The variations in the atmospheric refractivity in the lower atmosphere create a natural phenomenon known as atmospheric ducts. The atmospheric ducts allow radio signals to travel long distances. This can adversely affect telecommunication systems, as cells with similar frequencies can interfere with each other due to frequency reuse, which is intended to optimize resource allocation. Thus, the downlink signals of one base station will travel a long distance via the atmospheric duct and interfere with the uplink signals of another base station. This scenario is known as atmospheric duct interference (ADI). ADI could be mitigated using digital signal processing, machine learning, and hybrid approaches. To address this challenge, we explore machine learning and deep learning techniques for ADI prediction and mitigation in Time-Division Long-Term Evolution (TD-LTE) networks. Our results show that the Random Forest algorithm achieves the highest prediction accuracy, while a convolutional neural network demonstrates the best mitigation performance with accuracy. Additionally, we propose optimizing special subframe configurations in TD-LTE networks using machine learning-based methods to effectively reduce ADI. Full article

In this study, a diagnostic model for lower atmospheric ducts was developed using the polar weather research and forecasting model. A five-year simulation was then conducted across the entire Arctic region to investigate the temporal and spatial characteristics of lower atmospheric ducts. The model demonstrated excellent performance in simulating modified atmospheric refractivity, with root mean square errors ranging from 0 M to 5 M. The five-year simulation results revealed that duct occurrence rates across the Arctic region were all below 1% and exhibited a negative relationship with latitude. Regarding the difference between surface ducts and elevated ducts, a higher frequency of surface ducts was detected in the Arctic region. The height and thickness of surface ducts were generally lower than those of elevated ducts, but the strength of surface ducts was slightly greater. Regionally, surface ducts mainly occurred in the land areas surrounding the Arctic Ocean, while more elevated ducts were found in the North Atlantic Sea area. Additionally, a negative correlation was observed between the polar vortex indices and the characteristics of ducts, particularly for surface ducts. The ducts in Greenland were notably influenced by polar vortex activity, whereas the ducts in other regions, such as the Norwegian Sea and Kara Sea, were less affected. Full article

Atmospheric ducts play a critical role in the propagation of electromagnetic waves by minimizing signal loss and extending transmission distances, which is essential for radar, communication, and navigation systems. This study leverages meteorological sounding data and reanalysis data to analyze the distribution of atmospheric ducts in the Bohai Sea and Yellow Sea regions of China. The parabolic equation method was employed to simulate the propagation characteristics of electromagnetic waves in evaporation ducts, surface ducts, and mixed duct environments, focusing on the effects of electromagnetic wave frequency and antenna height. In the Bohai Sea region, the height of evaporation ducts peaks at 13 m in spring and autumn, decreasing to 6 m in winter. In the Yellow Sea region, the height reaches 12 m in autumn and drops to 7 m in summer, indicating a heterogeneous distribution. The monthly mean occurrence rate of atmospheric ducts is defined as the number of atmospheric duct events in a given month divided by the total number of samples for that month. Influenced by the summer and winter monsoons, the occurrence rate of surface ducts is higher from May to September and lower from October to April of the following year. In contrast, elevated ducts reach their peak occurrence rate of 60% in October. In an evaporation duct environment, propagation loss gradually increases with distance, and the loss is more pronounced in non-uniform environments. In surface ducts, propagation loss exhibits periodic fluctuations with distance, exceeding 47 dB. The mixed duct environment integrates the characteristics of both evaporation and surface ducts, effectively filling the shadow zone between 10 m and 70 m. Full article

Air plate solar collectors provide a sustainable and efficient solution for building heating. The absorber plate collects solar radiation and converts it into heat. Atmospheric air is then circulated through the collector plate with perforated baffles by forced convection. The heated air is then directed through ducts into the building’s heating system. By significantly reducing reliance on fossil fuels for building heating, these collectors contribute to a lower life-cycle carbon footprint for buildings compared to conventional heating systems. While flat-plate solar collectors are widely used for renewable energy generation, their efficiency is frequently limited by the airflow path and the heat transfer efficiency within the collector. This study aims to quantify the impact of longitudinal, transverse, and perforated baffles with different hole diameters on the heat transfer characteristics and to identify the optimal design for maximizing thermal efficiency. This study also aims to integrate solar air collector in a conventional building and help reduce the overall energy demand of buildings and their associated carbon emissions. A three-dimensional numerical investigation was carried out on a flat-plate solar collector equipped with perforated transverse baffles with varying hole diameter and thickness. The results from the study predicted that perforated baffles with two holes with a diameter of 15 mm provided a maximum Nu of 79.56 and a pressure drop of 459 Pa for a Re of 8500. Full article

