Motors are among the most energy-consuming devices worldwide. With growing interest in eco-friendly solutions, minimum efficiency regulations for industrial motors are being enforced. In response to continuously rising minimum efficiency requirements, research on improving the efficiency of motors is actively underway. In the case of induction motors, which are the most widely used industrial electric motors, rotor ohmic loss occurs due to their operating characteristics. In contrast, line-start synchronous reluctance motors (LS-SynRMs) have a significant advantage in efficiency because once they reach synchronous speed, no eddy currents are generated by the fundamental current waveform. This leads to a sharp decrease in rotor ohmic losses, greatly enhancing efficiency. In this paper, a rotor design is carried out to improve the efficiency of LS-SynRMs. To support the rotor design, the torque characteristics of LS-SynRMs were analyzed under both asynchronous and synchronous state operations, and improvement directions for enhancing efficiency were identified. For rotor type selection, two bar-type rotors with linear flux barriers and two boomerang-type rotors with curved flux barriers were designed. The electromagnetic characteristics of these designs were compared using finite element analysis. Among them, the boomerang-type rotor that exhibited the best electromagnetic performance was selected as the final rotor type. Its final geometry was derived through detailed design, considering the mechanical safety of the rotor. Finally, experimental validation was conducted to verify the effectiveness of the proposed rotor design. Full article

This study investigates and optimizes chromatographic separation in a Centrifugal Partition Chromatograph. Therefore, a model system is separated in a single-disc rotor. The occurring loss of the stationary phase lowers the separation efficiency over time. We introduced a new mode of operation, called the redosing of the stationary phase, to counteract this hydrodynamic phenomenon. Experiments with redosing at an optimized operating point demonstrate almost constant separation performance over 12 h, reducing solvent consumption by 45% and increasing chromatographic resolution by 37%. The improvement in retention by 69% contributes to this enhancement. Accordingly, reference experiments without redosing were conducted as a benchmark, highlighting the automated mode’s benefits, as mentioned. Full article

Highly three–dimensional and complex flow structures are closely related to the aerodynamic losses occurring in the transonic axial–flow compressor. The large eddy simulation (LES) approach was adopted to study the aerodynamic performance of the NASA rotor 37 for the cases at the design, the near stall (NS), and the near choke (NC) flow rate. The internal flow vortex topology was analyzed by the Q–criterion method, the omega (Ω) vortex identification method, and the Liutex identification method. It was observed that the Q–criterion method was vulnerable to being influenced by the flow with high–shear deformation rate, especially near the end–wall regions. The Ω method was adopted to recognize the three–dimensional vortex structure with a higher precision than that of the Q–criterion method. Meanwhile, the Liutex vortex identification method showed a good performance in vortex identification, and the corresponding contribution of Liutex components in the vortex topology was analyzed. The results show that the high–vortex fields around the separation line and reattachment line had high vortex components in the x–axis, the tip clearance vortices presented a high–vortex component in the y–axis, and the suction side corner vortex possessed high–vortex components in the y– and z–axes. Full article

Improving efficiency is a general task in the design process of high-speed journal bearings. A specific fixed-pad bearing geometry featuring reduced pad length and additional design measures with the intention of reducing frictional power loss is investigated, experimentally and theoretically, for a journal diameter of 500 mm up to surface speeds of 94 m/s and unit loads of 5.0 MPa. To model fluid flow in the bearing outside the lubricant gap, an extension to Elrod’s cavitation algorithm based on assuming the inertia of fluid flow is proposed. Validation of the extended thermo-elasto-hydrodynamic lubrication (TEHL) model shows good agreement between measurement and prediction in wide operating ranges, however, with systematic tendencies of the remaining deviations. Furthermore, measured local pressure and film thickness distributions indicate a complex formation of cavitation with an influence of axial flow that is not covered by pure Couette-flow in the cavitation region. Measured as well as predicted data prove increased bearing efficiency for high rotor speeds. To provide understanding on the impact of the applied design measures improving efficiency, their combination is separated into the individual ones. Reduced axial and peripheral pad length both contribute almost equally to the reduction in power loss and improve its value by 37% compared to the standard design. Finally, further steps to deeper identify the behavior of the bearing are comprehensively discussed. Full article

