Wireless power transfer (WPT), characterized by its excellent insulation properties and ease of maintenance, has recently emerged as a promising solution to the power supply challenges faced by online monitoring equipment on high-voltage transmission towers in complex environments. Existing research primarily relies on regular, closely wound solenoids to power these monitoring devices; however, this approach often makes it difficult to optimize the magnetic field distribution to maximize mutual inductance, thereby limiting transmission efficiency and power and hindering lightweight design. To address these issues, this paper proposes an optimized design scheme for variable-pitch (non-uniform) domino WPT coils based on insulator string structures. First, a parameter calculation model utilizing segmented current analysis is constructed to accurately determine the inductance of non-uniform solenoids, with simulations confirming an error rate below 5%. Subsequently, by integrating domino multi-coil theory into an elitist non-dominated sorting genetic algorithm (NSGA-II), dual-objective optimization is performed. Targeting maximum transmission efficiency and output power under spatial and insulation constraints, a set of Pareto optimal solutions is derived. Ultimately, a 113.7 W insulator domino coil WPT system prototype is constructed to validate the design’s stability. The proposed system achieves a maximum efficiency of 85.73%, with a single-stage load delivering up to 97.48 W. Full article

This paper presents the design and validation of a compact high-performance electromagnetic contactor for high-current direct current (DC) applications in harsh environments, with particular focus on cold cranking of heavy-duty vehicles. Cold cranking imposes stringent requirements due to elevated current demand, reduced battery capability, and tight actuation timing constraints. To address these challenges, a systematic design methodology is used, combining analytical magnetic circuit modelling, finite element analysis (FEA), and experimental validation. The study investigates key design aspects, including magnetic core selection, coil sizing, and contact geometry, under strict dimensional and thermal constraints. An analytical model is first used to predict electromagnetic force and current dynamics, and is subsequently validated using FEA. A prototype contactor is then constructed and experimentally tested to verify the predicted performance. Results show strong agreement between analytical, numerical, and experimental approaches, with force prediction errors below 10% across the operating range. The findings confirm the suitability of simplified analytical models for initial design stages and highlight the impact of material selection and inductance on actuation speed. The proposed workflow provides practical design guidelines for developing compact, efficient, and reliable contactors for high-current automotive applications operating under extreme conditions. Full article

With the increasing demand for higher efficiency and power density, innovative winding techniques have become crucial in modern electric machines. Hairpin windings are increasingly used in electric machines, particularly in high-current applications. A novel analytical model is proposed to estimate slot leakage inductance in hairpin windings. Traditional models are limited to random windings, which fail to capture the complex mutual inductance between multiple coil layers. This paper derives a generalized model to estimate specific permeance and total mutual specific permeance for the hairpin windings, which are key factors in determining slot leakage inductance. The proposed model is also valid for fractional-pitch windings. The derived analytical model is validated through finite element analysis (FEA) on an electric motor similar to that employed in Tesla Model S. In addition, experimental validation is performed to further validate the proposed model. Furthermore, parametric analysis is conducted to analyze the influence of slot geometry and conductor dimensions on the slot leakage inductance. This paper contributes an accurate method for predicting slot leakage inductance in hairpin windings; this provides electrical machine designers with a valuable tool for precise modeling and optimization for improved efficiency and performance in various applications. Full article

To address dependence on external power and the limited capability of conventional hydroelectric units to detect low-amplitude vibrations, this work introduces a self-contained, highly accurate monitoring device. The design incorporates a magnetically levitated configuration, with triboelectric films placed on both the upper and lower faces of the floating magnet. Under minor oscillations, magnetic repulsion increases the relative displacement between the friction layers, producing a substantial voltage that permits low-level vibration sensing. A surrounding induction coil responds to the levitated pole’s vertical motion; this motion intersects the magnetic flux, generating a current that provides stable energy for wireless data transmission. Experimental outcomes confirm a detection limit of 0.1 mm. At an amplitude of 1 mm and a load of 1000 Ω, the system achieves a maximum output of 9 mW and a power density of 1.587 W/m², ensuring reliable power. This configuration provides a new pathway for monitoring vibrations in hydroelectric turbine generators. Full article

