Search Results (97)

The article presents a comprehensive review of key issues and challenges related to enhancing the durability of hot forging tools. It discusses modern strategies aimed at increasing tool life, including modifications to tool materials, heat treatment, surface engineering, tool and die design, die geometry, tribological conditions, and lubrication. The review is based on extensive literature data, including recent publications and the authors’ own research, which has been implemented under industrial conditions at the modern forging facility in Forge Plant “Glinik” (Poland). The study introduces original design and technological solutions, such as an innovative concept for manufacturing forging dies from alloy structural steels with welded impressions, replacing traditional hot-work tool steel dies. It also proposes a zonal hardfacing approach, which involves applying welds with different chemical compositions to specific surface zones of the die impressions, selected according to the dominant wear mechanisms in each zone. General guidelines for selecting hardfacing material compositions are also provided. Additionally, the article presents technological processes for die production and regeneration. The importance and application of computer simulations of forging processes are emphasized, particularly in predicting wear mechanisms and intensity, as well as in optimizing tool and forging geometry. Full article

H13 steel, a widely used material in hot work tooling, faces premature failure due to insufficient hardness and wear resistance. To address this limitation, Mo₂FeB₂ cermet coatings were fabricated on H13 alloy steel via plasma spray welding, and subsequently quenched at 850 °C, 1000 °C, and 1150 °C. The effects of the quenching temperature on the microstructure and wear resistance were investigated using optical microscopy (OM) for cross-sectional morphology, scanning electron microscopy (SEM) for microstructural and wear surface analyses, energy-dispersive spectroscopy (EDS) for elemental composition analysis, and X-ray diffraction (XRD) for phase identification. The coating primarily consisted of α-Fe, Mo₂FeB₂, (Mo,Fe,Cr)₃B₂, and Fe₂₃(B,C)₆ phases. Increasing the temperature to 1150 °C increased the Mo₂FeB₂ hard phase and elevated microhardness by 32.04% (from 827 HV_0.5 to 1092 HV_0.5). Wear resistance improved by 46.38% (mass loss reduced from 6.9 mg to 3.7 mg). The main wear mechanism was identified as abrasive wear due to the spalling of hard phase particles. These results demonstrate that optimizing quenching temperature enhances the hardness and wear resistance in Mo₂FeB₂ coatings, offering a viable strategy to extend H13 steel service life in high-temperature industrial applications. Full article

Roll wear significantly affects production efficiency and product quality in hot-rolled strip steel manufacturing by reducing roll lifespan and impeding the control of strip shape. This study addresses these challenges through a comprehensive analysis of the roll wear mechanism and the integration of an elastic deformation model. We propose an optimized wear prediction model for work and backup rolls in a hot continuous rolling finishing mill, dynamically accounting for variations in strip specifications and cumulative wear effects. A three-dimensional elastic–plastic thermo-mechanical coupled finite element model was established using MARC 2020 software, with experimental calibration of wear coefficients under specific production conditions. The developed dynamic simulation software achieved high-precision wear prediction, validated by field measurements. The optimized model reduced prediction deviations for work and backup rolls to 0.012 and 0.004, respectively, improving accuracy by 5.3% and 3.25% for uniform and mixed strip specifications. This research provides a robust theoretical framework and practical tool for precision roll wear management in industrial hot rolling processes. Full article

In this work, measurements of the thermal diffusivity and thermal expansion of hot-working tool steel WLV (1.2365) were carried out in the temperature range from (−)50 °C to 500 °C. The results of these measurements were compared with those published earlier by the authors for other selected hot-working tool steels, i.e., 38HMJ (1.8509) and WCL (1.2342), in the temperature range from (−)50 °C to 500 °C and from room temperature (RT) to 1100 °C. This paper describes the procedures used to relate the thermal characteristics of the thermal diffusivity and thermal expansion obtained at low temperatures to those obtained at high temperatures. Thermal diffusivity and thermal expansion of WLV, 38HMJ and WCL steels in the temperature range from (−)50 °C to 1100 °C were used as input data for numerical simulations of heat transfer in devices made of these steels and operating in a wide temperature range. Thermophysical properties were tested using specialized NETZSCH test stands. Thermal diffusivity was studied using a LFA 467 light flash apparatus in the temperature range from (−)50 °C to 500 °C and a LFA 427 laser flash apparatus in the temperature range from RT to 1100 °C. Thermal expansion was tested using a DIL 402 Expedis dilatometer in the range from (−)50 °C to 500 °C and a DIL 402 C dilatometer in the temperature range from RT to 1100 °C. Finally, the results of tests on thermophysical properties of selected steels in the temperature range from (−)50 °C to 1100 °C were summarized. Full article