The complicated flow conditions and massive design parameters bring two main difficulties to the aerodynamic optimization of axial compressors: expensive evaluations and numerous optimization variables. To address these challenges, this paper establishes a novel fast aerodynamic optimization platform for axial compressors, consisting of a radial basic function (RBF)-based blade parameterization method, a data-driven differential evolution optimizer, and a computational fluid dynamic (CFD) solver. As a versatile interpolation method, RBF is used as the shape parameterization and deformation technique to reduce optimization variables. Aiming to acquire competitive solutions in limited steps, a data-driven evolution optimizer is developed, named the pre-screen surrogate model assistant differential evolution (pre-SADE) optimizer. Different from most surrogate model-assisted evolutionary algorithms, surrogate models in pre-SADE are used to screen the samples, rather than directly estimate them, in each generation to reduce expensive evaluations. The polynomial regression model, Kriging model, and RBF model are integrated in the surrogate model to improve the accuracy. To further save optimization time, the optimizer also integrates parallel task management programs. The aerodynamic optimization of a transonic rotor (NASA Rotor 37) is performed as the validation of the platform. A differential evolution (DE) optimizer and another surrogate model-assisted algorithm, committee-based active learning for surrogate model assisted particle swarm optimization (CAL-SAPSO), are introduced for the comparison runs. After optimization, the adiabatic efficiency, total pressure ratio, and surge margin are, respectively, increased by 1.47%, 1.0%, and 0.79% compared to the initial rotor. In the same limited steps, pre-SADE gets a 0.57% and 0.51% higher rotor adiabatic efficiency than DE and CAL-SAPSO, respectively. With the help of parallel techniques, pre-SADE and DE save half the optimization time compared to CAL-SAPSO. The results verify the effectiveness and the rapidity of the fast aerodynamic optimization platform. Full article

Based on the COMSOL software, body forces substituted into the Reynolds-averaged Navier–Stokes (RANS) equations as the source terms instead of the actual blade rows were improved to better predict the compressor performance. Improvements in parallel body force modeling were implemented, central to which were the local flow quantities. This ensured accurate and reliable off-design performance prediction. The parallel force magnitude mainly depended on the meridional entropy gradient extracted from three-dimensional (3D) steady single-passage RANS solutions. The COMSOL software could easily and accurately translate the pitchwise-averaged entropy into the grid points of the body force domain. A NASA Rotor 37 was used to quantify the improved body force model to represent the compressor. Compared with the previous model, the improved body force model was more efficient for the numerical calculations, and it agreed well with the experimental data and computational fluid dynamics (CFD) results. The results indicate that the improved body force model could quickly and efficiently capture the flow field through a turbomachinery blade row. Full article

Atmospheric air is a commonly used working fluid in turbomachinery. The air typically contains a certain amount of suspended solid particles, as well as water in the form of vapor or droplets. In the current paper, we focus on the numerical modeling of humid air transonic flow in turbomachinery. In this paper we demonstrate a rarely considered, but as presented herein important influence of air humidity, pollution and liquid water content on the performance of the first stage of the gas turbine compressor and turbofan engine fan (NASA rotors 37 and 67). We also discuss the impact of the interfacial heat transfer associated with steam condensation or water evaporation on the distribution of stagnation parameters at the rotor outlet, the rotor performance, and flow conditions, as well as losses. Results demonstrate the impact of the number of pollution particles and water droplets on the compression process in the analyzed rotors, especially on the Mach number distribution in the blade-to-blade channel. In this paper we highlight that the air pollution and liquid water content, together with such physical phenomena as steam condensation or water droplets evaporation, exert a significant influence on work parameters, losses and efficiency, and thus should be considered in high-velocity airflow simulations. Full article

In the late 19th century, the three-phase induction motor was the central element of productivity increase in the second industrial revolution in Europe and the United States. Currently, it is the main load on electrical systems in global terms, reaching approximately 70% of electrical energy consumption in the industrial sector worldwide. During the 20th century, electric motors underwent intense technological innovations that enabled significant performance gains. Thus, this work analyses the performance changes in squirrel-cage rotor three-phase induction electric motors (SCIMs) with mechanical powers of 3.7 kW, 37 kW, and 150 kW and speed ranges corresponding to two poles and eight poles, connected to a low voltage at a frequency of 60 Hz and tested between 1945 and 2020. The study confirms accumulated performance gains of above 10% in some cases. Insulating materials for electrical conductors have gone through several generations (cotton, silk, and currently, varnish). Improvements to the housing for cooling, the bearings, the quality of active materials, and the design were the elements that enabled the high gains in performance. The first commercial two-pole SCIM with a shaft power of 4.4 kW was marketed in 1891, with a weight/power ratio of 86 kg/kW, and until the 2000s, this value gradually decreased, eventually reaching 4.8 kg/kW. Between 2000 and 2020, this ratio showed a reversed trend based on improvements in the performance of SCIMs. More active materials were used, causing the weight/power ratio to reach 8.6 kg/kW. The MEPS (minimum energy performance standards) of SCIMs had an essential role in the performance gain over the last three decades. Data collection was via tests at the Electrical Machines Laboratory of the Institute of Energy and Environment of the University of São Paulo. The laboratory has a history of tests on electrical equipment dating from 1911. Full article

