vehicle movements, on the road network. This study aims to propose an area-based spatial analysis method that allows for the flexible application of analysis scales using individual vehicle data, as opposed to node and link generation for linear road networks. The analysis focused on nine expressways, conducting a microscopic analysis of speed-homogeneous sections. The final analysis showed that out of 375 cells, 91 cells in the final 12 division cells did not meet the homogeneity criteria. This discrepancy was ascertained to be due to vehicles decelerating or accelerating when entering or exiting highways at ramps or interchanges, not due to directional speed differences but lane-specific speed variations. The final cells with large speed deviations were found to be influenced by connections to highway on-ramps or off-ramps. In contrast, sections with small speed variations within a cell were influenced by traffic factors such as connection points and traffic volume, which hindered normal driving. As a result, this study validated that traffic information from highways, typically provided as linear data, could be divided into cells based on real-time GPS speed data and presented on an area-based scale. While dividing regions based on fixed intervals does not pinpoint exact speed change points, this study found that reasonable segmentation is possible based on spatial size and speed-homogeneous sections. Full article

The presence of contaminants influences braking efficiency in the railway system because it alters the adhesion at the wheel–rail interface. It is essential to study this phenomenon, as contaminants reduce the friction between wheels and rails, which impacts braking and transport safety. In addition, these contaminants increase the risk of derailments. The objective of the research was to determine the impact of different contaminants and operating speeds on the critical braking system’s responses. Using the 3^k full factorial experimental design methodology, with analysis of variance (ANOVA) and linear and quadratic regressions, visualized using surface graphs, the effects of three operating conditions were studied: clean rails, with sand and sawdust, and driving the train at three operating speeds. These conditions gave rise to variations in braking distances, maximum creep, wheel slip times, and maximum peaks of electric current when braking in each experiment. The tests were carried out on the straight section of a β-shaped track and a railway vehicle, designed at a scale of 1:20. The analysis reveals that the braking distance increases significantly with surface roughness (clean track < sawdust < sand). At 0.75 m/s, the sawdust track reduces braking distance by 21% compared with the clean track; at 1.00 m/s, the reduction is 19%; and at 1.30 m/s, it is 35%. Full article

The efficiency of collecting and distributing goods has been improved by establishing railway lines that serve new automated container terminals (ACTs) and by constructing central railway stations close to ports. To aid in this process, intelligent guided vehicles (IGVs), which are renowned for their flexibility and for the convenience with which one can adjust their number and speed, have been developed to be used as horizontal transport vehicles that can transport goods between the railway yard and the front of the port. However, they also introduce some difficulties and complexities that affect terminal scheduling. Therefore, we took the automated rail-mounted container gantry crane (ARMG) scheduling problem as our main research object in this study. We established a mixed-integer linear programming (MILP) model to minimize the makespan of ARMGs, designed an adaptive large neighborhood search (ALNS) algorithm, and explored the influence of IGV configuration on ARMG scheduling through a series of experiments applied to a series of large-scale numerical examples. The experimental results show that increasing the number of IGVs can improve the operational efficiency of railway yards, but this strategy reduces the overall time taken for the ARMG to complete various tasks. Increasing or decreasing the speed of the IGVs within a given range has a clear effect on the problem at hand, while increasing the IGV travel speed can effectively reduce the time required for the ARMG to complete various tasks. Operators must properly adjust the IGV speed to meet the requirements of the planned operation. Full article

The tribological properties of steels used to realise railway wheels play a fundamental role in the performances of both vehicle and infrastructure. In particular, the wear process, caused by the wheel–rail interaction, modifies the shape of wheel and rail profiles, changing the performances of the vehicle. For this reason, research institutes and vehicle manufacturers have worked hard to develop predictive tools able to estimate the evolution of the wheel and rail profiles. The efficiency of these tools is strongly influenced by the tribological properties of the materials, i.e., the wear coefficients, which are used as input data. The characterisation of these properties requires specific tools and long-lasting experimental campaigns, which are usually performed under controlled operating conditions, using twin-disc test benches. These devices usually do not consider the real contact conditions in terms of normal load, contact geometry, and slip velocity, since they are equipped with small-size rollers. The paper proposes an innovative 1:5 scaled twin-disc, which allows the reproduction of the real wheel–rail contact conditions, thanks to Pascal’s scaling technique. The testing device allows the reproduction of a wide range of typical operating conditions of railway vehicles, thanks to high-power independent brushless motors, used to actuate the rollers, and an innovative loading system. Full article

