Search Results (27)

Splashed droplets in the vacuum chamber play an important role in decarburization and degassing in Ruhrstahl–Heraeus (RH), but the scholars do not pay attention to the behaviors of splashed droplets. Thus, it is necessary to propose a new method to investigate the splashed droplets. A Euler–Euler model and the inter-phase momentum transfer are applied to investigate the interaction between the molten steel and the bubbles, and the gas domain in the vacuum chamber is included in the computational domain in order to describe the movement of the splashed droplets. Numerical results show that the flow field predicted by Euler–Euler model agrees well with the experimental data. There is a higher gas volume fraction near the up-snorkel wall, the “fountain” formed by the upward flow from the up-snorkel exceeds 0.1 m above the free surface, and the center of the vortex between the upward stream and the downward stream is closer to the upward stream in the vacuum chamber. Full article

Accurately describing the behavior of a gas-water two-phase flow in shale gas reservoirs is crucial for analyzing production dynamics in the field. Current research generally lacks consideration of the differences in physical properties and adsorption characteristics between the oleophilic organic matrix and the hydrophilic inorganic matrix. This study considers the organic matrix system as a single-phase gas flow, while the inorganic matrix and fracture systems involve a gas-water two-phase flow. Taking into account the impact of the adsorbed water layer on permeability at the surface of nanoscale pores in an inorganic matrix, the model comprehensively incorporates multiple mechanisms such as adsorption-desorption, the slippage effect, and Knudsen diffusion in the organic matrix and clay minerals. A multiscale gas-water two-phase comprehensive flow model for shale gas reservoirs has been established, and the results of the numerical model were validated against commercial software and actual field data. Simulation results over 1000 days indicate that early production from gas wells is primarily supplied by fractures, whereas free gas or desorbed gas from inorganic and organic matrices gradually contributes to the flow during the middle and later stages of production. As the Langmuir pressure and volume in the organic matrix and clay minerals increase, so does the corresponding gas production. The adsorbed water layer on the surface of inorganic nanopores reduces permeability, leading to a decrease in single-well cumulative gas production by 8.41%. The impact of the adsorbed water layer on gas production cannot be overlooked. The simulation method proposed in this study provides theoretical support for analyzing the gas-water two-phase flow behavior in shale gas reservoirs. Full article

This study examines the influence of drift angle on the wave and flow field generated by a submarine navigating through a density-stratified fluid. Employing a numerical methodology, this research computed the viscous flow field around the SUBOFF bare hull under conditions of oblique shipping maneuvers. The analytical framework relies on the Reynolds-Averaged Navier–Stokes (RANS) equations, supplemented by the Re-Normalization Group (RNG) k-ε turbulence model and the Volume of Fluid (VOF) method. The initial phases of this study involved verifying grid convergence and the accuracy of the numerical methods used. Subsequently, numerical simulations were performed across a spectrum of drift angles while maintaining a fixed Froude number of F_n = 0.5, with submergence depths set at 1.1 D and 2.0 D. The analysis focused on the wave profiles at both the free surface and the internal surface. The results indicate that the presence of a drift angle produces significant alterations in the characteristics of the free surface and internal surface when compared with straight-ahead motion. Specifically, the asymmetry in the flow field is enhanced, and the variability in the roughness of the free surface is pronounced. Full article

The drainage systems of tunnels situated in limestone regions frequently encounter crystallization blockages. Numerous studies have addressed this issue, and their findings identified factors such as the flow velocity and temperature as influencing the crystallization process. However, these studies could not predict the occurrence of crystallization. Regarding theoretical approaches, most studies have focused on full-pipe operations or have solely considered flow-field dynamics without including simulations of the chemical reactions and mass transfers. This study introduces a mass-transfer model for drainage pipes based on a two-phase flow (water and air) with a free surface and non-full pipe flow that simulates the crystallization deposition process in drainage pipes. This model can predict the deposition conditions at varying flow velocities and intuitively visualize the crystallization process under the influence of various factors. The impact of flow velocity on the overall crystallization deposition process can be directly analyzed through simulations developed using this model. The results show that under conditions of incomplete pipe flow with no pressure at the outlet, the weight of the deposition first increases and then decreases within a certain velocity. This model can depict the variations within a 30 d period. Full article

