This paper reports a statistical analysis of a database archiving information on the strengths of the materials in existing Italian bridges having pre- and post-tensioned concrete beams. Data were collected in anonymous form by analyzing a stock of about 170 bridges built between 1960 and 2000 and located in several Italian regions. To date, the database refers to steel reinforcing bars, concrete, and prestressing steel, whose strengths were gathered from design nominal values, acceptance certificates, and in situ test results, all derived by consulting the available documents for each examined bridge. At first, this paper describes how the available data were collected. Then, the results of a statistical analysis are presented and commented on. Moreover, goodness-of-fit tests are carried out to verify the assumption validity of a normal distribution for steel reinforcing bars and prestressing steel, and a log-normal distribution for concrete. The database represents a valuable resource for researchers and practitioners for the assessment of existing bridges. It may be applied for the use of prior knowledge within a framework where Bayesian methods are included for reducing uncertainties. The database provides essential information on the strengths of the materials to be used for a simulated design and/or for verification in the case of limited knowledge. Goodness-of-fit tests make the collected information very useful, even if probabilistic methods are applied. Full article

In order to verify the rationality and feasibility of a demountable and replaceable fabricated RC beam with bolted connection under mid-span compression, one cast-in-place RC beam and four fabricated RC beams were designed and fabricated. Through the mid-span static loading test and analysis of five full-scale RC beams, the effects of high-strength bolt specifications and stiffeners were compared, and the behavior of the fabricated RC beams with bolted connections was analyzed. The test process was observed and the test results were analyzed. The failure mode, cracking load, yield load, ultimate load, stiffness change, deflection measured value, ductility, and other indicators of the specimens were compared and analyzed. It was shown that the failure mode of the fabricated RC beam was reinforcement failure, which met the three stress stages of the normal section bending of the reinforcement beam. The failure position occurred at 10~15 cm of the concrete outside the bolt connection, and the beam support and the core area of the bolt connection were not damaged. The fabricated RC beam has good mechanical performance and high bearing capacity. In addition, comparing the test value with the simulation value, it is found that they are in good agreement, indicating that ABAQUS software of 2024 can be well used for the simulation analysis of the behavior of fabricated RC beam structure. Full article

In this study, acoustic emission (AE) analysis was carried out to evaluate and quantify the cracking behavior of large-scale multi-layered reinforced concrete beams under flexural tests. Four normal concrete beams were repaired by adding a layer of crumb rubberized engineered cementitious composites (CRECCs) or powder rubberized engineered cementitious composites (PRECCs), in either the tension or compression zone of the beam. Additional three unrepaired control beams, fully cast with either normal concrete, CRECCs, or PRECCs, were tested for comparison. Flexural tests were performed on all the tested beams in conjunction with AE monitoring until failure. AE raw data obtained from the flexural testing was filtered and then analyzed to detect and assess the cracking behavior of all the tested beams. A variety of AE parameters, including number of hits and cumulative signal strength, were utilized to study the crack propagation throughout the testing. Furthermore, b-value and intensity analyses were implemented and yielded additional parameters called b-value, historic index [H (t)], and severity (S_r)_. The analysis of the changes in the AE parameters allowed the identification of the first crack in all tested beams. Moreover, varying the rubber particle size (crumb rubber or powder rubber), repair layer location, or AE sensor location showed a significant impact on the number of hits and signal amplitude. Finally, by using the results of the study, it was possible to develop a damage quantification chart that can identify different damage stages (first crack and ultimate load) related to the intensity analysis parameters (H (t) and S_r). Full article

