Search Results (29)

Polarization volume gratings (PVGs) have been recognized as a groundbreaking technology with the potential to revolutionize holographic waveguides and facilitate immersive experiences in augmented and virtual reality (AR/VR) applications. This study investigated the design, fabrication, and utilization of PVGs within the framework of holographic waveguides for immersive encounters. The essay begins by presenting a comprehensive overview of waveguide technologies. The display devices and optical combiners combine the actual and virtual worlds that the naked eye can see. This review categorizes current visual solutions for micro-optical combiners in augmented reality head-mounted displays (AR-HMDs). Subsequently, an investigation was carried out into the manufacturing process, physical principles, optical structures, performance characteristics, and other aspects. Furthermore, a review and assessment of their merits and drawbacks were conducted. Full article

This paper examines the effect of irregular bathymetry on the holographic reconstruction of the sound field generated by a moving source in shallow water. In this scenario, acoustic waves propagate along the path between the source and receiver. Spatial inhomogeneities in the waveguide, resulting from the complex bottom topography, cause the notable horizontal refraction of acoustic modes. The study focuses on how this horizontal refraction affects the structure of the interferogram and the hologram corresponding to the moving source. This investigation is carried out through numerical simulations that incorporate ray refraction due to irregularities in the waveguide. The interferogram, representing the received sound intensity in the frequency-time domain, and the hologram, obtained via a two-dimensional Fourier transform of the interferogram, are analyzed in the presence of spatial variability caused by non-uniform bathymetry. A key finding is that, despite these irregularities, the hologram retains sufficient structural information to extract and reconstruct source parameters (e.g., range, velocity). The paper also provides a quantitative estimate of the reconstruction error associated with this approach. Full article

This paper studies how intense internal waves (IIWs) affect the holographic reconstruction of the sound field generated by a moving source in a shallow-water environment. It is assumed that the IIWs propagate along the acoustic path between the source and the receiver. The presence of IIWs introduces inhomogeneities into the waveguide and causes significant mode coupling, which perturbs the received sound field. This paper proposes the use of holographic signal processing (HSP) to eliminate perturbations in the received signal caused by mode coupling due to IIWs. Within the HSP framework, we examine the interferogram (the received sound intensity distribution in the frequency–time domain) and the hologram (the two-dimensional Fourier transform of the interferogram) of a moving source in the presence of space–time inhomogeneities caused by IIWs. A key finding is that under the influence of IIWs, the hologram is divided into two regions that correspond to the unperturbed and perturbed components of the sound field. This hologram structure enables the extraction and reconstruction of the interferogram corresponding to the unperturbed field as it would appear in a shallow-water waveguide without IIWs. Numerical simulations of HSP application under the realistic conditions of the SWARM’95 experiment were carried out for stationary and moving sources. The results demonstrate the high efficiency of holographic reconstruction of the unperturbed sound field. Unlike matched field processing (MFP), HSP does not require prior knowledge of the propagation environment. These research results advance signal processing methods in underwater acoustics by introducing efficient HSP methods for environments with spatiotemporal inhomogeneities. Full article

The rapid advancement of terahertz (THz) communication systems has positioned this technology as a key enabler for next-generation telecommunication networks, including 6G, secure communications, and hybrid wireless-optical systems. This review comprehensively analyzes THz communication, emphasizing its integration with free-space optical (FSO) systems to overcome conventional bandwidth limitations. While THz-FSO technology promises ultra-high data rates, it is significantly affected by atmospheric absorption, particularly absorption beyond 500 GHz, where the attenuation exceeds 100 dB/km, which severely limits its transmission range. However, the presence of a lower-loss transmission window at 680 GHz provides an opportunity for optimized THz-FSO communication. This paper explores recent developments in high-power THz sources, such as quantum cascade lasers, photonic mixers, and free-electron lasers, which facilitate the attainment of ultra-high data rates. Additionally, adaptive optics, machine learning-based beam alignment, and low-loss materials are examined as potential solutions to mitigating signal degradation due to atmospheric absorption. The integration of THz-FSO systems with optical and radio frequency (RF) technologies is assessed within the framework of software-defined networking (SDN) and multi-band adaptive communication, enhancing their reliability and range. Furthermore, this review discusses emerging applications such as self-driving systems in 6G networks, ultra-low latency communication, holographic telepresence, and inter-satellite links. Future research directions include the use of artificial intelligence for network optimization, creating energy-efficient system designs, and quantum encryption to obtain secure THz communications. Despite the severe constraints imposed by atmospheric attenuation, the technology’s power efficiency, and the materials that are used, THz-FSO technology is promising for the field of ultra-fast and secure next-generation networks. Addressing these limitations through hybrid optical-THz architectures, AI-driven adaptation, and advanced waveguides will be critical for the full realization of THz-FSO communication in modern telecommunication infrastructures. Full article

