One of the key indicators of the foundation soil consolidation is the smear effect brought on by the insertion of a Prefabricated vertical drain (PVD), which also smears the extent of disturbance. Prior research primarily examined the impact of the diameter of the Prefabricated vertical drain sleeves, ignoring the impact of pile shoe size on smear effect. The penetration process of pile shoes of varying sizes in layered soils was simulated using transparent soil model experiments, and Particle Image Velocimetry (PIV) technology was used to visualize and assess the soil disturbance caused by the pile shoes. Theoretical and experimental data are used to suggest and analyze the correction coefficients for the geometric characteristics of pile shoes using the Mohr–Coulomb criterion and reaming theory. The study’s findings demonstrate that transparent soil and the PIV method can successfully capture the dynamic evolution of the “inverted cone” in the smeared area, which is consistent with the theory of cylindrical pore expansion’s prediction. The horizontal disturbance range will increase as the equivalent radius of the pile shoes increases, and it is 4.5d for pile shoes with an equivalent radius of 1.5 mm and 5d for pile shoes with an equivalent radius of 2.0 mm. The discontinuity of the soil layer interface will be made worse by pile shoes with a high equivalent radius, making the phenomenon of stress concentration more noticeable. Its quantitative analysis demonstrates the reasonableness of the correction factor λ, which offers a trustworthy tool to quantify the perturbation effect of the pile shoe size. A correction factor λ is proposed so that the error between the corrected theoretical value and the test value is less than 5%. Full article

This study incorporates a nonlinear seepage relationship into Biot’s consolidation theory and simulates the consolidation of a single vertical drain under vacuum preloading using the finite element method. The model, simplified via the equal-strain assumption, is validated against theoretical predictions. Under the axisymmetric Biot’s framework, consolidation behavior is analyzed in detail. The results show that in the early stages of consolidation, excess pore water pressure in the vicinity of the prefabricated vertical drain (PVD) does not fully dissipate and may even increase, indicating the occurrence of the Mandel–Cryer effect. As the consolidation process advances, the consolidation front gradually extends outward, and the void ratio near the PVD decreases rapidly, leading to the formation of a clogging zone. In contrast, the reduction in the void ratio in the non-clogging region is relatively slow. The progressive development of the clogging zone significantly impedes the overall consolidation rate. Furthermore, this study explores the influence of key parameters—including the compression index, permeability coefficient, well diameter ratio, smear effect, and well resistance—on the formation of the clogging zone and the Mandel–Cryer effect. Full article

To accelerate the dissipation of excess pore water pressure, enhance the bearing capacity of piles, and mitigate long-term settlement in soft ground, a novel green and lowcarbon pile foundation technology, termed the precast drainage pile (PDP) technology, is proposed. This innovative approach integrated precast pipe piles with prefabricated vertical drains (PVDs) attached to their sides. The piles were installed using static pile pressing and were subsequently subjected to vacuum-induced negative pressure to facilitate soil consolidation, which enhances the resource utilization rate of pile foundations and promotes the sustainable utilization of soft soil foundations. To investigate the bearing characteristics of the PDP, this study combined the shear displacement method for piles with the consolidation theory of soft soil foundations. A calculation model for the load-settlement behavior of precast piles, accounting for the influence of vacuum-induced soil consolidation, was derived, establishing a method for analyzing the load transfer mechanism of PDPs. The reliability of the theoretical model was validated through comparisons with engineering test results. Building on this foundation, the influence of factors such as consolidation period and pile length on the bearing characteristics of PDPs was analyzed. The results demonstrated that, compared to a 10 m precast pile without drainage, the ultimate bearing capacity of single piles with drainage durations of 3, 7, 14, and 28 days increased by 7.3%, 12.7%, 20.3%, and 29.6%, respectively. Furthermore, under a 7-day drainage condition, the bearing capacity of piles with lengths of 10 m, 20 m, and 30 m increased by 12.7%, 12.8%, and 13.1%, respectively. Overall, the findings of this study provide a theoretical basis for the research, development, and design calculations of this new sustainable pile technology. Full article

