Search Results (26)

Rail corrugation causes various problems such as a decrease in ride comfort due to aggravation of train noise and vibration, and an increase in the amount of track component maintenance due to the amplification of the track impact. Most of the preceding research on rail corrugation has been conducted on the causes and characteristics of rail corrugation, but there are no countermeasures or management plans for existing rail corrugation. In this study, dynamic track response measurement results are analyzed. The dynamic wheel load, rail acceleration, and displacement of the rails and sleepers due to rail grinding were reduced by approximately 48%, 18%, and 12%, respectively. The analysis model was confirmed to be appropriate by comparing the measured and analyzed values of the dynamic wheel load before and after rail grinding in the section where rail corrugation occurred. Additionally, a maintenance method for rail corrugation was proposed considering the wheel–rail interaction force by calculating the appropriate grinding amount (upper and lower limit) for each train speed. Full article

To improve the mechanical properties and wear resistance of QAl9-4 aluminum bronze alloy parts of high-speed rail brake calipers, the solid aluminum bronze alloy was treated with a pulsed magnetic field in which the magnetic induction intensity was 3T at room temperature. After that, a tensile test and a friction and wear test were carried out on the alloy. The results indicate that the magnetic field promotes the movement of low-angle grain boundaries less than 2° and splices to form subcrystals or fine crystals, which reduces the mean grain size of the alloy. The disordered dislocation changed into a locally ordered dislocation line, the dislocation distribution became uniform, and the dislocation density increased, which simultaneously improved the alloy’s tensile strength and elongation. The elongation increased by 10.2% compared with that without the magnetic field. The increase in strength can provide strong support for the wear-resistant hard phase, and the enhancement of plasticity can increase the alloy’s ability to absorb frictional vibration. Therefore, it was hard for cracks to form and extend, and the specimen’s average friction coefficient was reduced by 22.05%. The grinding crack width and depth decreased, the wear debris became more uniform and fine, and the alloy’s wear resistance increased. Full article

Turnouts are the weak spot in high-speed rail systems, and it is simple for the phenomenon of the wheel–rail force and the carbody lateral acceleration over-limit to arise when the train passes through, which affects the service life of the rail and the running stability of the train. In this paper, the turnout with wheel–rail force over-limit and carbody lateral acceleration over-limit is selected for analysis, and the profiles of the wheel and rail are monitored. Then, the vehicle–turnout coupled multi-body dynamics model is simulated. Additionally, the portable vibration analyzer, the comprehensive inspection train, and the wheel–rail contact dynamic stress tester monitors the data and evaluates the impact of rail grinding on high-speed railway. The results of this study demonstrated that the turnout profiles are in good agreement with the standard wheel profiles following grinding, and the wheel–rail contact point and equivalent conicity both improved. When the train passes the ground turnout at high speed with and without the wheel polygonal wear, the wheel–rail force and the carbody acceleration were clearly improved. Using the wheel–rail contact dynamic stress tester, the comprehensive inspection train, and the portable vibration analyzer monitoring the changes in the carbody acceleration, the wheel–rail force and the carbody acceleration are definitely better after grinding. Similar to the pattern in the simulation, the train’s running steadiness increased by grinding. Full article

Grinding chatter is a kind of self-excited vibration in which the grinding system continuously absorbs energy from the grinding machine, increasing the mechanical energy of the system. Grinding chatter can damage the surface of the workpiece and accelerate the abrasion of the grinding wheel. The theoretical analysis of the grinding chatter for the beam surface was launched based on the behavior of a single abrasive grain, whose cutting thickness is a key factor affecting grinding stability. The dynamic grinding force model has been developed, which is the interaction interface between the grinding wheel and the workpiece. In this paper, rail beam grinding was taken as an example. The vibration performance of the rail beam was described with the Timoshenko beam. The characteristics of the frequency domain of the grinding wheel-workpiece system were observed, and the condition of the stability at any position in the longitudinal direction of the beam was gained, which could be quantitatively characterized with the stability limit curve. The grinding experiments of the rail beam surface demonstrated that as chatter developed, the chatter marks could be investigated on the surface of the rail, and the energy of the chatter signal was mainly concentrated around the chatter frequency, which was higher than the natural frequency of the grinding wheel. Full article

