Search Results (46)

This study compares the performance of a quartz tuning fork (QTF) with a highly sensitive ultrasound microphone in the context of acoustic measurements, applying the substitution calibration method. QTF sensors are increasingly used for high-precision tasks due to their sensitivity and stability, while microphones are still the standard in general acoustic measurements. The aim of this study is to evaluate both technologies across several key performance metrics, including linearity of response, sensitivity, noise characteristics, and acoustic detection limit. Which sensor is better suited to which acoustic and physical condition? The results show that QTFs perform exceptionally well in applications requiring high precision, especially in high-frequency and narrow-band measurements. The signal-to-noise-ratio (SNR) of the QTF at its resonance frequency is 14 dB higher than that of the microphone, whereas the detection limit and linearity are comparable. The findings suggest that QTF sensors are particularly advantageous for specialized applications like photoacoustic spectroscopy (PAS). Full article

Quartz-enhanced photoacoustic spectroscopy (QEPAS) has shown great promise for monitoring greenhouse gases and pollutants with a high measurement accuracy and limit of detection. A QEPAS sensor, which can achieve high photoacoustic signal gain without requiring the laser beam to pass through the two prongs of a quartz tuning fork (QTF), is reported. A custom QTF with a resonant frequency of 7.2 kHz and a quality factor of 8406 was employed as a sound detection element, and the parameters of the acoustic micro-resonator (AmR) in the off-beam QEPAS spectrophone were optimized. A signal-to-noise ratio (SNR) gain of 16 was achieved based on the optimal AmR dimensions compared to the bare custom QTF. Water vapor (H₂O) was detected utilizing the QEPAS sensor equipped with the off-beam spectrophone, achieving a minimum detection limit (MDL) of 4 ppm with a normalized noise equivalent absorption coefficient (NNEA) of 5.7 × 10⁻⁸ cm⁻¹·W·Hz^−1/2 at an integration time of 300 ms. Full article

Based on photoacoustic spectroscopy and finite element simulation technology, a simulation model of sound field excitation in a cylindrical resonant photoacoustic cell was established. The finite element simulation method was used to analyze the acoustic mode and sound pressure distribution of the cavity structure of the photoacoustic cell. The effects of the geometric parameters of the resonator and the buffer cavity on the performance of the photoacoustic cell were compared. The frequency response characteristics of the photoacoustic cell and the effects of the air intake and the air outlet were studied. Based on the simulation results, a cylindrical resonant photoacoustic cell was designed, and a photoacoustic sensor for NO₂ detection was built. NO₂ with a volume fraction of 10⁻⁵ was taken as the sample gas through frequency scanning to obtain the frequency response curve of the system. The resonant frequency is 1730 Hz, and the cell constant is about 542.3 (Pa*cm)/W. The quality factor is 10.05. By linear fitting the calibration curve of the sensor, the fitting slope is 0.012 µV/ppb, and R² is 0.998. Atmospheric NO₂ detection was carried out for two consecutive weeks, whose findings are in good agreement with the data released by a Huainan environmental monitoring site. The experimental results show that the system can detect NO₂ in the atmosphere with high sensitivity. Full article

In this study, we address the challenge of estimating the resonance frequency of a photoacoustic detector (PAD) gas cell under varying temperature conditions, which is crucial for improving the accuracy of gas concentration measurements. We introduce a novel approach that uses a long short-term memory network and a self-attention mechanism to model resonance frequency shifts based on temperature data. To investigate the impact of the gas mixture temperature on the resonance frequency, we modified the PAD to include an internal temperature sensor. Our experiments involved multiple heating and cooling cycles with varying methane concentrations, resulting in a comprehensive dataset of temperature and resonance frequency measurements. The proposed models were trained and validated on this dataset, and the results demonstrate real-time prediction capabilities with a mean absolute error of less than 1 Hz for frequency shifts exceeding 30 Hz over four-hour periods. This approach allows continuous, real-time tracking of the resonance frequency without interrupting the laser operation, significantly enhancing gas concentration measurements and contributing to the long-term stabilization of the sensor. The results suggest that the proposed approach is effective in managing temperature-induced frequency shifts, making it a valuable tool for improving the accuracy and stability of gas sensors in practical applications. Full article

