Search Results (67)

Unbalanced accelerations occurring during tram travel have a significant impact on passenger comfort and safety, as well as on the rate of wear and tear on infrastructure and rolling stock. Ideally, these dynamic forces should be monitored continuously in real-time; however, traditional systems require high-precision accelerometers and proprietary software—investments often beyond the reach of municipally funded tram operators. To this end, as part of the research project “Accelerometer Measurements in Rail Passenger Transport Vehicles”, pilot measurement campaigns were conducted in Poland on tram lines in Gdańsk, Toruń, Bydgoszcz, and Olsztyn. Off-the-shelf smartphones equipped with MEMS accelerometers and GPS modules, running the Physics Toolbox Sensor Suite Pro app, were used. Although the research employs widely known methods, this paper addresses part of the gap in affordable real-time monitoring by demonstrating that, in the future, equipment equipped solely with consumer-grade MEMS accelerometers can deliver sufficiently accurate data in applications where high precision is not critical. This paper presents an analysis of a subset of results from the Gdańsk tram network. Lateral (x) and vertical (z) accelerations were recorded at three fixed points inside two tram models (Pesa 128NG Jazz Duo and Düwag N8C), while longitudinal accelerations were deliberately omitted at this stage due to their strong dependence on driver behavior. Raw data were exported as CSV files, processed and analyzed in R version 4.2.2, and then mapped spatially using ArcGIS cartograms. Vehicle speed was calculated both via the haversine formula—accounting for Earth’s curvature—and via a Cartesian approximation. Over the ~7 km route, both methods yielded virtually identical results, validating the simpler approach for short distances. Acceleration histograms approximated Gaussian distributions, with most values between 0.05 and 0.15 m/s², and extreme values approaching 1 m/s². The results demonstrate that low-cost mobile devices, after future calibration against certified accelerometers, can provide sufficiently rich data for ride-comfort assessment and show promise for cost-effective condition monitoring of both track and rolling stock. Future work will focus on optimizing the app’s data collection pipeline, refining standard-based analysis algorithms, and validating smartphone measurements against benchmark sensors. Full article

Earthquakes can trigger emergency braking in urban rail systems, yet the combined effect of braking and ground motion on train–bridge safety remains poorly quantified. Using the Wuxi Metro Line S1 (160 km/h initial speed) on a ten-span simply supported bridge as a case study, we build a multi-body dynamic subway model coupled to a finite element track–bridge model with non-linear Hertz wheel–rail contact. Under the design-basis earthquake (PGA ≈ 0.10 g), the train’s derailment coefficient and lateral car body acceleration rise by 37% and 45%, while the bridge’s lateral and vertical accelerations increase by 62% and 30%, respectively. Introducing a constant emergency brake deceleration of 1.2 m/s² cuts those train-side peaks by 20–25% and lowers the bridge’s lateral acceleration by 18%. The results show that timely braking not only protects passengers but also mitigates seismic demand on the structure, offering quantitative guidance for urban rail emergency protocols in earthquake-prone regions. Full article

The dynamic performance of a ballastless track on bridges affects the vibration performance of the vehicle–bridge coupling system, which, in turn, will affect safety, the smoothness of operating trains, and passenger comfort. However, in the existing literature, few studies focus on the coupled vibration response analysis of large-span continuous beam bridges for high-speed railways, especially high-pier bridges. Dynamic response tests with multiple measurement points installed on the rail, concrete slab, and bridge deck are conducted. This study investigates the dynamic characteristics of bridges with high piers under train loads. A dynamic system is built by the co-simulation platform of SIMPACK v9 and ANSYS v2022, consisting of several models, a coupling mechanism, etc. The vibration response of a train passing through the bridge at 300 km/h is analyzed, and the influence of operating speed on the motivation performance of the coupled system is further studied. The results indicate that the simulation results are validated against experimental data, showing good agreement; the train–track–continuous beam bridge coupling system meets the specification limits and has some margins for further optimization with an operating speed of 300 km/h. The refined model of train–rail–bridge coupling vibration established in this paper provides theoretical guidance for the design and application of high-speed railways. Full article