Managing head checks is a crucial task for an infrastructure manager as in case of deep cracks, rails can break and, thus, accidents might be the consequence. Many infrastructure managers use vehicle-mounted eddy-current testing for detecting cracks. This is sufficient for guaranteeing safe railway operation in applying a reactive maintenance regime removing cracks of a pre-defined depth. Moving this towards a predictive maintenance regime is only possible through assessing the crack growth. Establishing a stable deterioration function needs a sound data basis including a proper re-positioning of the test results of consecutive testing campaigns. This paper presents the results achieved from analysing the eddy-current testing campaigns of 10 years on a main line of the Austrian railway network and calculating a crack growth function as regression to field data. While it is possible to derive stable functions, the testing frequency needs to be shortened in order to move further to predictive maintenance. Full article

For high-tech manufacturing industries, developing large-scale complex nonlinear dynamic systems must be taken as one of the basic works, formulating problems to be solved, steering system design in a more preferable direction, and making correct strategic decisions. By using effective tools of big data mining, Dynamic Design Methodology was proposed to establish a technical platform for Multidiscipline Design Optimization such as High-Speed Rolling Stock, including three key technologies: analysis graph of full-vehicle stability properties and variation patterns, improved transaction strategy of flexible body to MBS interface, seamless collaboration with weldline fatigue damage assessments through correct Modal Stress Recovery. By applying the above methodology, a self-adaptive improved solution was formulated with optimal parameter configuration, which is one of the more favorable options for higher-speed bogies. While within a velocity (140–200) km/h at λ_e < 0.10, car body instability’s influence on ride comfort can be easily improved by using a semi-active vibration reduction technique between inter-vehicles through outer windshields. Comprehensive evaluations show that only under rational conditions of wheel-rail matching, i.e., 0.10 ≥ λ_eN > λ_emin and λ_emin = (0.03–0.06), can this low-cost solution achieve the three goals of low track conicity, optimal route planning, and investment benefit maximization. So, rail vehicle experts are necessary to collaborate and innovate intensively with passenger transportation and steel rail ones. Specifically, by adopting rail grinding treatment, occurrence probability is controlled at 85% and 5% for track conicity of (0.03–0.10) and (0.25–0.35). By optimizing routing planning, operating across dedicated lines of different speed grades can achieve self-cleaning of central hollow tread wear over time. According to the inherent rigid-flex coupling relationship, geometric nonlinearities of worn wheel-rail contact should be avoided as much as possible for HSR practices. Only under weak coupling interfaces in the floor frame can the structural integrity of an aluminum alloy car body be ensured. Full article

A scheme for manufacturing heavy-duty rail grinding wheels with silicone-modified phenolic resin (SMPR) as a binder in the field of rail grinding is presented to improve the performance of grinding wheels. To optimize the heat resistance and mechanical performance of rail grinding wheels, an SMPR for industrial production of rail grinding wheels was prepared in a two-step reaction using methyl-trimethoxy-silane (MTMS) as the organosilicon modifier by guiding the occurrence of the transesterification and addition polymerization reactions. The effect of MTMS concentration on the performance of silicone-modified phenolic resin for application in rail grinding wheels was investigated. The molecular structure, thermal stability, bending strength, and impact strength values of the SMPR were characterized by Fourier transform infrared spectroscopy (FTIR), thermogravimetric analysis (TGA), and mechanical property testing, and the effect of MTMS content on the resin properties was investigated. The results indicated that MTMS successfully improved the performance of the phenolic resin. The thermogravimetric weight loss temperature of the SMPR modified by MTMS with 40% phenol mass at 30% weight loss is 66% higher than that of common phenolic resin (UMPR), exhibiting the best thermal stability; in addition, its bending strength and impact strength were enhanced by approximately 14% and 6%, respectively, compared with those of common UMPR. This study utilized an innovative Bronsted acid as a catalyst and simplified several intermediate reactions in the conventional silicone-modified phenolic resin technology. This new investigation of the synthesis process decreases the manufacturing cost of the SMPR, liberates it from the restrictions of grinding applications, and enables the SMPR to maximize its performance in the rail grinding industry. This study serves as a reference for future work on resin binders for grinding wheels and the development of rail grinding wheel manufacturing technology. Full article