This article investigates the velocity field of a free-surface flow subjected to harmonic deformation of the channel bottom, progressing asymptotically from a flat initial state to a maximum amplitude. Assuming a uniform main flow with the primary velocity component transverse to the bed undulation, analytical solutions are obtained for the three velocity components and free surface distortion using the method of perturbations. The perturbation components of the velocity field, streamlines, and surface deformation depend on a dimensionless parameter that reflects the fluid inertia induced by bed deformation relative to viscous resistance. When viscous effects dominate, a monotonic decay of the perturbations from the bed to the free surface is observed. In contrast, when inertia dominates, the perturbations can exhibit an oscillatory behavior and introduce circulation cells in the plane normal to the main flow. The interplay between inertia and viscosity reveals scenarios where surface and bed deformations are either in or out of phase, influencing vertical velocity components. Figures illustrate these phenomena, providing insights into the complex dynamics of free-surface flows with harmonic bed deformation in the direction normal to the main flow, and amplitude growing with time. The results are limited to small deformations of the channel bottom, as imposed by the linearization of the momentum equations. Even so, to the best of the authors’ knowledge, this problem has not been addressed before. Full article

The Volume of Fluid (VOF) method is used in two-phase fluid flow problems of ship hydrodynamic calculations, to capture the motion and distribution of the gas–liquid free surface. To ensure solution stability and accuracy, numerical simulations typically require separate mesh refinement for the free surface or a reduced time step, resulting in a significant increase in solution time. This study aims to compare the drag and vessel attitude change calculations of the VOF implicit multi-step method with the traditional single-step method, and to verify the feasibility of the method in the numerical prediction of ship resistance and flow field analysis. The results show that an implicit multi-step method with a reasonable number of internal iterations could obtain results close to those of the single-step method with a reduced time step, and the error in trim angle was relatively large, about 2%, but the solving time was only about half that of the latter. The method could also capture the shape and location of waves on the hull, especially in the vicinity of the ship, while the distribution of the waves in the far field differed from those in the experiments to some extent. Full article

The interaction between solitary waves and underwater barriers is investigated using our in-house code, entitled VPM (volume-average/point-value multi-moment)–THINC/QQ (THINC method with quadratic surface representation and Gaussian quadrature)-coupled model. The stability and accuracy of the proposed model are validated by comparing the numerical results with those of the well established two-phase flow solver interFoam. All the results indicate that the presented coupled model has the advantage of high fidelity in simulating solitary wave propagation. Subsequently, solitary waves passing over a single underwater barrier are simulated by the present model. Numerical results are compared with experimental results in terms of the free surface elevation, velocity profile, vorticity field, and wave forces. Great agreements are obtained. In the end, the interactions between solitary waves and double underwater barriers are investigated numerically. The results reveal that the reflection coefficient increases first, and then decreases, with the increasing space between the two barriers. For cases with different wave heights, the transmission coefficient decreases monotonically, and the dissipation coefficient is opposed to the transmission coefficient. Full article

Based on a rigorous solution to the problem, analytical expressions are obtained for calculating the diffraction of the electromagnetic field of a grounded cable on an elongated dielectric spheroid in a conductive layer. The field of a grounded AC cable in a conductive layer is determined by solving the Helmholtz equation for the vector potential by using the method of integral Fourier–Bessel transformations, taking into account the boundary conditions at the bottom and surface of the conductive layer. The process of finding the secondary field of an elongated dielectric spheroid on an alternating current in a conducting layer is divided into two stages. First, we find an exact solution to the problem of an elongated dielectric spheroid at a constant current in a homogeneous field, in free space, decomposing this solution into a Taylor series and retaining the first term, which is a dipole approximation. In the second stage, the resulting field as the sum of the fields of the horizontal and vertical dipoles is analytically continued into the frequency domain. The field of the horizontal and vertical dipoles in the conducting layer is obtained by using the method of integral Fourier–Bessel transformations, taking into account the boundary conditions at the bottom and surface of the conducting layer. The resulting solution is presented in a closed form in elementary functions and has an accuracy level acceptable for the practice. Graphs showing the flow characteristics of an elongated dielectric spheroid modeling a swimmer in a light diving suit are given. The influence of the water–air boundary on the increase in the secondary field of the dielectric spheroid, which leads to an increase in the reliability of object detection, is revealed. The practical implementation of the described device protected by a patent and the experimental data of testing the device layout on the Gulf of Finland are given. A good agreement between the theoretical and experimental flow characteristics of a dielectric object both in shape, amplitude, and phase, is revealed. Full article