Augmented reality (AR) technology has been widely applied across a variety of fields, with head-up displays (HUDs) being one of its prominent uses, offering immersive three-dimensional (3D) experiences and interaction with digital content and the real world. AR-HUDs face challenges such as limited field of view (FOV), small eye-box, bulky form factor, and absence of accommodation cue, often compromising trade-offs between these factors. Recently, optical waveguide based on pupil replication process has attracted increasing attention as an optical element for its compact form factor and exit-pupil expansion. Despite these advantages, current waveguide displays struggle to integrate visual information with real scenes because they do not produce accommodation-capable virtual content. In this paper, we introduce a lensless accommodation-capable holographic system based on a waveguide. Our system aims to expand the eye-box at the optimal viewing distance that provides the maximum FOV. We devised a formalized CGH algorithm based on bold assumption and two constraints and successfully performed numerical observation simulation. In optical experiments, accommodation-capable images with a maximum horizontal FOV of 7.0 degrees were successfully observed within an expanded eye-box of 9.18 mm at an optimal observation distance of 112 mm. Full article

The holographic signal-processing method for a single vector scalar receiver (VSR) in the high-frequency band in shallow water is developed in the paper. The aim of this paper is to present the results of the theoretical analysis, numerical modeling, and experimental verification of holographic signal processing for a noise source by the VSR. The developed method is based on the formation of the 2D interferogram and 2D hologram of a noise source in a shallow-water waveguide. The 2D interferograms and 2D holograms for different channels of the VSR (P sound pressure and $V_X$ and $V_Y$ vibration velocity components) are considered. It is shown that the 2D interferogram consists of parallel interference fingers in the presence of a moving noise source. As a result, the 2D hologram contains focal points located on a straight line, and the angular distribution of the holograms has the main extreme value. It is shown in the paper that the holographic signal-processing method allows detecting the source, estimating the source bearing, and filtering the useful signal from the noise. The results of the source detection, source bearing estimation, and noise filtering are presented within the framework of experimental data processing and numerical modeling. Full article

Diffraction gratings are becoming a preferred option for waveguide head-mounted in–out coupling devices due to their flexible optical properties and small size and light weight. At present, diffraction waveguide coupling devices for AR head-mounted displays (HMD) have difficulties such as a long development cycle and complicated processing. In this paper, we first establish a set of two-dimensional (2D) grating ray tracing models, based on which we determine the initial architecture of the dual-region two-dimensional exit pupil expansion (2D-EPE) AR-HMD holographic waveguide diffraction system. Second, we propose a honeycomb coupled grating array and optimize the optical energy utilization and brightness uniformity of the holographic waveguide and use a custom dynamic linked library (DLL) function to implement the ray tracing of the 2D grating and add a probabilistic splitting function to the DLL, which reduces the single simulation time from 11.853 min to 1.77 min. We also propose a holographic lithography device composed of holographic optical elements (HOEs) and a method for preparing HOEs. Finally, in order to obtain the diffraction efficiency preoptimized by the above DLL for the uniformity of the exit pupil brightness and light energy utilization, we inverse design with the preparation process parameters as the optimization variables and develop the adaptable electromagnetic calculation program Holo-RCWA. Using Holo-RCWA with nondominated sorting genetic algorithm II (NSGA-II), we inverse design to obtain the process parameters satisfying the diffraction efficiency distribution, and the optimization time of the whole system is reduced from 2–3 days to 10 h. This work is of great significance for AR/VR applications. Full article

Optical tweezers (OTs) can transfer light momentum to particles, achieving the precise manipulation of particles through optical forces. Due to the properties of non-contact and precise control, OTs have provided a gateway for exploring the mysteries behind nonlinear optics, soft-condensed-matter physics, molecular biology, and analytical chemistry. In recent years, OTs have been combined with microfluidic chips to overcome their limitations in, for instance, speed and efficiency, creating a technology known as “optofluidic tweezers.” This paper describes static OTs briefly first. Next, we overview recent developments in optofluidic tweezers, summarizing advancements in capture, manipulation, sorting, and measurement based on different technologies. The focus is on various kinds of optofluidic tweezers, such as holographic optical tweezers, photonic-crystal optical tweezers, and waveguide optical tweezers. Moreover, there is a continuing trend of combining optofluidic tweezers with other techniques to achieve greater functionality, such as antigen–antibody interactions and Raman tweezers. We conclude by summarizing the main challenges and future directions in this research field. Full article