A full-scale embankment on soft clays improved with prefabricated vertical drains (PVDs) have to be analyzed in 3D conditions due to a great number of vertical drains under an embankment. However, 3D analysis is very complex, time-consuming, and needs a powerful computer. Therefore, axisymmetric vertical drains have to be converted into equivalent plane-strain conditions for 2D analysis. Different matching approaches based on unit cell concept have been developed in the literature and the matching can be achieved by modifying the drain distance and/or soil permeability according with relatively simple instructions. This paper investigates verification of three different matching approaches to be used in the numerical analysis of full-scale embankment built on multiple vertical drains. The elasto-plastic soft soil model was used in the numerical analysis, and the results are compared with the laboratory and field measurements. The results of numerical analysis demonstrate that the matching methods are in extremely good agreement with the measurements if the effect of both the smear zone and discharge capacity are taken into consideration. It is seen that these methods provide practical solutions and important advantages to geotechnical engineers. Full article

By comparing different settlement forecast methods, eight methods were selected considering the creep of marine soft soils in this case study, including the Hyperbolic Method (HM), Exponential Curve Method (ECM), Pearl Growth Curve Modeling (PGCM), Gompertz Growth Curve Modeling (GGCM), Grey (1, 1) Model (GM), Grey Verhulst Model (GVM), Back Propagation of Artificial Neural Network (BPANN) with Levenberg–Marquardt Algorithm (BPLM), and BPANN with Gradient Descent of Momentum and Adaptive Learning Rate (BPGD). Taking Lingni Seawall soil ground improved with prefabricated vertical drain-assisted staged riprap filling as an example, forecasts of the short-term, medium-term, long-term, and final settlements at different locations of the soft ground were performed with the eight selected methods. The forecasting values were compared with each other and with the monitored data. When relative errors were between 0 and −1%, both the forecasting accuracy and engineering safety were appropriate and reliable. It was concluded that the appropriate forecast methods were different not only due to the time periods during the settlement process, but also the locations of soft ground. Among these methods, only BPGD was appropriate for all the time periods and locations, such as at the edge of the berm, and at the center of the berm and embankment. Full article

During the consolidation period of vacuum preloading drainage of dredged mud slurry, the clogging behaviors of the filter drainage structural layers and the core boards of prefabricated vertical drains (PVD) determine the drainage capacities of PVD. However, currently, there is a lack of comprehensive research on the evaluation criteria for these two clogging behaviors. Therefore, based on typical dredged mud slurry, typical geomembranes, and raw material core boards with different bending forms, relevant macro and micro-scale experimental studies have been carried out in this study. The research results show that (1) with the application of the gradient ratio test method, the clogging behaviors of filter membranes of PVD under graded vacuum preloading can be effectively simulated. Also, in the design of graded vacuum preloading, characteristics of equivalent pore sizes and pore structures should be emphasized to investigate the suitability of filtration and drainage performance of PVD filter membranes. (2) The compressive yield strength of core board grooves is a key factor influencing the reduction rate of flow capacity. The reduction rate of flow capacity and well resistance increment can be used as comprehensive indicators reflecting the clogging behaviors of core boards, while the bending angles and bending rates of core boards can be used as specific technical indicators. (3) The proposed clogging evaluation criteria for PVD are as follows: a filter membrane gradient ratio (GR) > 4.0, a core board bending rate >60% and a core board bending angle < 45°, or a reduction rate of flow capacity of bending drainage board > 90% or well-resistance increment > 9. Also, these criteria can be incorporated into the control indicators for drainage performance of PVD used in such types of foundations. Full article

Prefabricated vertical drains (PVDs) with staged riprap preloading have been widely used in soft soil ground improvement and embankment construction. However, ground treatment effectiveness evaluation is still a difficult problem due to multiple factors. Considering this, in situ monitoring and numerical simulation were conducted to study the deformation and strength characteristics of marine soft soil ground treated by PVD-assisted staged riprap under the Lingni Seawall construction in China. Monitoring and analysis of results showed that use of PVD-assisted staged riprap resulted in a good improvement effect. In particular, in the PVD-treated zone within 10 m in depth, corresponding to a half-length of the PVD, the average radial degree of consolidation reached up to 75–100%, and the soil strength increased significantly by 200–700%. Moreover, numerical simulation showed that the linear 1-dimensional drain element of PVD closely met the engineering accuracy requirements with good consistency with the monitoring data. Compared with a totally solid element model, the numbers of elements and nodes were reduced and the calculating efficiency and model accuracy were increased by using a PVD linear element, which provides a basis for building large complex finite element models. Full article