The Coupled Ocean–Atmosphere–Wave–Sediment Transport (COAWST) model serves as the foundation for creating a forecast model to detect lower atmospheric ducts in this study. A set of prediction tests with different forecasting times focusing on the South China Sea domain was conducted to evaluate the short-term forecasting effectiveness of lower atmospheric ducts. The assessment of sounding observation data revealed that the prediction model performed well in predicting the characteristics of all types of ducts. The mean values of the forecasting errors were slightly lower than the reanalysis data but had lower levels of correlation coefficients. At an altitude of about 2000 m, the forecasted error of modified atmospheric refractivity reached peak values and then decreased gradually with increasing altitude. The accuracy of forecasted surface ducts was higher than that of elevated ducts. Noticeable land–sea differences were identified for the spatial distributions of duct characteristics, and the occurrence rates of both the surface and elevated ducts were high at sea. As for the differences among the forecasts of 24, 48, and 72 h ahead, the differences primarily occurred at altitude levels below 20 m and 500 m~1500 m, which are consistent with the differences in the duct height. Full article

Carbon dioxide (CO₂) is a known greenhouse gas and one of the largest contributors to global warming in the Earth’s atmosphere. The remote detection and measurement of CO₂ from industrial emissions are not routinely carried out and are typically calculated from the fuel combusted or measured directly within ducted vents. However, these methods are not applicable for the quantification of fugitive emissions of CO₂. This work presents the results of remote measurement of CO₂ emissions using the differential absorption lidar (DIAL) technique at a wavelength of ~2 µm. The results from the DIAL measurements compare well with simultaneous in-stack measurements, these datasets were plotted against each other and can be described by a linear regression of y (t/h) = 1.04 x − 0.02, suggesting any bias in the DIAL data is likely small. Moreover, using the definition outlined in EN 15267-3 a lower detection limit of 0.12 t/h was estimated for the 2 µm wavelength DIAL data, this is three orders of magnitude lower than the corresponding CO₂ detection limit measured by NPL in the 1.5 µm wavelength region. Thus, this paper demonstrates the feasibility of high-resolution, ground-based DIAL measurements for quantifying industrial CO₂ emissions. Full article

The propagation of electromagnetic waves beyond the line of sight can be caused by atmospheric ducts, which are significant concerns in the fields of radar and communication. This paper utilizes data from seven automatic weather stations and five radio-sounding stations to statistically analyze the characteristics of the atmospheric ducts in the northwest region of the South China Sea (SCS). After verifying the practicality of numerical analysis data from NCEP CFSv2 and ECMWF in studying atmospheric ducts using measured data, we analyzed the spatial–temporal distribution characteristics of the height of the regional evaporation duct and the bottom height of the elevated duct. The study found that the NCEP CFSv2 data accurately capture the evaporation duct height and duct occurrence rate in the study area, and the elevated duct bottom height calculated from ERA5 and the measured data have good consistency. The occurrence rate and height of the evaporation duct in coastal stations in the northwest of the SCS vary significantly by month, demonstrating clear monthly distribution patterns; conversely, changes in the Xisha station are minimal, indicating good temporal uniformity. For lower atmospheric ducts, the difference in occurrence rates between 00:00 and 12:00 (UTC) is negligible. The occurrence probability of elevated ducts in the Beibu Gulf area is relatively high, mainly concentrated from January to April, and the Xisha area is dominated by surface ducts without foundation layers, mainly concentrated from June to August. Monsoons play a critical role in the generation and evolution of atmospheric ducts in the northwest of the SCS, with the height of the evaporation duct increasing and the bottom height of the elevated duct decreasing after the onset of the summer monsoon. In the end, we simulated electromagnetic propagation loss under different frequencies and radiation elevation angles in various duct environments within a typical atmospheric duct structure. Full article

Atmospheric ducts are special super-refractive atmospheric structures that can cause over-the-horizon propagation of electromagnetic waves. Different types of atmospheric ducts have different influences on electromagnetic wave propagation. Owing to the complex marine atmospheric environment, different types of atmospheric ducts often occur together. When evaluating the performance of an electromagnetic system near the sea surface, the combined influence of various atmospheric ducts should be considered comprehensively. In this paper, the statistical distribution of atmospheric ducts over the northern South China Sea is analyzed using sounding data and reanalysis data. This paper uses the parabolic equation model to analyze the propagation characteristics of microwaves near the sea surface in the presence of both surface and evaporation ducts. It is found that compared with cases where only one type of atmospheric duct is considered, a hybrid atmospheric duct structure can capture more microwave energy at a lower receiving height. At an antenna height of 5 m, the path loss begins to fluctuate beyond a propagation distance of 50 km, with the maximum fluctuation reaching about 15 dB. Microwave propagation characteristics at different microwave frequencies and antenna heights are also simulated and analyzed. Full article