Striving to increase the speed of rail vehicles and thus improve the comfort of traveling passengers at the same time, undertakes activities in the sphere of ensuring an appropriate level of safety of rail, passenger, and freight transport. One of the elements of activities in this area is the training of train drivers. Until recently, this training consisted of a theoretical and practical part on the vehicle, alongside an experienced train driver. Considering the increasing level of automation of railway traffic control systems and locomotive equipment, as well as training costs and requirements related to the introduction of TSI, it is becoming an increasingly common requirement to conduct practical training on railway vehicle traffic simulators, while the conditions in the simulator cabin and the trainee’s feelings should correspond to the actual driving conditions. A locomotive driving simulator is a system consisting of a cabin of a suitable type of locomotive or EMU, mapped in 1:1 scale, coupled with a motion excitation system and computer programs connected together forming the software of the cab visualization and dynamics system. The basic program simulating the dynamics and kinematics of the cabin’s motion is a program containing a motion dynamics model that generates signals forcing the movement of the exciters on which the cabin’s platform is mounted. The correct operation of the simulation model depends on the created mathematical model, which can be built in several ways. This article presents the issue of building a mathematical model describing the dynamics of the rail vehicle motion, which can then be used in the simulation model of the simulator cabin motion. Two ways of proceeding in the process of approaching the construction of a mathematical model of rail vehicle motion dynamics will be presented, with the possibility of later use in creating a simulation model of the motion of the locomotive simulator cabin. One of the possible routes was used in the past in the construction of the EP09 locomotive simulator. Full article

In this paper, the vertical vibration behaviour of an experimental scale demonstrator of a railway vehicle carbody fitted with an anti-bending bar system of innovative design is studied to highlight its ability to raise the bending natural frequency of the railway vehicle carbody and to reduce the intensity of the vibration. The anti-bending bar system has been previously proposed by the second author as a new passive method to improve comfort in passenger coaches with long carbodies that have a natural bending frequency located in the range of maximum sensitivity of human beings to vertical vibration. The experimental scale demonstrator consists of an aluminium plate supported on four rubber supports. The aluminium beam reproduces to a scale of 1:10 the length of a passenger coach carbody, and its thickness is set so that the first bending frequency of the plate is close to the usual value of real carbodies. The anti-bending bar system consists of two steel bars arranged longitudinally in the middle of the aluminium plate, near its side edges. Each anti-bending bar is fixed at the ends to the aluminium plate by joints consisting of a clamping arm welded to a fixing flange. The two anti-bending bars oppose the bending movement of the aluminium plate, thus increasing its bending stiffness. This results in increasing the bending natural frequency of the aluminium plate and reduction its vibration. Testing the effectiveness of the anti-bending bar system consists of experimentally determining the frequency response of the aluminium plate acceleration without/with the anti-bending bar system by the impact hammer method. The experimental results show the first bending natural frequency increases from 9.01 Hz to 13.4 Hz and the acceleration amplitude decreases by more than 50% when the anti-bending bar system is used. To confirm these results, a theoretical model of the experimental scale demonstrator based on the finite element method was developed. The results obtained with this model are in line with those obtained experimentally. Full article

Track fastener defect detection is an essential component in ensuring railway safety operations. Traditional manual inspection methods no longer meet the requirements of modern railways. The use of deep learning image processing techniques for classifying and recognizing abnormal fasteners is faster, more accurate, and more intelligent. With the widespread use of unmanned aerial vehicles (UAVs), conducting railway inspections using lightweight, low-power devices carried by UAVs has become a future trend. In this paper, we address the characteristics of track fastener detection tasks by improving the YOLOv4-tiny object detection model. We improved the model to output single-scale features and used the K-means++ algorithm to cluster the dataset, obtaining anchor boxes that were better suited to the dataset. Finally, we developed the FPGA platform and deployed the transformed model on this platform. The experimental results demonstrated that the improved model achieved an mAP of 95.1% and a speed of 295.9 FPS on the FPGA, surpassing the performance of existing object detection models. Moreover, the lightweight and low-powered FPGA platform meets the requirements for UAV deployment. Full article