A growing need to reduce the environmental impact and cost of manufacturing stainless steels has led to the development of ferritic stainless steel as an alternative to austenitic and duplex steels. The development of new stainless steels involves the optimization of their hot rolling processes, with the aim of minimizing the occurrence of defects and improving productivity. In this context, numerical simulation using the finite element method (FEM) is presented as a key tool to reduce the time and cost associated with traditional trial-and-error optimization methods. Previous work oriented towards the simulation of stainless steels has been focused on the study of small samples, on the performance of laboratory-scale tests, and on the use of 2D FEM models. In this study, a three-dimensional FEM model is proposed to simulate the hot rolling process of large-scale AISI 430 ferritic stainless-steel slabs using an industrial rolling schedule employed in the actual manufacturing process of flat products. Model optimization is performed in order to reduce the computational cost of the simulations, based on the simulation of the first pass of the hot rolling process of AISI 430 stainless steel. The results show that model optimization reduces the computational time by 90.2% without compromising the accuracy of the results. Thus, it was found that the results for thickness and rolling load showed a good correlation with the experimental values. In addition, the simulations performed allowed for the analysis of the distribution of temperature and effective plastic strain. Full article

This paper provides a detailed analysis of the operation of representative forging tools (in the context of using various surface engineering techniques) used in the process of the hot forging of nickel–chromium steel elements. The influence of the microstructure and hardness of the material on the durability of the tools is also discussed, which is important for understanding the mechanisms of their wear. The research showed that the standard tools used in the process (only after nitriding) as a reference point worked for the shortest period, making an average of about 1400 forgings. In turn, the tools coated with the CrAlSiN coating allowed for the production of the largest number of forgings, reaching 2400 pieces, with uniform wear. In comparison, the tools with the CrAlBN coating made 1900 forgings. Three-dimensional scanning analysis showed that CrAlSiN- and CrAlBN-coated tools have lower volumetric wear, around 41–43 mm³, compared to 59 mm³ for nitrided tools. For a better comparison of tool life, the authors proposed the Z-factor, as the material loss to the number of forgings. The CrAlSiN coating showed the lowest material loss, despite a slightly higher Z-factor value compared to the CrAlBN coating. The use of hybrid coatings such as CrAlSiN and CrAlBN significantly reduces tool wear while increasing service life compared to tools that are nitrided only. Full article

The impact of manufacturing strategies on the development of residual stresses in Dievar steel is presented. Two fabrication methods were investigated: conventional ingot casting and selective laser melting as an additive manufacturing process. Subsequently, plastic deformation in the form of hot rotary swaging at 900 °C was applied. Residual stresses were measured using neutron diffraction. Microstructural and phase analysis, precipitate characterization, and hardness measurement—carried out to complement the investigation—showed the microstructure improvement by rotary swaging. The study reveals that the manufacturing method has a significant effect on the distribution of residual stresses in the bars. The results showed that conventional ingot casting resulted in low levels of residual stresses (up to ±200 MPa), with an increase in hardness after rotary swaging from 172 HV1 to 613 HV1. SLM-manufactured bars developed tensile hoop and axial residual stresses in the vicinity of the surface and large compressive axial stresses (−600 MPa) in the core due to rapid cooling. The subsequent thermomechanical treatment via rotary swaging effectively reduced both the surface tensile (to approximately +200 MPa) and the core compressive residual stresses (to −300 MPa). Moreover, it resulted in a predominantly hydrostatic stress character and a reduction in von Mises stresses, offering relatively favorable residual stress characteristics and, therefore, a reduction in the risk of material failure. In addition to the significantly improved stress profile, rotary swaging contributed to a fine grain (3–5 µm instead of 10–15 µm for the conventional sample) and increased the hardness of the SLM samples from 560 HV1 to 606 HV1. These insights confirm the utility of rotary swaging as a post-processing technique that not only reduces residual stresses but also improves the microstructural and mechanical properties of additively manufactured components. Full article

