Search Results (18)

Substantial improvements in the performance of optical interconnects based on multi-mode fibers are required to support emerging single-channel data transmission rates of 200 Gb/s and 400 Gb/s. Future optical components must combine very high modulation bandwidths—supporting signaling at 100 Gbaud and 200 Gbaud—with reduced spectral width to mitigate chromatic-dispersion-induced pulse broadening and increased brightness to further restrict flux-confining area in multi-mode fibers and thereby increase the effective modal bandwidth (EMB). A particularly promising route to improved performance within standard oxide-confined VCSEL technology is the introduction of multiple isolated or optically coupled oxide-confined apertures, which we refer to collectively as multi-aperture (MA) VCSEL arrays. We show that properly designed MA VCSELs exhibit narrow emission spectra, narrow far-field profiles and extended intrinsic modulation bandwidths, enabling longer-reach data transmission over both multi-mode (MMF) and single-mode fibers (SMF). One approach uses optically isolated apertures with lateral dimensions of approximately 2–3 µm arranged with a pitch of 10–12 µm or less. Such devices demonstrate relaxation oscillation frequencies of around 30 GHz in continuous-wave operation and intrinsic modulation bandwidths approaching 50 GHz. Compared with a conventional single-aperture VCSELs of equivalent oxide-confined area, MA designs can reduce the spectral width (root mean square values < 0.15 nm), lower series resistance (≈50 Ω) and limit junction overheating through more efficient multi-spot heat dissipation at the same total current. As each aperture lases in a single transverse mode, these devices exhibit narrow far-field patterns. In combination with well-defined spacing between emitting spots, they permit tailored restricted launch conditions in MMFs, enhancing effective modal bandwidth. In another MA approach, the apertures are optically coupled such that self-injection locking (SIL) leads to lasing in a single supermode. One may regard one of the supermodes as acting as a master mode controlling the other one. Streak-camera studies reveal post-pulse oscillations in the SIL regime at frequencies up to 100 GHz. MA VCSELs enable a favorable combination of wavelength chirp and chromatic dispersion, extending transmission distances over MMFs beyond those expected for zero-chirp sources and supporting transfer bandwidths up to 60 GHz over kilometer-length SMF links. Full article

Multimode VCSELs coupled into waveguides can be a practical path toward realizing commercially viable photonic interposer chips. The experimental coupling of multimode VCSEL light to a non-silicon waveguide fabricated using a CMOS-compatible process is demonstrated. The GaP prism was tested and adopted as a coupling method. Both conventional and cavity-type optical waveguides, fabricated from CMOS-compatible PECVD SiO₂, Si₃N₄, and SiO_xN_y materials, were evaluated. The average propagation loss transmitted through the cavity-type waveguide was measured as 0.444 dB/cm. A polyimide micro-lens, cavity-type waveguide, and a GaP prism coupler are developed to inject the multimode VCSEL light into the waveguide measuring the net coupling loss of 0.762 dB. The packaged size of VCSEL has an area of 0.4 mm² and a height of 0.64 mm. MUX/DeMUX was designed on the bottom of the prism. A light source, a modulator, and MUX/DeMUX are all located in the same area of the prism bottom in VCSEL-based interconnections. Full article

By combining the Fourier series expansion method with the perfect matching layer strategy, this study provides a detailed analysis of symmetric periodic chains consisting of two-dimensional monolayer dielectric cylinders. The numerical and field distribution characteristics were systematically compared by varying the semidiameter and dielectric constant of the monolayer cylindrical periodic structure. The results show that, under a constant dielectric constant, structural chains with larger radii support both odd and even modes, enabling multimode communication. Additionally, when the radius is fixed, structural chains with a lower dielectric constant exhibit more stable single-mode behavior under the same radius conditions. These findings provide valuable theoretical insights for the design of high-density optical interconnects and reconfigurable photonic networks, contributing to the advancement of next-generation optical communication systems. Full article

