The integration of tilted photovoltaic strings on large, flat roofs, typical of industrial and commercial buildings, raises complex design challenges, particularly regarding wind-induced loads. This study presents a comprehensive wind tunnel investigation aimed at evaluating the aerodynamic effects on rooftop PV strings under various representative configurations and the correlation between characteristic geometric parameters such as tilt angle, bottom clearance, row spacing, and wind direction. Following a literature review, a detailed 1:10 scaled model with geometric adjustment capabilities was developed and eventually tested in a boundary-layer wind tunnel. High-resolution pressure measurements were processed to derive force and moment resultants normalised by reference wind pressure. Envelopes of force/moment resultants are presented for each representative geometric configuration and for each wind exposure angle. The results present severe variations in local wind actions, particularly significant at the strings’ free ends and for oblique wind angles. The severe underestimation of local wind loads by standard codes is discussed. The findings underline the importance of detailed wind-load assessment for both new constructions and retrofits, suggesting that reliance solely on code provisions might result in unsafe designs. Full article

Photovoltaic (PV) systems have experienced rapid global deployment. However, line-to-line short-circuit faults pose serious safety risks and can lead to significant power losses or fire hazards. While existing fault detection methods can identify fault types, they cannot precisely locate fault positions, resulting in time-consuming and costly maintenance. This paper proposes a heuristic algorithm for accurately locating such faults in PV arrays based on module group voltage measurements. The algorithm employs a two-phase approach: fault candidate marking and fault location determination, capable of handling both intra-string and cross-string faults. Simulation tests on a 21 × 2 PV array configuration demonstrate a 97.56% fault location success rate, reducing the troubleshooting scope to within a single-module group. The proposed method offers a simple, fast, and cost-effective solution for PV system maintenance, potentially saving significant labor costs and reducing system downtime. Full article

In this paper, a better power optimizer architecture has been presented for PV strings, using a buck converter for each PV module to address partial shading conditions. The buck converter, though rarely used, is a natural converter for partial shading effects, as it converts the lower current of the shaded module to a higher output current. Usually, the advanced architecture activates the isolated converters (complex) of only shaded modules to draw extra current from the inverter’s DC-link node to maintain the string current ($I_{string}$). On the other hand, the conventional architecture activates converters (basic) of all modules regardless of their shading status. The proposed architecture contains a unique design with a new schematic layout, where it activates the buck converters of only shaded modules without drawing extra current from the DC-link. Thus, it combines the benefits of both architectures—selective converter operation, basic topology, high efficiency, low voltage stress, and low control complexity—while eliminating their drawbacks. The designing philosophy, control mechanism, and fundamental operation of the proposed architecture have been comprehensively explained and validated through simulation experiments. Three levels of shading are used to test the proposed architecture for string containing three PV modules: (1) a single module moderate (15%) shading level, (2) a single module strong (50%) shading level, and (3) a double module extreme (75%) and moderate (25%) shading levels. The results show a successful operation of the proposed architecture as it maintains a common $I_{string}$ for an inverter, where all the shaded modules remain active. The architecture exhibits an average efficiency over 97% under normal conditions. A comparative analysis of architectures has been presented to indicate the enhanced features of the proposed architecture. Full article

Accurate and reliable fault detection in photovoltaic (PV) systems is essential for optimizing their performance and durability. This paper introduces a novel approach for fault detection and diagnosis in large-scale PV systems, utilizing power loss analysis and predictive models based on Random Forest (RF) and K-Nearest Neighbors (KNN) algorithms. The proposed methodology establishes a predictive baseline model of the system’s healthy behavior under normal operating conditions, enabling real-time detection of deviations between expected and actual performance. Faults such as string disconnections, module short-circuits, and shading effects have been identified using two key indicators: current error (Ec) and voltage error (Ev). By focusing on power losses as a fault indicator, this method provides high-accuracy fault detection without requiring extensive labeled data, a significant advantage for large-scale PV systems where data acquisition can be challenging. Additionally, a key contribution of this work is the identification and correction of faulty sensors, specifically pyranometer misalignment, which leads to inaccurate irradiation measurements and disrupts fault diagnosis. The approach ensures reliable input data for the predictive models, where RF achieved an R² of 0.99657 for current prediction and 0.99459 for power prediction, while KNN reached an R² of 0.99674 for voltage estimation, improving both the accuracy of fault detection and the system’s overall performance. The outlined approach was experimentally validated using real-world data from a 500 kWp grid-connected PV system in Ain El Melh, Algeria. The results demonstrate that this innovative method offers an efficient, scalable solution for real-time fault detection, enhancing the reliability of large PV systems while reducing maintenance costs. Full article