This paper offers a novel view for managing and controlling the movement of driverless, i.e., autonomous, vehicles by converting this movement to a simulated train movement moving on a rail track. It expands on the “virtual track” theory and creates a model for virtual track autonomous vehicle management and control based on the ideas and methods of railway train operation. The developed model and adopted algorithm allow for large-scale autonomous driving vehicle control on the highway while considering the temporal-spatial distribution of vehicles, temporal-spatial trajectory diagram optimization, and the management and control model and algorithm for autonomous vehicles, as design goals. The ultimate objective is to increase the safety of the road traffic environment when autonomous vehicles are operating in it together with human-driven vehicles and achieve more integrated and precise organization and scheduling of these vehicles in such mixed traffic conditions. The developed model adopted a “particle swarm” optimization algorithm that is tested in a hypothetical network pending a full-scale test on a real highway. The paper concludes that the proposed management and control model and algorithm based on the “virtual track” theory is promising and demonstrates feasibility and effectiveness for further development and future application. Full article

For better small-radius curve negotiation performance, the independently rotating wheelset has the potential to be equipped in urban rail transit. As a crucial part of the running gear, its dynamic characteristics directly affect the railway vehicle’s stability and curve negotiation ability. This study follows a model–simulation–experiment method to delve into the dynamic process and steady convergent process of the independently rotating wheelset. An improved mathematical dynamic model of the independently rotating wheelset is established, considering the gravitational restoring forces of the wheelset and different creepages between the left and right wheels. In addition, the gyroscopic effects on the independently rotating wheelset with positive wheel tread conicity and at high speeds are introduced and analyzed. With variations in the longitudinal speed and yaw suspension coefficients, three kinds of motions, derailment, hunting, and offset running, occur on the independently rotating wheelset. We find that the gyroscopic effects contribute to the slight self-guidance ability of the independently rotating wheelset, causing a hunting motion at high speeds. Through sufficient simulations, the improved mathematical dynamic model is verified to be closer to the dynamic model built in the general multibody system simulation software SIMPACK 2018 than the classical mathematical dynamic model. Further, we perform experiments on a scaled independently rotating wheelset experiment system. The dynamic characteristics derived from theoretical analysis, especially the slight self-guidance ability at high speeds, are verified. Full article

This paper presents an initial study of the computational modeling for determining the stress–strain behavior of the cord–rubber segment, tailored to be used as a flexible member in the construction of torque transfer coupling in railway vehicles. The presented computational models use the multibody simulation approach for the assessment of segment deformation under diverse loading characteristics. The results are then used in the finite element computational models of the cord–rubber segment. The computational model is validated through tension tests of cord–rubber segments. The homogenized and microstructural models show their ability to simulate the overall stiffness of the segment relatively accurately in tension, but they are limited in not being able to include the influence of the segment’s manufacturing technology. The micro-scale computational model then incorporates realistic representations of cord bundles, considering various cross-sectional shapes, whereas a very important factor significantly influencing the correlation of the results of the technical experiment and simulation is the consideration of the manufacturing technology in the process of building the computational model. The results show that the computational modeling approach in this work can be used for the determination of the optimal manufacturing technology conditions with regard to the stress–strain behavior of the given segment. Full article

With the continuous expansion of the scale of power grid and transportation infrastructure construction, the number of crossovers between transmission lines and high-speed railways continues to increase. At present, there is a lack of systematic research on the dynamic characteristics of transmission tower-line structures crossing high-speed railways under vehicle-induced ground vibration. This article focuses on the phenomenon of accidents such as line drops when crossing areas in recent years and establishes a high-speed train track foundation soil finite element model in ABAQUS that considers track irregularity. The three-dimensional vibration characteristics and attenuation law of train ground vibration are analyzed. Acceleration data for key points are also extracted. A separate finite element model of the transmission tower-line system is established in ANSYS, where acceleration is applied as an excitation to the transmission tower-line system, and the coupling effect between the tower and the line is considered to analyze its dynamic response. Subsequently, modal analysis is conducted on the tower-line system, providing the vibration modes and natural frequencies of the transmission tower-line structure. The effects of factors such as train speed, soil quality, and distance from the tower to the track on the dynamic response of the transmission tower-line system under vehicle-induced ground vibration are studied. The results show that the speed range (300 km/h–400 km/h) and track distance range (4.5 m–30 m) with the greatest impacts are obtained. The research results can provide a reference for the reasonable design of transmission tower-line systems in high-speed railway sections. Full article