Between 2019 and 2022, passenger volume on China’s urban rail transit system sharply declined due to strict COVID-19 control measures. On 8 January 2023, China implemented the “Class B infectious disease Class B management” policy, marking a significant shift towards a more relaxed approach to epidemic control. The main objective of this study is to evaluate the immediate and lasting effects of this policy on urban rail transit passenger volume. We used interrupted time series (ITS), combined with quasi-Poisson regression models and counterfactual analysis, to analyze monthly urban rail transit operation data covering the period from January 2021 to June 2024 for 42 cities. Our analysis shows that, relative to the expected trend without any intervention, monthly average passenger volume increased by approximately 101.34% after the policy’s implementation, with significant immediate effects observed in 41 cities and significant lasting effects observed in 33 cities. The study concludes that the “Class B infectious disease Class B management” policy has generally promoted the nationwide recovery of urban rail transit passenger volume, although with significant heterogeneity across cities. This result indicates that the reduction in travel restrictions and the restoration of public safety, resulting from the relaxation of COVID-19 prevention and control measures, contributed to the overall recovery of urban rail transit. This study not only provides innovative methodological insights but also offers valuable guidance on developing more effective urban planning strategies and urban rail transit operational measures in the post-pandemic era. Full article

The most effective way to solve urban traffic congestion in mega cities is to develop rail transit, which is also an important strategy for sustainable urban development. Improving the service performance of rail transit equipment is the key to ensuring the sustainable operation of urban rail transit. Automatic fare collection (AFC) is an indispensable system in urban rail transit. AFC directly serves passengers, and its condition directly affects the sustainability and safety of urban rail transit. This study proposes remaining useful life (RUL) prediction framework for AFC systems. Firstly, it proposes the quantification of AFC health state based on health degree, and proposes a health state assessment method based on digital analog fusion, which compensates for the shortcomings of single data-driven or model driven health methods. Secondly, it constructs a multi feature extraction method based on multi-layer LSTM, which can capture long-term temporal dependencies and multi-dimensional feature, overcoming the limitation of low model accuracy because of the weak data features. Then, the SSA-XGBoost model for AFC RUL prediction is proposed, which effectively performs global and local searches, reduces the possibility of overfitting, and improves the accuracy of the prediction model. Finally, we put it into practice of the AFC system of Shanghai Metro Line 10. The experiment shows that the proposed model has an MSE of 0.00111 and MAE of 0.02869 on the test set, while on the validation set, MSE is 0.00004 and MAE is 0.00659. These indicators are significantly better than other comparative models such as XGBoost, random forest regression, and linear regression. In addition, the SSA-XGBoost model also performs well on R-squared, further verifying its effectiveness in prediction accuracy and model fitting. Full article

The stability of the damping pad floating slab track (DPFST) plays a critical role in the operational safety and passenger comfort of urban rail transit systems and represents a significant technical challenge. This paper introduces a novel harmonic frequency damping device (HFDD) with preload characteristics to enhance DPFST stability. First, the rubber damping pad’s constitutive relationship is determined using uniaxial tensile tests and the Mooney–Rivlin model. Next, a vehicle–track coupled dynamic model and a finite element model of the DPFST with HFDD are developed. Finally, the effects of HFDD installation and parameter adjustments on the DPFS’s modal and dynamic responses are examined. Results show that the HFDD effectively adjusts the DPFS’s natural frequency and suppresses its acceleration and displacement. Increasing HFDD stiffness from 0 to 10 kN/mm raises the DPFS’s natural frequency by up to 7.58 Hz. Within the stiffness and damping ranges of 0–20 kN/mm and 0–100 kN·s/m, respectively, the HFDD significantly reduces DPFS vibration, with maximum reductions in acceleration of 45.64% and 64.24% and in displacement of 47.55% and 39.06%. However, beyond these ranges, further increases in stiffness and damping substantially reduce the HFDD’s vibration suppression effectiveness and excessively high values are impractical for engineering use. Full article