To date, planar waveguides are under development for augmented reality systems with waveguide combiners. The next step of their development is the transition to curved waveguides, which could make the combiners more ergonomic. In the present work, a method has been developed that makes it possible to minimize aberrations of a virtual image during its in-coupling to and out-coupling from a cylindrical waveguide. The method is based on the use of in-coupling and out-coupling diffractive optical elements (DOE) with a variable grating period, which provide virtual image pre-aberration when radiation is in-coupled into the waveguide and compensation of the waveguide curvature at the out-coupling. Analytical laws are derived for the period variation of the in-coupling and out-coupling DOEs for an arbitrary curvature of a cylindrical waveguide. These dependences were optimized to minimize virtual image aberrations when using a radiation source with finite dimensions. Samples of cylindrical concentric PMMA waveguides with a curvature radius of 150 mm and in-coupling/out-coupling holographic optical elements (HOEs) have been created. The transmission of test monochrome virtual images through these waveguides without doubling and breaks in the field of view has been experimentally demonstrated. Full article

In this research, studies were conducted on the possibility of providing thermal compensation of the information display device circuit based on a holographic waveguide when the wavelength of the radiation source ch as a result of changes in ambient temperature. A variant of implementing the waveguide structure in terms of the geometry of the diffraction gratings arrangement is proposed, its main parameters (grating period, thickness, refractive index) and the dependencies between them affecting the quality of the reproduced image are determined. Full article

The paper analyzes the image quality in augmented reality display based on holographic waveguides. Brightness, brightness non-uniformity, image noise, etc., depend on the parameters of the waveguide substrate, the configuration, and the relief shape of diffraction optical elements. The optimal structure of holographic waveguides obtained by analog holography has been studied. The presented recommendations to achieve the best image quality are based on experimental results for different configurations of holographic waveguides. Full article

To reveal the fundamental characteristic of the volume holographic waveguide for a head-mounted display (HMD), we analyzed the resolution of a virtual image. We built a mathematical model considering the off-Bragg diffraction for each ray angle of the signal light ray. The display resolution performance of the HMD depended on the thickness of the waveguide and the ray angle. At the lowest-resolution ray angle, the input-point image was broadened more than 0.1° in a viewing angle for a 1-mm-thick waveguide. Conversely, our previously proposed line-symmetric image-input method, in which the input images were symmetrically arranged with respect to the center line, improved the resolution performance and luminance uniformity. We observed that the spread of the point image was suppressed to 0.01°, which was a sufficient resolution for a person with a visual acuity of 0.8. Full article

Holographic characteristics of chalcogenide film materials with a typical thickness of 0.5–1.5 µm of a number of Ge-S and As-S compositions have been studied theoretically and experimentally with the aim of using them in augmented reality waveguide devices. The possibility of controlling the spectral and holographic properties of materials by varying their composition is shown. The recording of both volume and surface holographic elements operating in the total internal reflection mode was carried out. The operation of holograms in the “periscope mode” with a diffraction efficiency of about 10% is demonstrated. It is concluded that the recording of high-performance holographic elements on chalcogenide films requires significant values of exposure energy when recording in the near UV range (325–355 nm), which makes holographic recording currently ineffective for creating such elements. Full article

In this paper we compare two implementations of the holographic technique for recording long, nonlinear, elastic waves of low amplitude in solid polymer waveguides: classical holographic interferometry and digital holography. Both implementations are realized in transmission configuration, with recording in the off-axis schematic. The advantages and disadvantages of these implementations are discussed as applied to the investigation of the evolution of shock waves and strain solitons in transparent solid waveguides. Full article

In this paper, a novel method for generating a circularly polarized (CP) quasi-non-diffractive vortex wave carrying orbital angular momentum (OAM), based on the microwave holographic metasurface integrated with a monopole, is proposed. This method is the combination of the non-diffraction theory and the principle of waveguide-fed-based holography and is equivalent to a superposition of two scalar impedance modulation surfaces. To verify the proposed method, a holographic metasurface generating a left-handed circularly polarized (LHCP) quasi-non-diffractive vortex wave carrying −1 mode OAM at the normal direction, was simulated and analyzed. The metasurface consisted of inhomogeneous slot units on a grounded substrate and a monopole excitation. Moreover, the location distribution of slots was determined by a computed interferogram between the reference wave and the object wave with the non-diffractive feature. Compared with an ordinary vortex wave, the quasi-non-diffractive wave obtained by our proposed method possessed a smaller divergence radius and a stronger electric field strength in the 9 times wavelength range. It paved a new path for manipulating the non-diffractive vortex wave in medium distance without using an external feeding source, which holds great potential for the miniaturization devices applied in medium-distance high-capacity secure communication, high-resolution imaging and intelligent detection. Full article