Electroluminescence imaging is increasingly used in photovoltaic power plant inspections due to its effectiveness in detecting various types of failures in solar cells. This article presents a novel technique that enables the modulation of an arbitrary electroluminescence signal in PV modules using an electronic device that controls the signal by modulating an arbitrary current waveform in a photovoltaic module, utilizing the string current as its energy source. As a result, measurements do not require a power supply and can be performed during the normal operation of a PV string. Throughout the paper, this method is compared to a more conventional approach that relies solely on a power supply to generate the current signal. Capturing a sequence of images while modulating the current with different waveforms allows the application of the Fast Fourier Transform to suppress background signals caused by sunlight, resulting in high-quality EL images. Experimental results demonstrate that the proposed method delivers imaging quality comparable to that achieved with a power supply, while effectively detecting a broad range of solar cell failures. Furthermore, the calculated signal-to-noise ratio for both approaches yields similar values, indicating comparable quality in quantitative terms. Finally, square wave modulation has shown slightly better performance than other waveforms, such as sinusoidal and half-sinusoidal modulation. Full article

The P-V and I-V curves of photovoltaic (PV) strings show multiple peaks when exposed to partial shading conditions (PSCs). The traditional maximum power point tracking (MPPT) method cannot track the global maximum power point (GMPP) due to the multi-peak characteristics, power fluctuation, and tracking speed. In this paper, a multi-peak PV MPPT method based on the honey badger algorithm (HBA) is proposed to track the GMPP in a localized shading environment. The performance of this method is also compared and analyzed with the traditional MPPT methods based on the perturbation observation (P&O) method and Particle Swarm Optimization (PSO) algorithm. The experimental results have proven that, compared with the MPPT methods based on P&O and PSO, the proposed multi-peak MPPT method based on the HBA algorithm has a faster tracking speed, higher tracking accuracy, and fewer iterations. Full article

Maintenance and monitoring of solar photovoltaic (PV) systems are essential for enhancing reliability, extending lifespan, and maintaining efficiency. Some defects in PV cells cannot be detected through output measurements due to the string configuration of interconnected cells. Inspection methods such as thermal imaging, electroluminescence, and photoluminescence are commonly used for fault detection. Among these, thermal imaging is widely adopted for diagnosing PV modules due to its rapid procedure, affordability, and reliability in identifying defects. Similarly, current–voltage (I-V) curve analysis provides valuable insights into the electrical performance of solar cells, offering critical information on potential defects and operational inconsistencies. Different data types can be effectively managed and analyzed using artificial intelligence (AI) algorithms, enabling accurate predictions and automated processing. This paper presents the development of a machine learning algorithm utilizing transfer learning, with thermal imaging and I-V curves as dual and single inputs, to validate its effectiveness in detecting faults in PV cells at King Saud University, Riyadh. Findings demonstrate that integrating thermal images with I-V curve data significantly enhances defect detection by capturing both surface-level and performance-based information, achieving an accuracy and recall of more than 98% for both dual and single inputs. The approach reduces resource requirements while improving fault detection accuracy. With further development, this hybrid method holds the potential to provide a more comprehensive diagnostic solution, improving system performance assessments and enabling the adoption of proactive maintenance strategies, with promising prospects for large-scale solar plant implementation. Full article

The paper proposes an original single-phase transformerless three-level (S-PT) photovoltaic (PV) inverter in the cascade H bridge (CHB) configuration. The DC-link voltage of the inverter is created by two serial voltage sources with a voltage twice as low as the DC-link voltage. An appropriate V_CC DC-link voltage is generated by a two-phase DC-DC boost converter, fed from the string panel output at a level determined by the maximum power point tracking (MPPT) algorithm. Two symmetrical sources with V_CC/2 are formed by a divider of two series-connected capacitors of large and the same capacitance. The common mode (CM) voltage of the proposed inverter is constant, and the voltage stresses across all switches, diodes and gate drive circuits are half of the DC-link voltage. The principles of operation of the S-PT inverter, an implementation of a complete gate control system with galvanic isolation for all IGBTs, are also presented. The proposed inverter topologies have been implemented using high-speed IGBTs and simulated in PSPICE, as well as being experimentally validated. Full article