The emergency evacuation sign system is crucial for the safety and sustainable development of urban rail transit. Dynamic emergency evacuation signs, which offer real-time guidance during emergencies, are gaining prominence. There is an urgent need to develop a dynamic system that balances perceptual and cognitive visibility. Against this backdrop, this study built a simulation experiment platform based on BIM, Unity, and VR. Eight experimental scenarios were created using the platform: two emergency events (fire/fire accompanied by power outage) × four emergency evacuation signage systems (static emergency signage system/dynamic dissuasion emergency signage system/dynamic dissuasion emergency signage system with flashing/dynamic dissuasion emergency signage system with flashing and auxiliary information), and experimental testing was completed. The evacuation behavior parameters of 39 passengers were extracted and used to construct a multidimensional indicator system. Subsequently, generalized estimation equations were applied to investigate the impact mechanism of signage systems on passengers’ evacuation behavior. Finally, the coupling coordination degree model was used to quantitatively evaluate the coupling coordination level of four emergency evacuation signage systems under different emergencies. Results indicate that compared to static signage system, the three sets of dynamic identification system schemes have a positive impact on passenger evacuation behavior and significantly reduce the number of decision-making errors. Particularly in high-risk scenarios involving fire accompanied by power outages, the dynamic dissuasion emergency signage system with flashing and auxiliary information outperforms others by achieving a better balance of reliability, efficiency, and safety. This study investigates the efficacy of various emergency evacuation signage systems across diverse emergency scenarios, offering insights for the enhanced design of such systems and thereby fostering the sustainable development of urban rail transit infrastructure. Full article

The increasing frequency of urban flooding, driven by global climate change, poses significant threats to the safety and resilience of urban rail transit systems. This study systematically examines the cascading failure processes and resilience of these networks under flood conditions, with a specific focus on the Shanghai Metro. A comprehensive resilience evaluation model was developed by integrating geographic information, static network characteristics, and dynamic passenger flow indicators. This study employs an improved Coupled Map Lattice (CML) model to simulate cascading failures by considering the coupling effects of station centrality, geographic elevation, and passenger flow dynamics. The results indicate that stations with higher degrees of centrality are more likely to trigger rapid cascading failures across the network. However, incorporating dynamic passenger flow and geographic elevation data helps mitigate these effects, emphasizing the need for multi-dimensional resilience strategies. The findings provide valuable insights for urban transit management, offering a scientific foundation for developing targeted disaster response strategies to enhance network resilience against floods. This study advances our understanding of the vulnerability of urban rail transit systems and offers practical guidance for improving disaster preparedness in urban transportation infrastructure. Full article

Railway level crossings pose risks to both train passengers and road users, worsened by the complex interaction between rail and road traffic, particularly on local railways. This study introduces a Risk Management (RM) framework designed to enhance safety at level crossings on local railways by providing a decision-support tool. By individually assessing risk factors, the framework allows for a precise evaluation of the current risk levels in terms of both Cumulated and Individual Risk levels, Individual Risk, and the impacts of potential modifications. The framework allows the quantitative assessment of risk and resource optimization, enabling infrastructure managers to identify high-risk crossings and select the most effective safety interventions. The framework was applied to 96 level crossings on an Italian local railway line, demonstrating its ability to support decision-making for targeted interventions as well as broader network-level actions, significantly improving system safety. Full article