A casing treatment using inclined oblique slots (INOS) is proposed to improve the stability of the single-stage transonic axial compressor, NASA Stage 37, during operation. The slots are installed on the casing of the rotor blades. The aerodynamic performance was estimated using three-dimensional steady Reynolds-Averaged Navier-Stokes analysis. The results showed that the slots effectively increased the stall margin of the compressor with slight reductions in the pressure ratio and adiabatic efficiency. Three geometric parameters were tested in a parametric study. A single-objective optimization to maximize the stall margin was carried out using a Genetic Algorithm coupled with a surrogate model created by a radial basis neural network. The optimized design increased the stall margin by 37.1% compared to that of the smooth casing with little impacts on the efficiency and pressure ratio. Full article

This work focuses its attention on possibilities to enhance the stability of an axial compressor using a casing treatment technique. Circumferential grooves machined into the case are considered and their performances evaluated using three-dimensional steady state computational simulations. The effects of rectangular and new T-shape grooves on NASA Rotor 37 performances are investigated, resolving in detail the flow field near the blade tip in order to understand the stall inception delay mechanism produced by the casing treatment. First, a validation of the computational model was carried out analysing a smooth wall case without grooves. The comparisons of the total pressure ratio, total temperature ratio and adiabatic efficiency profiles with experimental data highlighted the accuracy and validity of the model. Then, the results for a rectangular groove chosen as the baseline case demonstrated that the groove interacts with the tip leakage flow, weakening the vortex breakdown and reducing the separation at the blade suction side. These effects delay stall inception, improving compressor stability. New T-shape grooves were designed keeping the volume as a constant parameter and their performances were evaluated in terms of stall margin improvement and efficiency variation. All the configurations showed a common efficiency loss near the peak condition and some of them revealed a stall margin improvement with respect to the baseline. Due to their reduced depth, these new configurations are interesting because they enable the use of a thinner light-weight compressor case as is desirable in aerospace applications. Full article

This study explores the damping effects of tuned liquid dampers (TLDs) on a monopile offshore wind turbine (OWT). The fluid–solid coupling of ANSYS was used to simulate the damping effect of a TLD on the structures. The environmental conditions refer to the IEC-61400-3 and the Design Load Case (DLC) 1.2 for the annual average environmental conditions and DLC 6.2 for the 50-year regression period, and the extreme environmental conditions were used in the study. The turbulent wind field simulation was performed by TurbSim, and the load of wind waves on structures was generated by FAST, which were all developed by the NREL (National Renewable Energy Laboratory). In addition to wind and waves, the seismic force was also considered. The cylindrical TLD was located above the rotor nacelle assembly (RNA). A TLD has different damping effects when acting under wind, wave, and earthquake loads, respectively. The effect of the TLD regarding motion reduction on the OWT under coupled wind, wave, and seismic loads was studied. This study also designed a simple experiment to verify the correctness of the numerical simulation results. Fatigue analysis shows that multi-layer TLDs can extend the fatigue life (37%) of an OWT. In addition, under extreme environmental load conditions, multi-layer TLDs have a better vibration damping performance than single-layer TLDs. The study demonstrates that multi-layer TLDs can be considered as a vibration reduction damper for OWTs. Full article

A proof of concept is provided by computational fluid dynamic simulations of a new recirculating type casing treatment. This treatment aims at extending the stable operating range of highly loaded axial compressors, so to improve the safety of sorties of high-speed, high-performance aircraft powered by high specific thrust engines. This casing treatment, featuring an axisymmetric recirculation channel, is evaluated on the NASA rotor 37 test case by steady and unsteady Reynolds Averaged Navier Stokes (RANS) simulations, using the realizable k-ε model. Flow blockage at the recirculation channel outlet was mitigated by chamfering the exit of the recirculation channel inner wall. The channel axial location from the rotor blade tip leading edge was optimized parametrically over the range −4.6% to 47.6% of the rotor tip axial chord $c_z$ . Locating the channel at 18.2% $c_z$ provided the best stall margin gain of approximately 5.5% compared to the untreated rotor. No rotor adiabatic efficiency was lost by the application of this casing treatment. The investigation into the flow structure with the recirculating channel gave a good insight into how the new casing treatment generates this benefit. The combination of stall margin gain at no rotor adiabatic efficiency loss makes this design attractive for applications to high-speed gas turbine engines. Full article

The tip leakage flow over the blades of an axial compressor rotor adversely affects the axial rotor efficiency and can determine the onset of tip leakage stall. The performance of a new casing treatment concept in the shape of an axisymmetric recirculation channel is explored by steady Reynolds-Averaged Navier–Stokes (RANS) realizable k-ε modelling on the NASA Rotor 37 test case. The modelling exposed a number of attractive features. The casing treatment increased the stall margin at no penalty to the rotor isentropic efficiency over the rotor operating line. A recirculation in the casing channel self-activated and self-adjusted with the rotor loading to provide more passive flow control at higher rotor loading conditions. The nozzle-shaped recirculation channel outflow opposed the tip leakage jet, re-located the casing surface flow interface further downstream, and reduced the rotor blade tip incidence angle. This combination of features makes the new casing treatment particularly attractive for applications to high thrust-to-weight ratio engines, typical of high-performance jet aircraft. Full article