Large-scale photovoltaic (PV) systems are being widely deployed to meet global environmental goals and renewable energy targets. Advances in PV technology have driven investment in the electric sector. However, as the size of PV arrays grows, more obstacles and challenges emerge. The primary obstacles are the occurrence of direct current (DC) faults and shading in a large array of PV panels, where any malfunction in a single panel can have a detrimental impact on the overall output power of the entire series-connected PV string and therefore the PV array. Due to the abrupt and frequent fluctuations in power, beside the low-PV systems’ moment of inertia, various technical problems may arise at the point of common coupling (PCC) of grid-connected PV generations, such as frequency and voltage stability, power efficiency, voltage sag, harmonic distortion, and other power quality factors. The majority of the suggested solutions were deficient in several crucial transient operating features and cost feasibility; therefore, this paper introduces a novel power electronic DC–DC converter that seeks to mitigate these effects by compensating for the decrease in current on the DC side of the system. The suggested solution was derived from the dual-source voltage-fed quasi-Z-source inverter (VF-qZSI), where the PV generation power can be supported by an energy storage element. This paper also presents the system architecture and the corresponding power switching control. The feasibility of the proposed method is investigated with real field data and the PSCAD simulation platform during all possible weather conditions and array faults. The results demonstrate the feasibility and capability of the proposed scheme, which contributes in suppressing the peak of the transient power-to-time variation (dP/dt) by 72% and reducing its normalized root-mean-square error by about 38%, with an AC current total harmonic distortion (THD) of only 1.04%. Full article

Recent advancements in power electronics have significantly improved photovoltaic (PV) inverters by equipping them with sophisticated monitoring capabilities. These enhancements provide economic advantages by facilitating swift failure detection and lowering monitoring costs. Educating users on the economic repercussions of undetected failures in specific inverter monitoring systems is crucial. This paper introduces a novel metric, “Cost of Detection”, which assesses the financial impact of failures, considering the repair expenses and the “quality” of the monitoring system in place. The study analyzed fifteen inverter monitoring solutions, focusing on the variance in alerts generated by the manufacturers’ standard and extra monitoring features. Employing the Failure Mode and Effects Analysis (FMEA) method, alerts were prioritized based on their importance for two PV system scenarios: a low-power residential system (5 kWp) and a medium-power industrial/commercial system (100 kWp). Lisbon, Rome, and Berlin were chosen as the locations for these systems. The economic impact of system failures is evaluated annually for each capacity and city. Given the differing costs and annual yields, comparing their economic performance over time is essential. This comparison utilizes the Net Present Value (NPV), which estimates an investment’s worth by calculating the present value of all cash flows. The investment assessment includes only the costs of inverters and optimizers, excluding O&M expenses, licenses, and fees. Over five years, a higher NPV signifies a more economically advantageous solution. For residential systems, string inverters with optimizers have the highest NPV, surpassing those without optimizers by 17% across all three cities. The optimal monitoring solution in the industrial/commercial context was a string inverter with one optimizer for every two panels. Here, Rome emerged as the location with the most substantial NPV increase of 50%, followed by Berlin with 33% and Lisbon with 28%. Full article

The inevitability of faults arises due to prolonged exposure of photovoltaic (PV) power plants to intricate environmental conditions. Therefore, fault diagnosis of PV power plants is crucial to ensure the continuity and reliability of power generation. This paper proposes a fault diagnosis method that integrates PV power prediction and an exponentially weighted moving average (EWMA) control chart. This method predicts the PV power based on meteorological factors using the adaptive particle swarm algorithm-back propagation neural network (APSO-BPNN) model and takes its error from the actual value as a control quantity for the EWMA control chart. The EWMA control chart then monitors the error values to identify fault types. Finally, it is verified by comparison with the discrete rate (DR) analysis method. The results showed that the coefficient of determination of the prediction model of the proposed method reached 0.98. Although the DR analysis can evaluate the overall performance of the inverter and identify the faults, it often fails to point out the specific location of the faults accurately. In contrast, the EWMA control chart can monitor abnormal states such as open and short circuits and accurately locate the string where the fault occurs. Full article