To address the severe shielding of conventional electromagnetic signals by metallic pipelines and the inherent design trade-off under fixed-voltage excitation, whereby increasing coil size suppresses current and limits magnetic field intensity, this study proposes an independently parallel-fed multistage coil enhancement scheme for the transmitter of through-wall magnetic induction communication. Based on electromagnetic theory and COMSOL6.3 simulations, a coupled analysis framework for multistage coils was established to systematically evaluate the effects of axial partitioning, radial partitioning, nonuniform turn allocation, and magnetic-core loading on branch-current amplitude and phase consistency as well as spatial magnetic field intensity. The results show that, under in-phase, equal-frequency excitation, the resultant magnetic field intensity increases approximately linearly with the number of partitions. The partition scheme significantly alters the mutual inductance distribution among sub-coils, thereby affecting current synchronization and magnetic field synthesis efficiency. The introduction of a high-permeability magnetic core markedly improves the amplitude and phase consistency of the radially partitioned structure and enhances output stability. Considering magnetic field output, current synchronization, and engineering feasibility, the axial–radial hybrid four-partition structure with a magnetic core was identified as the preferred configuration. These findings provide a theoretical basis and structural guidance for transmitter design in low-frequency through-wall magnetic induction communication under metallic shielding conditions. Full article

This work presents wirelessly interrogated microelectromechanical system (MEMS) capacitive sensors for continuous intraocular pressure (IOP) monitoring. The sensor uses a passive inductor–capacitor (LC) tank circuit comprising a fixed, on-chip spiral inductor and a pressure-sensitive, variable-gap capacitor with parallel-plate membrane electrodes and side anchors. The membrane is designed with dimensions of 500 µm × 500 µm × 2 µm and a capacitive transducer gap of 2.5 µm. Applied pressure deflects the top membrane, producing a corresponding capacitance variation that changes the frequency and phase response of the LC tank circuit, enabling real-time and continuous IOP monitoring over a target detection range of 0–50 mmHg and beyond. Mutual inductive coupling between the sensor and the external readout coil is investigated as a reliable readout mechanism. Full article

To address the issue of traditional bistable vibration energy harvesters (BVEHs) being prone to becoming trapped in a single potential well—which results in a narrowed energy harvesting bandwidth and reduced efficiency—this paper proposes a method that utilizes the nonlinear electromagnetic force generated during the induction process to modulate the kinematic behavior of the oscillator. The characteristics and influencing factors of the nonlinear force produced during electromagnetic induction are analyzed. A dual-cantilever beam structure is designed, with an iron-core coil and a magnet placed at the respective free ends. A mathematical model of a piezoelectric–electromagnetic coupled bimodal broadband vibration energy harvester is established and numerically simulated. Furthermore, a vertical vibration experimental platform is constructed to conduct frequency sweep tests. The experimental results demonstrate that the proposed piezoelectric–electromagnetic coupled bimodal broadband vibration energy harvester effectively improves energy harvesting efficiency. Within the frequency range of 5–20 Hz, the system exhibits two vibration modes, with resonant frequencies of approximately 7.7 Hz and 15.7 Hz. For a single-layer PVDF piezoelectric film, the maximum output power at the first and second resonance points is 8.9 μW and 9.7 μW, respectively. The electromagnetic module achieves maximum output powers of 0.39 W and 0.71 W. Moreover, within the frequency ranges of 6.3–9.8 Hz and 14–17.7 Hz (a total bandwidth of 7.2 Hz), the device maintains a stable power output. The effective bandwidth is broadened by approximately 80%, demonstrating excellent broadband performance. Full article

Accurate measurement of spool displacement is essential for achieving high-performance closed-loop control and condition monitoring in hydraulic systems. However, conventional inductive displacement transducers typically rely on sinusoidal excitation and complex analog signal conditioning circuits, resulting in higher hardware cost and limited system integration. To address these issues, this paper proposes a software-based demodulation method for a differential inductive displacement transducer under symmetric complementary square-wave excitation. First, the structure and operating principle of the transducer are analyzed, and an electromagnetic model describing the nonlinear relationship between coil inductance and the position of the inductive core is established, along with its electrical characteristics. Then, a simplified signal acquisition circuit is designed to enable digital extraction of inductance variations using a microprocessor. Compared with conventional approaches, the proposed scheme significantly reduces hardware complexity and cost while being more suitable for embedded system integration. A simulation model is developed to analyze the inductance variation and to validate the proposed hardware circuit. In addition, a test platform is built to conduct static calibration and dynamic response experiments. The experimental results show that the proposed method achieves a linearity of 2.36% and a sensitivity of 155.6 mV/mm and exhibits strong robustness against switching noise. Finally, application tests in a hydraulic valve system demonstrate that the proposed transducer and demodulation method enable accurate and stable spool position measurement, providing a low-cost and easily integrated solution for embedded hydraulic control systems. Full article