Many current 1 × 2 splitter couplers based on multimode interference (MMI) face difficulties such as significant back reflection and limited flexibility in waveguide segmentation at the output, which necessitate the addition of transitional structures like tapered waveguides or S-Bends. These limitations reduce their effectiveness as photonic data-center applications, where precise waveguide configurations are crucial. To address these challenges, we propose a novel nanoscale 1 × 2 angled multimode interference (AMMI) power splitter with silicon nitride (SiN) buried core and silica cladding. The innovative angled light path design improved performance by minimizing back reflections back to the source and by providing greater flexibility of waveguide interconnections, making the splitter more adaptable for data-center applications. The SiN core was selected due to its lower refractive index contrast with silica compared to silicon, which helps further reduce back reflection. The dimensions of the splitter were optimized using full vectorial beam propagation method (FV-BPM), finite-difference time domain (FDTD), and multivariable optimization scanning tool (MOST) simulations to support transmission across the O-band. Our proposed device demonstrated excellent performance, achieving an excess loss of 0.22 dB and an imbalance of <0.01 dB at the output ports at an operational wavelength of 1.31 µm. The total device length is 101 µm with a thickness of 0.4 µm. Across the entire O-band range (1260–1360 nm), the performance of the splitter presented excess loss of up to 1.57 dB and an imbalance of up to 0.05 dB. Additionally, back reflections at the operational wavelength were measured at −40.96 dB and up to −39.67 dB over the O-band. This silicon-on-insulator (SOI) complementary metal-oxide semiconductor (CMOS) compatible AMMI splitter demonstrates high tolerance for manufacturing deviations due to its geometric layout, dimensions, and material selection. Furthermore, the proposed splitter is well-suited for use in O-band transceiver systems and can enhance data-center optical networks by supporting high-speed, low-loss data transmission. The compact design and CMOS compatibility make this device ideal for integrating into dense, high-performance computing environments, ensuring reliable signal distribution and minimal power loss. The splitter can support multiple communication channels, thus enhancing bandwidth and scalability for next-generation data-center infrastructures. Full article

We design and fabricate meter-scale long connectorized paper-like flexible multimode polymer waveguide film with a large bandwidth-length product (BLP) for board-level optical interconnects application. The measured BLP of the multimode waveguide is greater than 57.3 GHz·m at a wavelength of 850 nm under the strictest overfilled launch condition with a maximum length of 2.1 m and 10-dB insertion loss. The fabricated waveguide films are as flexible as regular printing paper and can be conveniently interfaced with standard mechanically transferable (MT) fiber connectors with low loss. The average insertion loss of the connectorized waveguide is about 0.042 dB/cm with inter-channel crosstalk as low as −46.4 dB, and the bending loss is less than 1 dB at a bending radius of 1 mm under the overfilled launch condition. We also demonstrate a vertical-cavity surface-emitting laser (VCSEL)-based single-lane 100 Gbps PAM4 transmission. Our results show that the meter-scale long paper-like polymer waveguide film has both excellent optical properties and large bandwidth and is ideal for high-speed board-level optical interconnects application with a single-lane data rate of 100 Gbps and beyond, especially those that have a strict requirement on the length of connection and compactness. Full article

Many non-destructive optical testing methods are currently used for material research, providing various information about material parameters. At RECENDT, a multimodal experimental setup has been designed that combines terahertz (THz) spectroscopy, optical coherence tomography (OCT), infrared (IR), and Raman spectroscopy with a tensile test stage. This setup aims to gather material information such as crystallinity and optical parameters of high-density polyethylene (HDPE) during a tensile test. The setup compares common IR and Raman spectroscopy and the less common optical methods THz and OCT. Complementarity is achieved through different frequency ranges and measurement approaches, resulting in different measured optical material parameters and depths. During tensile testing, HDPE samples with varying crystallinity were analysed, and the determined optical parameters such as refractive index, birefringence, scattering coefficient of decay, and penetration depth can be correlated with the change in crystallinity. These findings demonstrate that the optical methods and their outcomes can be interconnected. With further optimization of the experimental setup, it would be possible to observe the alignment of fibres in fibre composite panels and the stress distribution of polymers effectively. This opens interesting possibilities for polymer characterization in the future, including quality control during moulding processes and material testing. Full article

Mode-division multiplexing (MDM) is a promising multiplexing technique to further improve the transmission capacity of optical communication and on-chip optical interconnection systems. Furthermore, the multimode optical switch is of great importance in the MDM system, since it makes the MDM system more flexible by directly switching multiple spatial signals simultaneously. In this paper, we proposed a mode-independent optical switch based on the graphene–polymer hybrid waveguide platform that could process the TE₁₁, TE₁₂, TE₂₁ and TE₂₂ modes in a few-mode waveguide. The presented switch is independent of the four guided modes, optimizing the buried position of graphene capacitors in the polymer waveguide to regulate the coplanar interaction between the graphene capacitors and spatial modes. The TE₁₁, TE₁₂, TE₂₁ and TE₂₂ modes can be regulated simultaneously by changing the chemical potential of graphene capacitors in a straight waveguide. Our presented switch can enable the independent management of the spatial modes to be more flexible and efficient and has wide application in the MDM transmission systems. Full article