To address the incomplete image data collection of close-to-ground structures, such as bridge piers and local features like the suspension cables in bridges, obtained from single unmanned aerial vehicle (UAV) oblique photography and the difficulty in acquiring point cloud data for the top structures of bridges using single terrestrial laser scanners (TLSs), as well as the lack of textural information in TLS point clouds, this study aims to establish a high-precision, complete, and realistic bridge model by integrating UAV image data and TLS point cloud data. Using a particular large-scale dual-track bridge as a case study, the methodology involves aerial surveys using a DJI Phantom 4 RTK for comprehensive image capture. We obtain 564 images circling the bridge arches, 508 images for orthorectification, and 491 images of close-range side views. Subsequently, all images, POS data, and ground control point information are imported into Context Capture 2023 software for aerial triangulation and multi-view image dense matching to generate dense point clouds of the bridge. Additionally, ground LiDAR scanning, involving the placement of six scanning stations both on and beneath the bridge, was conducted and the point cloud data from each station are registered in Trimble Business Center 5.5.2 software based on identical feature points. Noise point clouds are then removed using statistical filtering techniques. The integration of UAV image point clouds with TLS point clouds is achieved using the iterative closest point (ICP) algorithm, followed by the creation of a TIN model and texture mapping using Context Capture 2023 software. The effectiveness of the integrated modeling is verified by comparing the geometric accuracy and completeness of the images with those obtained from a single UAV image-based model. The integrated model is used to generate cross-sectional profiles of the dual-track bridge, with detailed annotations of boundary dimensions. Structural inspections reveal honeycomb surfaces and seepage in the bridge piers, as well as painted rust and cracks in the arch ribs. The geometric accuracy of the integrated model in the X, Y, and Z directions is 1.2 cm, 0.8 cm, and 0.9 cm, respectively, while the overall 3D model accuracy is 1.70 cm. This method provides technical reference for the reconstruction of three-dimensional point cloud bridge models. Through 3D reconstruction, railway operators can better monitor and assess the condition of bridge structures, promptly identifying potential defects and damages, thus enabling the adoption of necessary maintenance and repair measures to ensure the structural safety of the bridges. Full article

This paper proposes an active steering controller for Driven Independently Rotating Wheelset (DIRW) vehicles based on deep reinforcement learning (DRL). For the two-axle railway vehicles equipped with Independently Rotating Wheelsets (IRWs), each wheel connected to a wheel-side motor, the Ape-X DDPG controller, an enhanced version of the Deep Deterministic Policy Gradient (DDPG) algorithm, is adopted. Incorporating Distributed Prioritized Experience Replay (DPER), Ape-X DDPG trains neural network function approximators to obtain a data-driven DIRW active steering controller. This controller is utilized to control the input torque of each wheel, aiming to improve the steering capability of IRWs. Simulation results indicate that compared to the existing model-based H∞ control algorithm and data-driven DDPG control algorithm, the Ape-X DDPG active steering controller demonstrates better curving steering performance and centering ability in straight tracks across different running conditions and significantly reduces wheel–rail wear. To validate the proposed algorithm’s efficacy in real vehicles, a 1:5 scale model of the DIRW vehicle and its digital twin dynamic model were designed and manufactured. The proposed control algorithm was deployed on the scale vehicle and subjected to active steering control experiments on a scaled track. The experimental results reveal that under the active steering control of the Ape-X DDPG controller, the steering performance of the DIRW scale model on both straight and curved tracks is significantly enhanced. Full article

In this paper, we study the communication performance of applying unmanned aerial vehicles (UAVs) combined with intelligent reflective surfaces (IRS) in a high speed railway (HSR) scenario. This study investigates the design and performance of (multiple-input-multiple-output) MIMO systems with UAV and IRS assistance technology in high-mobility scenarios. Direct links between base stations (BS) and trains are often obstructed in suburban environments, especially in mountainous areas. We mount the IRS on the UAVs so that it can assist in the communication between the trains and the BS. With the help of the UAV-IRS, straight-line links can be established effectively, which greatly improves communication for train passengers. This paper considers the employment of large-scale antenna arrays at both the BS and train ends. Train passengers communicate with UAVs via antennas assembled on the roof of the train as gateways, which in turn communicate with the BS. We consider two types of antenna layouts on the train: all antennas are located in the center of the train named Co-located antennas (CA) layout and uniformly distributed along the train called distributed antennas (DA) layout. We can obtain the analytical up-link capacity by averaging over all locations in a cell for the above two layouts by considering the radio frequency consumption. Overall, the CA layout is found to be a better option for trains when attempting to maximize cell mean value of capacity, and DA layout achieves a more uniformly distribution of capacity over the entire cell. Ultimately, the best solution will depend on the specific requirements and constraints of the selected deployment scenario. Full article