This paper presents the design, prototype realization, and experimental validation of an inductive wireless power transfer (WPT) platform for static charging of electric vehicles. The study integrates magnetic-coupler design, resonant power-stage realization, and occupied-area magnetic-field assessment within a prototype-oriented engineering framework. The realized Tx/Rx magnetic assembly has dimensions of approximately 700 × 800 × 60 mm per coil, an inductance of about 60 μH, a coupling factor of about 0.45, and estimated coil losses of around 2%. The proposed system belongs to the 35 kW class, while the realized prototype was experimentally validated at a nominal 30 kW operating level, with peak capability up to 45 kW for 1 min. Experimental evaluation was carried out for air gaps up to about 100 mm, with measured transfer efficiency in the range 80–92% and favorable operation around 30 kW and a vertical air gap of approximately 70 mm. Representative occupied-area magnetic-flux-density measurements remained below the adopted 27 μT reference level under the reported operating conditions. The results confirm the practical feasibility of the proposed static EV charging platform and support its engineering relevance for high-power inductive charging applications. Possible extension toward on-route charging is discussed only as future work. Full article

Triaxial induction logging is particularly outstanding in identifying reservoir parameters including anisotropic strata, inclined boreholes and horizontal wells. However, the coplanar systems follow the traditional induction method of using a shielding coil to offset the direct coupling. This method results in severe horns in the coplanar coil response, which makes it more difficult to evaluate the water (oil) saturation of the reservoir. In this study, we used an analytic method to derive the magnetic field in a finite-thickness anisotropic medium by applying tangential continuity of the electric and magnetic field strengths, introducing the magnetic vector potential and Bessel functions. The response model influenced by different parameters was established. Under the same environmental parameters, the measurement range of the vertical and horizontal conductivities was larger than that of the traditional coplanar system. The apparent conductivity of the target layer was closer to the true value of the vertical conductivity in the layered strata, with an accuracy improvement of 78.9%. Furthermore, the improved coplanar system mechanism was revealed by analyzing the spatial distributions of eddy currents and the magnitudes of the magnetic fields generated. Finally, we designed an experimental device for a coplanar sensing system. Under the same parameters, the received signals of the improved coplanar system were greater than those of the traditional coplanar system in the air, which laid a foundation for the quantitative evaluation of stratigraphic anisotropy response characterization and inversion. Full article

Search coil magnetometers (SCMs) are widely used in space science missions to measure time-varying magnetic fields. However, conventional SCM designs often increase sensor mass and electronic power consumption in order to meet mission-specific sensitivity requirements. This study presents the design and ground-based test results of a space search coil magnetometer (SSCM) concept aimed at reducing sensor mass and electronic power consumption while maintaining practical system operability for platform-constrained missions. Mass reduction was achieved by adopting a rolling-sheet core configuration. In addition, printed circuit board (PCB)-based interconnections between segmented windings were implemented to improve the reproducibility of assembly and mechanical robustness without additional structural complexity. Power reduction was achieved by employing an application-specific integrated circuit (ASIC)-based sensor amplifier and a compact control electronic unit implemented as a modular stack with a 1U CubeSat standard board form factor. Performance tests confirmed the stable operation of the integrated sensor–electronics chain over the target measurement band. The system-level noise-equivalent magnetic induction (NEMI) measured under laboratory conditions was 33 fT/√Hz at 1 kHz. Environmental tests including vibration and thermal cycling were performed to further verify the structural safety and functional stability of the sensor assembly under space-relevant conditions. The proposed SSCM architecture provides a practical approach for implementing low-mass and low-power magnetic field instruments for platform-constrained space missions. Full article

The widespread commercialization of wireless chargers for electric vehicles generally suffers from one main problem, which is the perfect alignment between the two coils, leading to a decrease in mutual inductance, which causes a drop in magnetic coupling and even a failure to transfer power. To address this persistent problem, this work proposes a comprehensive and integrated method for optimizing the coils and control architecture for reliable and safe battery charging. To address the challenges of a complex, nonlinear design space and the need for misalignment-tolerant geometries, we employ a memetic algorithm (MA) that hybridizes Particle Swarm Optimization (PSO) for broad global exploration with Mesh Adaptive Direct Search (MADS) for precise local refinement. This combination effectively avoids poor local solutions—a limitation of standalone PSO or GA approaches reported in recent studies—while efficiently converging to coil geometries that maintain strong magnetic coupling under misalignment. After the coils have been designed, electromagnetic validation is tested using finite element analysis (FEA), which allows the magnetic field distribution to be evaluated, as well as the coupling coefficient under different scenarios of misalignment and variation in the air gap between the ground side and the vehicle side. At the same time, a comprehensive control strategy for the primary side of the system has been developed. This control method ensures power management on the primary side, enabling system interoperability for charging multiple types of vehicles, as well as reducing vehicle weight for greater range. All this is combined with an innovative pulsed current charging method, chosen for its advantages in terms of thermal stability, ensuring safe and efficient recharging that is mindful of battery health. Simulation and experimental validation demonstrate that the proposed framework maintains stable wireless power transfer and achieves over 87% DC–DC efficiency under lateral misalignments up to 100 mm, fully complying with SAE J2954 alignment tolerance requirements. Full article