This paper presents the first stage of an experimental investigation of creep in two-layer reinforced concrete beams. It deals with the methodology of testing beams under long-term loading aimed at the investigation of the real linear creep effect. The investigated beams consisted of a normal-strength concrete (NSC) in the tensile zone and steel-fibered high-strength concrete (SFHSC) in the compression one. The specimens are subjected to four-point bending under loads that correspond to 70 and 85% of their load-bearing capacity. The loads are applied using special amplifying devices. The experiments at this stage lasted 90 days. Deflections are measured in the midspan of each specimen. During the first 24 h after applying the loads, the deflections were recorded every 10 s, and after 24 h, every hour. During the tests, no cracks have been observed near the supports as well as between the NSC and SFHSC layers. The cracks appeared within the limits of the pure bending zone only. Load-deflection curves were obtained and analyzed. The maximum midspan deflection in the tested beams was less than 1/250 of the beam span, which indicated that at linear creep, the two-layer beams are safe and remain in the elastic stage. The obtained results form a basis for the second stage of the experimental research that will be focused on the non-linear creep effect in such beams. Full article

The issues of numerous steel beam components and the tendency for deck cracking under negative bending moment zones have long been challenges faced by traditional composite I-beams with flat steel webs. This study introduces an optimized approach by modifying the structural design and material selection, specifically substituting flat steel webs with corrugated steel webs and using ultra-high-performance concrete for the deck in the negative bending moment zone. Three sets of model tests were conducted to compare and investigate the influence of deck material and web forms on the bending and crack resistance of steel–concrete composite I-beams under a negative bending moment zone. The findings indicate that, compared to a conventional steel–normal concrete composite I-beam, incorporating ultra-high performance concrete into the negative bending zone enhances the cracking load by 98%, resulting in finer and denser cracks, and improves the ultimate bearing capacity by approximately 10%. In comparison to the composite I-beam with flat steel webs, the longitudinal stiffness of the composite I-beam with corrugated steel webs is smaller, which can further enhance the bridge deck’s resistance to cracking in the negative bending moment zone, and maximize the steel-strengthening effect of the lower flange of the steel I-beam. Based on the findings of this study, it is recommended to use steel ultra-high-performance concrete composite I-beams with corrugated steel webs due to their superior crack resistance, bending strength, and efficient material utilization. Full article

The construction industry continually seeks to optimize the materials used in building projects to balance structural integrity with economic and environmental concerns. Particularly in urban high-rise construction and seismic zones, the choice of material can significantly affect the project’s feasibility and safety. This study investigated the mechanical response of regular and lightweight concrete to bending stresses, which are critical factors in the structural design process. By comparing the strain–stress relationships, densities, and deformation capacities of these two varieties of concrete, this research aimed to clarify their fundamental differences. Lightweight concrete, with its lower density of 1800 kg/m³, offers noticeable weight reductions, thus presenting a viable solution for structures where reduced mass is beneficial, such as in areas with load-bearing limitations or for components that require ease of transportation and assembly. However, this study found that the reduction in weight is accompanied by lower compressive and flexural strength compared to normal concrete, which, with a density of 2400 kg/m³, exhibited greater mechanical strength and resilience under bending stresses. Stress–strain graphs generated from the experimental data illustrated both types of concrete’s elastic and plastic deformation behaviors, highlighting the material’s transition from elasticity to plasticity at specific stress points. This nuanced understanding of the materials’ behaviors is vital for construction professionals as it equips them with the information necessary to make informed decisions on material selection, ensuring safety, sustainability, and cost-effectiveness in construction projects. Full article

Limited investigations have evaluated the potential of using layered sections of normal-weight and lightweight concrete (NWC and LWC) mixtures in structural beams and slabs. The main objective of this paper is to assess the flexural strength properties of layered reinforced concrete (RC) beams, which help conserve natural resources and reduce construction weight. Six RC beams cast with different NWC/LWC combinations are tested to determine the damage patterns, concrete strains, ultimate load, displacements at failure, and ductility. The test results showed that the LWC cast in the tension zone (and up to the neutral axis) has a negligible effect on the beam’s stiffness and ultimate load since the overall behavior remains governed by the yielding of tensile steel reinforcement. Nevertheless, the deflection at failure and ductility seem to gradually curtail when the NWC is partially replaced by LWC at different elevations across the beam’s cross-section. A finite element analysis using ABAQUS software 6.14 is performed, and the results are compared with experimental data for model validation. Such data can be of interest to structural engineers and consultants aiming for optimized design of slabs and beams using layered concrete casting, which helps reduce the overall construction weight while maintaining the structural integrity of members. Full article