For solitary waves on a horizontal bed, the study deals experimentally with the high ratio of wave height (H₀) to still water depth (h₀) that amplifies the wave nonlinearity. The value of H₀/h₀ tested in a wave flume ranges from 0.050 to 0.550, indicating the shift from a quasi-linear solitary wave to a highly nonlinear one. A high-speed particle image velocimetry (HSPIV) and a flow visualization technique of particle-trajectory tracking method are utilized to measure velocity fields and identify near-bed flow structures. The unsteady free-stream velocities with equal magnitude take place in a free-stream zone, FSZ). The FSZ underlies the internal flow zone, over which the external free surface of solitary wave exists and is situated beyond the boundary layer. The spatio-temporal variation of free-stream velocity, moving in phase with the free surface elevation, characterizes the pattern of pressure gradient in the FSZ and thus dominates the behavior of boundary layer flow. Accordingly, nonlinear effects on the time series as well as the maximum values of horizontal velocity, particle acceleration, and pressure gradient in the FSZs of solitary waves are presented. Before, at, and after the wave crest’s intersection with a given measurement location, favorable, zero, and adverse pressure gradients occur in the FSZ, respectively. For H₀/h₀ = 0.179, 0.363, and 0.550, the values of the dimensionless maximum free-stream velocity are about 3.10, 5.32, and 6.20 times that (= 0.0473) for H₀/h₀ = 0.050; and the corresponding values of the dimensionless maximum adverse pressure gradient are about 5.74, 14.54 and 19.84 times that (= 0.0061) for H₀/h₀ = 0.050. This evidence highlights the nonlinear effect on the kinematic and hydrodynamic features of solitary waves. Finally, the effect of nonlinearity on the relationship between the dimensionless time for the maximum adverse pressure gradient in the FSZ and that for the incipient flow reversal in the bottom boundary layer is explored for the first time. It is found that the incipient flow reversal takes place immediately after the maximum adverse pressure gradient, together with a decrease in the dimensionless time for flow reversal if H₀/h₀ increases. The fact accentuates the nonlinear effect on the incipient flow reversal right above the bed. Full article

The main forms of gas kicks into the wellbore during drilling in fractured carbonate reservoirs are underbalanced pressure and gravity displacement. These two forms of gas kicks have different mechanisms of gas entry into the wellbore and different well control measures, which require the timely identification of the type of gas kick when it occurs. A two-phase flow model with a wellbore-formation coupling was developed, based on the gas kick rate models. The variation characteristics of the bottomhole gas influx rate, the wellbore free gas, the bottomhole pressure, the bottomhole pressure change rate, the pit gain and the outlet flow rate during an underbalanced pressure gas kick and a gravity displacement gas kick, were compared and analyzed. Combining the dynamic time warping (DTW) and the wellbore-formation, coupled with a two-phase flow model, an identification method of the gas kick type, based on the DTW was proposed. Following the detection of the gas kick, the identification is performed by calculating the DTW distance between the surface parameter time series, obtained from the two-phase flow simulation and the surface parameter time series, measured in real time. The field example results show that the method can identify the type of gas kick, based on the real-time surface measurement parameters and provide a basis for taking targeted well control measures. Full article

The coupled momenta induced by thermal effects near interfaces cause complex three-dimensional flow structures, called thermocapillary flow or Marangoni convection. Thermocapillary convection is crucial for crystal growth quality, and the mainstream method used to study thermocapillary convection is the half-zone liquid bridge model. This paper designs a gas–liquid two-phase system and reports the numerical results on the instability and associated roll structures of thermocapillary convection in half-zone liquid bridge under microgravity environment. The gas and liquid transferred momentum and energy through the free surface. The geometry of interest is high aspect ratio (AR) silicone oil suspended between coaxial disks heated differentially. It was found that with the increase in AR, the vortex of thermocapillary convection gradually moves to the upper disk at the steady state. In the range of 2 < AR < 2.5, the vortex cell splits from 1 to 2, and the distance between the vortex center increases with the increase in AR. The flow field after the onset of instability exhibits a traveling wave with wave number m = 1 when AR ≤ 3 and exhibits a standing wave with wave number m = 1 when AR ≥ 3.5. Full article