This article provides a comparative knowledge of predicted and measured settlements of road embankments with prefabricated vertical drains (PVDs). The emphasis of this study was to investigate and back-analyse the ratio of horizontal permeability in an undisturbed area to a smeared zone, which affects the behaviour of vertical drains. Two models of PVDs in soft ground were developed by utilising a plane strain 2D numerical approach based on the equivalent permeability. Suggestions for the improvement of numerical accuracy of the soft ground beneath road embankments have been made in regards to the obtained results. The employment of the equivalent horizontal permeability in numerical analysis produced significantly similar results to those of the measured values. Furthermore, a smear effect permeability ratio of 300 produced a considerably accurate result with a model based on the equivalent horizontal permeability and measured data. Lastly, the smear effect ratio of 6 using the equivalent horizontal permeability approach was employed in order to predict the behaviour of vertical drains in the soft grounds under road embankments. Full article

The prefabricated vertical drain (PVD) is an essential means to mitigate the settlement of soft soil foundations in coastal areas of South China. The commonly used elastoplastic analytical method cannot directly reflect the interaction of different PVDs and the resulting displacement of soft soil. At the same time, these elastoplastic analysis and numerical simulation methods are greatly influenced by the values adopted for rock and soil material parameters. In this paper, we present a stochastic medium model that can directly reflect the interaction of different PVDs and the resulting displacement of soft soil. It is not affected by the characteristics of rock and soil themselves and can also reflect the actual deformation process of soft soil. According to engineering practice, the settlement curves of soft soil foundations in coastal areas of South China with PVDs exhibited distinct normal distribution characteristics, which was consistent with the description of settlement by the stochastic medium model. Hence, based on the stochastic medium model, this paper analyzed the settlement mechanism of PVDs and established a stochastic medium model for the settlement calculation of PVDs. A function for the soft soil foundation in the coastal area of South China cross-section settlement curve was presented by back analysis of the PVD model. We chose the stochastic medium model based on this methodology to explore the interaction between different PVDs. The above models were then applied to an expressway in South China. Comparing actual settlement monitoring values to calculated values obtained with the PVD model, the error between the two models was less than 15%. This research provides a new settlement calculation method of PVDs in soft soil foundations in the coastal area of South China and a new basis for designing soft soil foundations. Full article

The vacuum preloading method is commonly adopted for improving the soft ground that the embankment of the railway line is laid on. The PIV (Particle Image Velocimetry) technique is a powerful tool in observing the formation of the soil column, a phenomenon that is unique to the dredged slurry when treated by vacuum preloading. However, it is not clear to what extent the motions of the slurry particles can be represented by the PIV tracers. In this paper, a mesoscopic model has been established by using the CFD-DEM method to reproduce the vacuum consolidation process of the slurry, in which the PVD (Prefabricated Vertical Drain) membrane, the slurry particles, and the tracers are described by the DEM, and the pore water is governed by the CFD method. Eight computational cases that can cover a broad range of material parameters governing the PIV model tests on the dredged slurry have been designed and studied by the established model. The representativeness of the PIV tracer is evaluated by comparing the statistic displacement of the tracer to that of the slurry particles. It is found that for the commonly used tracer, the carbon powder, can reliably represent the particle motions of the slurry since the difference in displacements of the tracer and the slurry particles is smaller than 6.5% if the diameter ratio between the tracer and the slurry particle is within 1.8. Full article

This paper presents the analytical solution of the radial consolidation of a prefabricated vertical drain (PVD) foundation under the unsaturated condition. In the proposed modeling, air and water phases in the foundation are thought to dissipate horizontally toward to the drain, and the smear effect, drain resistance and external time-dependent loading are fully considered. The analytical mathematical tools, namely the general integration method, Fourier series expansion method, decoupling method and the constant variation method, are utilized to solve the partial differential equations. Moreover, the current solutions are verified with existing solutions in the literature. Finally, a case study considering the ramp loading and exponential loading is conducted to investigate the consolidation patterns under various loading parameters. The results show that smear effect and drain resistance can significantly hinder the dissipation process of excess pore pressures, and different external loading types will lead to various dissipation characteristics (i.e., peak values). Full article