Mode division multiplexing (MDM) technology is an effective solution for high-capacity optical interconnection, and multimode power splitters, as essential components in MDM systems, have attracted widespread attention. However, supporting a wide range of modes and arbitrary power splitting ratios with large bandwidth in power splitters remains a significant challenge. In this paper, we designed a power splitter based on a subwavelength grating (SWG) structure with tilted placement on a silicon-on-insulator (SOI) substrate. We achieve arbitrary TE₀–TE₉ mode-insensitive power distribution by altering the filling coefficient of the SWG. Thanks to our specific selection of cladding materials and compensatory design for the optical wave transmission and reflection shifts induced by SWG, our device demonstrates low additional loss (EL < 1.1 dB) and inter-mode crosstalk (−18.8 < CT < −60 dB) for optical modes ranging from TE₀ to TE₉, covering a wavelength range from 1200 nm to 1700 nm. Furthermore, our proposed device can be easily extended to higher-order modes with little loss of device performance, offering significant potential in MDM platforms. Full article

We put forward and demonstrate a silicon photonics (SiPh)-based mode division multiplexed (MDM) optical power splitter that supports transverse-electric (TE) single-mode, dual-mode, and triple-mode (i.e., TE₀, TE₁, and TE₂). An optical power splitter is needed for optical signal distribution and routing in optical interconnects. However, a traditional optical splitter only divides the power of the input optical signal. This means the same data information is received at all the output ports of the optical splitter. The powers at different output ports may change depending on the splitting ratio of the optical splitter. The main contributions of our proposed optical splitter are: (i) Different data information is received at different output ports of the optical splitter via the utilization of NOMA. By adjusting the power ratios of different channels in the digital domain (i.e., via software control) at the Tx, different channel data information can be received at different output ports of the splitter. It can increase the flexibility of optical signal distribution and routing. (ii) Besides, the proposed optical splitter can support the fundamental TE₀ mode and the higher modes TE₁, TE₂, etc. Supporting mode-division multiplexing and multi-mode operation are important for future optical interconnects since the number of port counts is limited by the chip size. This can significantly increase the capacity besides wavelength division multiplexing (WDM) and spatial division multiplexing (SDM). The integrated SiPh MDM optical power splitter consists of a mode up-conversion section implemented by asymmetric directional couplers (ADCs) and a Y-branch structure for MDM power distribution. Here, we also propose and discuss the use of the Genetic algorithm (GA) for the MDM optical power splitter parameter optimization. Finally, to provide adjustable data rates at different output ports after the MDM optical power splitter, non-orthogonal multiple access—orthogonal frequency division multiplexing (NOMA-OFDM) is also employed. Experimental results validate that, in three modes (TE₀, TE₁, and TE₂), user-1 and user-2 achieve data rates of (user-1: greater than 22 Gbit/s; user-2: greater than 12 Gbit/s) and (user-1: greater than 12 Gbit/s; user-2: 24 Gbit/s), respectively, at power-ratio (PR) = 2.0 or 3.0. Each channel meets the hard-decision forward-error-correction (HD-FEC, i.e., BER = 3.8 × 10⁻³) threshold. The proposed method allows flexible data rate allocation for multiple users for optical interconnects and system-on-chip networks. Full article

Following Moore’s law, the density of integrated circuits is increasing in all dimensions, for instance, in 3D stacked chip networks. Amongst other electro-optic solutions, multimode optical interconnects on a silicon interposer promise to enable high throughput for modern hardware platforms in a restricted space. Such integrated architectures require confidential communication between multiple chips as a key factor for high-performance infrastructures in the 5G era and beyond. Physical layer security is an approach providing information theoretic security among network participants, exploiting the uniqueness of the data channel. We experimentally project orthogonal and non-orthogonal symbols through 380 $\mathsf{\mu }$m long multimode on-chip interconnects by wavefront shaping. These interconnects are investigated for their uniqueness by repeating these experiments across multiple channels and samples. We show that the detected speckle patterns resulting from modal crosstalk can be recognized by training a deep neural network, which is used to transform these patterns into a corresponding readable output. The results showcase the feasibility of applying physical layer security to multimode interconnects on silicon interposers for confidential optical 3D chip networks. Full article

Optical Wireless Networks on-Chip are an emerging technology recently proposed to improve the interconnection between different processing units in densely integrated computing architectures. In this work, we propose a 4 × 4 optical wireless switch (OWS) based on optical phased arrays (OPAs) for broadband reconfigurable on-chip communication. The OPA and OWS design criteria are reported. Moreover, the performances of the OWS are analyzed and optimized considering the electromagnetic propagation in on-chip multilayer structures, with different thicknesses of the cladding layer. The effect on the OWS behavior of a non-ideal distribution of the power in input to the OPA is also investigated by designing a 1 × 7 beam splitter, based on a single-stage multi-mode interference (MMI) device to be used as a single element of the OWS. Then, the MMI output signals are considered in input to the transmitting OPAs and the OWS performances are evaluated. Full article

