There is growing concern regarding air pollutants (NOx, SOx, and PM) and carbon emissions from ocean-going vessels in harbor areas and the role of high-voltage shore connection (HVSC) systems in mitigating these emissions during vessel berthing. The HVSC operates as a TN grounding system in humid environments, and it needs a proper grounding design to ensure safety when faults occur. This article intends to examine the overvoltage resulting from fault currents and its implications for the safety of operators when a single line-to-ground fault takes place within the design of HVSC grounding systems. The assessment is carried out by employing actual scenarios and parameters from a container berth at Kaohsiung Harbor in Taiwan. Considering site conditions, such as the wet ground surface, human body resistance, and electric shock duration, the tolerable safe voltage level is derived using IEEE Std. 80 and IEC 60479-1. Based on the shore power system grounding architecture specified in IEEE/IEC 80005-1, an equivalent circuit model is constructed to calculate the fault currents using symmetrical component analysis. The actual touch voltages generated in various locations are analyzed under scenarios of connecting or disconnecting the equipotential bonding between the ship and the shore using neutral grounding resistor (NGR) designs. This article delves into the scenarios of electric shock that may occur during the operation of an actual container ship’s shore power system. It evaluates whether various contact voltage values exceed current international standards and verifies the grounding design and safety voltage specifications of IEEE/IEC 80005-1. According to the results of this study, the use of NGR and protective earthed neutral (PEN) conductors in HVSC is crucial. This can limit fault currents, reduce touch voltage, and ensure the safety of personnel and equipment. Therefore, ensuring and monitoring equipment conductors and adopting NGRs of appropriate sizes are crucial elements in maintaining electrical safety in HVSC systems. Full article

This paper addresses the growing concern over air pollutant emissions (NOx, SOx, PM, CO₂) from ocean-going vessels in harbor areas and the role of Onshore Power Supply (OPS) systems in mitigating these emissions during vessel berthing. However, the slow progress in global shore power facilities is attributed to safety- and specification-related concerns. Our study conducts a comprehensive analysis, comparing international shore power regulations, with a specific focus on the IEC/IEEE 80005-1 standard and guidelines from various ship classification societies. We introduce checklists, scoring tables, and spider diagrams to evaluate the regulatory content, highlighting the strengths and weaknesses of each approach. Furthermore, this paper emphasizes the significance of a well-defined operational process for high-voltage shore connection (HVSC) to ensure the safety of OPS operations. We present process diagrams for key operational stages, based on IEC/IEEE 80005-1 specifications and evaluation criteria. The ultimate goal of this research is to drive the global adoption of shore power and foster the establishment of shore power facilities worldwide. This aligns with the broader environmental protection objectives of achieving cleaner ports and reducing emissions for a sustainable future. Full article

Ship-to-shore connection is an important technological element that reduces air pollution in ports. Therefore, ports install facilities that allow mooring ships to connect to the port distribution network. By 2025, this will be mandatory for all ports in Europe. This can be a challenging task in most ports due to the different frequency of the network and ship frequency. This problem can be solved by the use of grid-forming static frequency converters. This solution also brings some other advantages: The ship is not threatened by high shore short-circuit currents, and the port distribution network is not affected by the character of the ship load. However, frequency converter software must include a droop control algorithm to ensure that voltage deviations do not exceed the allowed limits during transients. Typical frequency converters used for shore connection are those developed as static frequency converters (SFCs). However, those converters were not developed for large power outputs, which are needed to power large vessels, such as ferries or cruise ships. This paper proposes motor drives that were modified to operate as SFCs. This approach has quite a lot of advantages which are described in this article. This paper describes both a standard shore connection system without a frequency converter and a solution that includes static frequency converters. The paper then focusses on voltage deviation estimations during connection/disconnection of large load (ferry or cruise ship) to static frequency converters. In this work, a high-voltage shore connection (HVSC) simulation model is developed, including a frequency converter, a shoreside transformer, medium-voltage (MV) connection cables, and a power system of the ship, to analyze in detail the behavior of the system in the case of connection or disconnection of the ship load. The model was made in DIgSILENT PowerFactory for the case of a commercial port in southern France. The model gives credible estimations of voltage drops/surges during transient and steady states. Full article