In this work, a miniaturized Y-sphere coupled photoacoustic (YSCPA) sensor is proposed for trace C₂H₂ gas detection. The cavity volume of the designed YSCPA sensor is about 0.7 mL. The finite element method (FEM) has been performed to analyze the comparative performance of the YSCPA sensor and T-type PA sensor, indicating that the first-order resonance frequency (FORF) of the newly proposed YSCPA sensor has been reduced by half while the PA signal has been improved by a factor of 3 compared to the T-type PA sensor. C₂H₂ is employed as a target gas to test the performance of the YSCPA sensor. The experimental test results show that the response time of the gas is 26 s. The minimum detection limit (MDL) reaches 189 ppb at a lock-in integration time of 1 s. By extending the lock-in integration time to 100 s, the MDL of the designed PA sensor is reduced to 18.1 ppb. The designed YSCPA sensor has the advantages of small size, low gas consumption, simple structure, and high sensitivity, which is expected to be an effective solution for rapid and real-time monitoring of dissolved C₂H₂ gas in transformer oil. Full article

The measurement of partial pressures of oxygen (O₂) and carbon dioxide (CO₂) is fundamental for evaluating a patient’s conditions in clinical practice. There are many ways to retrieve O₂/CO₂ partial pressures and concentrations. Arterial blood gas (ABG) analysis is the gold standard technique for such a purpose, but it is invasive, intermittent, and potentially painful. Among all the alternative methods for gas monitoring, non-invasive transcutaneous O₂ and CO₂ monitoring has been emerging since the 1970s, being able to overcome the main drawbacks of ABG analysis. Clark and Severinghaus electrodes enabled the breakthrough for transcutaneous O₂ and CO₂ monitoring, respectively, and in the last twenty years, many innovations have been introduced as alternatives to overcome their limitations. This review reports the most recent solutions for transcutaneous O₂ and CO₂ monitoring, with a particular consideration for wearable measurement systems. Luminescence-based electronic paramagnetic resonance and photoacoustic sensors are investigated. Optical sensors appear to be the most promising, giving fast and accurate measurements without the need for frequent calibrations and being suitable for integration into wearable measurement systems. Full article

The quartz tuning fork used as an acoustic sensor in quartz-enhanced photo-acoustic spectroscopy gas detection systems is usually read out by means of a transimpedance preamplifier based on a low-noise operational amplifier closed in a feedback loop. The gain–bandwidth product of the operational amplifier used in the circuit is a key parameter which must be properly chosen to guarantee that the circuit works as expected. Here, we demonstrate that if the value of this parameter is not sufficiently large, the response of the preamplifier exhibits a peak at a frequency which does not coincide with the series resonant frequency of the quartz tuning fork. If this peak frequency is selected for modulating the laser bias current and is also used as the reference frequency of the lock-in amplifier, a penalty results in terms of signal-to-noise ratio at the output of the QEPAS sensor. This worsens the performance of the gas sensing system in terms of ultimate detection limits. We show that this happens when the front-end preamplifier of the quartz tuning fork is based on some amplifier models that are typically used for such application, both when the integration time of the lock-in amplifier filter is long, to boost noise rejection, and when it is short, in order to comply with a relevant measurement rate. Full article

A single-fiber photoacoustic (PA) sensor with a silicon cantilever beam for trace acetylene (C₂H₂) gas analysis was proposed. The miniature gas sensor mainly consisted of a microcantilever and a non-resonant PA cell for the real-time detection of acetylene gas. The gas diffused into the photoacoustic cell through the silicon cantilever beam gap. The volume of the PA cell in the sensor was about 14 μL. By using a 1 × 2 fiber optical coupler, a 1532.8 nm distributed feedback (DFB) laser and a white light interference demodulation module were connected to the single-fiber photoacoustic sensor. A silicon cantilever was utilized to improve the performance when detecting the PA signal. To eliminate the interference of the laser-reflected light, a part of the Fabry–Perot (F-P) interference spectrum was used for phase demodulation to achieve the highly sensitive detection of acetylene gas. The minimum detection limit (MDL) achieved was 0.2 ppm with 100 s averaging time. In addition, the calculated normalized noise equivalent absorption (NNEA) coefficient was 4.4 × 10⁻⁹ W·cm⁻¹·Hz^−1/2. The single-fiber photoacoustic sensor designed has great application prospects in the early warning of transformer faults. Full article

