We propose and experimentally demonstrate an Integrated Multiband-Mode Multiplexing Photonic Lantern (IM3PL) that enables the selective excitation of high-order modes and stable modal preservation across multiple wavelength bands. As a proof-of-concept configuration, the IM3PL integrates a custom-designed input fiber array composed of three 980 nm single-mode fibers (SMFs) and two few-mode fibers (FMFs) operating at 1310 nm and 1550 nm, respectively. Simulations verify that 980 nm input signals can selectively excite $L{P}_{01}$, $L{P}_{11a}$, and $L{P}_{11b}$ modes at the FMF output, while the modal integrity of high-order linear polarized modes is preserved at 1310 nm and 1550 nm. The fabricated IM3PL device is experimentally validated via near-field pattern measurements, confirming the selective excitation at 980 nm and low-loss, mode-preserving transmission at the signal bands. This work offers a scalable and reconfigurable solution for multiband high-order-mode multiplexing, with promising applications in mode-division multiplexed fiber communication systems and multiband high-mode fiber lasers. Full article

Exploring innovative approaches to enhance the performance of photonic lanterns is greatly valuable. In this paper, we first propose an air-hole-assisted pure silica-based capillary (AHC), featuring a single ring of embedded air holes. As a result, the PL based on the AHC exhibits good performance, successfully exciting LP₀₁, LP_11a & LP_11b, LP_21a & LP_21b, LP₀₂, and LP_31a & LP_21b modes. The average mode loss, mode-dependent loss, and maximum crosstalk are 0.08 dB, 0.04 dB, and −27.2 dB, respectively. In fact, the overall performance of the proposed AHC-based PL is on par with that of the traditional PL. Furthermore, an error analysis is provided to confirm the feasibility of our approach. The AHC-based PLs possess high numerical apertures and are expected to enable high spatial resolution imaging in optical imaging. Full article

A photonic lantern is a low-loss device that connects a single multimode waveguide to multiple single-mode waveguides and can enhance the beam quality of a fiber laser by adaptively controlling the optical parameters (amplitude, phase, polarization) at the input. In this work, we combined the gains and losses of individual modes within the fiber amplifier and introduced a mode content parameter at the amplifier’s output as an evaluation function to simulate mode control effects. Mode competition within the gain fiber can degrade the control effect of the fundamental mode and lead to it taking a longer time for the control to converge. Optimal parameters, such as the gain fiber length and pumping method, were identified to improve control effectiveness. Specifically, an optimal gain fiber length of 8 m was determined, and backward pumping was found to achieve higher pumping efficiency and better control results. The system demonstrated significant power amplification potential and could stabilize mode control under different pumping powers ranging from 50 W to 5 kW. In conclusion, our research demonstrates that an adaptive fiber amplifier based on a photonic lantern can achieve a stable, high-power, large-mode-field, near-fundamental-mode output from the gain fiber. Although mode competition within the gain fiber can degrade the control effect of the fundamental mode and cause the control to take a longer time to converge, these aspects should be further studied to improve the control’s effectiveness. These findings contribute to the development of advanced simulation models that guide high-power mode control experiments and deepen our understanding of physical processes in science and technology. Full article

Induction motors are widely applied in motor drive systems. Effective temperature monitoring is one of the keys to ensuring the reliability and optimal performance of the motors. Therefore, this paper introduces a multiplexed optical temperature sensing system for induction motors based on few-mode fiber (FMF) spatial mode diversity. By using the spatial mode dimension of FMF, fiber Bragg grating (FBG) carried by different spatial modes of optical paths is embedded in different positions of the motor to realize multipoint synchronous multiplexing temperature monitoring. The paper establishes and demonstrates a photonic lantern-based mode division sensing system for motor temperature monitoring. As a proof of concept, the system demonstrates experiments in multiplexed temperature sensing for motor stators using the fundamental mode LP₀₁ and high-order spatial modes LP₁₁, LP₂₁, and LP₀₂. The FBG sensitivity carried by the above mode is 0.0107 nm/°C, 0.0106 nm/°C, 0.0097 nm/°C, and 0.0116 nm/°C, respectively. The dynamic temperature changes in the stator at different positions of the motor under speeds of 1k rpm, 1.5k rpm, 2k rpm with no load, 3 kg load, and 5 kg load, as well as at three specific speed–load combinations of 1.5k rpm_3 kg, 1k rpm_0kg, 2k rpm_5 kg and so on are measured, and the measured results of different spatial modes are compared and analyzed. The findings indicate that different spatial modes can accurately reflect temperature variations at various positions in motor stator winding. Full article