In this study, in order to improve the characteristics of the vegetable-based cutting fluids used in the MQL technique and increase the machining performance of MQL and its positive effects on sustainable manufacturing, the effects of the MQL method with nano-Al₂O₃ additives on surface roughness (Ra) and cutting temperature (Ctt) were examined through turning experiments carried out by adding nano-Al₂O₃ to the vegetable-based cutting fluid. For this purpose, machining tests were carried out on hot work tool steel alloyed with Cr-Ni-Mo that has a delivery hardness of 45 HRC. In hard machining experiments, three techniques for cooling and lubricating (dry cutting, MQL, and nano-MQL), three cutting speeds (V) (100, 130, 160 m/min), three feed rates (f) (0.10, 0.125, and 0.15 mm/rev), and two different ceramic cutting tools (uncoated and TiN-coated with PVD methods) were used as control factors. For Ra, the nano-MQL method provided an average of 21.49% improvement compared to other cooling methods. For Ctt, this rate increased to 26.7%. In crater wear areas, the nano-MQL method again exhibited the lowest wear values, decreasing performance by approximately 50%. The results of this research showed that the tests conducted using the cooling of nano-MQL approach produced the best results for all output metrics (Ra, Ctt, and crater wear). Full article

The article presents the classification of the wear mechanisms of forging tools. The durability of dies can be enhanced through a variety of methods, including the selection of appropriate hot working tool steel, the application of effective heat treatment, the utilization of advanced surface engineering techniques, and the incorporation of lubricating and cooling agents. Two popular methods of tool regeneration, such as re-profiling and laser regeneration, are presented. The issue of numerical wear prediction based on the Archard model, the correlation of this model with experimental results, low-cycle fatigue (HTLCF), and an alternative method based on artificial neural networks are discussed. The paper aims to present currently known wear mechanisms and the methods of increasing and predicting tool durability. Full article

Additive manufacturing techniques employing laser-based metal melting have garnered significant attention within the scientific community. Despite a decade of comprehensive research on the fundamentals of these techniques, there still remain unexplored facets related to heat flux impact on metallic alloys’ properties. Particularly, the effects of point-by-point laser operation on melt pool formation in metallic materials still remain unclear. Thus, this study focuses on the implications of laser metal melting, particularly investigating a point-by-point laser mode operation’s influence on melt pool formation and its geometry in the phase-transformation-sensitive material H11 hot work tool steel. To examine the melt pool, singular laser tracks with various laser parameters were scanned across H11 sheet metal, which allowed for the elimination of layer-by-layer heat cycles’ influence on the melt pool’s microstructure. Samples were examined by means of metallography, revealing significant differences in the melt pool’s depth, influenced mostly by exposure time rather than volumetric energy density. Heat-affected zone effects were found to have a limited range and thus potentially marginal effects in layer-by-layer manufacturing conditions. At the same time, retained austenite concentrations near fusion lines have been found within melt pools, suggesting potential micro-segregation of the alloying additions. The results present guidelines towards laser melting processes optimization. Full article

In order to prepare coating with good friction and wear resistance at elevated temperature on the surface of hot-working tool steel, by using a CO₂ laser, FeCrNiTiZr high-entropy alloy coating with different laser scanning speeds (360, 480 and 600 mm/min, respectively) was successfully fabricated by using laser cladding technology on the surface of H13 steel in this paper. Phase constitutions, microhardness, microstructure, and wear characteristics of FeCrNiTiZr coatings under different laser scanning speeds were analyzed. It was determined that 480 mm/min was the optimal laser scanning speed. The results showed that the coating at the scanning speed of 480 mm/min consists of a BCC phase with significant lattice distortion and high dislocation density; the crystal structure is cellular crystal and dendrite crystal. The coating demonstrates the highest microhardness (842 HV_0.2), which is 4.2 times that of the substrate (200 HV_0.2). Its average friction coefficients at room temperature and 823 K are approximately one-seventh and one-third of the substrate’s, respectively, and its wear volume is reduced by about 98% and 81% under these conditions. Compared to the substrate, the coating underwent slight abrasive wear, adhesive wear, and oxidative wear at both room temperature and 823 K. In contrast, the substrate underwent severe abrasive wear, adhesive wear, oxidative wear, and even fatigue wear. Full article