Anti-resonant hollow core fibers (AR-HCFs) provide a promising solution for photothermal spectroscopy and photoacoustic imaging applications. Here, the AR-HCF serves as a micro platform to induce the photothermal/photoacoustic effect. Since the Bragg structure can induce multiple AR effects compared with the general AR-HCF, we proposed a novel device, the AR-BHCF (AR-HCF with Bragg cladding), to enhance the excitation efficiency. The simulation and experimental results validate that the AR-BHCF dominates in having a stronger ability to confine the optical field in the air core indeed. Then, the acoustic signal stimulated by the photoacoustic effect will propagate along with the fiber axial, and part of it will penetrate out of the AR-BHCF. The results revealed that the transmission bandwidth of the acoustic wave in the AR-BHCF ranges from 1 Hz to 1 MHz, covering infrasound to ultrasound. In particular, a constant coefficient of 0.5 exists in the acoustic wave fading process, related to the propagation frequency and time. The acoustic signal can be monitored in real time, assisted by the ultra-highly sensitive sensor head. Therefore, BHCF-based devices combined with photoacoustic techniques may accelerate their sensing applications. Meanwhile, this scheme shines a light on the theoretical foundation of novel short-haul distributed acoustic sensing. Full article

Due to the rise in global temperature and climate change, the detection of CO₂, SO₂ and NO pollutants is important in smart cities. In this paper, an H-shaped photoacoustic cell is utilized for the detection of low-concentration gases. The geometry of the cell is miniaturized and designed with specific parameters in order to increase its efficiency and performance. The designed cell eliminates problems such as bulkiness and cost, which prevent the use of sensors in detecting greenhouse gases. The simplicity of the design expands the application rate of the cell in practice. In order to consider the viscosity and thermal effects, the cell is formulized by fully linearized Navier–Stokes equations, and various parameters, such as acoustic pressure, frequency response, sound speed (sound velocity) and quality factor, are investigated for the mentioned gases. The performance of the system is frequency-based, and the target gases can be detected by using a microelectromechanical resonator as a pressure sensor. Quality factor analysis expresses that CO₂, SO₂ and NO gases have quality factors of 27.84, 33.62 and 33.32, respectively. The performance of the cell in the resonance state can be expressed by the linear correlation between the results. The background noise generated in the photoacoustic research has been removed by miniaturization due to the obtained resonance, and the proposed cell provides a proper signal-to-noise ratio. The results of the proposed system represent the increase in the quality factor, which reduces the losses and thus increases the sensitivity of the system in the study of greenhouse gases. Full article

This paper presents the development of a highly sensitive gas detection system based on a resonant photoacoustic cell for detecting dissolved gases in transformer oil. A simulation model of the resonant photoacoustic cell was studied and optimized the buffer chamber volume while ensuring signal enhancement. The volume of the photoacoustic cell was reduced by about 80% compared to the classical model. A resonant photoacoustic cell was then fabricated based on the optimized simulation optimization. The dual-resonance photoacoustic system was constructed by combining the resonant PA cell with a handmade cantilever fiber acoustic sensor. The system’s sensitivity was further improved by using an erbium-doped fiber amplifier, wavelength modulation, and harmonic detection technology. The experimental results showed that the system achieved a detection limit of 6 ppb and an excellent linear range under 1000 ppm for C₂H₂ gas. The developed gas detection system has potential applications for monitoring the condition of power transformers in power grids. Full article

In this invited paper, a highly sensitive methane (CH₄) trace gas sensor based on quartz-enhanced photoacoustic spectroscopy (QEPAS) technique using a high-power diode laser and a miniaturized 3D-printed acoustic detection unit (ADU) is demonstrated for the first time. A high-power diode laser emitting at 6057.10 cm⁻¹ (1650.96 nm), with the optical power up to 38 mW, was selected as the excitation source to provide a strong excitation. A 3D-printed ADU, including the optical and photoacoustic detection elements, had a dimension of 42 mm, 27 mm, and 8 mm in length, width, and height, respectively. The total weight of this 3D-printed ADU, including all elements, was 6 g. A quartz tuning fork (QTF) with a resonant frequency and Q factor of 32.749 kHz and 10,598, respectively, was used as an acoustic transducer. The performance of the high-power diode laser-based CH₄–QEPAS sensor, with 3D-printed ADU, was investigated in detail. The optimum laser wavelength modulation depth was found to be 0.302 cm⁻¹. The concentration response of this CH₄–QEPAS sensor was researched when the CH₄ gas sample, with different concentration samples, was adopted. The obtained results showed that this CH₄–QEPAS sensor had an outstanding linear concentration response. The minimum detection limit (MDL) was found to be 14.93 ppm. The normalized noise equivalent absorption (NNEA) coefficient was obtained as 2.20 × 10⁻⁷ cm⁻¹W/Hz^−1/2. A highly sensitive CH₄–QEPAS sensor, with a small volume and light weight of ADU, is advantageous for the real applications. It can be portable and carried on some platforms, such as an unmanned aerial vehicle (UAV) and a balloon. Full article