As a result of global efforts to combat the rise in global climate change and carbon dioxide emissions, there has been a substantial increase in renewable energy investment for both residential and utility power generation. Solar power facilities are estimated to be among the major contributors to global decarbonization in terms of capacity by 2050. Consequently, the majority of economically significant countries are progressively implementing utility-scale photovoltaic (U-PV) systems. Nevertheless, a major obstacle to the expansion of U-PV generation is the identification and assessment of direct current (DC) faults in the extensive array of PV panels. In order to address this obstacle, it is imperative to provide an evaluation method that can accurately and cost-effectively identify and locate potential DC faults in PV arrays. Therefore, many studies attempted to utilize thermal cameras, voltage and current sensors, power databases, and other detecting elements; however, some of these technologies provide extra hurdles in terms of the quantity and expense of the utilized hardware equipment. This work presents a sophisticated system that aims to diagnose and locate various types of PV faults, such as line-to-ground, line-to-line, inter-string, open-circuit, and partial shading events, within a PV array strings down to a module level. This study primarily depends on three crucial indicators: precise calculation of the PV array output power and current, optimal placement of a limited number of voltage sensors, and execution of specifically specified tests. The estimation of PV array power, along with selectively placed voltage sensors, minimizes the time and equipment required for fault detection and diagnosis. The feasibility of the proposed method is investigated with real field data and the PSCAD simulation platform during all possible weather conditions and array faults. The results demonstrate that the proposed approach can accurately diagnose and localize faults with only N_S/2 voltage sensors, where N_S is the number of PV array parallel strings. Full article

Identifying underperforming photovoltaic (PV) modules is crucial to ensure optimal energy production and financial returns, as well as preventing potential safety hazards in case of severe damage. To this aim, current–voltage (I-V) curve tracing can be employed as in situ monitoring technique for the early detection of faults. In this paper, we introduce a novel low-cost, microcontroller-based I-V tracer for the diagnosis of individual PV modules. The tool features a unique power conditioning circuit, facilitating accurate data acquisition under static conditions as well as the even distribution of the measured points along the I-V curve. A specific active disconnecting circuit enables in situ and on-line measurement without interrupting the string power generation. The designed prototype is used to characterize a set of PV modules under real operating conditions. The measured I-V curves exhibit expected trends, with the measured data closely matching theoretical values and an estimated mean relative error less than 3%. Full article

Building-integrated photovoltaics (BIPV) comprise the integration of a solar power generation system into the exterior design and architectural elements of a building to produce electricity, which allows the building itself to generate electricity. By integrating shingled technology into the photovoltaic module with optimization of the optical effect, the output performance of the module can be increased while securing an aesthetic appeal as an architectural exterior material for the building simultaneously. In this research, we studied enhancing the performance of BIPV modules through an analysis of the optical coupling effect for shingled technology using PSpice simulation. Compared to the efficiency of 0.2 cm string spacing, the optical coupling effect was increased by 33.33%, 46.98%, 67.01%, and 193.49% according to the string spacing of 0.5 cm, 1 cm, 2 cm and 4 cm, respectively. To analyze this increase, we focused on studying the increase in current due to the reflection and re-absorption of light in the back layer of the solar cell as the cause of this output enhancement. Additionally, the coupling effect in accord with different layers showed that using white EVA to reflect the incident light from the top layer resulted in 117.14% and 521.90% enhancements in maximum output power (Pm) loss % compared to the conventional and black backsheet applied PV modules, respectively. Full article

This study introduces a novel algorithm tailored for the precise detection of lower outliers (i.e., data points at the lower tail) in univariate datasets, which is particularly suited for scenarios with a single cluster and similar data distribution. The approach leverages a combination of transformative techniques and advanced filtration methods to efficiently segregate anomalies from normal values. Notably, the algorithm emphasizes high-precision outlier detection, ensuring minimal false positives, and requires only a few parameters for configuration. Its unsupervised nature enables robust outlier filtering without the need for extensive manual intervention. To validate its efficacy, the algorithm is rigorously tested using real-world data obtained from photovoltaic (PV) module strings with similar DC capacities, containing various outliers. The results demonstrate the algorithm’s capability to accurately identify lower outliers while maintaining computational efficiency and reliability in practical applications. Full article