This paper investigates, experimentally and numerically, the shear strengthening of Normal Concrete (NC) beams using post-tensioning steel bars and Engineered Cementitious Composite (ECC) reinforced with chemically cured Palm Fronds (PFs). The benefits of strain-hardening ECC and the tensile strength of PFs cured with 6% wt Alkali NaOH solution beside post-tensioned bars have been employed herein. Seven full-scale Reinforced Concrete (RC) beams were fabricated and experimented with under three-point loading until failure. The test parameters include the strengthening technique, type, and configuration of the material used for strengthening. The strengthening process has been implemented through two techniques: Externally Bonded Reinforcement (EBR) and Near-Surface Mounted (NSM) Reinforcement. The strengthening materials have been configured and placed in horizontal, vertical, and inclined positions. The effectiveness of the strengthening methods has been evaluated by examining their cracking propagations, load-deflection responses, collapse modes, elastic stiffness, and absorbed energy. It was found that the proposed strengthening systems could significantly control the crack pattern and failure mode, and they could enhance the ultimate load amplitude up to 37% and 50% for NSM ECC with PFs and EBR post-tensioning steel bars, respectively. Nonlinear three-dimensional finite element models of the tested beams were developed and validated with the test data, where it was found that finite element models predict the structural performance of tested beams with a maximum error of only 2%. Full article

The effectiveness of repair work relies on whether the interface substrate can achieve sufficient bond strength when subjected to numerous stresses. This study investigated the bond properties of repaired normal concrete (NC-to-NC) elements, including cube, beam, and U-shaped specimens, after undergoing natural fracture due to flexural and tensile stresses. The specimens were repaired using a polyurethane (PU) matrix by gluing the two parts and applying compression, splitting, and drop-weight impact (DWI) tests to evaluate the bond strength properties. The results revealed that the PU matrix effectively repairs NC substrate with adequate bond strength, which exceeds the minimum allowable bond strength specified in the ASTM ACI 546-06 to rehabilitate damage concrete structures. The reference beams exhibit a peak applied load capacity of 15.6 kN with less deflection than the repaired samples. The compressive strength of the NC-to-NC repaired specimens loaded along and parallel to the interface plane revealed a decrease in compressive strength of 47.3% and 31.5% compared to the NC-R samples, respectively. The mean number of blows at the cracking stages appeared nearly equal for reference and repaired NC-to-NC specimens. The reference specimens exhibited an average number of 24 and 31 blows at the initial and failure stages, respectively, which were higher by 9.1% and 5.2% than the NC-to-NC repaired specimens. The PU binder showed promising results in achieving adequate interfacial bond strength under static and impact loads. Full article

Longitudinal ordinary rebars are discontinuous at the joints of precast concrete segmental bridges (PCSBs), which can open under tensile stresses induced by bending moments. This will lead to durability issues with the joints. To improve the bending properties of PCSBs, a novel joint type featuring continuous rebars was proposed in the present study. Three specimens were subjected to testing to examine the bending behavior of PCSBs using this new joint design compared to traditional joints. The crack propagation, structural deformation, joint opening width, strain in rebars, failure mode, stiffness, and flexural capacity were comprehensively investigated. The test results reveal that the continuous rebars effectively transferred bending normal stress between joints, ensuring full development of cracks in each beam segment. Effective control of joint opening width was also observed. Compared to traditional joints, the new joints exhibited a 29% to 33% increase in cracking load and a 32% increase in ultimate load. Failure in the continuous rebar joints was characterized by partial anchorage failure of the rebars along with localized concrete crushing in the top compression zone. Based on the test results, a computational method was proposed for calculating the cracking strength and flexural capacity of the new joints. Full article