A serious problem affecting the local radio industry in Cyprus is radio interference from the Middle East. This problem is especially acute on the highway along the coast during the summer months because interference degrades the sound quality in vehicle receivers due to chirping noise, hissing, fading and distortion. During the last decade the issue was explored by monitoring the field strength intensity of unwanted signals with respect to atmospheric conditions that excacerbate interference. According to the research outcomes presented in this paper, severe interference occurs due to “Tropospheric Ducting”, i.e., radio energy becomes trapped between two boundaries in the lower layers of Earth’s atmosphere. Thereby, this phenomenon acts as a waveguide that favors radio waves to propagate beyond the horizon with very strong field strength intensity where under certain atmospheric conditions exceeding the expected free space theoretical value. Because the commercial Band FM is already oversaturated for years, it was considered important to expand this research to explore the impact of interference on the new digital DAB, DAB+ radio, that will soon be launched in Cyprus, as it is discussed below. Full article

On the basis of 12 years of the European Centre for Mesoscale Weather Forecasts (ECMWF) reanalysis dataset, we statistically analyzed the spatiotemporal distribution of lower atmospheric ducts over the seas around China, and we investigated the possible generation mechanisms. The results show that the ducts’ occurrence had obvious seasonal and regional variations. Ducting events were more likely to occur in spring and summer, and the maximum occurrence rate reached 45.6%, which was closely related to the East Asian monsoon. The ducts’ altitude in continental coastal areas was lower than that far from the coast due to the dominance of surface ducts. The ducts’ thickness varied between 50 m and 450 m, and the thicker ducts were mainly concentrated in the South China Sea and the Pacific Ocean on the east side of the East China Sea near the Philippines and Taiwan. Except for a few areas, the ducts’ intensity was less than 10 M-units (an M-unit is the unit of atmospheric modified refractivity) and the diurnal variations were less pronounced. The duct formation in the lower atmosphere was related to factors such as monsoons, tropical cyclones, ocean currents, radiative cooling, and sea–land breezes. Full article

Since the evaporation duct height (EDH) only covers the antenna height of most shipborne microwave radars, mastering the EDH in advance has great significance in achieving long-range target detection. In this paper, a set of hydrological and meteorological sensors based on the gradient meteorological instrument (GMI) were built to monitor the evaporation duct of the South China Sea (SCS). However, the monitoring needed to be interrupted during the battery replacement of the sensor, which could result in the loss of some important data collection. On the basis of the inductively coupled power transfer (ICPT) technology, the resonance principle was used to compensate the inductive reactance on the closed steel ring (CSR), and the energy stored in the super capacitor was introduced for data collection and return. A novel measuring system for the detection of an evaporation duct was proposed. To avoid iterative calculation by setting the initial value of the current evaporation duct models in large-scale and multi time evaporation duct prediction and diagnosis, on the basis of the non-iterative air–sea flux (NAF) model, the EDH was obtained by introducing the K theoretical flux observation method into the atmospheric refractive index equation. Finally, preliminary experimental results are presented for the detection of evaporation duct to demonstrate the feasibility and effectiveness of the proposed system. The communication accuracy rate of the proposed system was 99.7%. The system transmission power reached 22.8 W. The research results of the NAF model adaptability showed that the mean value of the EDH was 8.7 m, which was lower than the mean EDH of the SCS. The EDH calculated by the NAF model in the unstable air–sea stratification state was slightly lower than that calculated by the NPS model. The diagnosis of the EDH by the NAF model was similar to that of the NPS model, but the calculation stability of the NAF model was better. Full article

The evaporation duct (ED) is generated by the evaporation of seawater and can be an influential factor of electromagnetic (EM)-wave propagation. Rainfall also affects atmospheric factors and EM-wave propagation. However, the distribution of the ED and path loss (PL) during rainfall has rarely been reported. This paper analyzes the distribution of the atmospheric factors and ED in the South China Sea (SCS). The results show that the evaporation duct height (EDH) in the area of rainfall is generally lower. The effect of the ED on the over-the-horizon (OTH) propagation reaches 0.69 dB km⁻¹ on average, which is 4.3 times stronger than the maximum rain attenuation (0.16 dB km⁻¹) when the rainfall is less than 5 mm h⁻¹. In the SCS, a 53 km long OTH link was established between Donghai Island and Jizhao Bay to observe the PL. The measurement results show that the nearly saturated relative humidity (RH) leads to a high PL. The results also show that the change in the direction of the sea–land breeze causes a 42.4 dB decrease of PL by transferring the moist patches. Rainfall has an attenuation effect on OTH propagation in ED, mainly owing to the high RH. Full article