An enhanced MEMS capacitive sensor is developed for photoacoustic gas detection. This work attempts to address the lack of the literature regarding integrated and compact silicon-based photoacoustic gas sensors. The proposed mechanical resonator combines the advantages of silicon technology used in MEMS microphones and the high-quality factor, characteristic of quartz tuning fork (QTF). The suggested design focuses on a functional partitioning of the structure to simultaneously enhance the collection of the photoacoustic energy, overcome viscous damping, and provide high nominal capacitance. The sensor is modeled and fabricated using silicon-on-insulator (SOI) wafers. First, an electrical characterization is performed to evaluate the resonator frequency response and nominal capacitance. Then, under photoacoustic excitation and without using an acoustic cavity, the viability and the linearity of the sensor are demonstrated by performing measurements on calibrated concentrations of methane in dry nitrogen. In the first harmonic detection, the limit of detection (LOD) is 104 ppmv (for 1 s integration time), leading to a normalized noise equivalent absorption coefficient (NNEA) of 8.6 ⋅ 10⁻⁸ Wcm⁻¹ Hz^−1/2, which is better than that of bare Quartz-Enhanced Photoacoustic Spectroscopy (QEPAS), a state-of-the-art reference to compact and selective gas sensors. Full article

We demonstrate a highly sensitive acoustic vibration sensor based on a tapered-tip optical fiber acting as a microcantilever. The tapered-tip fiber has a unique output profile that exhibits a circular fringe pattern, whose distribution is highly sensitive to the vibration of the fiber tip. A piezo transducer is used for the acoustic excitation of the fiber microcantilever, which results in a periodic bending of the tip and thereby a significant output power modulation. Using a multimode readout fiber connected to an electric spectrum analyzer, we measured the amplitude of these power modulations over the 10–50 kHz range and observed resonances over certain frequency ranges. Two types of tapered-tip fibers were fabricated with diameter values of 1.5 µm and 1.8 µm and their frequency responses were compared with a non-tapered fiber tip. Thanks to the resonance effect as well as the sensitive fringe pattern of the tapered-tip fibers, the limit of detection and the sensitivity of the fiber sensor were obtained as 0.1 nm and 15.7 V/nm, respectively, which were significantly better than the values obtained with the non-tapered fiber tip (i.e., 1.1 nm and 0.12 V/nm, respectively). The sensor is highly sensitive, easy to fabricate, low-cost, and can detect sub-nanometer displacements, which makes it a promising tool for vibration sensing, particularly in the photoacoustic sensing of greenhouse gases. Full article

Photoacoustic spectroscopy (PAS) has received extensive attention in optical gas sensing due to the advantages of high sensitivity, gas selectivity, and online detection. Here, a mid-infrared hollow-core fiber (HCF) based flexible longitudinal photoacoustic resonator for PAS-based gas sensing is proposed and theoretically demonstrated. A mid-infrared anti-resonant HCF is designed to innovatively replace the traditional metallic acoustic resonator and obtain a flexible photoacoustic cell in PAS. Optical transmission characteristics of the HCF are analyzed and discussed, achieving single mode operation with below 1 dB/m confinement loss between 3 and 8 μm and covering strong absorptions of some hydrocarbons and carbon oxides. With varied bending radii from 10 mm to 200 mm, the optical mode could be maintained in the hollow core. Based on the photoacoustic effect, generated acoustic mode distributions in the HCF-based flexible photoacoustic resonator are analyzed and compared. Results show that the PAS-based sensor has a stable and converged acoustic profile at the resonant frequency of around 16,787 Hz and a favorable linear response to light source power and gas concentration. The proposed novel photoacoustic resonator using HCF presents bring potential for advanced flexible PAS-based gas detection. Full article