Photonic lantern is a key device in space division multiplexing (SDM) system. The key challenge of a photonic lantern is mode scalability, which requires the taper length to increase nonlinearly as the mode number scales up. The traditional photonic lantern fabrication method requires stacking the input fibers into the hollow, low-index outer cladding before tapering. It implicitly sets geometric constraints on the input fibers’ core positioning. We propose a photonic lantern design with drilling preform and reduced cladding fibers to lift these constraints and make photonic lanterns more adiabatic. By analyzing the effects of loosening the constraints on the adiabatic requirement of a three-mode photonic lantern, we find further progress could be made to alleviate this adiabatic requirement. The optimal structure for our design is proposed and demonstrated through the beam propagation method (BPM). Our findings could help further improve the mode scalability of photonic lanterns. Full article

High-order transverse-mode lasers have important potential application value in many fields. To address the current issue of the limited controllability of modes in high-order transverse-mode lasers, we have designed a self-matching photonic lantern (SMPL). The SMPL is formed by introducing a few-mode fiber into the input fiber array of the traditional photonic lantern. The parameters of the few-mode fiber match those of the tapered few-mode port of the SMPL; thus, it can transmit high-order modes in a closed loop. The designed SMPL exhibits dual-band multiplexing characteristics at 980/1550 nm, manifesting specifically as high-order mode selectivity excitation at 980 nm and mode preservation at 1550 nm. These characteristics have been validated through simulation and preliminary experiments. The SMPL is designed for constructing all few-mode fiber ring cavity lasers, enabling the pumping of the 980 nm fundamental mode to high-order modes and the transmission of multiple high-order transverse-mode lasers at 1550 nm in a closed loop. The proposed SMPL extends the configuration and functionality of the photonic lantern family, offering a flexible and effective approach to facilitate the generation of multiple high-order transverse-mode lasers. The SMPL combined with fiber laser systems could effectively broaden communication channels and enhance communication bandwidth. It also holds significant value in optical sensing, high-resolution imaging, laser micro-processing, and other fields. Full article

A photonic lantern is a coherent beam combination device that can increase the fiber laser brightness by adaptively controlling the input light properties, such as phase, intensity, and polarization. However, the control effect is closely related to the initial optical field, which affects the convergence speed to obtain the optimum solutions. In this work, we propose a novel control strategy using the prior structural information of the photonic lantern. Taking a 6 × 1 photonic lantern as an example, we calculate the transmission matrix of the photonic lantern. The initial optical field conditions, fed as the control inputs, for various mode outputs can be obtained. Compared with the random and equal amplitude control methods, the preset method from the transmission matrix presents a significant improvement of the desired mode content. Our optimization method is generally useful for adaptive control systems to improve their performance, taking advantage of their own structural information. Full article

Microwave photonic links (MPLs) have long been considered as an excellent way for radio frequency (RF) transmission due to their advantages such as light weight, high bandwidth, low cost and large spurious-free dynamic range (SFDR). However, the effective mode-field area (A_eff) of the single-mode fiber (SMF) used in the traditional MPL is not large, so the MPL based on SMF have relatively strong nonlinearity, which limits the processing power of SMFs to a level of few milliwatts. Few-mode fibers (FMFs) have been applied in MPL as an alternative due to the larger A_eff, and photonic lanterns are used simultaneously to excite the high-order mode of FMFs for RF signal transmission. However, the photonic lantern could bring additional insertion loss, and the production cost of FMFs is high, so we propose an MPL based on multimode fibers (MMFs) with mode field adapters (MFAs). Since MMFs have larger A_eff, the nonlinearity of the link can be greatly reduced. And matched MFAs realized by reverse tapering, to excite only the fundamental mode in MMFs to reduce the crosstalk, which are very stable. As a result, the stimulated Brillouin scattering threshold and SFDR are improved by 5 dB and 14.5 dB, respectively. Full article