Tropospheric duct is an anomalous atmospheric phenomenon over the sea surface that seriously affects the normal operation and performance evaluation of electromagnetic communication equipment at sea. Therefore, achieving precise sensing of tropospheric duct is of profound significance for the propagation of electromagnetic signals. The approach of inverting atmospheric refractivity from easily measurable radar sea clutter is also known as the refractivity from clutter (RFC) technique. However, inversion precision of the conventional RFC technique is low in the low-altitude evaporation duct environment. Due to the weak attenuation of the over-the-horizon target signal as it passes through the tropospheric duct, its strength is much stronger than that of sea clutter. Therefore, this study proposes a new method for the joint inversion of evaporation duct height (EDH) based on sea clutter and target echo by combining deep learning. By testing the inversion performance and noise immunity of the new joint inversion method, the experimental results show that the mean error RMSE and MAE of the new method proposed in this paper are reduced by 41.2% and 40.3%, respectively, compared with the conventional method in the EDH range from 0 to 40 m. In particular, the RMSE and MAE in the EDH range from 0 to 16.7 m are reduced by 54.2% and 56.4%, respectively, compared with the conventional method. It shows that the target signal is more sensitive to the lower evaporation duct, which obviously enhances the inversion precision of the lower evaporation duct and has effectively improved the weak practicality of the conventional RFC technique. Full article

Since the height of sea detection radar antenna and ship targets is relatively low, it is generally believed that its over-the-horizon detection is mainly caused by the evaporation duct at sea. To fully understand the influence of atmospheric ducts on radar over-the-horizon detection, a shore-based navigation radar was used to carry out over-the-horizon detection experiments; radiosondes were used to measure the atmospheric profile and evaporation duct monitoring equipment was used to measure the evaporation duct. Based on experimental data and model simulation, a comparative analysis of a navigation radar’s over-the-horizon detection, the evaporation duct, and the lower atmospheric duct is presented in this study. The results show that the atmospheric duct can affect the signal propagation of the navigation radar, thus resulting in over-the-horizon detection. The long-range over-the-horizon detection of the navigation radar is caused by the strong lower atmospheric duct, while the evaporation duct can generally only form weak over-the-horizon detection, which is different from the general cognition. Full article

The anomalous propagation conditions, particularly the tropospheric ducts, severely impact the regular operation and performance evaluation of radio devices in the atmospheric boundary layer. Therefore, it is necessary to provide the regional distribution of tropospheric ducts for utilizing or avoiding these abnormal propagation phenomena. As significant uncooperative signal sources, the global navigation satellite systems (GNSS) have been widely applied in the remote sensing of the ocean and atmosphere due to the greater convenience and lower cost. With the completed deployment of the BeiDou Navigation Satellite System (BDS) in 2020, an additional source can be chosen in the relevant studies. Taking the BDS as an example, since the scattered signals from the ocean surface at low satellite elevation angles can be effectively trapped by tropospheric ducts, we propose a method to invert for the regional distribution of tropospheric ducts using the received power of ocean-scattered signals in this paper. Firstly, the propagation model was built to calculate the received power, and a suite of simulations was made in various atmospheric environments. The results suggested that the received power is more sensitive to the surface duct without a base layer. Then, we made a preliminary estimation of the tropospheric ducts on the ocean nearby Qingdao utilizing the Weather Research and Forecasting (WRF) model as well as the echo data measured by a Doppler weather radar. Before the inversion, the actual satellite azimuth and elevation angles should be obtained to evaluate the bistatic scattering coefficients and the received powers of the selected satellite signals. Finally, we presented an inversion example using the proposed method. In absence of the actual measurements, the received powers pre-estimated at different SNRs served as the inputs of the inversion process and the estimated duct parameters were used to verify the validity of the proposed inversion method. For both the received power and modified refractivity profile, the fitness between the values pre-estimated using the estimated duct parameters and calculated by the inverted duct parameters gets better as the elevation angle decreases and the SNR increases. The variation of the fitness between the estimated and inverted values is slightly different for each duct parameter. Moreover, the calculation of inversion errors further explained the above behaviors, including the mean absolute error (MAE) and the root mean square error (RMSE). Despite some certain errors, the inversion results maintain the overall tendencies and most characteristics of the estimated values, thus proving the validity of the inversion method. Full article