Precast rectangular reinforced concrete (PRRC) beams are joined on construction sites using concrete in situ to achieve the desired length. Limited research exists on the effect of intermediate connection shapes and the types of infilled concrete on the flexural performance of PRRC beams. This paper presents a comprehensive experimental and numerical investigation into the performance of PRRC beams with various intermediate connection geometries and infilled materials under flexural loading. The study examines rectangular, triangular, and semi-circular intermediate connections, along with the performance of beams infilled with normal concrete (NC), engineered cementitious composites (ECC), ultra-high-performance ECC (UHPECC), and rubberized ECC (RECC). The experimental results indicate that the rectangular intermediate connection exhibits superior performance in terms of strength and energy absorption compared to the triangular and semi-circular shapes. Beams incorporating UHPECC demonstrated the most significant improvements in strength and energy absorption, outperforming those with ECC and RECC for any shape of intermediate connection. Moreover, beams with rectangular connections and UHPECC infill exhibited the most significant increase in energy absorption and ultimate load compared to the beams with ECC and RECC. The ultimate load of the beams with UHPECC and tensile reinforcement bar diameters of 10 mm and 12 mm increased by 13% and 29%, respectively, compared to the control beam. The energy absorption of the beams with tensile reinforcement bar diameters of 10 and 12 mm was found to be 75% and 184% higher, respectively, than the control beam. In addition, an increase in tensile bar diameter was found to enhance both the energy absorption and the ultimate load capacity of the beams, regardless of the type of infill concrete. Beams incorporating UHPECC demonstrated the most significant improvements in strength and energy absorption, outperforming those with ECC and RECC. In particular, beams with rectangular connections and UHPECC infill exhibited an increase in energy absorption and ultimate load of up to 184% and 29%, respectively. UHPC was calculated to be as high as 184%, and 29%, respectively, compared to the control beams. In addition, an increase in tensile bar diameter was found to enhance both energy absorption and ultimate load capacity. Finite element modeling (FEM) was developed and validated against the experimental results to ensure accuracy. A parametric study was conducted to study the effects of various concrete types in triangular and semi-circular connections, as well as the influence of intermediate connection length on semi-circular connections under flexural loads. The findings reveal that increasing the length of intermediate connections increases the ultimate load of the beams. Full article

The shear stirrups and bend-up reinforcement in ultra-high-performance concrete (UHPC) beams could potentially be excluded due to the superior mechanical properties of UHPC. This paper reports the new findings of an experimental research into the factors that influence the shear behavior of non-stirrup UHPC beams. Fourteen beams were tested in shear, comprising twelve non-stirrup UHPC beams and two normal concrete (NC) beams reinforced with stirrups. The test variables included the steel fiber volume content (2.0%, 1.5%, and 0%), the shear span-to-effective-depth ratio (1.2, 1.8, 2.0, and 3.1), beam width (150 mm and 200 mm), and beam height (300 mm, 350 mm, and 400 mm). The results demonstrated that the steel fiber volume content had a significant influence on the shear behavior of the non-stirrup UHPC beams. The failure modes of the beams without steel fibers were typically brittle, whereas those reinforced with steel fibers exhibited ductile failure. The shear resistance of the beams could be significantly enhanced by the addition of steel fibers in the concrete mix. Furthermore, the post-cracking load-bearing performance of the beams could also be markedly improved by the addition of steel fibers. In addition, the shear span-to-effective-depth ratio had a considerable impact on the failure mode and the ultimate shear strength of the tested beams. The contribution of steel fibers to the shear capacity of the UHPC beams was observed to increase as the shear span-to-effective-depth ratio increased. The French standard formulae tended to overestimate the contribution of steel fibers, and the calculation results were found to be more accurate for UHPC beams with a moderate shear span-to-effective-depth ratio (around 2.0). Moreover, the French standard formulae demonstrated greater accuracy at a larger beam height for calculating the contribution of UHPC matrix. Full article