Based on the theory of computational fluid dynamics (CFD), with the help of the Fluent software and the powerful parallel computing capability of the super cloud computer, the single-phase flow transient simulation calculation of the windage power loss of the engagement spiral bevel gear pair (SBGP) was performed. The two-equation SST k-ω turbulence model based on the assumption of eddy viscosity was adopted, which was improved from the standard k-ε model combined with the Wilcox k-ω model. The SST k-ω turbulence model inherited the respective advantages of the Wilcox k-ω model in the near-wall region and the k-ε model in the free shear layer and could more accurately describe the resistance and separation effect of the gear tooth surface on the airflow. The simulation analyzed the airflow characteristics around SBGP and the mechanism of the windshield to reduce the windage loss of the gear. It also studied the influence of the windshield clearance and opening size on the windage power loss. Then the orthogonal experimental analysis method was adopted to perform numerical simulation analysis. The windage torque was studied under different clearance values between the windshield and the gear tooth surface, as well as the large end and the small end. The variance analysis was performed on the numerical simulation data. The results showed that when the windshield clearance value was 1 mm and the engagement opening was 30°, the windage torque was the smallest, and the effect of reducing the windage power loss was the best. According to the changes in the pressure, velocity, and turbulent kinetic energy cloud diagram of the flow field in the reducer during multi-group simulation tests, the local optimal windshield configuration was obtained, which provided a method for further research on the multi-objective optimization of the windshield and the windage loss of the gear pair under the oil–gas two-phase flow and also provided a reference for the practical engineering application of the windshield. Full article

SedWaveFoam, an OpenFOAM-based two-phase model that concurrently resolves the free surface wave field, and the bottom boundary layer is used to investigate sediment transport throughout the entire water column. The numerical model was validated with large-scale wave flume data for sheet flow driven by shoaling skewed-asymmetric waves with two different grain sizes. Newly obtained model results were combined with previous nonbreaking and near-breaking wave cases to develop parameterization methods for time-dependent bed shear stress and sediment transport rate under various sediment sizes and wave conditions. Gonzalez-Rodriguez and Madsen (GRM07) and quasi-steady approaches were compared for intra-wave bed shear stress. The results show that in strongly asymmetric flows, considering the separated boundary layer development processes at each half wave-cycle (i.e., GRM07) is essential to accurately estimating bed shear stress and highlights the impact of phase-lag effects on sediment transport rates. The quasi-steady approach underpredicts (∼60%) sediment transport rates, especially for fine grains under large velocity asymmetry. A modified phase-lag parameter, incorporating velocity asymmetry, sediment stirring, and settling processes is proposed to extend the Meyer-Peter and Mueller type power law formula. The extended formula accurately estimated the enhanced net onshore sediment transport rate observed under skewed-asymmetric wave conditions. Full article

A two-fluid Eulerian–Lagrangian coupled model is developed to investigate the complex interactions between solid particles and the ambient water during the process of submerged granular column collapse. In this model, the water phase is considered to be a Newtonian fluid, whereas the granular column is modeled as an elastic–perfectly plastic material. The water flow field is calculated by the mesh-based Eulerian Finite Volume Method (FVM), with the free surface captured by the Volume-of-Fluid (VOF) technique. The large deformation of the granular material is simulated by the mesh-free, particle-based Lagrangian Smoothed Particle Hydrodynamics method (SPH). Information transfer between Eulerian nodes and Lagrangian particles is performed by the aid of the SPH interpolation function. Both dry and submerged granular column collapses are simulated with the proposed model. Experiments of the submerged cases are also conducted for comparison. Effects of dilatancy (compaction) of initially dense (loose) packing granular columns on the mixture dynamics are investigated to reveal the mechanisms of different flow regimes. Pore water pressure field and granular velocity field are in good agreement between our numerical results and experimental observations, which demonstrates the capability of the proposed Eulerian–Lagrangian coupled method in dealing with complex submerged water–granular mixture flows. Full article

The objective of the present paper is to develop a validated numerical model of a water vortex power plant that serves as a digital twin for further studies such as assessments of the ethohydraulic characteristics or the performance of such devices. The reference for the validation process is a large-scale hydraulic installation equipped with a full-scale water vortex power plant prototype installed in Dresden (Germany), where flow field measurements were carried out using three-dimensional Acoustic Doppler Velocimetry. The numerical model was implemented within the software package Star-CCM+. The unsteady, two-phase flow was solved with the Reynolds-Averaged Navier–Stokes equations in a Eulerian Multiphase approach, deploying a Volume of Fluid method to describe the free-surface flow. Water level and flow velocities were systematically compared in key areas of the device, demonstrating that the simulation is in good agreement with experimental observations. Relative differences are limited to at most 4% regarding water height in the system, and even the much more challenging velocity fields are reproduced with typical relative errors of roughly 10%. This validates the ability of the model to model the challenging flow conditions found in a water vortex power plant, enabling subsequent studies of the characteristics of this power plant concerning fish migration. Full article