Vanadis 4E (V4E) is a powder metallurgical cold work tool steel predominantly used in application with demand for wear resistance, high hardness, and toughness. It is of interest to have a processing route that enables full density starting from clean gas-atomized powder allowing component shaping capabilities. This study presents a process involving freeze granulation of powder to facilitate compaction by means of cold isostatic pressing, followed by sintering to allow for capsule-free hot isostatic pressing (HIP) and subsequent heat treatments of fully densified specimens. The sintering stage has been studied in particular, and it is shown how sintering in pure nitrogen at 1150 °C results in predominantly closed porosity, while sintering at 1200 °C gives near full density. Microstructural investigation shows that vanadium-rich carbonitride (MX) is formed as a result of the nitrogen uptake during sintering, with coarser appearance for the higher temperature. Nearly complete densification, approximately 7.80 ± 0.01 g/cm³, was achieved after sintering at 1200 °C, and after sintering at 1150 °C, followed by capsule-free HIP, hardening, and tempering. Irrespective of processing once the MX is formed, the nitrogen is locked into this phase and the austenite is stabilised, which means any tempering tends to result in a mixture of austenite and tempered martensite, the former being predominate during the sequential tempering, whereas martensite formation during cooling from austenitization temperatures becomes limited. Full article

Diamond-like carbon (DLC) coatings enhance tool wear resistance across various temperatures. The sp³/sp² bond ratio within DLC significantly impacts its properties and thermal stability. Elevated temperatures can alter DLC’s structure, while metallic elements and interlayers like chromium can modify its microstructure and performance. To evaluate the potential of W-DLC coatings with a chromium interlayer on 40CrMoV5-1 hot work tool steel under elevated temperatures, mechanical and tribological properties were assessed at room temperature and at temperatures of 100, 200, 300, 400, and 500 °C. Nanoindentation revealed a maximum hardness of 14.1 ± 1.3 GPa for the coating deposited at room temperature, attributed to a high sp³ content confirmed by Raman spectroscopy. Hardness decreased to 9.3 ± 1.0 GPa at 400 °C due to graphitization. The elastic modulus remained relatively constant across all temperatures. Tribological tests indicated a low coefficient of friction (CoF) of 0.15 at room temperature, increasing to 0.35 at 100 °C. The CoF further rose to 0.5 at 200 °C, coinciding with increased graphitization. However, the CoF reduced to 0.45 and 0.35 at 400 °C and 500 °C, respectively, likely due to the formation of a WO₃ tribo-film and the protective effect of the chromium interlayer. Full article

Nowadays, H13 hot work steel is a commonly used hot work die material in the industry; however, its creep behavior for additively manufactured H13 steel parts has not been widely investigated. This research paper examines the impact of volumetric energy density (VED), a critical parameter in additive manufacturing (AM), and the effect of post heat-treatment nitrification on the creep behavior of H13 hot work tool steel, which is constructed through selective laser melting (SLM), which is a powder bed fusion process according to ISO/ASTM 52900:2021. The study utilizes nanoindentation tests to investigate the creep response and the associated parameters such as the steady-state creep strain rate. Measurements and observations taken during the holding phase offer a valuable understanding of the behavior of the studied material. The findings of this study highlight a substantial influence of both VED and nitrification on several factors including hardness, modulus of elasticity, indentation depth, and creep displacement. Interestingly, the creep strain rate appears to be largely unaltered by these parameters. The study concludes with the observation that the creep stress exponent (n) shows a decreasing trend with an increase in VED and the application of nitrification treatment. Full article

The article discusses the phenomena and destructive mechanisms occurring on the surface of 1.2344 steel dies used during the hot forging of disc-type forgings. Preliminary research has shown that gas nitriding alone, used so far, is insufficient due to the occurrence of destructive mechanisms other than abrasive wear, such as thermal and thermomechanical fatigue, which cause the average durability of such tools to be approximately 5000 forgings. Analyses were also carried out to assess the load on forging tools using numerical modeling (Forge 3.0NxT), which confirmed the occurrence of large and cyclically changing thermal and mechanical loads during the forging process. Therefore, in order to increase operational durability, it was decided to use two types of hybrid layers, differing in the PVD coating used: TiCrAlN and CrN, and then subjected to gas nitriding (GN). The obtained results showed that, depending on the area of the tool and the current working conditions, the applied PVD coatings protect the surface layer of the tool against the dominant destructive mechanisms. In both cases, the strength increased to the level of 7000 forgings, the tools could continue to work, and globally, slightly better results were obtained for the GN+TiCrAlN layer. The CrN-type layer protects the tool more against thermal fatigue, while the TiCrAlN layer is more resistant to abrasive wear. In areas where the hybrid layer was worn, a decrease in hardness was observed from 1300 HV to 600–700 HV, and in places of intense material flow (front—point 2 and tool bridge—point 9) the hardness dropped to below 400 HV, which may indicate local tempering of the material. Moreover, the research has shown that each process and tool should be analyzed individually, and the areas in the tool where particular destructive mechanisms dominate should be identified, so as to further protect the forging tool by using appropriate protective coatings in these areas. Full article