This work investigates the geometric design and optimisation of a dynamic inductive power transfer coupler for two-wheeled electric vehicles under misalignment and magnetic-field exposure constraints. A computational three-dimensional finite-element model of a shielded rectangular coupler is developed to characterise coupling coefficients and magnetic flux density levels on control planes along the longitudinal travel range and under lateral and angular misalignments. Two simulation datasets are generated: one varying only geometric parameters at a nominal position for surrogate construction and global sensitivity analysis, and a second jointly sampling geometry, the travel range and misalignments for optimisation. Sparse Polynomial Chaos Expansions and Canonical Low-Rank Approximation surrogates are built to quantify Sobol’ indices, revealing that a small subset of primary-side geometric variables dominates both coupling efficiency and magnetic field levels. Random forest regressors are then trained on the extended dataset and embedded in the Non-dominated Sorting Genetic Algorithm II to solve a multi-objective optimisation problem that maximises worst-case coupling, improves robustness to misalignment, and enforces magnetic-field leakage limits. Optimal designs were obtained, and a subset was selected for re-evaluation using the finite-element method. The results confirm that the proposed surrogate-assisted framework yields coupler geometries with enhanced coupling and reduced magnetic field leakage while respecting the mechanical constraints for the electric motorcycle system. Full article

To meet the power supply requirements of autonomous underwater vehicles (AUVs) in dynamic ocean environments, this study proposes a wireless power transfer (WPT) system for AUVs, incorporating novel nanocrystalline flake ribbon cores. The proposed system utilizes the excellent magnetic field concentrating and shielding characteristics of nanocrystalline materials. The flake ribbons are fabricated by compressing dielectric materials mixed with nanocrystalline ribbons, which effectively reduces eddy-current loss. The layout arrangement of nanocrystalline materials is investigated, and a magnetic coupler employing ribbon-type nanocrystalline materials is adopted based on simulation analysis and comparison. The influence of nanocrystalline materials on the mutual inductance distribution between the transmitting and receiving coils is explored. Considering the potential positional misalignments between the transmitting and receiving coils in practical marine environments, the misalignment tolerance of the system is comprehensively analyzed and experimentally verified. An experimental prototype is established, and the results demonstrate that the proposed magnetic coupler design significantly improves the performance of the WPT system. Compared with the conventional WPT system without nanocrystalline flake ribbon cores, the proposed design effectively increases the power transfer efficiency by 2.99% and greatly stabilizes the output power by 36%. This study validates the effectiveness and practicability of using nanocrystalline flake ribbon cores in WPT systems for AUV applications. Full article

Dynamic wireless power transfer (DWPT) systems for in-motion electric vehicle (EV) charging often suffer from unstable power delivery due to spatial variations in magnetic coupling caused by vehicle misalignment. This study presents a stabilization-oriented DWPT design methodology that prioritizes minimizing spatial variations of mutual inductance rather than maximizing peak coupling under perfect alignment. A ferrite-backed double-D coil configuration is analyzed and refined using three-dimensional finite-element electromagnetic modeling integrated with circuit-level co-simulation to evaluate coupling behavior, magnetic field homogeneity, and power transfer efficiency under realistic dynamic misalignment conditions. The proposed design achieves a coupling coefficient of 0.50–0.55 under aligned conditions and exhibits smooth, predictable degradation for lateral offsets up to 40–50 mm. Quantitative analysis demonstrates a low spatial coupling gradient of approximately 0.001 mm⁻¹, indicating that abrupt coupling transitions are effectively suppressed during vehicle motion. The system attains a maximum power transfer efficiency of 84.37% at an 80 mm air gap, while maintaining stable performance under both lateral and vertical displacement. Comparative evaluation shows improved misalignment tolerance and coupling stability relative to conventional double-D configurations. The results demonstrate that electromagnetic field shaping focused on coupling smoothness is an effective and practical strategy for reliable dynamic wireless charging of electric vehicles. Full article