Rail corrugation is a degradation phenomenon that manifests as a quasi-periodic irregularity on the running surface of the rail. It is a critical problem for urban railway lines because it induces ground-borne vibrations transmitted to the buildings near the infrastructure, causing complaints from the inhabitants. A typical treatment to mitigate the rail corrugation problem is the periodic grinding of the rails, performed by dedicated vehicles. The scheduling of rail maintenance is particularly critical because it can be performed only when the service is interrupted. A procedure for the continuous monitoring of rail corrugation is proposed, based on axlebox acceleration measurements. The rail irregularity is estimated from the measured acceleration by means of a frequency domain model of vertical dynamics of the wheel–rail interaction. The results obtained by using two different methods (a state-of-the-art method and a new one) are compared. Finally, the study of the evolution of the power content of the rail irregularity enables the identification of the track sections where corrugation is developing and rail grinding is necessary. Full article

Aimed at the problems of difficult treatment, unreasonable utilization and serious waste of fruit tree residue, combined with the terrain and planting characteristics of hilly orchards, a self-propelled monorail branch chipper was developed. It can realize long distances and large ranges of crushing operations and debris tiling in the garden. Because the monorail branch chipper adopts the half-empty suspension support method, the moving operations and discontinuous cutting of branches can lead to vibration failures or hazards. In response to this problem, modal analysis of a track system with different numbers of nodes by ANSYS software showed that an increase in the number of track sections decreases the natural frequency of each order under the condition of rigid fixation of the support rods, and weakness of vibration is especially seen in sections 1–4, but after a certain amount, the vibrational change tends to level off. The number of lateral rods should be increased for distal short rail branches of less than four sections to reduce operational and operational vibration. The vibration level test results of field multi-condition and multi-point grinding operations showed that the static vibration amplitude of the crusher is basically the same as that of the mobile state. The vibration amplitude of the chipper is significantly increased when in the states from no-load to grinding operation, and the maximum vibration occurs in the left and right direction of the transverse rail, which provides a theoretical basis and optimization direction for further optimization of the single-track branch chipper operational stability problem. Full article

In order to achieve the goal of lightening the braking system of urban rail trains, SiCp/ZL101 and ZL101 plates were welded by friction stir lap welding (FSLW) to prepare a new type of brake disc material. The friction and wear properties of the friction-stir-processed composite material were studied at different temperatures (30 °C, 100 °C, 150 °C, 200 °C, 250 °C, 300 °C) to provide a theoretical basis for the evaluation of braking performance. The experimental results showed that the sliding friction processes at each temperature were relatively stable, the friction coefficients did not vary much and the average friction coefficients changed slightly, stabilizing at about 0.4. The wear extent and the depth of wear scars increased with the increase in the temperature, reaching the highest at 150 °C and then began to decrease. At room temperature, the wear forms were mainly oxidative wear and abrasive wear; as the temperature rose, under the cyclic shearing action of the grinding ball, the abrasive debris fell off under the expansion of fatigue cracks and fatigue wear was the main form at this stage. When the temperature reached 200 °C, it began to show the characteristics of adhesive wear; after 250 °C, due to the gradual formation of a mechanical mixed layer containing more SiC particles and oxides on the wear surface, it exhibited high-temperature lubrication characteristics, and the wear extent was equivalent to 35% of the wear extent at normal temperature, indicating that the composite material had good high-temperature friction and wear properties. Full article

High-speed rail grinding is a unique passive grinding maintenance strategy that differs from conventional grinding techniques. Its grinding behavior is dependent on the relative motion between the grinding wheel and rail; hence, it possesses great speed and efficiency. In this study, the effects of the duration of grinding time and the increase in the number of grinding passes on the grinding of high-speed rails were investigated using passive grinding tests with a single grinding time of 10 s and 30 s and grinding passes of once, twice, and three times, respectively. The results show that when the total grinding time was the same, the rail removal, grinding ratio of grinding wheels, rail grinding effect, grinding force, and grinding temperature were better in three passes of 10 s grinding than in one pass of 30 s grinding, indicating that the short-time and multi-pass grinding scheme is not only conducive to improving the grinding efficiency and grinding quality in the high-speed rail grinding but can also extend the service life of the grinding wheels. Moreover, when the single grinding times were 10 s and 30 s, respectively, the grinding removal, grinding efficiency, grinding marks depth, and surface roughness of rail increased with the number of grinding passes, implying that the desired rail grinding objective can be achieved by extending the grinding time via the multi-pass grinding strategy. The results and theoretical analysis of this study will contribute to re-conceptualizing the practical operation of high-speed rail grinding and provide references for the development of the grinding process and grinding technology. Full article