This study investigates the torsional performance of reinforced concrete beams with transverse circular openings and examines methods to mitigate the detrimental effects of these openings using Ultra-High-Performance Concrete (UHPC) and diagonal reinforcement. The experimental component involved casting and evaluating eight beams with dimensions of 150 × 200 × 1200 mm under pure torsion. Among these, two beams were solid (without openings), one was made from normal-strength concrete (NSC), and the rest were cast with UHPC. The beams with openings were categorized into two groups based on the size of the openings—small and large. Each group comprised three beams: the first was cast from NSC and included diagonal reinforcement, the second from UHPC with diagonal reinforcement, and the third from UHPC but without diagonal reinforcement. Results indicated that all beams with openings cast from UHPC exhibited a substantial increase in ultimate torque compared to the control NSC solid beam. NSC beams with small openings showed a marginal decrease in ultimate load capacity by 1.47%, whereas those with large openings experienced a significant reduction of 17.65%. UHPC effectively compensated for the strength lost due to the absence of diagonal reinforcement in both small and large openings. Initial stiffness in NSC beams decreased by 19.4% and 70.1% for small and large openings, respectively. Conversely, UHPC beams demonstrated improved initial stiffness, with increases of approximately 64% for small and 34% for large openings. This study proposes ultimate torsional equations for UHPC beams with various opening sizes. These equations are validated by comparing them with results from previous experimental research, examining the performance of UHPC beams with and without openings. Full article

Despite extensive research on lightweight aggregate concrete (LWAC), the precise effects of different coarse aggregate types and their physical properties on the shear capacity of reinforced all lightweight aggregate concrete (ALWAC) beams remain unclear. A comprehensive understanding of how aggregates influence the shear behavior of reinforced concrete (RC) beams is essential for accurately predicting shear strength and effectively designing ALWAC structures. To advance this understanding, experiments were conducted on twelve RC beams: four made of normal-weight concrete (NWC) and eight of ALWAC. ALWAC beams exhibited more extensive and wider flexural cracks compared to NWC beams under the same loading conditions. ALWAC beams demonstrated structural performance similar to NWC beams under identical loading conditions. The cracking loads of ALWAC can be estimated through measured concrete strength, with the post-cracking behavior predominantly influenced by the tensile reinforcement. All considered design codes underestimated the shear capacity of the tested ALWAC beams, and the shear resistance estimated by EC2 corresponded more closely than other existing codes. Lastly, the limitations and future work based on the results of this study were discussed and summarized. Full article

The use of seawater sea sand concrete (SSSC) and fiber-reinforced polymer (FRP) has broad application prospect in island and coastal areas. However, the elastic modulus of FRP reinforcement is obviously lower than that of ordinary steel reinforcement, and the properties of SSSC are different from that of ordinary concrete, which results in a limit in the bearing capacity and stiffness of structures. In order to improve the flexural performance of FRP-reinforced SSSC beams, a novel SSSC beam with built-in glass FRP (GFRP) tubes was proposed in this study. Referring to many large-scale beam experiments, one specimen was used for one situation to illustrate the study considering costs and feasibility. Firstly, flexural performance tests of SSSC beams with GFRP tubes were conducted. Then, the effects of the GFRP tubes’ height, the strength grades of concrete inside and outside the GFRP tubes, and the GFRP reinforcement ratio on the flexural behaviors of the beams were investigated. In addition, the concept of capacity reserve was proposed to assess the ductility of the beams, and the interaction between the concrete outside the GFRP tube, the GFRP tube and concrete inside the tube was discussed. Finally, the formulas for the normal section bearing capacity of beams with built-in GFRP tubes were derived and verified. Compared to the beam without GFRP tubes, under the same conditions, the ultimate bearing capacities of the SSSC beam with 80 mm, 100, and 200 mm height GFRP tubes were increased by 17.67 kN, 24.52 kN, and 144.42 kN, respectively. Full article