Vacuum preloading combined with prefabricated vertical drains (PVDs) has the potential to improve the soft sediments under water, however, its development is partly limited by the unclear understanding of the mechanism. This paper aims to extend the comprehension of the influential mechanism of overlapping water in the scenario of underwater vacuum preloading with PVDs. The systematic investigations were conducted by small strain finite element drained analyses, with the separated analysis schemes considering suction-induced consolidation, seepage and their combination. The development of settlement in the improved soil region and the evolution of seepage flow from the overlapping water through the non-improved soil region into improved zone are examined in terms of the build-up of excess pore pressure. Based on the results of numerical analyses, a theoretical approach was set out. It was capable to estimate the time-dependent non-uniform settlement along the improved soil surface in response to the combined effects of suction-induced consolidation and seepage. The difference of underwater and onshore vacuum preloading with PVDs is discussed with some practical implication and suggestion provided. Full article

In Bangkok, the demand for housing is extensively high due to the city growing rapidly, so some swampy areas are filled with soil. A Prefabricated Vertical Drain (PVD) with the Vacuum Consolidation Method (VCM) is required to make the soil applicable for construction. However, it is difficult to monitor the soil strength during the process because the airtight sheet will be broken. This research aims to study the possibility of using the Spectral Analysis of Surface Waves (SASW) test to monitor the effectiveness of the VCM method and to study the development of shear-wave velocity over the consolidation period. Multiple instruments were installed on site, namely, vacuum gauges, settlement plates, and a piezometer, as well as a borehole to monitor the pump pressure, settlement, porewater pressure, and soil properties. Ten SASW tests were taken to measure the change in shear-wave velocity (Vs) over 7 months. The results showed an increment in the Vs along with increments in the settlement and undrained shear strength (Su), as well as a decrement in pore pressure during the consolidation period. The correlation between Vs and soil settlement was developed to predict the amount of settlement using Vs. These all indicated the potential of using the SASW method for soil improvement monitoring purposes. Full article

This paper presents the quantification of uncertainties in the prediction of settlements of embankments built on prefabricated vertical drains (PVDs) improved soft soil deposits based on data collected from two well-documented projects, located in Karakore, Ethiopia, and Ballina, Australia. For this purpose, settlement prediction biases and settlement distributions were statistically computed based on analyses conducted on two Class A and Class C numerical predictions made using PLAXIS 2D finite element modelling. From the results of prediction bias, Class C predictions agreed well with the field measured settlements at both sites. In Class C predictions, the computed settlements were biased to the measured values. For Class A predictions, the calculated settlement values were in the range of mean and mean minus 3SD (standard deviations) for Karakore clay, and they were within mean and mean minus 2SD limit for the Ballina soil. The contributing factors to the settlement uncertainties of the Karakore site may include variability within the soil profile of the alluvial deposit, particularly the presence of interbedded granular layer within the soft layers, and the high embankment fills, and the limited number of samples available for laboratory testing. At the Ballina test embankment site, the uncertainties may have been associated with the presence of transitional layers at the bottom of estuarine clay and sensitivity of soft soil to sample disturbances and limitations in representing all the site conditions. Full article

The present work describes the program Simulation of Consolidation with Vertical Drains (SICOMED_2018), a tool for the solution of consolidation processes in heterogeneous soils, with totally or partially penetrating prefabricated vertical drains (PVD) and considering both the effects of the smear zone, generated when introducing the drain into the ground, and the limitation in the discharge capacity of the drain. In order to provide a completely free program, the code Next-Generation Simulation Program with Integrated Circuit Emphasis (Ngspice) has been used as a numerical tool while the Matrix Laboratory (MATLAB) code was used to program and create an interface with the user through interactive screens. In this way, SICOMED_2018 is presented as an easy-to-use and intuitive program, with a simple graphical interface that allows the user to enter all the soil properties and geometry of the problem without having to resort to a complex software package that requires programming. Illustrative applications describe both the versatility of the program and the reliability of its numerical solutions. Full article