The development of a laser cladding repair strategy is critical for the continued growth of heavy-haul railway networks. Premium hypereutectoid rails have undergone laser cladding using a new martensitic stainless-steel alloy, 415SS, developed for high carbon rails after standard cladding metals were found to be incompatible. Non-destructive neutron diffraction techniques were used to measure the residual stress in different layers generated across a dissimilar metal joint during laser cladding. The internal stress distribution across the cladding, heat-affected zone (HAZ), and substrate was measured in the untempered rail, after 350 °C and 540 °C heat treatment procedures and two surface grinding operations. The martensitic 415SS depositions produce compressive stress in the cladding, regardless of tempering procedures, which may inhibit fatigue crack propagation whilst grinding operations locally relive surface stress. Balancing tensile stresses were recorded below the fusion boundary in the HAZ due to thermal gradients altering the microstructure. The combination of 540 °C tempering and 0.5 mm surface layer removal produced a desirable combination of compression in the cladding deposition with significantly reduced tensile stresses in the HAZ. A comparison with the current literature shows that this alloy achieves a unique combination of desirable hardness, low tensile stress, and compression in the cladding layer. Data obtained during strain scanning has been used to determine the location of microstructural changes at the fusion boundary and HAZ through correlation of the stress, strain, full width at half maximum (FWHM), and intensity profiles. Therefore, neutron diffraction can be used for both the accurate measurement of internal residual stress and to obtain microstructural information of a metallurgical join non-destructively. Full article

The peripheral surface of the grinding wheel can grind the rail according to the envelope of the contour of the rail surface, thus a fuller and smoother rail surface can be obtained. Specifically, a better grinding effect can be obtained in that the end face of the grinding wheel deviates from the longitudinal section of the rail at a certain angle. Based on the traditional grinding technology theory, the mathematical models of the peripheral grinding parameters (kinematic contact arc length, wheel-rail grinding contact area, and maximum undeformed chip thickness) and the grinding force are established, in which the angle exists between the grinding wheel end face and the rail longitudinal section. The main influence of grinding wheel circumferential speed, grinding wheel kinematic speed, and the deflection angle of the grinding wheel end face on the grinding parameters and the force are analyzed. The result shows that: when there is angle θ in the models, the ratios of peripheral grinding parameters between up-grinding and down-grinding varies monotonically with the increase in v_m, and their maximum variation range is about 12%, v_s has the greatest influence on the peripheral grinding parameters, and the maximum variation range of the ratios is about 20% when the v_s is 10 m/s. With the increase in the grinding width, Fa’ cannot be ignored and will increase gradually with the increase in angle θ. The analysis and conclusion have guiding significance for the structural design, grinding control strategy, and experimental research regarding rail curved surface grinding equipment. Full article

The prospect of growth of a railway system impacts both the network size and its occupation. Due to the overloaded infrastructure, it is necessary to increase reliability by adopting fast maintenance services to reach economic and security conditions. In this context, one major problem is the excessive friction caused by the wheels. This contingency may cause ruptures with severe consequences. While eddy’s current approaches are adequate to detect superficial damages in metal structures, there are still open challenges concerning automatic identification of rail defects. Herein, we propose an embedded system for online detection and location of rails defects based on eddy current. Moreover, we propose a new method to interpret eddy current signals by analyzing their wavelet transforms through a convolutional neural network. With this approach, the embedded system locates and classifies different types of anomalies, enabling an optimization of the railway maintenance plan. Field tests were performed, in which the rail anomalies were grouped in three classes: squids, weld and joints. The results showed a classification efficiency of ~98%, surpassing the most commonly used methods found in the literature. Full article

The noise caused by rail corrugation seriously affects the operation quality of metro vehicles. In this work, the rail corrugation, interior noise and wheel–rail noise of a metro line were tested, and the test results were compared with those after two kinds of treatments. The results show that rail corrugation is the main cause of the abnormal interior noise. The interior noise in many sections exceeds the limit, where clear rail corrugations from 31.5~63 mm are found. When the train passes through the rail corrugation section, the interior noise shows a clear increase, and the maximum increase is higher than 25 dB(A). After increasing the lateral stiffness of the track and rail grinding, the interior noise is reduced by 11.4 dB(A). After a long renovation time, the interior noise is effectively equal to that when the renovation was completed. The research results of this work can provide a reference for rail corrugation treatment and noise control. Full article