Elevated stations are integral components of urban rail transit systems, significantly impacting passengers’ travel experience and the operational efficiency of the transportation system. However, current elevated station designs often do not sufficiently consider the structural dynamic response under various operating conditions. This oversight can limit the operational efficiency of the stations and pose potential safety hazards. Addressing this issue, this study establishes a vehicle-bridge-station spatial coupling vibration simulation model utilizing the self-developed software GSAP V1.0, focusing on integrated station-bridge and combined station-bridge elevated station designs. The simulation results are meticulously compared with field data to ensure the fidelity of the model. Analyzing the dynamic response of the station in relation to train parameters reveals significant insights. Notably, under similar travel conditions, integrated stations exhibit lower vertical acceleration in the rail-bearing layer compared to combined stations, while the vertical acceleration patterns at the platform and hall layers demonstrate contrasting behaviors. At lower speeds, the vertical acceleration at the station concourse level is comparable for both station types, yet integrated stations exhibit notably higher platform-level acceleration. Conversely, under high-speed conditions, integrated stations show increased vertical acceleration at the platform and hall levels compared to combined stations, particularly under unloaded double-line working conditions, indicating a superior dynamic performance of combined stations in complex operational scenarios. However, challenges such as increased station height due to bridge box girder maintenance, track layer waterproofing, and track girder support maintenance exist for combined stations, warranting comprehensive evaluation for station selection. Further analysis of integrated station-bridge structures reveals that adjustments in the floor slab thickness at the rail-bearing and platform levels significantly reduce dynamic responses, whereas increasing the rail beam height notably diminishes displacement responses. Conversely, alterations in the waiting hall floor slab thickness and frame column cross-sections exhibit a minimal impact on the station dynamics. Overall, optimizing structural dimensions can effectively mitigate dynamic responses, offering valuable insights for station design and operation. Full article

Urban rail transit encounters supply–demand contradictions during peak hours, seriously affecting passenger experience. Therefore, it is necessary to explore and optimize passenger-flow control strategies for urban rail transit stations during peak hours. However, current research mostly focuses on passenger-flow control at the network level, and there is insufficient exploration of specific operational strategies at the station level. At the same time, the microscopic simulation model for passenger-flow control at the station level faces the challenge of balancing efficiency and accuracy. This paper presents a simulation optimization approach to optimize the station-level passenger-flow controlling measures, based on a queueing network and surrogate model, aiming to improve throughput, minimize congestion, and enhance passenger experience. The first stage of the method modeled the urban railway station using queueing network theory and multi-agent theory, and then built a mesoscale simulation model that was based on an urban railway station. In the second stage, a passenger flow management and control model for ingress flow was established by combining the Kriging model with a queuing network model, and the particle swarm optimization algorithm was used to solve the model. On this basis, a simulation optimization method for station passenger-flow control was established. Finally, we conducted an example analysis of Zhongguancun Station on the Beijing subway. By comparing the simulation results before and after control, as well as comparing the optimal control scheme obtained by this method with the results of other control schemes, the results showed that the simulation optimization method proposed in this paper can propose an optimal passenger-flow control scheme. By using this method, stations can significantly enhance sustainability. For example, the method not only saves human resources but also effectively avoids or reduces congestion, boosting passenger travel efficiency and safety. By minimizing wait times, these methods lower energy consumption and support the sustainable development of public transportation systems, contributing to more sustainable urban environments. Full article

In a rail transit system, there is a constant leakage of current from the subway rails to the earth, and these stray currents have complex propagation paths and a wide range of influence. Since no stray current collection devices are installed at subway depots, some of the stray current leaking from the mainline will converge at the depot, seriously corroding the structural reinforcement and buried metal of the station, thereby jeopardizing the normal operation of subway trains and passenger safety. In this paper, a field-circuit coupling method is proposed to analyze the current leakage and distribution law of the subway mainline and depot. It is found that the failure of the gauge block at the mainline will trigger the maximum leakage of rail current. Additionally, it is observed that the stray current distribution at the depot is mainly influenced by the operating status of the one-way conduction device (OWCD) and the change of rail potential. These results validate the applicability and effectiveness of the field-circuit coupling method proposed in this paper and provide new technical support for the study of stray current leakage distribution in subways. Full article