We analyze the mode evolution in mode-selective photonic lanterns with respect to taper lengths, affected by possible mode phase differences varying along the taper. As a result, we design a three-mode orbital angular momentum (OAM) mode-selective photonic lantern by optimizing the taper length with mode crosstalk below −24 dB, which employs only one single mode fiber port to selectively generate one OAM mode. Full article

Orbital angular momentum (OAM) beams, characterized by the helical phase wavefront, have received significant interest in various areas of study. There are many methods to generate OAM beams, which can be roughly divided into two types: spatial methods and fiber methods. As a natural shaper of OAM beams, the fibers exhibit unique merits, namely, miniaturization and a low insertion loss. In this paper, we review the recent advances in fiber OAM mode generation systems, in both the interior and exterior of the beams. We introduce the basic concepts of fiber modes and the generation and detection theories of OAM modes. In addition, fiber systems based on different nuclear devices are introduced, including the long-period fiber grating, the mode-selective coupler, microstructural optical fiber, and the photonic lantern. Finally, the key challenges and prospects for fiber OAM mode systems are discussed. Full article

Astrophotonics is the application of photonic technologies to channel, manipulate, and disperse light from one or more telescopes to achieve scientific objectives in astronomy in an efficient and cost-effective way. Utilizing photonic advantage for astronomical spectroscopy is a promising approach to miniaturizing the next generation of spectrometers for large telescopes. It can be primarily attained by leveraging the two-dimensional nature of photonic structures on a chip or a set of fibers, thus reducing the size of spectroscopic instrumentation to a few centimeters and the weight to a few hundred grams. A wide variety of astrophotonic spectrometers is currently being developed, including arrayed waveguide gratings (AWGs), photonic echelle gratings (PEGs), and Fourier-transform spectrometer (FTS). These astrophotonic devices are flexible, cheaper to mass produce, easier to control, and much less susceptible to vibrations and flexure than conventional astronomical spectrographs. The applications of these spectrographs range from astronomy to biomedical analysis. This paper provides a brief review of this new class of astronomical spectrographs. Full article

The fields of molecular biology, immunology and genetics have generated many important developments that advance the understanding of the induction and progression of oncological, cardiological and neurological diseases as well as the identification of disease-associated molecules and drugs that specifically target diseased cells during therapy. These insights have triggered the development of targeted radiopharmaceuticals which open up a new dimension of radiopharmaceutical sciences in nuclear medicine. Radiopharmaceuticals, also called radiotracers, are radiolabelled molecules, bearing a “radioactive lantern”, and used as molecular probes to address clinically relevant biological targets such as receptors, enzymes, transport systems and others. Positron emission tomography (PET) and single photon emission computed tomography (SPECT) realised in the en-vogue hybrid technologies PET/CT, SPECT/CT and PET/MRI represent the state-of-the-art diagnostic imaging technologies in nuclear medicine which are used to follow the trace of the administered radiopharmaceutical noninvasively thereby in vivo visualising and assessing biological processes at the subcellular and molecular level in a highly sensitive manner. In this connexion novel radiopharmaceuticals for the noninvasive molecular imaging of early disease states and monitoring of treatment responses in vivo by means of PET/CT, SPECT/CT and PET/MRI are indispensable prerequisites to further advance and strengthen the unique competence of radiopharmaceutical sciences. In the era of personalised medicine the diagnostic potential of radiopharmaceuticals is directly linked to a subsequent individual therapeutic approach called endoradiotherapy. Depending on the “radioactive lantern” (gamma or particle emitter) used for radiolabelling of the respective tracer molecule, the field of Radiopharmaceutical Chemistry can contribute to the set-up of an “in vivo theranostic” approach especially in tumour patients by offering tailor-made (radio)chemical entities labelled either with a diagnostic or a therapeutic radionuclide. [...] Full article