Due to the popularity of different high bandwidth applications, it is becoming increasingly difficult to satisfy the huge data capacity requirements, since the traditional electrical interconnects suffer significantly from limited bandwidth and huge power consumption. Silicon photonics (SiPh) is one of the important technologies for increasing interconnect capacity and decreasing power consumption. Mode-division multiplexing (MDM) allows signals to be transmitted simultaneously, at different modes, in a single waveguide. Wavelength-division multiplexing (WDM), non-orthogonal multiple access (NOMA) and orthogonal-frequency-division multiplexing (OFDM) can also be utilized to further increase the optical interconnect capacity. In SiPh integrated circuits, waveguide bends are usually inevitable. However, for an MDM system with a multimode bus waveguide, the modal fields will become asymmetric when the waveguide bend is sharp. This will introduce inter-mode coupling and inter-mode crosstalk. One simple approach to achieve sharp bends in multimode bus waveguide is to use a Euler curve. Although it has been reported in the literature that sharp bends based on a Euler curve allow high performance and low inter-mode crosstalk multimode transmissions, we discover, by simulation and experiment, that the transmission performance between two Euler bends is length dependent, particularly when the bends are sharp. We investigate the length dependency of the straight multimode bus waveguide between two Euler bends. High transmission performance can be achieved by a proper design of the waveguide length, width, and bend radius. By using the optimized MDM bus waveguide length with sharp Euler bends, proof-of-concept NOMA-OFDM experimental transmissions, supporting two MDM modes and two NOMA users, are performed. Full article

Low-power-consumption optical devices are crucial for large-scale photonic integrated circuits (PICs). In this paper, a three-dimensional (3D) polymer variable optical attenuator (VOA) is proposed. For monolithic integration of silica and polymer-based planar lightwave circuits (PLCs), the vertical VOA is inserted between silica-based waveguides. Optical and thermal analyses are performed through the beam propagation method (BPM) and finite-element method (FEM), respectively. A compact size of 3092 μm × 4 μm × 7 μm is achieved with a vertical multimode interference (MMI) structure. The proposed VOA shows an insertion loss (IL) of 0.58 dB and an extinction ratio (ER) of 21.18 dB. Replacing the graphene heater with an aluminum (Al) electrode, the power consumption is decreased from 29.90 mW to 21.25 mW. The rise and fall time are improved to 353.85 μs and 192.87 μs, respectively. The compact and high-performance VOA shows great potential for a variety of applications, including optical communications, integrated optics, and optical interconnections. Full article

Mode-division multiplexing (MDM) can achieve ultra-high data capacity in optical fiber communication. Several impressive works on multicore fiber (MCF), multi-mode fiber, and few-mode multicore fiber have made significant achievements in MDM. However, none of the previous works can simultaneously maintain the transmission loss, chromatic dispersion (CD), and differential group delay (DGD) at a relatively low level. A nested multiple hollow-core anti-resonant fiber (NMH-ARF) has significant potential for applications in MDM. This study proposes a novel NMH-ARF with its structural design based on the traditional single-core nested anti-resonant fiber. We increased the number of nodes between capillaries. By changing the position of the nested tubes, several interconnected areas form when a single core is separated. We investigated the mode-coupling theory and transmission characteristics of this fiber. This fiber structure showed a low sensitivity to bending and achieved a super-low DGD and a super-low confinement loss (CL) at a wavelength of 1.55 µm while keeping CD relatively low. Full article

Optical network-on-chip (ONoC) is based on optical interconnects and optical routers (ORs), which have obvious advantages in bandwidth and power consumption. Transmission capacity is a significant performance in ONoC architecture, which has to be fully considered during the design process. Relying on mode-division multiplexing (MDM) technology, the system capacity of optical interconnection is greatly improved compared to the traditional multiplexing technology. With the explosion in MDM technology, the optical router supporting MDM came into being. In this paper, we design a multimode optical router (MDM-OR) model and analyze its indicators. Above all, we propose a novel multimode switching element and design an N-port universal multimode optical router (MDM-OR) model. Secondly, we analyze the insertion loss model of different optical devices and the crosstalk noise model of N-port MDM-OR. On this basis, a multimode router structure of a single-mode five-port optical router is proposed. At the same time, we analyze the transmission loss, crosstalk noise, signal-to-noise radio (OSNR), and bit error rate (BER) of different input–output pairs by inputting the 1550 nm TE${}_0$, TE${}_1$, and TE${}_2$ modes to the router. Full article