Striving to increase the speed of rail vehicles and thus improve the comfort of traveling passengers at the same time, undertakes activities in the sphere of ensuring an appropriate level of safety of rail, passenger, and freight transport. One of the elements of activities in this area is the training of train drivers. Until recently, this training consisted of a theoretical and practical part on the vehicle, alongside an experienced train driver. Considering the increasing level of automation of railway traffic control systems and locomotive equipment, as well as training costs and requirements related to the introduction of TSI, it is becoming an increasingly common requirement to conduct practical training on railway vehicle traffic simulators, while the conditions in the simulator cabin and the trainee’s feelings should correspond to the actual driving conditions. A locomotive driving simulator is a system consisting of a cabin of a suitable type of locomotive or EMU, mapped in 1:1 scale, coupled with a motion excitation system and computer programs connected together forming the software of the cab visualization and dynamics system. The basic program simulating the dynamics and kinematics of the cabin’s motion is a program containing a motion dynamics model that generates signals forcing the movement of the exciters on which the cabin’s platform is mounted. The correct operation of the simulation model depends on the created mathematical model, which can be built in several ways. This article presents the issue of building a mathematical model describing the dynamics of the rail vehicle motion, which can then be used in the simulation model of the simulator cabin motion. Two ways of proceeding in the process of approaching the construction of a mathematical model of rail vehicle motion dynamics will be presented, with the possibility of later use in creating a simulation model of the motion of the locomotive simulator cabin. One of the possible routes was used in the past in the construction of the EP09 locomotive simulator. Full article

When urban subway trains run in the depot, they can cause vibration and noise, which affects the safety and reliability of the structure under the track, and these transmits to the over-track buildings and often trouble passengers and staff. This paper established a coupling model of a track–metro depot–over-track building based on the structural finite element method and analyzed vibration response and then summarized the vibration transmission and distribution characteristics as the speed changes. The results show that, at train speeds of 20 km/h and 5 km/h, the Z-vibration level difference between the two at the rail is nearly 20 dB, and the vibration can be reduced by 17.9% at most. The difference between the two on the 9 m platform is 6–8 dB and 5–14 dB on the 16 m platform, and the vibration can be reduced by 17.7% at most. The difference between the two in the over-track building is 3–11 dB, and the vibration can be reduced by 13.0% at most. The vibration has the highest energy within a range of 2 m radiating from the center of the line, reaching a maximum of 118.5 dB. The vibration shows a ring-shaped distribution, and the ring-shaped distribution is more pronounced as the train speed increases. In the horizontal direction of the track line, the vibration energy distribution is within a range of −4 m to 11.5 m from the track line. In the longitudinal direction of the track line, the ring-shaped distribution of vibration energy exhibits a periodic pattern. The results provide a reference for the vibration control of the over-track buildings. Full article

The influence of passenger gender, age, educational background, and other personal characteristics on satisfaction with an urban rail transit was studied. In total, 6340 valid questionnaires were completed, and basic data about the passengers were statistically analyzed. Based on AHP and the fuzzy comprehensive evaluation method, 94.594 percent of passengers reported overall satisfaction with the Qingdao rail transit; the data for subgroups based on gender, age, and other aspects were also calculated. An independent samples t-test and one-way analysis of variance were used to analyze the correlations between passenger satisfaction and the following parameters: gender, age, education, occupation, income, ride frequency, and private car availability. The results show that women attach more importance to the caring they feel in the process of travel than men, and no significant difference exists in travel satisfaction between passengers with private cars and those without private cars (p > 0.05). Older passengers report more satisfaction than younger passengers. Additionally, for passengers with high education and high income, satisfaction is lower in terms of safety, convenience, and comfort and caring. There are also significant differences in the safety, convenience, comfort, and caring experienced across different occupational groups. These research results provide a theoretical basis for understanding how passengers with different backgrounds perceive the operational services of an urban rail transit with regard to service defects, the weaknesses in the operation process, and passenger satisfaction. Full article
